SKS Germany COMPIT Manual de usuario

Instruction Manual - Version 11.2022

COMPIT · COMPIT+

/POWER · COMPIT/STEM

+COM/CHARGER · COM/PAD

Table of Contents

Table of contents 3

Notes on the manual and the manufacturer 4

Keeping this manual available 4

Design features of this manual 4

Manufacturer’s address 5

Safety instructions 6

Basic safety instructions 7

Design Features of Warnings 8

Design Features of Property Damage 8

Design features of tips 8

Scope of delivery 9

COMPIT 9

COMPIT+/POWER 11

COMPIT STEM 13

+COM/CHARGER 13

Mounting options 14

Assembly 16

COMPIT & COMPIT+/POWER 17

COMPIT 35mm 20

COMPIT Widening 21

COMPIT STEM 23

COMPIT COVER 24

COMPIT ADAPTER 25

Task and function 26

COMPIT 26

COMPIT+ & +COM/CHARGER 26

COMPIT STEM 26

COMPIT SPACER 27

Technical data +COM/CHARGER 27

LED status display 28

Unpacking and checking the scope of delivery 28

Attaching and removing COMPIT to bike handlebars 29

Attaching and removing smartphone to COMPIT 29

Adjusting the inclination 31

COM/PAD 32

Maintaining the product 36

Accessories 36

Disposing of the product 37

Warranty Statement 38

Returning the product to customer service 39

Information about the manual and the manufacturer

This manual will help you to safely use the COMPIT and COMPIT+/POWER as well as the COMPIT

STEM and COMPIT STEM+ product family. The COMPIT is a smartphone holder for smartphones. The

COMPIT+/POWER consists of a COMPIT and +COM/CHARGER. The +COM/UNIT is a power bank for

smartphones. The COMPIT and the +COM/CHARGER are all referred to hereinafter as the “product”

for short, unless a distinction needs to be made between the different functions of the products.

The +COMPIT/STEM smartphone holder mounts the smartphone under the ahead cap on the

handlebar stem.

Keep the manual to hand

➤ This manual is part of the product.

➤ Always retain this manual.

➤ Hand over this manual if you sell the product or pass it on in any other way.

Features of this manual

Various elements of this manual have deﬁned features.

This allows you to easily distinguish between the following elements:

Normal text

● Lists

➤ Action steps

Information about the manual and the manufacturer

This manual contains information that is subject to copyright. This manual may not be copied, printed,

ﬁlmed, processed, reproduced or distributed in any form, in whole or in part, without the prior written

consent of SKS metaplast Scheffer-Klute GmbH.

Manufacturer’s address

SKS metaplast Scheffer-Klute GmbH

Zur Huberstushalle 4

59846 Sundern / Germany

Tel.: +49-2933-8310

Website: sks-germany.com

Safety

Intended use

The product is designed for private use.

The COMPIT is used for mounting a smartphone on the handlebar of a bike.

It is intended for a handlebar with the following diameters.

● 22.2 mm

● 25.4 mm

● 31.8 mm

● 35 mm

The stem width is a maximum of 80 mm (see page 21).

The +COM/CHARGER is additionally included in the scope of delivery for the COMPIT+/POWER.

The +COM/CHARGER is intended for charging a smartphone and can be mounted on the COMPIT.

The smartphone can only be used on the COMPIT and the +COM/CHARGER with a COVER, COVER

ADAPTER or special bag not included in the scope of delivery. Please refer to the Accessories section,

page 32. Intended use also includes observing and following all the information contained in this

manual, particularly the safety instructions. Any other use is expressly considered improper use.

COMPIT STEM

➤ There may be an overhang in the knee area depending on the mounting option.

Attention: risk of falling!

➤ The product should only be mounted by a technically adept person.

If necessary, contact your bicycle dealer or the SKS GERMANY customer service team.

Safety

Basic safety instructions

Avoid ﬁre, explosion or electric shock

Severe or fatal injuries caused by explosion, ﬁre or electric shock may be caused

if the product is used improperly.

➤ Check whether the voltage indicated on the power adapter is the same as the local

mains voltage before connecting the adapter to the power supply.

➤ Only use authorised power adapters.

➤ Do not use the power adapter, COMPIT or +COM/CHARGER if they are damaged.

➤ Never open the housing of the +COM/CHARGER. Always have repair work carried

out by qualiﬁed specialists.

➤ Do not stick metal labels or other objects onto the +COM/CHARGER.

➤ Do not use the +COM/CHARGER in the vicinity of heated surfaces.

➤ Do not use extension cables or overloaded multi-way sockets.

➤ Ensure that children and persons with reduced mental capabilities only

use the +COM/CHARGER when supervised.

Avoid failure of a pacemaker or another implant

The use of the +COM/CHARGER can lead to the failure of a pacemaker or another implant.

➤ If you have a pacemaker or another implant, consult your doctor or the implant

manufacturer before using the +COM/CHARGER.

Warning with the word CAUTION warn of a situation that may result in minor or

moderate injuries.

This information warns of a situation that will result in property damage and

reduced functionality.

Safety

Warnings

Property damage

CAUTION

ATTENTION

Tips

Tips contain additional information.

Side panels for the docking station 2x

Clamping arms for the COMPIT without an adapter 2x

Screws for mounting the COMPIT with clamping arms on the handlebar

of the bicycle (4x20), 4x

Clamping arms for the COMPIT with an adapter for the Bosch Intuvia

(R: right, L: left) 2x

DESIGNATIONNo.

Description

Overview of the scope of delivery for the COMPIT

1 2

10 9 8

516

13 12

For a handlebar

without a central

display

For central displays

(Bosch Intuvia)

COMPIT 35 mm

17 18 19 20

Description

3 mm Allen key

Torx® key Tx20

Rubber adapters for a handlebar with a diameter of 31.8 mm, 4x

Rubber adapters for a handlebar with a diameter of 22.2 mm, 4x

Rubber adapters for a handlebar with a diameter of 25.4 mm, 4x

PVC spacers, 4x

Screws for the COMPIT spacers for the docking station; (4x25), 2x

Screws for the COMPIT spacers for the COM/LIGHT; (5x25), 2x

Self locking nuts M4, 2x for the COMPIT adapter

O-rings for the docking station, 2x

Screws for the docking station; (4x18), 2x

Clamping arms COMPIT 35 mm left

Clamping arms COMPIT 35 mm right

Screw M5, 2x

Square nut M5, 2x

DESIGNATIONNo.
