Pocket Pump TOUCH

Installation/Operation Caution Guide

The SKC Pocket Pump TOUCH (Model 220-1000TC) Intrinsically Safe/Sécurité

Intrinsèque personal air sample pump was evaluated in accordance with the

following standards:

•UL 913 STANDARD FOR INTRINSICALLY SAFE APPARATUS AND

ASSOCIATED APPARATUS FOR USE IN CLASS I, II, III, DIVISION 1,

HAZARDOUS (CLASSIFIED) LOCATIONS - Edition 8 (2015)

•CSA C22.2 NO. 157-92 INTRINSICALLY SAFE AND NON-INCENDIVE

EQUIPMENT FOR USE IN HAZARDOUS LOCATIONS - Edition 3 (2003)

•CENELEC EN 60079-0 EXPLOSIVE ATMOSPHERES - PART 0: EQUIPMENT

- GENERAL REQUIREMENTS - Edition 7 (2018)

•CENELEC EN 60079-11 EXPLOSIVE ATMOSPHERES - PART 11:

EQUIPMENT PROTECTION BY INTRINSIC SAFETY “I” - Edition N/A (2012)

•

IEC 60079-0 EXPLOSIVE ATMOSPHERES - PART 0: EQUIPMENT GENERAL

REQUIREMENTS - Edition 7 (2017)

•IEC 60079-11 EXPLOSIVE ATMOSPHERES –PART 11: EQUIPMENT

PROTECTION BY INTRINSIC SAFETY “I” - Edition 6 (2014)

MARKINGS*

* UKCA mark and UL22UKEX2584 added based on previously issued ATEX/IECEx

certificates

220-1000TC PocketPump, SKC Inc. SN YY9999

Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class III, T4;

Class I, Zone 0, Group IIC T4; Exia -20oC ≤ Ta ≤ 45oC

II 1G Exia IIC T4 Ga

IECEx UL 16.0113, DEMKO 16ATEX 1600, UL22UKEX2584

0539 0843

Form

38059

Rev

220810

WARNINGS/AVERTISSEMENT

•WARNING: Substitution of components may impair intrinsic safety.

AVERTISSEMENT: La substitution de composants peut compromettre la

Sécurité Intrinsèque.

•WARNING: To prevent ignition of hazardous atmosphere, batteries must only

be charged (removed and replaced) in an area to be known non-hazardous.

AVERTISSEMENT: Afin de prévenir l’inflammation d’atmosphères

dangereuses, ne changer les batteries que dans des emplacements désignés

non dangereux.

•WARNING: Use only SKC charger Cat. No. 220-300.

•WARNING: Maximum charge input voltage Um = 5.5V DC.

CAUTIONS

•CAUTION: The battery used in this device may present ariskof fire or explosion

when heated above 212 F (100 C) or incinerated. Replace battery with SKC

Battery Pack Cat. No. P76303 only. Use of another battery may present a risk

of fire or explosion.

Battery Pack Replacement

1. Turn oﬀ pump by pressing the Power On/Oﬀ button located on the top of the

pump. The screen will go dark.

2. Use 1.5-mm hex key to loosen two screws on back of battery pack housing.

3. To remove battery pack, lift it up against belt clip. Once clear of case, pull away

from pump case.

4. To install battery pack, align it with bottom of pump case and push it up

against belt clip until battery pack presses easily into place. Ensure it fits

flush with pump case. Use 1.5-mm hex key to tighten two screws on back of

battery pack housing in alternating fashion.

SKC Inc., Eighty Four, PA •724-941-9701 •skcinc.com
