SIRS-E Pilotino-WiFi Manual de usuario

E518483

INDEX

1. Introduction

2. Safety Information

3. Electrical Speciﬁcations

4. Onboard Features (Nomenclature)

5. Mechanical Details

6. Installation

7. DMX Addressing

8. RDM and Available PID’s

8.1 RDM PID’s Description

8.2 Output Curve

8.3 Output Frequency

8.4 Bit Mode Selection

8.5 DMX Failure Settings

8.6 Response Time

8.7 Default Settings

8.8 Onboard Settings

9. Mode LED Indicator

10 . Hardware and Accessories

UL Certiﬁcation

Pg. 3

Pg. 4

Pg. 5

Pg. 6

Pg. 7

Pg. 8

Pg. 9

Pg. 10

Pg. 12

Pg. 16

Pg. 18

Pg. 19

Pg. 20

Pg. 22

Pg. 23

Pg. 25

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

1. Introduction

Key Features:

Wireless Capability

UL Regconized

DMX Ready

RDM Conﬁgurable

RDM Data Feedback

Selectable Output Frequency

The P ™ PCB is the newest addition to the LED CV DMX decoder family for SIRS-E. Control any

ILOTINO

kind of CV LED Strip, COB, and other constant voltage LED products. This version of the P ™ comes in

ILOTINO

a bare PCB format. This product is intended to be embedded into custom ﬁxtures and lighting control

systems in which component size is critical. Equipped with 6 mounting holes, the P ™ PCB is ready

ILOTINO

to be installed with M2.5 X 5mm stand-offs into any sort of enclosure.

P ™ PC

ILOTINO B

UL Class 2 Output Certiﬁed

Input CertiﬁedUL Registered

Onboard IO Socket (For Connectivity)

Small Footprint

Wire to Board Quick Connectors

Standoff Mounting

5 Year Limited Warranty

Made in Italy

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

E518483

Package Contents

P ™ PCB - : Pilotino-PCB

ILOTINO SKU

P ™ PCB Instruction Manual

ILOTINO

Updated 12/2021. Rev 2.8

Check our page Check our YouTube Video!

2. Safety Information

Safety Information

3 Electrical S. peciﬁcations

The exposed PCB design of this product results in a major reduction in its foot print. With a slim and narrow design, this

conﬁguration is intended to be used in applications that would beneﬁt from this feature. Some examples of applications

include: ﬁxture integration, custom control enclosures, and others. The exposed design comes with few precautions to

take notice of.

The P ™ PCB is a non-waterproof device with an IP 20 rating. Keep the unit dry at all times and away from liquids

ILOTINO

and humid environments. Make all connections to the LEDs and driver prior to powering on the circuit. All lead voltage

connections to the drivers must be performed by a licensed electrician. Do not touch any of the surfaces of the device

once the unit is powered on. Ensure that all connections are secure and eliminate all possibilities of shorting the unit.

Use the proper wire gauge for the wire to board connections and wiring blocks. We recommend using 12awg stranded

wire for the power input, and 18awg for the output connections that connect to the LEDs. Do not mount the unit where

vibrations or shock are present. Be sure that the thermal pad is attached to the back of the unit at all times.

WARNING - Risk of Fire or Electrical shock, do not interconnect output terminations

Ambient Operating Temperature: -10 °C - 45 °C

Relative Humidity: 5% - 80% non-condensing

IP Rating: IP 20 Non-waterproof (Keep dry)

Ventilation: Do not install in airtight spaces

Input Control protocol: DMX512-A

RDM: Yes

Control Options

DMX Resolution: 8/16 bit Selectable

Wi-Fi: ArtNet with P WiFi™ PCB

ILOTINO

CRMX: Lumen Radio with P CRMX™ PCB

ILOTINO

Ambient Parameters

Max Current / Channel: 2.5A

Working Voltage: 12-24V DC

Output Channels: 1-5 Selectable

Output Frequency: 1-5.2KHz PWM

UL Class 2 Output

Max Power / Channel: 30W @12V / 60W @24V

Max Power Out: 150W @12V / 300W @24V

Max Current: A12.5

Working Voltage: 12-24V DC

Max Power In: 150W @12V / 300W @24V

Input Voltage (UL Non-class 2)

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

4. Onboard Features

1. I/O Connection Socket + DMX in (For expansion Modules)

2. DMX IN/OUT Wire to board connector (As shown top to bottom: GND, D-, D+)

3. Dip Switches for DMX Addressing and other functions

4. Mounting holes for Standoffs M2.5 (metric)

5. Output wire to board connector Channel 1

6. Output wire to board connector Channel 2

7. Output wire to board connector Channel 3

8. Output wire to board connector Channel 4

9. Output wire to board connector Channel 5

10. Output wire to board dual connector COMM V+

11. Power Input wiring block connector

12. Mode Indicator LED

13. Thermal Pad (Do Not Remove)

5 6 7 8 9

34 4 4

24 44

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

5. Mechanical Details

P ™ PCB

ILOTINO Top View

P ™ PCB Side View

ILOTINO

45.09mm

22.23mm

48.26mm45.72mm

15.88mm

9.02mm

43.75mm

170.2 mm5

10.8mm 23.22mm

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

6 Installation.

Thermal Pad

The thermal pad that dissipates heat from the components of the device must always be used. This thermal pad is

included with each P ™ PCB

ILOTINO and comes installed from factory. Proper ventilation should be present within the

enclosure in which the unit is installed.

Standoffs

Six 2.5M x 5mm standoffs should be used to properly mount the unit onto a smooth and level surface. It is

recommended that the included factory 2.5M standoffs be used. To fasten the P ™ PCB onto a surface, ﬁrst

ILOTINO

tighten the four central screws in a crisscross pattern. Once the central screws are torque down to ¼ turn past

hand tight, do the same for the remaining 2 screws. Always tighten the screw opposite to the last screw that was

torque down. Do not over tighten the screws as doing so will result in damage to the device.

Clearance

Due to the exposed contact points on the P ™ PCB, the risk of shorting the unit should be considered. A

ILOTINO

minimum of 10mm of clearance space is recommended. Never install the P ™ PCB within an enclosed space in

ILOTINO

which the P ™ PCB does not have sufﬁcient space away from other components.

ILOTINO

Connections

The P ™ PCB comes equipped with wire to board connectors, and a socket connector for the connectivity

ILOTINO

expansion modules. All wire connections should ﬁt securely into the connectors; therefore, we recommend to used solid

wire when installing LED strips and power cable wires. Be sure to insert each wire into the connectors deep enough so

that no bare wire is exposed. A good rule of thumb is to strip the wires so that only about 3mm of insulation is removed.

Always use both output terminals for the COMM V+ connection (See section 4, “Onboard Features” for more details).

The P ™ PCB can be connected in a daisy chain format for the distribution of DMX signal. Never daisy chain more

ILOTINO

than 30 P ™ PCB in a single line. For larger projects, make use of DMX splitters to distribute the DMX data.

ILOTINO

Settings

All of the advanced settings in the P ™ are meant to be accessed through RDM connectivity only. Any setting

ILOTINO

beyond the DMX addressing can only be edited through the use of an RDM controller or software. The P ™ is

ILOTINO

equipped with the latest version of RDM and is compatible with any controller, board, or software capable of RDM.

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

7. DMX Addressing

DMX Addressing

The P ™ PCB can be addressed by setting the onboard DIP switches in the following way:

ILOTINO

(Be sure to perform all connections prior to turning on the power supply.)

1. Connect the input power from the power supply

2. Connect the LEDs to the output wire to board connectors

3. Connect the DMX input to the connectors or achieve a wireless connection with the CRMX module

4. Switch ON the power supply

5. The green indicator LED will turn on steady

6. Set the desired address by following the binary value expressed by the DIP switch positions

7. DIP 1-9 Set DMX address: “Base 1” numbering is adopted with DMX channel 1= Code 1

DMX Channel 512=Unavailable

8. The green indicator LED will now ﬂash steadily if the DMX signal is present

* To select DMX address with RDM compatible software , switch ON the DIP switch 10 and use the “DMX Start

Address” menu.

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

8. RDM and Available PIDs

What is RDM?

RDM, or Remote Device Management, is a standardized bi-directional communication protocol used for managing,

monitoring, and conﬁguring lighting ﬁxtures and other equipment that come equipped with RDM capability. This

protocol is an enhancement of the USITT DMX512 protocol that is commonly used for conﬁguring a wide array of

lighting ﬁxtures and other equipment.

Pilotino™ and RMD

The Pilotino™ comes equipped with full RDM capability and is compatible with any kind of RDM software, board, or

controller. All of the advanced settings that the Pilotino™ is capable of can only be edited through an RDM device. The

only setting that does not require an RDM device is the DMX addressing. This can be done through the onboard DIP

switches (More information on addressing the Pilotino™ is available on page 9).

What are PIDs?

A PID within the RDM context is a certain parameter or setting that is available through the RDM protocol for

conﬁguring a ﬁxture or a piece of equipment. Each PID can “Get” or “Set” information for conﬁguring an RDM capable

device.

Available PIDs for Pilotino™

DMX START ADDRESS - SET

FACTORY DEFAULTS - SET

CURVE - SET

CURVE DESCRIPTION - GET

DMX PERSONALITY - SET

DMX PERSONALITY DESCRIPTION - GET

OUTPUT RESPONSE TIME - SET

OUTPUT RESPONSE TIME DESCRIPTION - GET

MODULATION FREQUENCY - SET

MODULATION FREQUENCY DESCRIPTION - GET

DMX FAIL MODE - SET

SENSOR VALUE SUPPLY VOLTAGE - GET

SENSOR VALUE INTERNAL TEMPERATURE - GET

SENSOR VALUE SUPPLY CURRENT - GET

SOFTWARE VERSION LABEL - GET

DEVICE HOURS - GET

LAMP HOURS - GET

SUPPORTED PARAMETERS - GET

DEVICE INFO - GET

DEVICE MODEL DESCRIPTION- GET

MANUFACTURER LABEL - GET

DEVICE LABEL - SET

IDENTIFY DEVICE - SET

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8

8.1 RDM PID Descriptions

Used to conﬁgure the starting DMX address of the P ™ PCB.DMX START ADDRESS - SET: ILOTINO

Used to revert the P ™ PCB to factory default settings.FACTORY DEFAULTS - SET: ILOTINO

Used to set the Dimming Curve to achieve different dimming styles. There are 2 curve modes, CURVE - SET:

linear and quadratic.

Shows the currently selected Dimming Curve.CURVE DESCRIPTION - GET:

Used to set the desired output mode (1-5 channel 8 bit or 1-5 channel 16 bit). DMX PERSONALITY - SET:

The P ™ is capable of operating in 10 different Personality modes.

ILOTINO

Shows the currently selected DMX Personality.DMX PERSONALITY DESCRIPTION - GET:

Used to set the dimming response time related to the input signal.OUTPUT RESPONSE TIME - SET:

OUTPUT RESPONSE TIME DESCRIPTION - GET: Shows the currently set Output Response Time.

MODULATION FREQUENCY - SET: Used for conﬁguring the PWM rate output frequency to the LEDs

(1-5.2KHz are available).

MODULATION FREQUENCY DESCRIPTION - GET: Shows the currently selected Modulation Frequency setting.

DMX FAIL MODE - SET: Used for conﬁguring the action employed by the device in the event of a DMX signal failure

or loss. There are 3 fail modes to chose from: (1) Hold Last Value (2) Full , (3) Test= 60 DMX= 5% Output.

Shows a live feed of the input voltage value to the P ™.SENSOR VALUE SUPPLY VOLTAGE - GET: ILOTINO

Shows a live feed of the internal temperature of the P ™.SENSOR VALUE INTERNAL TEMPERATURE -GET: ILOTINO

Shows a live feed of the current draw of the P ™.SENSOR VALUE SUPPLY CURRENT - GET: ILOTINO

3307 West Street Rosenberg, TX 77471 USA - (281) 324-0908

ILOTINO

Updated 12/2021. Rev 2.8
