Siqura BL1103M1-EI Manual de usuario

Use DHCP server

(a)

BL1103M1-EI

3 MP Intelligent IP bullet camera

Quick Start Guide

Version 1.1 (160707-1.1)

bl1103m1ei QSG (MW10)

Insert Micro SD card / Reset

Unpack

Connect

Use fixed IP address

Mount

Note: Subject to modification. Actual product and accessories may differ in appearance.

DHCP

Network switch IP = 10.x.y.z

IP = 10.x.y.z

DHCP:

IP = 10.x.y.z

DHCP

Network switch IP = 192.168.1.x

IP = 192.168.1.x

DHCP:

30 s

2 ~ 253

RJ-45

802.3af PoE

12 Vdc

Digital I/O

Note: Camera breakout cable connectors are labelled with their function and polarity.

Note: For mounting instructions for pole mount or wall mount, see respective manuals.

 Tilt angle (1)

 Pan angle (2)

 Camera rotation(3)

0°~360°

0°~100°

Micro SD/SDHC/SDXC

(up to 128 GB)

Reset button

Serial port

(debugging only)

Find additional manuals, the datasheet,

the EU Declaration of Conformity and the

latest firmware for this product at:

http://www.tkhsecurity.com/support-files

http://www.tkhsecurity.com

http://www.tkhsecurity-usa.com

Note: Use Device Manager (see next) to discover the camera on the network.

*Reset button: Press and hold for 10 sec. when powering on or rebooting.

Warning: Restores factory default settings, including IP address, user name and password!

View live video

Initialise lens / Adjust focus

Install Device Manager (optional)

Change IP address via Device Manager

Open web interface via Device Manager

Set password

Focus +

Focus -

Lens initialisation

Auxiliary focus

(push to focus)

Important: 1103 series cameras require Device Manager version 1.8.1 or later.

Replace an existing, older installation of this tool on your PC, if necessary.

Administrator / End User

Set a strong password!

qwerty1234

x6W@oM0a!9#F

Note: For information about user accounts and passwords, see User Manual.
