Sinclair SDV5 Series Manual de usuario

INDOOR FLOOR-CEILING UNITS SDV5-xxFA

COMMERCIAL AIR CONDITIONERS SDV5

Original instructions

IMPORTANT NOTE:

Read this manual carefully before installing or operating

your new air conditioning unit. Make sure to save this

manual for future reference.

201805 3

Ceiling & floor

1Specifications ........................................................................................ 4

2Dimensions............................................................................................ 6

3Unit Placement...................................................................................... 4

4Piping Diagram ...................................................................................... 5

5Wiring Diagram...................................................................................... 6

6Capacity Tables ...................................................................................... 8

7Electrical Characteristics ...................................................................... 16

8Sound Levels........................................................................................ 17

4 201805

Specifications

SDV5-36FA

SDV5-45FA

SDV5-56FA

SDV5-71FA

Table

1.1:

SDV5-36,45,56,71FA

specifications

Model

SDV5-36FA

SDV5-45FA

SDV5-56FA

SDV5-71FA

Power supply

1 phase, 220-240V, 50Hz

Cooling1

Capacity

3.6

4.5

5.6

7.1

kBtu/h

12.3

15.4

19.1

24.2

Power input

115

Heating2

Capacity

4.0

5.0

6.3

8.0

kBtu/h

13.6

17.1

21.5

27.3

Power input

115

Fan motor

Model

WZDK100-38GS-2

Type

Brand

Panasonic/Match-Well

Speed3

r/min 770/740/700/680/6

50/630/610

1380/1330/1300/1260/

1210/1140/1070

1380/1340/1300/12

60/1190/1140/1120

Indoor coil

Number of rows

Tube pitch × row pitch

mm 25.4×22

Fin spacing

mm 1.8

Fin type

Hydrophilic aluminum

Tube OD and type

mm Ф9.53 Inner-groove

Dimensions (L×H×W)

mm 804×254×44

804×254×66

Number of circuits

Air flow rate3

m3/h

550/525/500/480

/460/440/420

930/895/860/830/792/755/720

Sound pressure level4

dB(A)

40/39/38/38/37/

36/36

43/42/41/41/39/38/38

Sound power level

dB(A)

53/52/51/51/50/

49/49

56/55/54/54/52/51/51

Unit

Net dimensions5(WxHxD)

990×660×203

Packed dimensions (WxHxD)

1089×744×296

Net/Gross weight

26/32

28/34

Refrigerant type

R410A

Throttle

Type

Electronic expansion valve

Model

D20MISZ-1R(L)

Design pressure (H/L)

MPa

4.4/2.6

Pipe

connections

Liquid/Gas pipe

Ф6.35/Ф12.7

Ф9.53/Ф15.9

Drain pipe

OD Φ16

Notes:

1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.

2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.

3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.

4. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured in a semi-anechoic chamber.

5. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.

201805 5

Table

1.2:

SDV5-80,90,112,140FA

specifications

Model

SDV5-80FA SDV5-90FA

SDV5-112FA

SDV5-140FA

Power supply

1 phase, 220-240V, 50Hz

Cooling1

Capacity

8.0

9.0

11.2

14.0

kBtu/h

27.2

30.7

38.2

47.8

Power input

130

180

Heating2

Capacity

9.0

10.0

12.5

15.0

kBtu/h

30.7

34.1

42.7

51.2

Power input

130

180

Fan motor

Model

WZDK100-38GS-1

WZDK100-38GS-2

Type

Brand

Panasonic/Match-Well

Speed3

r/min

1300/1270/1230/1200/1160/1120/1090

1140/1090/1060/1040/1010/990/970

Indoor coil

Number of rows

Tube pitch × row pitch

mm 25.4×22

Fin spacing

mm 1.8

Fin type

Hydrophilic aluminum

Tube OD and type

mm Ф9.52 Inner-groove

Dimensions (L×H×W)

mm 1094×254×66 1360×254×66

Number of circuits

Air flow rate3

m3/h 1280/1245/1210/1170/1130/1085/1050 1890/1830/1765/1700/1660/1620/1580

Sound pressure level4

dB(A) 45/44/43/43/42/41/40 47/46/45/45/44/43/42

Sound power level

dB(A) 58/57/56/56/55/54/53 60/59/58/58/57/56/55

Unit

Net dimensions5

(WxHxD)

1280×660×203

1670×680×244

Packed dimensions

(WxHxD)

1379×744×296

1915×760×330

Net/Gross weight

35/41

48/58

Refrigerant type

R410A

Throttle

Type

Electronic expansion valve

Model

BD24FKS(L)

Design pressure (H/L)

MPa

4.4/2.6

Pipe

connections

Liquid/Gas pipe

Ф9.53/Ф15.9

Drain pipe

OD Φ16

Notes:

1. Indoor temperature 27°C DB, 19°C WB; outdoor temperature 35°C DB; equivalent refrigerant piping length 7.5m with zero level difference.

2. Indoor temperature 20°C DB; outdoor temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 7.5m with zero level difference.

3. Fan motor speed and air flow rate are from the highest speed to the lowest speed, total 7 rates for each model.

4. Sound pressure level is from highest level to lowest level, total 7 levels for each model. Sound pressure level is measured in a semi-anechoic chamber.

5. Unit body dimensions given are the largest external dimensions of the unit, including hanger attachments.

6 201805

2Dimensions

2.1 Unit Dimensions

Figure 2.1: Ceiling & floor dimensions (unit: mm)

Hook

Hanging arm

Table 2.1: Ceiling & floor dimensions

Model

Dimensions (mm)

A B C D E F G

SDV5-36FA

SDV5-45FA

SDV5-71FA

990 660 203 505 506 907 200

SDV5-80FA

SDV5-90FA 1280 660 203 795 506 1195 200

SDV5-112FA

SDV5-140FA 1670 680 244 1070 450 1542 200

Table 2.2: Ceiling & floor piping connections

Model Gas pipe (mm) Liquid pipe (mm)

SDV5-36FA

SDV5-45FA Ф12.7 Ф6.35

SDV5-71FA

SDV5-80FA

SDV5-90FA

SDV5-112FA

SDV5-140FA

Ф15.9 Ф9.53

4 201805

3Unit Placement

3.1 Placement Considerations

Unit placement should take account of the following considerations:

Units should not be installed in the following locations:

Where exposure to direct radiation from a high-temperature heat source or to interference from a source of

electromagnetic radiation may occur.

Where dust or dirt may affect heat exchangers.

Where exposure to oil or to corrosive or harmful gases, such as acidic or alkaline gases, may occur.

Where exposure to salinity may occur, such as seaside locations.

Where highly flammable materials are present.

Where exposure to oily air may occur, such as a kitchen.

Where exposure to very high humidity may occur, such as a laundry.

Units should be installed in positions where:

The ceiling is horizontal and is able to bear the unit’s weight.

There are no obstructions that could impede the airflow into and out of the unit.

The airflow out of the unit can reach throughout the room.

There is sufficient space for access during installation, servicing and maintenance.

The refrigerant piping and drain piping can be easily connected to the refrigerant piping and drain piping

systems.

Short-circuit ventilation (where outlet air returns quickly to a unit’s air inlet) will not occur.

3.2 Space Requirements

Figure 3.1: Ceiling & floor space requirements (unit: mm)

>600mm

600mm

>20

Air Outlet

Obstacle

Piping connection

Obstacle

Drop ceiling

Air Outlet

201805 5

4Piping Diagram

Figure 4.1: Ceiling & floor piping diagram

flare nut

T2B

gas side

motor

heat exchanger

fan

EXV

liquid side

Legend

T1 Indoor ambient temperature sensor

T2 Indoor heat exchanger mid-point temperature sensor

T2B Indoor heat exchanger outlet temperature sensor

6 201805

5Wiring Diagram

Figure 5.1: Ceiling & floor wiring diagram

201805 7

Caution

All installation, servicing and maintenance must be carried out by competent and suitably qualified, certified

and accredited professionals and in accordance with all applicable legislation.

Units should be grounded in accordance with all applicable legislation. Metal and other conductive components

should be insulated in accordance with all applicable legislation.

Power supply wiring should be securely fastened at the power supply terminals –loose power supply wiring

would represent a fire risk.

After installation, servicing or maintenance, the electric control box cover should be closed. Failing to close the

electric control box cover risks fire or electric shock.

Switch ENC1 (indoor unit capacity setting) is factory-set and its setting should normally not be changed. The

only circumstances in which a switch ENC1 might need to be set in the field is when replacing a main PCB.

When replacing a main PCB, ensure that the capacity setting on switch ENC1 on the new PCB is consistent with

the unit capacity given on the unit’s nameplate.

Notes for installers and service engineers


