SilverStone ST50NF Manual de usuario

April, 2011

ST50NF

NIGHTJAR SERIES

Industrial-class fanless power supply

Fan-less thermal solution, 0 dBA acoustics

Efficiency 82%~85% at 20%~100% loading

500W continuous power output

Strict ±3% voltage regulation

PCI-E 8pin and PCI-E 6pin connector support

Powerful class-leading single +12V rail

Aluminum construction

Server-level components

Support ATX 12V 2.3 & EPS 12V

Active PFC

NO:G11214010

ST50NF

Silverstone Nightjar

ST50NF

ATX12V / EPS 12V Switching Power Supply

With Active PFC

Fan-less Thermal Solution

80Plus Bronze

PS/2

The power supply shall be operated at universal input voltage defined in the following table.

Lnput Voltage

Voltage

MIN

NOM

110-240

MAX

264

1. Input Requirements

1-1. Input Voltage

The input frequency range is from 47Hz to 63Hz.

1-2. Frequency

The max inrush current is 100A for 115/230VAC.

1-3. Inrush Current

1-3-1. Cold Start

Conditions

Limits

115/230VAC, full load.

25 C ambient. No component over stress

or damage should occur to

the power supply.Input fuse

shall ot blow.

1-3-2. Warm Start

Conditions

Limits

Turn off at 132/264VAC full

load for 1 sec then turn on

at the peak of the input

voltage cycle at 25 C ambient.

No component over stress

or damage should occur to

the power supply.

Input fuse shall not blow.

1-4. AC Input Current

AC Input

115V

230V

Units

AMPS

MAX

6.5

Output Voltage

+5V

+12V

-12V

+3.3V

+5Vsb

MIN

+4.75

+11.40

-10.80

+3.135

+4.75

Nominal

+5.00

+12.00

-12.00

+3.30

+5.00

MAX

+5.25

+12.60

-13.20

+3.465

+5.25

Units

Volts

Range

10%

The minimum power supply system efficiency shall be >82%, measured at nominal

input voltage 115V or 230V and full loading.

1-5. Efficiency

3.5ma max, At 240Vac/60Hz

Note:

1. The above voltage range should also include ripple and noise.

2. The output voltage should be measured at the terminals of output connector.

1-6.Leakage current

2-1. Output Regulations

2. Output Requirements

ST50NF

The DC loads shall remain within the ranges specified in 2-2 DC Load Requirements and the DC

output voltages also shall remain within the regulation ranges specified in 2-1 Output Regulation

when measured at the load end of the output connectors.

+5V

0.5

+3.3V

0.5

+12V

0.5

-12V

0.5

+5VSB

0.1

2-2-1. Cross Regulation

The +5Vsb is on whenever the AC power is present.

Note: The measurements should be made by crossing a 47uf/ electrolytic and a 0.1uf ceramic disk

capacitors at each output with measuring bandwidth from DC to 20 mhz. If ambient temperature is

under 20 C or over 30 C, the AC input should be nominal input.

Figure 1. Differential Noise Test Setup

2-3. +5V standby voltage

Output Voltage

+5V

+12V

-12V

+3.3V

+5Vsb

Ripple & Noise Max

120

Units

2-2-1. Cross Regulation

2-5. Total Output Power

Ac Input Voltage

99V~264Vac

MAX

500

Units

Watts

MAX

500

Units

The power supply outputs shall be enabled with an active-low TTL signal.

When TTL signal is low, the DC outputs are to be enabled.

When TTL signal is high or open circuited, the DC outputs are to be disabled.

Electronic means or a mechanical switch may activate the TTL signal.

After the TTL signal is active high, must wait for 3 seconds before active low again.

2-6. Remote ON/OFF Control

FIGURE 2. Power Sequence

The test environment is 25 C condition

@ nominal input. See1-1

2-8. Power On Time (T1)

MAX.

Units

2-9. Rise Time (T2)

MIN.

100

MAX.

500

Units

2-10. Power Good Delay Time (T3)

MAX

Units

2-11. Power Good Rise Time (T4)

2-7. Power Sequence

ST50NF

Power good signal shall go to a down level 1ms before +5V output

voltage falls below the regulation limits during PS-ON signal pull high.

2-13. Power Fail Signal (T6)

When the DC outputs (+5V, +12V, +3.3V) have over voltage condition,

the power supply shall provide latch mode over voltage protection.

3-1. Over Voltage Protection

A short circuit placed to ground shall cause no damage or power supply shall be shutdown.

(The contact resistance is 0.05 ohm when the outputs short circuit.)

3-2. Short Circuit Protection

When the power supply latches into shutdown condition due to a fault on an+5V,+3.3V,+12V,

output (OVP, UVP,OCP)and OTP, the protection shall reset after the fault has been removed,

use remote on/off control or recycle the AC power again for a typical of 5 seconds.

3-3. Protection Reset

Any output overshoot at turn on shall be less than 15% of the nominal output value

(with resistive load) as described in sec. 2.1.

3-4. Over Shoot

3. Protections

DC output

+12V

+5V

+3.3V

Max

16.0

7.0

4.5

Unit

MIN.

Units

MIN.

Units

2-12. Hold Up Time (T5)

The test environment is 25 C & full

load condition @ nominal input.

At 115/230Vac input the power supply will shut down all DC output within max. 150% of full load.

3-5. Over Power Protection

Max.160% for +5V,+12V,+3.3V dc output rail.

3-6. Over Current Protection

When power supply temperature over 90 C (typ.)The power supply will be shutdown.

FIGURE 3. Operation/Storage Temperature Range

Caution: Fanless power supply recommends the systems require

additional external forced circulation cooling fan to extend product life.

3-7. Over Temperature Protection( Optional )

Operation: 20% to 90% RH(nominal input)

Storage: 5% to 95% RH

4-2. Humidity (none condensing)

Operation:

115V: 0 C to 35 C (Need to increase external forced air cooling) -P1(Note.)

230V: 0 C to 45 C (Need to increase external forced air cooling) -P2(Note.)

4-1. Operation/Storage Temperature Range

4. Environment

ST50NF

5-1. UL 60950-1, 2005 (2nd Edition.)

5-2. BSMI (CNS14336: 94)

5-3. TUV EN 60950-1: 2006+A11

5-4. CB

5. Safety

6-1. CE

6-2. BSMI (CNS13438: 95)

6-3. FCC Part 15 Subpart B, Class B at system load

6-4. CISPR 22 AS/NZS CISPR 22: 2006, CLASS B

6. EMI Requirements

The power supply shall withstand for 3 seconds without breakdown the application of an 1800Vac-supply

voltage applied between both input line and chassis (10ma AC Cutoff current). Isolating transformers shall

similarly withstand 4242Vdc applied between both primary and secondary windings for a minimum of one

minute.

7. Dielectric Voltage Withstand (HI-POT)

Active Power Factor Correction, complies with EN 61000-3-2: 1995 + A1 + A2: 1998, Class D.

8. PFC

Comply with IEC 61000-4-2.

9. Electrostatic Discharge (ESD)

Comply with IEC 61000-4-4.

10. EFT/ Burst

Comply with IEC 61000-4-5.

11. Surge

Applying 115 Vac

10 % or 230 Vac

10% input voltage and maximum load (60%)

for this product in 45

5 C chamber.

12. Burn-In

The power supply shall have a minimum mean time between failure greater than

80,000 hours Minimum (Without Cooling Fan) at continuous operation of 100%

load and an ambient temperature of 25 C.

13. M.T.B.F.

There are two leds for the monitoring the status of the power supply,which allows

users to perceiveA full awareness of the working condition of the power supply.

The temperature LED indicates surface temperature of the power supply’s housing cage.

14. LED Indicators

Dimension (W x H x D): 150mm (5.90”) x 86mm (3.38”) x 160mm (6.29”)

15.1. Physical Dimension

M/B 24PIN connector

15. MECHANICAL REQUIREMENTS

The Status-LED indicates power

supply’s working.

Caution: DO NOT TOUCH THE SURFACE OF POWER SUPPLY WHEN

THE TEMP-LED INDICATES RED, IT MIGHT BE DANGEROUS.

Temp. Status

High 55 C

Low 55 C

LED Color

Red

Green

Orange

Blue

Black

Green

Black

White

Red

Black

Signal

+3.3V

-12VDC

COM

PS-ON

COM

N/C

+5VDC

COM

Signal

+3.3V

COM

+5VDC

COM

+5VDC

COM

PWRGOOD

+5Vsb

+12V

+3.3V

Orange

Black

Red

Black

Red

Black

Grey

Purple

Yellow

Orange

Power Status

Standby

Power ON

Power Fault

LED Color

Amber

Green

Red

ST50NF

EPS 12V 8PIN connector

Yellow

Signal

+12V

Signal

COM

Black

ATX 12V 4PIN (4+4PIN EPS 12V in split mode)

Black

Signal

GND

Signal

+12V

Yellow

SATA connector

Orange

Black

Red

Black

Yellow

Signal

+3.3V

COM

+5V

COM

+12V

4PIN peripheral connector (HDD) 4PIN floppy connector (FDD)

Yellow

Black

Red

Signal

+12V

COM

+5VDC

Signal

+5VDC

COM

+12V

Red

Black

Yellow

8PIN PCI Express connector

Yellow

Black sense1

Signal

+12V

COM

Signal

COM

Black

6PIN PCI Express connector

Yellow

Signal

+12V

Signal

COM

Black
