Silvercrest 328625 2001 Manual de usuario
WET & DRY HANDHELD VACUUM CLEANER
SAS 7.4 LI B3
WET & DRY HANDHELD VACUUM CLEANER
Operating instructions
HANDSTAUBSAUGER NASS UND TROCKEN
Bedienungsanleitung
IAN 328625_2001
GB/IE/NI Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 15
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
A
4
1
2
q
0
8
7
6
3
5
9
w
Bre
2x
GB│IE│NI │ 1 ■
SAS 7.4 LI B3
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Description of the appliance .....................................3
Technical data .................................................4
Important safety instructions.....................................4
Prior to first use................................................7
Information about the batteries ..................................8
Installation of the wall bracket ...................................8
Charging .....................................................9
Operation ....................................................9
Cleaning.....................................................11
Disposal .....................................................12
Kompernass Handels GmbH warranty............................13
Service................................................................ 14
Importer ............................................................... 14
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 1 02.06.2020 13:12:53
■ 2 │ GB│IE│NI SAS 7.4 LI B3
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of this
product. They contain important information on safety, usage and disposal. Before
using the product, familiarise yourself with all operating and safety instructions. Use
the product only as described and for the specified areas of application. Please also
pass on these operating instructions to any future owner.
Intended use
This handheld vacuum cleaner may only be used to vacuum dry or wet surfaces,
or dry or wet materials and liquids. Do not vacuum people or animals with this
appliance. Any other usage of or modification to the appliance is deemed to be
improper and carries a significant risk of accidents. The manufacturer accepts no
liability for damages that result from improper use of the appliance or are caused
by the incorrect operation of it. The appliance is not intended for commercial use.
Package contents
▯ Hand-Held Wet & Dry Vacuum Cleaner
▯ Crevice tool
▯ Wet suction nozzle
▯ Wall bracket
▯ Mounting kit (2 screws, 2 wall plugs)
▯ Mains adapter
▯ Operating instructions
Check the package contents for completeness directly after unpacking.
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 2 02.06.2020 13:12:53
GB│IE│NI │ 3 ■
SAS 7.4 LI B3
Description of the appliance
(For illustrations see the fold-out side)
Figure A:
1Wet suction nozzle
2Crevice nozzle
3Wall bracket
4Mains adapter
5Barrel plug
6On/off switch
7Charge indicator lamp (red/green)
8Release button
9Dust filter bag
0Dust filter
qDirt container
wMotor unit
Figure B:
eScrew
rWall plug
NOTE
► This appliance is supplied with non-charged batteries. The batteries must be
charged before first use.
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 3 02.06.2020 13:12:53
■ 4 │ GB│IE│NI SAS 7.4 LI B3
Technical data
Appliance
Input voltage/current 9.6 V (DC) / 0.5 A
Rechargeable batteries
Capacity 2200 mAh
Rechargeable battery 7.4 V (DC)
(2 x 3.7 V Lithium-ion rechargeable batteries)
Mains adapter
Manufacturers
KOMPERNASS H. GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
Commercial register number:
HRB 4598
Model SAS 7.4 LI B3-2
Input voltage
100 ‒ 240 V ~(
AC
)
Input AC frequency 50/60 Hz
Output voltage 9.6 V (DC)
Output current 0.5 A
Output power 4.8 W
Average operating efficiency 78.3 %
Low load efficiency (10%) 72.1 %
No-load power consumption 0.07 W
Current consumption 0.3 A
Protection class II / (double insulation)
Polarity (positive inside, negative outside)
Efficiency class 6 VI
Important safety instructions
DANGER – ELECTRIC SHOCK!
► Never use the handheld vacuum cleaner if the cable, plug
or casing are damaged.
► To avoid risks, arrange to have damaged power cables
and/or plugs replaced as soon as possible by a qualified
specialist.
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 4 02.06.2020 13:13:01
GB│IE│NI │ 5 ■
SAS 7.4 LI B3
DANGER – ELECTRIC SHOCK!
► Have all repairs carried out by a specialist workshop. Under
no circumstances should you open the appliance yourself.
Repairs that are not carried out by a specialist workshop
could lead to physical injuries.
► Before switching on the appliance, make sure that the mains
voltage corresponds to the voltage indicated in the technical
data for the appliance.
► Never touch the mains adapter or the appliance with wet or
damp hands.
► Do not use the mains adapter with an extension cable; con-
nect the mains adapter directly to a power socket.
Do not charge or use the appliance outdoors.
WARNING! RISK OF INJURY!
► Do not change any accessories while the appliance is
switched on.
► Do not use the handheld vacuum cleaner for vacuuming up
sharp objects or glass shards.
► Never vacuum up burning matches, glowing ashes or ciga-
rette butts.
► Do not use the handheld vacuum cleaner for vacuuming up
chemical products, stone dust, gypsum, cement or similar
particles.
► This appliance is not suitable for use with inflammable and
explosive substances or chemical and aggressive liquids.
► Always store the appliance indoors. To prevent accidents,
keep the appliance in a dry location when not in use.
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 5 02.06.2020 13:13:03
■ 6 │ GB│IE│NI SAS 7.4 LI B3
WARNING! RISK OF INJURY!
► Under extreme conditions, leaks in the battery cells may oc-
cur. In the event that battery fluid comes into contact with skin
or eyes, the affected area must be rinsed off with water imme-
diately. Contact a physician.
► This appliance may be used by children aged 8 years and
above and by persons with limited physical, sensory or mental
capabilities or lack of experience and knowledge, provided
that they are under supervision or have been told how to use
the appliance safely and are aware of the potential risks.
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance tasks may not be carried
out by children unless they are supervised.
► Take special care when using the handheld vacuum cleaner
on stairs.
CAUTION! PROPERTY DAMAGE!
► Use only accessories recommended by the manufacturer.
► The mains adapter may not be used for other purposes.
Never carry the wall bracket or the mains adapter by the
cable. Do not pull on the cable when you want to move the
appliance.
► Always grip the power plug to disconnect the appliance
from the power supply.
► Always be sure to keep the handheld vacuum cleaner away
from heating elements, ovens or other heated appliances
and surfaces.
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 6 02.06.2020 13:13:03
GB│IE│NI │ 7 ■
SAS 7.4 LI B3
CAUTION! PROPERTY DAMAGE!
► Make sure that the ventilation slits are never obstructed.
A blocked ventilation circuit can result in overheating and
damage to the appliance.
► The appliance is suitable for vacuuming small amounts of
water; however, its housing is not splashproof. Therefore, do
not immerse the appliance in water and do not expose it to
moisture!
►
UN 34811
Tel. ____________
The product is equipped with or supplied with a
lithium-ion battery. Do not throw the batteries
into a fire and do not subject them to high
temperatures. There is a risk of explosion!
► Do not use the handheld vacuum cleaner without the dust
filter inserted.
► Do not use the mains adapter for a different product and do
not attempt to charge this appliance with a different mains
adapter. Use only the mains adapter supplied with this appli-
ance.
► Never attempt to recharge non-rechargeable batteries.
► The batteries in this appliance cannot be replaced.
Prior to first use
■ Remove all packaging materials from the appliance.
■ Press the dust filter bag 9and the dust filter 0a little way into the dirt
container q. They might have worked loose during transport and thus not
be positioned correctly inside the dirt container q.
■ Place the dirt container qon the motor unit w:
–Push the plastic tab on the underside of the handheld vacuum cleaner
into the recess on the dirt container q.
–Press the release button 8 and push the dirt container qonto the motor
unit wat the same time.
–Let go of the release button 8so that the restraint engages in the
recess. The dirt container qis now firmly seated on the motor unit w.
IB_328625_SAS7.4LIB3_LB6_IE-NI.indb 7 02.06.2020 13:13:03
