Silvercrest KH 2030 Manual de usuario
KH 2030
KOMPERNASS GMBH · BURGSTRASSE 21 ·
D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH2030-01/09-V2
MULTI-BAND RADIO
A
MULTI-BAND RADIO
Operating instructions
WIELOZAKRESOWY ODBIORNIK CYFROWY
Instrukcja obsługi
VILÁGVEVŐ RÁDIÓ
Használati utasítás
CV_KH2030_DT25841_LB4A.qxd 12.01.2009 12:48 Uhr Seite 1
KH 2030
fd
g
;2)
l
j
h
k
saoi
r
y
u
A
B
qew
t
CV_KH2030_DT25841_LB4A.qxd 12.01.2009 12:48 Uhr Seite 4
- 1 -
CONTENTS PAGE
Intended use 2
Technical Data 2
Safety information 4
Operating elements 7
Starting up 8
General functions 10
Time functions 11
Time, date, time zone and world time 11
Select display mode 15
Alarm function 15
Stop watch function 18
Countdown function 18
Radio operation 19
Setting the station 20
Fine tuning 21
Aerial 21
Memory functions 22
Cleaning 24
Disposal 24
Importer 25
Warranty & service 26
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 1
MULTI-BAND RADIO KH2030
Before using the device for the first time, read these operating instructions
carefully and keep them for later reference. Hand the instructions over
when transferring the device to a third party.
Intended use
This device is designed to receive generally approved radio transmissions in
all countries (world receiver) and only for domestic use.
It has not been designed to receive transmissions that are not generally ap-
proved, nor as part of safety radio systems, e.g. on board sports boats, nor
for industrial or commercial use. It has also not been designed for use in
temperatures beyond those stated in the Technical Data.
Technical Data
This device has been tested and approved for adherence to the basic requi-
rements and the other relevant regulations of the EMC Directive
2004/108/EC and the Directive on Low Voltage Devices 2006/95/EC.
Power consumption: 5 watts
Power consumption Standby: 1.3 W
Operating temperature: +5 ~+35°C
Humidity: 5 ~90%
(no condensation)
- 2 -
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 2
Dimensions (L x W x H): 180 x 40 x 110 mm
Weight: ca. 380 g
Batteries
4x 1.5 V, Type AA/LR6/Mignon (not supplied)
Frequency range radio:
VHF (FM): 87 – 109 MHz
SW: 5.85 - 17.90 MHz
MW (AM) Europe 522 - 1656 kHz
MW (AM) USA 520 - 1710 kHz
LW 144 - 299 kHz
The technical features of the device enable the frequency ranges stated
above to be set. Various countries may have different national rules on the
radio frequency ranges assigned. Please note that you may not sell, trans-
fer to third parties or abuse information received outside the assigned ra-
dio frequency ranges.
Tuning ranges (NORMAL/FINE):
FM (VHF) 100 kHz/50 kHz
SW 5 kHz/1 kHz
MW (AM) Europe 9 kHz/1 kHz
MW (AM) USA 10 kHz/1 kHz
LW 1 kHz
Sensitivity: SW can be set to 2 intervals
General
Memory positions : 1600 (400 for each frequency range)
- 3 -
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 3
Headphones
Model: E105
Impedance: 32 Ω
Wideband characteristic Voltage (WBCV): 100 mV
Headphone socket
max. Output voltage: 20 mV
Power transformer
Manufacturer: S&S MFG. LTD.
Model: A400-75
Primary: 230 V ~50 Hz / 30 mA
Secondary: 7.5 V DC 400 mA / 3VA
Safety information
• This device has not been designed for use by people (including chil-
dren) with restricted physical, sensory or intellectual abilities or lack of
experience and/or knowledge, unless they are supervised by a re-
sponsible person (for their own safety) or have received instructions
on how to use the device.
• Children should be supervised to ensure that they do not play with the
device.
• In order to avoid the device being switched on unintentionally, remo-
ve the adapter from the mains socket after each use and before
cleaning.
• Check the device and all parts for visible damage. The device’s safety con-
cept can only work if the device is in perfect condition.
• A mains adapter connected to the device must always be easily ac-
cessible so that the device can be quickly disconnected from the
mains power in an emergency.
- 4 -
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 4
Risk of electric shock!
• Only connect the device to a properly installed and earthed mains so-
cket. The mains voltage must agree with that stated on the device’s
specification plate.
• Damaged adapters or mains cables should be exchanged immediate-
ly by an authorised technician or the Customer Service in order to
avoid risks.
• Connection cables or devices that do not work perfectly or have been
damaged should be repaired or exchanged immediately by Customer
Services.
Never immerse the device in water! Simply wipe it with a slightly
damp cloth.
• Do not expose the device to rain or use it in a damp or wet environ-
ment.
• Ensure that the connection cable is never wet or damp when in use.
• You must not open or repair the device’s housing. This can be dangerous
and renders the warranty null and void.
• Protect the device from moisture and sprayed water. Therefore do not
place any objects filled with water (e.g. vases) on or near the device.
Risk of fire!
• Do not use the device near hot surfaces.
• Do not set the device up where it is exposed to direct sunlight. This
could cause it to overheat and damage it beyond repair.
• Never leave the device unattended during operation.
• Never cover the device’s ventilation slots when it is switched on.
• Do not place open flames, such as candles, on or near the device.
- 5 -
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 5
Risk of injury
• Keep children away from the connection cable and device. Children
frequently underestimate the danger of electrical devices.
• If the device has fallen down or is damaged it must no longer be used.
Have the device checked by a qualified specialist and, if necessary, re-
paired.
• Batteries must not be handled by children.
Children can put batteries in their mouths and swallow them.
If a battery has been swallowed, obtain medical assistance immediately.
Thunder storms!
Devices connected to mains power can be damaged during a thun-
der storm. If there is a thunder storm, always remove the mains plug
from the socket.
Information on voltage surges (EFT/electrical fast
transient) and electrostatic discharges:
If the product does not work properly due to electrical fast transient
processes (voltage surges) or electrostatic discharge, it must be
reset to restore normal operation. If necessary, remove the plug from
the power socket and insert it again. The batteries (if used) must be re-
moved and reinserted.
Information on separating the device from mains
power
The POWER button on this device does not completely separate it
from the mains network. In addition, the device uses power when in
standby mode. In order to completely separate the device from the
mains supply the plug must be removed from the mains socket.
- 6 -
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 6
Notes on handling batteries
The device uses batteries. Please note the following on handling batteries:
Risk of explosion!
Do not throw batteries into a fire. Do not recharge batteries.
• Never open, solder or weld batteries. There is a risk of explosion and injury!
• Check batteries regularly. Leaking batteries can damage the device.
• If the appliance is not going to be used for long periods, remove the
batteries.
• If batteries leak, put on protective gloves.
• Clean the battery compartment and contacts with a dry cloth.
Caution!
No liability/warranty applies to damage to the device caused by moi-
sture due to water penetrating the device or overheating!
Operating elements
Front side
qMemory buttons M.0/5–M.4/9
wScreen
ebutton SNOOZE
rFrequency selection switch
tbutton PAGE
ybutton FINE
ubutton POWER
ibuttons UP/DOWN
- 7 -
IB_KH2030_DT25841_LB4A 12.01.2009 16:59 Uhr Seite 7
obuttons VOL.+ (AL-1)/VOL.– (AL-2)
abutton MODE
sbutton BASS
dbutton MEMORY SCAN
fbutton MEM
gspeakers
Back
hStand
jAerial
kCarrying strap
lswitch SW SEN.
;Headphone output
2) EXT. DC 7.5 V 400 mA: Mains adapter connection
Starting up
Unpack the device
Remove all packaging materials.
Caution!
Do not let children play with the plastic film. There is a risk of suffocation.
Check the items supplied
Whilst unpacking, check that all of the following items are available to
you:
• Shortwave Radio
• Power transformer
- 8 -
