Silvercrest SED 3.7 D2 Manual de usuario
CORDLESS EPILATOR SED 3.7 D2
IAN 273035
CORDLESS EPILATOR
Operating instructions
EPILEERAPPARAAT,
ACCU/STROOM
Gebruiksaanwijzing
ÉPILATEUR BATTERIE/SECTEUR
Mode d’emploi
EPILIERER, AKKU/NETZ
Bedienungsanleitung
GB Operating instructions Page 1
FR / BE Mode d'emploi Page 17
NL / BE Gebruiksaanwijzing Pagina 33
DE / AT / CH Bedienungsanleitung Seite 49
Before reading, unfold the page containing the illustrations and familiarise
yourself with all functions of the device.
Avant de lire le mode d'emploi, ouvrez la page contenant les illustrations et
familiarisez-vous ensuite avec toutes les fonctions de l'appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en maak u
vertrouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen
Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
3
8
90
2
3
4
5
6
1
7
A
B
1
GB
SED 3.7 D2
Table of Contents
Introduction .................................. 2
Copyright ............................................2
Intended Use ................................. 2
Items supplied ................................ 3
Disposal of packaging ..................................3
Operating Elements............................ 4
Technical data ................................ 4
Safety instructions............................. 5
Mains power operation ........................ 8
Battery operation ............................. 8
Tips and Tricks ................................ 9
Epilation ....................................10
Cleaning and Care............................ 12
Storage ....................................13
Troubleshooting .............................13
Disposal of the appliance ......................14
Warranty and Service ........................15
Importer....................................16
GB
2SED 3.7 D2
Introduction
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product. These oper-
ating instructions are a part of this product. They contain important
information in regard to safety, use and disposal. Before using the
product, familiarise yourself with all of these operating and safety
instructions. Use the product only as described and only for the
specified areas of application. In addition, pass these documents on,
together with the product, to any future owner.
Copyright
This documentation is copyright protected.
Any copying or reproduction, including as extracts, as well as the
reproduction of images, also in an altered state, is only permitted
with the written authorisation of the manufacturer.
Intended Use
This appliance is intended exclusively for the epilation of human hair
in domestic households. Do not use it for commercial purposes! This
appliance is not intended for any other use or for uses beyond those
mentioned.
Claims of any kind resulting from damage caused by improper use,
incompetent repairs, unauthorised modifications or the use of non-
approved spare parts will not be acknowledged.
The operator alone bears the risk.
3
GB
SED 3.7 D2
Items supplied
The appliance is supplied with the following components as standard:
■ Cordless Epilator
■ Mains adapter
■ Cleaning brush
■ Storage pouch
■ Operating Instructions
Extract all parts of the appliance from the carton and remove all
packaging material. Check the contents to ensure everything has
been supplied, and for signs of visible damage.
TIPS
► As delivered, the storage pouch is located under the plastic
shell containing the device itself. You must remove the
cardboard under the plastic shell in order to take the storage
pouch out.
► If the delivery is incomplete, or has been damaged due to
defective packaging or transportation, contact the Service
Hotline (see chapter Warranty and Service).
Disposal of packaging
The packaging protects the appliance against transport damage.
The packaging materials are selected from the point of view of
their environmental friendliness and disposal technology and are
therefore recyclable.
The recirculation of packaging into the material circuit
saves on raw material and reduces generated waste.
Dispose of packaging material that is no longer needed
as per the regionally established regulations .
GB
4SED 3.7 D2
Operating Elements
Figure A:
Protective cap
Epilator head
Restraint fixtures for epilator head
Travel lock
Speed switch
Control lamps red/green
Socket for mains adapter
Figure B:
Mains power adapter
Storage pouch
Cleaning brush
Technical data
Mains adapter
Type ZDJ045100EU
Input voltage 100 - 240 V ~, 50/60 Hz
Power consumption 0.2 A Max.
Output voltage 4.5 V
Output current 1000 mA
Protection class II/
Polarity
5
GB
SED 3.7 D2
Device
Input voltage 4.5 V
Power consumption 1000 mA
Batteries 3,7 V 700mAh Lithium ion battery
Safety instructions
RISK OF ELECTRIC SHOCK
► Connect the appliance only to correctly in-
stalled mains power sockets supplying a current
rating of 100 - 240 V ~/ 50/60 Hz.
► The power cable on this appliance cannot be
replaced. In the event of it being damaged
the whole appliance must be disposed of.
► In the event of operational malfunction, and
for cleaning, always remove the plug from the
mains power socket.
► To disconnect the power cable, always pull
the plug itself from the mains power socket,
do not pull on the cable.
► Do not kink or crimp the power cable and
place it in such a way as to prevent anyone
from stepping on or tripping over it.
GB
6SED 3.7 D2
RISK OF ELECTRIC SHOCK
► Ensure that the power cable cannot become
wet or moist during operation. Place it such
that it cannot be squashed or damaged.
► To avoid risks, should the appliance be dam-
aged discontinue the use of it immediately.
► Do not use the appliance outdoors.
► Do not wrap the power cable around the ap-
pliance and protect it from being damaged.
► NEVER grasp the appliance, power cable or
plug with wet hands.
► TAKE NOTE! Keep the appliance dry.
Never use the appliance near water, particu-
larly not near sinks, baths or other vessels.
The proximity of moisture presents a danger,
even when the appliance is switched off.
After use, always remove the plug from the
mains power socket. As additional protection,
the installation of a faulty-current protection
unit with an activation power rating of not
more than 30 mA is recommended for the
power circuit in the bathroom.
Consult your electrician for advice.
7
GB
SED 3.7 D2
WARNING! RISK OF INJURY!
► Do not operate the appliance if it has sustained
a fall or is damaged. Arrange for the appliance
to be checked and/or repaired by qualified
technicians.
► Do not open the housing or attempt to repair
the appliance yourself. Should you do so, ap-
pliance safety can no longer be assured and
the warranty will become void. Permit only
authorised technicians to repair a defective
appliance if repairs should be necessary.
► Use the appliance only with the supplied power
adapter.
► Charge the appliance only with the supplied
power adapter.
► This appliance may be used by children aged 8
over and by persons with reduced physical, senso-
ry or mental capabilities or lack of experience and
knowledge, provided that they are under supervi-
sion or have been told how to use the appliance
safely and are aware of the potential risks.
► Children must not play with the appliance.
► Cleaning and user maintenance tasks must
not be carried out by children unless they are
supervised.
