Wireless M-Bus-EK

WIRELESS M-BUS DEMONSTRATION KIT USER’SGUIDE

1. Kit Contents

The Wireless M-Bus Demonstration Kit contains the following items:

Wireless M-Bus Demonstration Board

3.6 V Lithium battery

USB cable

AC to DC power adapter

868 MHz antenna

2. Introduction

The purpose of the Wireless M-Bus Demonstration Kit is to demonstrate a low-power meter application using the

Wireless M-Bus stack. The demonstration has three basic system components:

Wireless M-Bus Meter Demonstration Kit (Meter)

Monitor

PC Application

The Wireless M-Bus Meter Demonstration Kit performs the basic metering functions. It will either count pulses or

measure the temperature. The Meter will also periodically wake up and transmit the data using the Wireless M-Bus

protocol.

The Monitor measures and displays the current consumption of the Meter. The Monitor also communicates with the

PC application and configures the Meter over a UART connection.

The Wireless M-Bus Demonstration board is shown in Figure 1. The right half of the board implements the Meter,

and the left half of the board implements the Monitor.

Figure 1. Wireless M-Bus Demonstration Board

Wireless M-Bus-EK

2 Rev. 0.1

3. Hardware Overview

The Wireless M-Bus Demo board has two sections. The Wireless M-Bus meter section is on the right half as

shown in Figure 2.

Figure 2. Meter Section

The Wireless M-Bus meter section includes the following components.

C8051F930 Low-Power Microcontroller

Si4431 EZRadioPRO®Transceiver

CP2400 LCD Driver

The C8051F930 is well suited for Low-Power Metering solutions. This MCU includes 64 k of Flash and 4 k of RAM,

which is sufficient for the Wireless M-Bus stack and a large application. The C8051F930 has a very low-power

Sleep mode. The current consumption in Sleep mode is only 50 nA. The MCU also has a 32.768 kHz

SmaRTClockTM. The MCU SmaRTClockTM is used for all timing functions in the low-power meter.

The Si4431 EZRadioPRO®transceiver provides +13 dB of output power. This is the highest power permitted in the

868 MHz band used by the Wireless M-Bus Standard. The RF layout is matched for 868 MHz. The Si4431 is

placed in Shutdown mode when the radio is not in use. The current draw in shutdown mode is only 15 nA.

The CP2400 LCD driver features an SPI interface and can drive displays with up to 128 segments and four

backplanes. The Wireless M-Bus meter section uses a static four-digit display for the lowest possible power

consumption. The Meter Display is used to display either pulse count or Temperature. The Monitor Section is

shown in Figure 3.

C8051F930

CP2400

Si4431

Wireless M-Bus-EK

Rev. 0.1 3

Figure 3. Monitor Section

The monitor section includes the following components:

C8051F342 USB microcontroller

CP2400 LCD driver

The C8051F342 microcontroller is used to monitor the meter current consumption, display the current consumption

on the eight-digit alphanumeric display, and communicate over USB with the PC applications on the PC host. The

discrete current amplifier and integrator are used with the internal comparator and timer to calculate the average

current consumption.

A second CP2400 is used to drive the monitor display. The monitor display is an alphanumeric display with eight

14-segment characters. The monitor display is normally used to display average current consumption. Pressing

the Mode button will alternately display the elapsed time or output pulse frequency.

Three pin headers are provided for different power options. The Wireless M-Bus demo board may be powered from

a USB, a wall adapter, or a 3.6 V long-life Lithium battery. The meter section can be powered from the battery while

the monitor section is powered from USB or wall power.

C8051F342

CP2400

Wireless M-Bus-EK

4 Rev. 0.1

4. Software Overview

The software system diagram is shown in Figure 4. The meter application firmware runs on the C8051F930 and is

written on top of the Wireless M-Bus stack. The meter application firmware measures the temperature or counts

the number of pulses and is configured over the UART interface by the monitor application firmware.

The monitor application firmware runs on the C8051F342. The monitor application uses the USBXpress®library

and embedded API.

Figure 4. Software System Diagram

USBXpress

Wireless Meter

Bus Demo

Monitor App

EZRadioPRO

‘F930

USB

WMBus Stack

Meter App

‘F342

CP2400

SPI

UART

SPI

Wireless M-Bus-EK

Rev. 0.1 5

5. Install Wireless Meter-Bus Software

Download the Wireless M-Bus demo software from the Silicon Labs web site:

www.silabs.com/wirelessmbus

The Wireless Meter-Bus demo requires Windows 2000®, XP®, Server2003®, Vista®, or Windows 7®. Download

the software, unzip it, and run the installer executable.

6. Install USBXpress Driver

The Wireless M-Bus PC software uses the USBXpress API and requires the USBXpress driver. Download and

install the USBXpress driver before connecting the Wireless M-Bus board to the computer via USB. There is no

cause for concern if you have already connected the Wireless M-Bus demo board to the PC. Disconnect the

Wireless M-Bus demo board, and proceed with the USBXpress installation.

Download and install the USBXpress development kit for windows from the Silicon Labs website:

www.silabs.com/USBxpress

Unzip the file and run the executable program. When prompted, check the “Install USBXpress Drivers” checkbox to

install the USBXpress Drivers immediately. If you miss this step, the USBXpress driver can be installed later by

running the driver installer. The following path is the USBXpress driver installer default location:

C:\SiLabs\MCU\USBXpress\Driver\USBXpressInstaller.exe

Configure the shorting blocks before connecting the USB cable as explained in “7. Hardware Setup”.

Wireless M-Bus-EK

6 Rev. 0.1

7. Hardware Setup

Please install the USBXpress drivers before connecting the Wireless M-Bus demo board to the PC (see “6. Install

USBXpress Driver”).

The Wireless M-Bus Demo Board has three headers on the left side of the board to configure the C8051F342 and

C8051F930 power sources.

To configure both MCUs to operate from USB power, configure the headers as shown in Figure 5.

Configure shorting blocks to short pins 2 and 3 on J10.

Remove shorting block on J11.

Configure shorting blocks to short pins 1 and 2 of J12.

Figure 5. USB Power Configuration

The headers in the middle of the board provide options for measuring the current of the C8051F930 MCU, Si4431

EZRadioPRO, and CP2400 LCD Controller.

To configure the Monitor circuit to include the MCU and radio current, install the headers as shown inFigure 5.

Short pins 1 and 2 on J5 with a shorting block.

Remove shorting block on J6 to enable 1 resistor.

Short pins 2 and 3 on J7 to enable MCU current measurement.

Short pins 2 and 3 on J8 to enable radio current measurement.

Short pins 1 and 2 on J9 to disable LCD current measurement.

Short pins 2 and 3 on J13 to power the CP2400 from the meter supply.

After configuring the headers, connect one end of the USB cable to the Wireless M-Bus demo Board and the other

end to the PC. The first time the Wireless M-Bus demo board is connected to the computer, the Found New

Hardware wizard will indicate “Found New Hardware - USBXpress Device”. If the Found New Hardware wizard

fails to correctly identify the USBXpress device, ensure that the USBXpress drivers are installed correctly as

explained in “6. Install USBXpress Driver”.

SW2 SW1

J10

J11

J12

J13

SW3 F342

CP2400

F930

SILICON LABS

www.silabs.com

J4 J3

Monitor Meter Wireless M-Bus Demo Board

DIS2 DIS1

ANT1

Wireless M-Bus-EK

Rev. 0.1 7

8. PC Application

After installation, the Wireless M-Bus PC application is located in the following default directory:

C:\SiLabs\MCU\Wireless_Meter_Bus\Software\MBusDemo.exe

The initial screen is shown in Figure 6.

Figure 6. Wireless M-Bus Demo PC Application

If the M-Bus demo hardware is connected to the PC and the USBXpress driver has been installed, the demo board

serial number should be displayed in the Device drop-down menu. If the serial number is not displayed, perform

the following steps:

1. Check that the USBXpress driver has been installed.

2. Check that the shorting block configuration is set up according to the hardware setup.

3. Check the USB connection to your PC.

4. Check that the LCD displays are active.

If the LCD displays are not active, this indicates that the board is not powered.

Wireless M-Bus-EK

8 Rev. 0.1

The power consumption of the meter depends on the parameter settings. The PC application allows the following

parameters to be set:

Transmit Period

Data Field Length

M-Bus Mode

Transceiver Mode

Data Select

Pulse Frequency

Encryption

LCD Enabled

8.1. Transmit Period

The transmit period can be set for 1 second to 3600 seconds (5 minutes). The C8051F930 MCU will sleep for this

period with the Si4431 EZRadioPRO in shut-down. Then, it will wake up, take a measurement, and send the data.

The Transmit period has a large effect on the power consumption. A long transmit period is necessary to achieve

multi-year battery life.

8.2. Data Field Length

The data field length sets the length of the application payload in the M-Bus packet. The minimum length is 2,

including the required CI byte. The maximum is 100 bytes. If AES encryption is enabled, this field must be a

multiple of 16.

8.3. M-Bus Mode

The following menus can be used to select the M-Bus mode:

Mode S: 32,768 cps Manchester encoding

Mode SL: same as above with a very long preamble

Mode T: 100 kcps, three-out-of-six encoding

Mode R: 4800 cps, Manchester encoding

Mode T provides the highest data rate and gives the lowest power consumption. The current consumption of Mode

SL with the long preamble is slightly higher than Mode S. The long preamble is not necessary for the Si4431

EZRadioPRO. Power consumption is the highest using Mode R. Sending a long packet using Mode R may take

hundreds of milliseconds. Mode T2, Mode S2, and Mode R2 may be selected by choosing TX and RX in the

Transceiver mode menu. According to the specification, Mode R should always use TX and RX. For additional

information about M-Bus modes, refer to “AN451: Wireless M-Bus Software Implementation” and EN 13757-4.

8.4. Transceiver Mode

The Wireless M-Bus demo PC application provides two transceiver modes:

TX

TX and RX

If the TX only mode is selected, the meter will sleep for the transmit period, wake up, and transmit its data. If the TX

and RX mode is selected, the meter will wake up and send an access demand message. If the access demand

message is acknowledged, the meter will send its data to the other device.

When a meter reader (Other) device is present, the current consumption of the two-way communication is highest.

Because there is overhead associated with the two-way data transfer. If the meter reader (Other) is not present, the

two-way meter only needs to send the access demand message and wait for the response time. Still, the response

time is long compared to the message length; so, the one-way communication usually provides the lowest power

consumption.

Wireless M-Bus-EK

Rev. 0.1 9

8.5. Data Select

The options for the Data Select menu are:

Pulse

Temperature

None

The selected data is displayed on the LCD and transmitted in the data payload.

The Pulse option provides a pulse counter. The C8051F342 acts as a virtual water or gas meter. The C8051F930

will wake up on each rising and falling edge and count the number of pulses. The pulse rate is programmable.

The Temperature sensor uses the onboard temperature sensor on the C8051F930.

The power consumption will be higher using the pulse counter. This is because the MCU must wake up often to

count the number of pulses. Using the temperature sensor, the current consumption is less because the

temperature is only measured before each transmission.

8.6. Pulse Frequency

When pulse data is selected, the pulse frequency is programmable from 0.1 to 10 Hz. The 0.1 Hz provides one

pulse every ten seconds.

8.7. Encryption

The AES encryption option will encrypt the data before sending. The demo uses the AES 128 block cipher.

Ecrypting the data takes some extra time and results in higher power consumption. The encryption time will be

higher for longer data lengths.

Since the demo uses the basic AES128 block cypher, the data size must be a multiple of 16. The transmission data

should be padded with zeros. Other encryption modes might accommodate an arbitrary length.

8.8. LCD enabled

The LCD display takes power to operate and update. The three-pin header, J9, may be configured to exclude the

LCD current from the measurement. However, the C8051F930 is still updating the LCD display. Disabling the LCD

turns off the Meter display, and the MCU will not have to update the display. This decreases the time that the

C8051F930 has to be awake and lowers power consumption.

Normally, the CP2400 is powered from the same voltage supply as the C8051F930. However, the LCD current is

so low that the CP2400 may be powered from an I/O pin of the C8051F930. The LCD current may be further

decreased by configuring J13 with a shorting block on Pins 1 and 2. This powers the CP2400 from an C8051F930

I/O pin and further lowers the power consumption when the LCD is disabled.

Wireless M-Bus-EK

10 Rev. 0.1

9. Wireless M-Bus Stack

The source code for the Wireless M-Bus stack is available as a separate download from the M-Bus web page:

www.silabs.com/wirelessmbus

Additional information on the Wireless M-Bus stack may be found in the following application notes:

“AN451: Wireless M-Bus Software Implementation”

“AN452: Wireless M-Bus Stack Programmers Guide”

The source code may only be used in accordance with the terms in the click-through license agreement. The

source may only be used with a Silicon Labs MCU and Silicon Labs radio product.

The Wireless M-Bus source code supports two development platforms: The Si4431 EzRadioPRO development

platform using the C8051F930 MCU and the Si1000 integrated MCU/EZRadioPRO platform.

The M-Bus demo board is intended as a demo only. It is not supported as a development platform.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Silicon Laboratories

Silicon Laboratories

Silicon Laboratories C8051F91 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories EZRadioPRO Manual de usuario

Silicon Laboratories

Silicon Laboratories EM35 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F530A Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F500 Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F38 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051xxxDK Series Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM8 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F58 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F326-DK Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F310-TB Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F30 series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051T622 Manual de usuario

Silicon Laboratories

Silicon Laboratories Si4311-DB Manual de usuario

Silicon Laboratories

Silicon Laboratories Si1010 Manual de usuario

Silicon Laboratories

Silicon Laboratories Z-Wave 800 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F310DK-T Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM8BB3-SLSTK2022A Manual de usuario

Silicon Laboratories

Silicon Laboratories BRD4258B Manual de usuario

Silicon Laboratories

Silicon Laboratories AN1342 Manual de usuario

Silicon Laboratories

Silicon Laboratories I2C Manual de usuario

Silicon Laboratories

Silicon Laboratories SLWSTK6104A Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM32 Manual de usuario

Silicon Laboratories

Silicon Laboratories EFR32xG21 Wireless Gecko Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
