Sierra Wireless MC Series Manual de usuario

Richmond, BC Fax +1 604 231 1109

2400432, Rev. 1 Canada, V6V 3A4 www.sierrawireless.com

MiniCard (MC) Development Kit

Kit Contents

•(1) MC-series development kit printed circuit assembly

•(2) Ultra-wideband 4G dipole swivel terminal antennas

•(6) RF cables—U.FL micro coaxial cables (3 for Main/AUX/GNSS, 3 spares)

•(1) U.FL connector push/pull tool

•(1) USB cable (Type A to micro-B 3.0)

•(1) AC wall adapter power supply and international plug kit

•(1) micro-SIM to SIM adapter

•(2) Thermal pads (1 to install on heat shield, 1 spare). Pad type: 30.5 x 44.0 mm TENNVAC GP5000

•(3) M2x3 Phillips head module screws (2 to install module, 1 spare)

Module Insertion

1. Remove backing from the thermal pad (both sides), and position the thermal pad on the heat sink.

2. Insert the module as shown. (Insert at a 31º angle, rotate down, and push fully into the connector.)

3. Secure the module with two M2 screws.

SIM Card Connection

1. Slide the SIM card into CN202 (top left corner of the PCB), noting the location

of the notched corner. (If ESIM is enabled, DO NOT use a SIM in CN202.)

2. If supporting dual SIMs, insert a second SIM card into CN206.

Power Source Selection

Connector Jump Description Power connector(s) to use

CN101

(PWR IN

SELECT)

Pins 1 & 2 Power provided by barrel jack (AC adapter) CN103

Pins 3 & 4 Power provided by banana jack (3.125–4.4VDC)

Disable on-board LDO

CN114 (VCC) & CN116, or

CN115 (VCC_MODULE) & CN116

Pins 5 & 6 Power provided by USB cable (Default jumper

location)

CN105

CN117

CONNECT

MAIN VCC

Pins 1 & 2 Jumper required when selected power type is

AC adapter or USB cable.

Remove the jumper to isolate module power

from other circuits on the board.

HOW TO MATE (INSTALL) AND EXTRACT

MATE: ßâ

ãä

âMATE

EXTRACT:

ßLEAD-IN

ãRISE UP

äEXTRACT

áPUSH

àROTATE

31°

Switch Settings

Test Points

Switch Position Default Operation Description

SW100 1Off 3.0V Select voltage for MC module

(When selected power source is barrel jack or USB cable)

2On 3.3V

3Off 3.6V

4Off 4.2V

SW200 1Off W_Disable_N On=Set to logic low; Off=Set to logic high

2On LDO_EN On=Enable on-board bias voltage

Off=Disable on-board bias voltage

3On LDO_CODEC_EN On=Enable codec supply voltage

Off=Disable codec supply voltage

4Off ESIM_Reset On=ESIM in reset mode; Off=ESIM in active mode

(ESIM support will be implemented in a future revision.)

5Off DPR input On=DPR low; Off=DPR high

6NC NC No connect

7NC NC No connect

8NC NC No connect

9NC NC No connect

10 NC NC No connect

SW201 Button switch Reset Module

Connector Pin # Description Connector Pin # Description

CN207 1Ground CN208 1NC

2NC 2Ground

3On-board 1.8V 3On-board module LDO

4W_DISABLE_N 4NC

5Module 1.8V 5PCM_CLK

6NC 6UIM1_DET

7On-board module LDO 7PCM_DIN

8WAKE_ON_WWAN_N 8RESET_N

9UIM2_RST 9PCM_DOUT

10 UIM1_CLK 10 WWAN_LED_N

11 UIM2_CLK 11 PCM_SYNC

12 UIM1_RST 12 I2C_DATA

13 UIM2_DATA 13 NC

14 UIM1_DATA 14 NC

15 UIM2_PWR 15 NC

16 UIM1_PWR 16 RFFE_DATA

17 NC 17 UIM2_DET

18 DPR 18 RFFE_CLK

19 NC 19 I2C_CLK

20 NC 20 RFFE_VIO
