Siemens TC35iT
Installation & Programming
Manual
CONTENTS
TC35IT INSTALLATION & PROGRAMMING MANUAL............................................................................3
1) INTRODUCTION..............................................................................................................................................3
2. INSTALLING THE SIEMENS TC35IT MODEM .......................................................................................4
3. PROGRAMMING THE TC35IT MODEM....................................................................................................5
3.1 USING A STANDARD PSTN TELEPHONE LINE AT THE PC END ...................................................................................5
3.2 USING A SECOND TC35IT CELLULAR MODEM AT THE PC END.................................................................................7
3.2.1 Programming the TC35iT for the Datalogger site.................................................................................7
3.2.2 Programming the TC35iT for the PC....................................................................................................8
3.3 NOTES ON TC35IT MODEM PROGRAMMING............................................................................................................9
4. MODES OF OPERATION.............................................................................................................................11
FIGURE 1.............................................................................................................................................................12
INSIDE THE GSM MODEM UNIT..............................................................................................................................12
FIGURE 2.............................................................................................................................................................13
Cable Entries on base of GSM Modem nit..................................................................................................13
FIGURE 3.............................................................................................................................................................14
MODEM POWER CONTROL.......................................................................................................................................14
APPENDIX 1 - USING WINDOWS HYPERTERMINAL..............................................................................15
APPENDIX 2 - WIRING DETAILS FOR MODEM PROGRAMMING CABLE........................................1
2
1) INTRODUCTION
This manual gives instructions to distributors who are purchasing a GSM module from Skye, and
fitting the Siemens TC35iT module themselves.
However, if you have purchased the TC35iT from Skye we will have already installed it in its
housing however it is possible that you may have to reprogram the modem for your own local
GSM network.
The Siemens TC35iT modem is dual band for use with a 900 or 1800 MHz GSM cellular telephone
system only. An airtime contract and SIM card must be obtained from the mobile phone network
provider. This can be a standard “Voice” contract with a Data number added, or some network
providers offer a “Data only” contract. You need the Data “telephone” number to dial up the
MiniMet weather station. The Voice telephone number will not work.
When requesting the Data number from the network provider, please ask for:
1. Circuit Switched data number (modem type connection)
2. 9600 bps
3. 8 data bits, No Parity bits, 1 Stop Bit
4. Non-Transparency enabled (also known as error corrected or “RLP”)
Connection to the remote MiniMet or DataHog logger can be made from the office PC which is
fitted either with a standard modem connected to the PSTN telephone line or via a second TC35iT
cellular modem and SIM card using the Skye MOD3 unit. Please see the Chapters 3.1 and 3.2 for
setting up these two options.
3
TC35iT Installation & Programming Manual
2. INSTALLING THE SIEMENS TC35iT MODEM
This chapter refers to the remote MiniMet or DataHog GSM housing enclosure (with the green
label).
Make sure no power is available to the GSM Modem Unit before proceeding.
Remove the lid from the Skye GSM Modem Unit by unscrewing the 4 corner screws.
The Siemens TC35iT is supplied with a short aerial lead and connector only. It has 2 mounting
holes which can be used to fix it to the aluminium mounting plate inside the Skye GSM Modem
Unit. See Figure 1.
There are 2 sockets on the TC35iT. The Skye GSM Modem Unit has a grey 9 pin D connector and a
small clear connector with 6 gold contacts which match these sockets. Push the clear connector into
its socket, connect the grey D connector and screw up to secure.
Before connecting the aerial remember to feed the aerial cable through the cable gland in the
base of the GSM Modem Unit. See Figure 2. Screw together the 2 aerial connectors and make the
excess cable tidy. Tighten the cable gland over the ‘built up’ portion of the aerial cable to make a
waterproof seal.
To install the airtime contract SIM card, locate the small black tray marked SIM on the side of the
TC35iT itself. Push the little yellow button beside it to release the tray, insert the SIM card (it will
only go in one way) and replace the tray, pushing fully home.
NOTE: before installing the SIM card it is a good idea to insert it into a hand phone to check its
functionality. You may need to switch off the PIN code request function, we would also
recommend switching off all divert calls (e.g. divert to voice mail if not answered etc).
The TC35iT then requires programming before use (see below).
4
TC35iT Installation & Programming Manual
3. PROGRAMMING THE TC35iT MODEM
It is necessary to change the factory settings of the Siemens TC35iT modem suitable for
communication with the DataHog or MiniMet logger. When the TC35iT is purchased through Skye,
we will have already done this initial programming for you (the default setting is described in
Chapter 3.1 for use with a standard PSTN telephone line).
However in some countries we have found that one or two settings are slightly different to those
used in the U , so you may have to change these. You may need to seek advice from either a
local Siemens dealer, or the GSM network provider technical department, who should be able to
advise on different programming settings for your own country.
Programming the TC35iT is very easy and full instructions are given below. You will need the
special 'Modem Programming' cable (see Appendix 2 for details), the Skye GSM Modem Unit, an
aerial and a 12V battery or 12V power supply.
3.1 Using a standard PSTN telephone line at the PC end
In this case you will have just one Siemens TC35iT modem, fitted into the GSM Modem Unit
housing, which will be installed on the MiniMet mast.
The office PC which will dial up the station must also have a modem connection. This must be a
standard analogue fax / modem (internal or external to the PC) connected to an analogue
standard PSTN telephone line. An ISDN digital telephone line will not work.
PLEASE FOLLOW THESE INSTRUCTIONS IN ORDER, CAREFULLY. IF POWER IS APPLIED TO THE
TC35iT UNIT BEFORE OTHER CONNECTIONS ARE MADE, THE MODEM CAN BE PERMANENTLY
DAMAGED.
1. Disconnect the grey 9 pin D connector from the GSM Modem Unit to the TC35iT. Replace this
with the male end of the Skye 'TC35iT programmer' cable. Connect the female end to a serial
port of a PC.
2. Make sure the aerial is fitted to the TC35iT.
3. Connect a 12V battery (or power supply) to the GSM Module Unit using the red and black
'spade' connectors fitted to the thick white cable exiting the base of the housing. At this point
the red LED marked MODEM ACTIVE WHEN LIT should come on (in the bottom right hand side
of the PCB).
Start Windows HyperTerminal on the PC. To begin communications, configure the appropriate
Comm Port and use the settings 9600 baud rate, no handshake, no parity, 1 stop bit. If you are
unfamiliar with HyperTerminal please see Appendix 1.
5
TC35iT Installation & Programming Manual
Follow these instructions for the programming sequence:
1. Type at and press return. O should come back.
(NOTE – if the TC35iT has already been programmed by Skye, you may not see the O come
back. In this case type ate1 and press return. Then type atq0 and press return. Now try typing at
again and press return. O should come back.)
2. Type at&f and press return. O should come back.
3. Type ats0=2 and press return.
4. Type ats7=90 and press return.
5. Type ats10=200 and press return.
6. Type at&c1 and press return.
7. Type at&d0 and press return.
8. Type at&s1 and press return.
9. Type at%d0 and press return.
10. Type at+icf=3 and press return.
11. Type at+ifc=2,2 and press return.
12. Type at+ipr=9600 and press return.
13. Type at+cbst=7,0,1 and press return.
14. Type atq1 and press return.
15. Type ate0 and press return.
16. Type at&w0 and press return.
17. Type at&v and press return. The modems settings are displayed.
18. Check to see that the changes you have entered are all there. There will also be other settings
which you have not changed.
To check the TC35iT is correctly set up, make a call from it through the PC (if an airtime contract
barring outward calls is in place, this may not be possible). To do this type atdt then the
telephone number, then press return. You will see the message CONNECT 9600 on the screen if
successful. Try to ring a telephone nearby so that you can hear it ring and answer it! To hang up,
type +++ath and press enter.
IMPORTANT - it is important to switch off the power to the TC35iT before disconnecting any other
cables, to prevent damage. When power has been removed the red LED ‘Modem Active’ light will
go off.
Disconnect the 'TC35iT programmer' cable from the PC and TC35iT. Reconnect the grey 9 pin D
connector between the GSM Modem Unit and the TC35iT.
Replace the housing’s lid, taking care not to damage the rubber ‘O’ ring seal.
6
TC35iT Installation & Programming Manual
3.2 Using a second TC35iT cellular modem at the PC end
In this case you will have two Siemens TC35iT modems, one fitted into the GSM Modem Unit
housing which will be installed on the MiniMet mast, plus a second which will be with the non
waterproof MOD3 unit next to the PC.
The programming requirements are different for each modem, please see below. Use the remote
GSM Modem Unit to power and program each modem in turn, using the instructions below.
PLEASE FOLLOW THESE INSTRUCTIONS IN ORDER, CAREFULLY. IF POWER IS APPLIED TO THE
TC35iT UNIT BEFORE OTHER CONNECTIONS ARE MADE, THE MODEM CAN BE PERMANENTLY
DAMAGED.
3.2.1 Programming the TC35iT for the Datalogger site
1. Disconnect the grey 9 pin D connector from the GSM Modem Unit to the TC35iT. Replace this
with the male end of the Skye 'TC35iT programmer' cable. Connect the female end to a serial
port of a PC.
2. Make sure the aerial is fitted to the TC35iT.
3. Connect a 12V battery (or power supply) to the GSM Module Unit using the red and black
'spade' connectors fitted to the thick white cable exiting the base of the housing. At this point
the red LED marked MODEM ACTIVE WHEN LIT should come on (in the bottom right hand side
of the PCB).
Start Windows HyperTerminal on the PC. To begin communications, configure the appropriate
Comm Port and use the settings 9600 baud rate, no handshake, no parity, 1 stop bit. If you are
unfamiliar with HyperTerminal please see Appendix 1.
Follow these instructions for the programming sequence:
1. Type at and press return. O should come back.
(NOTE – if the TC35iT has already been programmed by Skye, you may not see the O come
back. In this case type ate1 and press return. Then type atq0 and press return. Now try typing at
again and press return. O should come back.)
2. Type at&f and press return. O should come back.
3. Type ats0=2 and press return.
4. Type ats7=90 and press return.
5. Type ats10=200 and press return.
6. Type at&c1 and press return.
7. Type at&d0 and press return.
7
TC35iT Installation & Programming Manual
8. Type at&s1 and press return.
9. Type at%d0 and press return.
10. Type at+icf=3 and press return.
11. Type at+ifc=2,2 and press return.
12. Type at+ipr=9600 and press return.
13. Type at+cbst=71,0,1 and press return.
14. Type atq1 and press return.
15. Type ate0 and press return.
16. Type at&w0 and press return.
17. Type at&v and press return. The modems settings are displayed.
18. Check to see that the changes you have entered are all there. There will also be other settings
which you have not changed.
To check the TC35iT is correctly set up, make a call from it through the PC (if an airtime contract
barring outward calls is in place, this may not be possible). To do this type atdt then the
telephone number, then press return. You will see the message CONNECT 9600 on the screen if
successful. Try to ring a telephone nearby so that you can hear it ring and answer it! To hang up,
type +++ath and press enter.
IMPORTANT - it is important to switch off the power to the TC35iT before disconnecting any other
cables, to prevent damage. When power has been removed the red LED ‘Modem Active’ light will
go off.
Disconnect the 'TC35iT programmer' cable from the PC and TC35iT.
To reinstall the modem in the GSM Modem Unit remote housing, reconnect the internal grey 9 pin
D connector. Replace the housing’s lid, taking care not to damage the rubber ‘O’ ring seal.
To reinstall the modem in the MOD3 unit, remove from the GSM Modem Unit remote housing,
install in the MOD3 housing and reconnect the internal grey 9 pin D connector.
3.2.2 Programming the TC35iT for the PC
1. Just for the purpose of programming, connect the TC35iT which is to be used with the PC to the
GSM Modem Unit as in 3.2.1 above.
2. Connect the male end of the Skye 'TC35iT programmer' cable to the TC35iT. Connect the
female end to a serial port of a PC.
3. Make sure the aerial is fitted to the TC35iT.
4. Connect a 12V battery (or power supply) to the GSM Module Unit using the red and black
'spade' connectors fitted to the thick white cable exiting the base of the housing. At this point
the red LED marked MODEM ACTIVE WHEN LIT should come on (in the bottom right hand side
of the PCB).
8
TC35iT Installation & Programming Manual
Start Windows HyperTerminal on the PC. To begin communications, configure the appropriate
Comm Port and use the settings 9600 baud rate, no handshake, no parity, 1 stop bit. If you are
unfamiliar with HyperTerminal please see Appendix 1.
Follow these instructions for the programming sequence:
1. Type at and press return. O should come back.
(NOTE – if the TC35iT has already been programmed by Skye, you may not see the O come
back. In this case type ate1 and press return. Then type atq0 and press return. Now try typing at
again and press return. O should come back.)
2. Type at&f and press return. O should come back.
3. Type at+cbst=71,0,1 and press return.
4. Type at&w0 and press return.
5. Type at&v and press return. The modems settings are displayed.
6. Check to see that the changes you have entered are all there. There will also be other settings
which you have not changed.
To check the TC35iT is correctly set up, make a call from it through the PC (if an airtime contract
barring outward calls is in place, this may not be possible). To do this type atdt then the
telephone number, then press return. You will see the message CONNECT 9600 on the screen if
successful. Try to ring a telephone nearby so that you can hear it ring and answer it! To hang up,
type +++ath and press enter.
IMPORTANT - it is important to switch off the power to the TC35iT before disconnecting any other
cables, to prevent damage. When power has been removed the red LED ‘Modem Active’ light will
go off.
Disconnect the 'TC35iT programmer' cable from the PC and TC35iT. Connect this TC35iT to the PC as
required. Replace the datalogger site TC35iT in the GSM Housing Unit as described in 3.2.1.
3.3 Notes on TC35iT modem programming
The above settings have been tested on U networks only.
There is only one difference between the datalogger modem programme in Chapters 3.1 and 3.2,
that is instruction 13. The command at+cbst defines the type of modem connection as follows:
9
TC35iT Installation & Programming Manual
at+cbst=0,0,1 autobauding
(for connecting an analogue modem or a TC35iT at PC end to the TC35iT modem at the MiniMet
end)
at+cbst=7,0,1 instructs a V32 analogue modem connection @ 9600 baud
(for connecting an analogue modem at PC end to the TC35iT modem at the MiniMet end)
at+cbst=71,0,1 instructs a V110 digital modem connection @ 9600 baud
(for connecting a TC35iT modem at PC end to the TC35iT modem at the MiniMet end)
10
TC35iT Installation & Programming Manual
Tabla de contenidos
Otros manuales de Módem de Siemens
Siemens
Siemens SE505 Manual de usuario
Siemens
Siemens Gigaset USB Stick 108 Manual de usuario
Siemens
Siemens MC35 Terminal Manual de usuario
Siemens
Siemens SITRANS TK Manual de usuario
Siemens
Siemens TC35i Terminal Manual de usuario
Siemens
Siemens Simatic S7-300 Manual de usuario
Siemens
Siemens Brodersen MC55 AT Instrucciones de instalación
Siemens
Siemens Gigaset SX685 WiMAX Manual de usuario
Siemens
Siemens SpeedStream 4100 Manual de usuario
Siemens
Siemens Insys 56k Manual de usuario
Siemens
Siemens Gigaset USB Stick 54 Manual de usuario
Siemens
Siemens TC35 Manual de usuario
Siemens
Siemens 7XV5655-0BB00 Manual de usuario
Siemens
Siemens Gigaset USB Stick 108 Manual de usuario
Siemens
Siemens C2-010 Manual de usuario
Siemens
Siemens SE366 Manual de usuario
Siemens
Siemens SINAUT MD720-3 Manual de usuario
Siemens
Siemens SINAUT MD720-3 Guía del usuario
Siemens
Siemens EDGE Speed ES75 Manual de usuario
Siemens
Siemens SIMATIC NET MODEM MD720 Guía del usuario
Manuales populares de Módem de otras marcas
US Robotics
US Robotics 3453C Manual de usuario
MaxTech
MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manual de usuario
Zte
Zte MF823 Manual de usuario
Four-Faith
Four-Faith F1403 Manual de usuario
Sierra Wireless
Sierra Wireless AIRLINK MP595W Manual de usuario
Gemtek
Gemtek WiMAX WIXFBR-103 Manual de usuario
