Siemens 9810 Series Manual de usuario

9810 series

User manual

7EN05-0336-09

01/2023

www.usa.siemens.com/pds

Safety information

Important information

Read these instructions carefully and look at the equipment to become familiar with the

device before trying to install, operate, service, or maintain it. The following special

messages may appear throughout this manual or on the equipment to warn of potential

hazards or to call attention to information that clarifies or simplifies a procedure.

The addition of either symbol to a "Danger" or "Warning" safety label indicates that an

electrical hazard exists which will result in personal injury if the instructions are not followed.

This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey

all safety messages that follow this symbol to avoid possible injury or death.

DANGER

DANGER indicates a hazardous situation which, if not avoided, will result in death or serious

injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, could result in death or

serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, could result in minor or

moderate injury.

NOTICE

NOTICE is used to address practices not related to physical injury.

Please note

Electrical equipment should be installed, operated, serviced and maintained only by qualified

personnel. No responsibility is assumed by Siemens for any consequences arising out of the use

of this material. A qualified person is one who has skills and knowledge related to the

construction, installation, and operation of electrical equipment and has received safety training to

recognize and avoid the hazards involved.

Notices

FCC

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that the

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment to an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

The user is cautioned that any changes or modifications not expressly approved by Siemens

could void the user’s authority to operate the equipment.

This digital apparatus complies with CAN ICES-3 (B) /NMB-3(B).

Open source software components

This Siemens product is provided with certain open source software components (collectively,

“OSS”) developed by third parties. Refer to "Open source software components" on page 279 for

details.

Metering equipment symbols

The following IEC 60417 and ISO 7000 symbols may be used on the metering equipment:

Symbol Reference Title and description

IEC 60417-5017

Earth; ground

To identify an earth (ground) terminal in cases where

neither the symbol 5018 nor 5019 is explicitly required.

IEC 60417-5018

Functional earthing; functional grounding (US) *

To identify a functional earthing (grounding) terminal, for

example, of a specially designed earthing (grounding)

system to avoid causing malfunction of the equipment.

IEC 60417-5019

Protective class I; Protective earth/ground

To identify any terminal which is intended for connection

to an external conductor for protection against electric

shock in case of a fault, or the terminal of a protective

earth (ground) electrode.

IEC 60417-5172

Protective class II equipment **

To identify equipment meeting the safety requirements

specified for Class II equipment (double or reinforced

insulation).

ISO 7000-0434B

Caution, refer to accompanying documents

To indicate that caution is necessary when operating the

device or control close to where the symbol is placed. To

indicate that the current situation needs operator

awareness or operator action in order to avoid

undesirable consequences.

ISO 7000-1641

Operator's manual; operating instructions

To identify the location where the operator's manual is

stored or to identify information that relates to the

operating instructions. To indicate operating instructions

should be considered when operating the device or

operating controls close to where the symbol is placed.

* There may be national differences concerning the use of this symbol.

** Protective class equipment requirements are outlined in IEC 61140.

About this manual

This manual discusses features of the Siemens 9410 series power meter and provides

configuration instructions.

Throughout the manual, the term “meter” refers to all models of the Siemens 9410 series meter.

All differences between the models, such as a feature specific to one model, are indicated with the

appropriate model number or description.

This manual assumes you have an understanding of power metering and are familiar with the

equipment and power system in which your meter is installed.

This manual does not provide configuration information for advanced features where an expert

user would perform advanced configuration. It also does not include instructions on how to

incorporate meter data or perform meter configuration using energy management systems or

software, other than ION Setup. ION Setup is a free configuration tool available for download from

www.usa.siemens.com/pds.

Contact your local Siemens representative to learn what additional training opportunities are

available regarding the Siemens 9410 series meter.

Make sure you are using the most up-to-date version of your meter’s firmware in order to access

the latest features.

The most up-to-date documentation about your meter is available for download from

www.usa.siemens.com/pds.

Document Number

Siemens 9410 series - Panel Mount installation guide MFR52309

Siemens 9410 series - DIN Mount installation guide NVE23945

ION Reference 7EN05-0290

ION device template reference –

Fiber Ethernet option module US2:948MFIBER

Related documents

Table of Contents

Notices 3

Metering equipment symbols 4

Table of Contents 6

Safety precautions 15

Meter overview 17

9410 series overview 17

Your meter in an energy management system 18

Communications 18

Supported protocols 18

Meter configuration 18

ION Setup device configuration tool 18

Switching ION Setup to Advanced mode 19

Data display 19

Built-in web server and webpages 19

Localization 19

Display 19

Notification 19

Active and historical alarms 19

Email notifications 19

9410 meter models and accessories 20

Mounting adaptors 21

Terminal covers 21

Cybersecurity 22

Recommended actions 22

Plan 25

Cybersecurity awareness 25

System defense-in-depth assumptions 26

Device security capabilities 27

Security risks and mitigation strategies 30

Configure 31

Meter security configuration 32

Disabling and enabling protocols and changing port numbers 42

Verifying the meter security settings 43

Viewing the Device Configuration Checklist 44

Applying security settings to multiple meters 44

Updating passwords on multiple meters 45

Default meter security settings 46

Advanced security mode 47

Operate 49

Monitoring the event log 49

Reporting a security vulnerability 50

7EN05-0336-09 6

Table of Contents 9410 series - User manual

7 7EN05-0336-09

Maintain 50

Viewing and downloading an event log 50

Upgrades and security configuration 51

Decommission 51

Wiping the device 51

Overwriting the meter template file 53

Restoring default security configuration 53

Overwriting factory module registers 53

Overwriting communication module registers 54

Disposal, reuse, recycling 54

Installation and commissioning 56

Installation 56

Power system wiring 57

Residual current measurement 57

Option modules 57

Maximum number of option modules 58

Panel-mount meter and remote display mounting and wiring recommendations 59

Commissioning 59

Factory default settings 59

Commissioning using ION Setup 60

Configuring metering parameters 60

Using the Phasor Viewer 61

Basic setup using the webpages or display 61

Communications 63

Communications overview 63

Ethernet communications 63

Ethernet communications connections 63

Protocols, ports, and connections 65

Self-discovery over Ethernet 65

Ethernet configuration 67

DHCP 76

Meter domain name 77

Network protocol control 78

Serial communications 80

RS-485 80

RS-485 wiring 80

RS-485 configuration 81

Disabling serial communications ports 85

ION 86

Secure ION 86

ION sessions 89

Modbus 89

Key terms 90

Ethernet Modbus device prerequisites 90

Serial Modbus device prerequisites 91

Your meter as a Modbus client 91

Your meter as a Modbus server 94

Supported Modbus features 96

Modbus implementation 98

Modbus map 99

Configuring custom Modbus data using ION Setup 100

Ethernet gateway 102

EtherGate configuration 102

Modbus Ethernet gateway 104

Creating an Ethernet gateway site using ION Setup 106

HTTPS 107

Changing web protocol settings using ION Setup 107

Secure website indicator 107

Default SSL certificate and webpages security 108

Uploading a custom SSL certificate 108

Generating a new self-signed SSL certificate 108

Deleting a custom SSL certificate 108

Secure File Transfer Protocol (SFTP) 109

Transferring files using SFTP 109

Free up flash memory 109

SFTP folders and file permissions 109

SFTP filename requirements 110

Simple Network Management Protocol (SNMP) 110

Key terms 110

Your meter in an SNMP system 110

SNMP trapping 111

Configuring SNMP using ION Setup 111

Configuring SNMP using webpages 112

SNMP implementation 113

Default SNMP mapping 115

Configuring SNMP MIB files 115

IEC 61850 117

Mapping additional data to IEC 61850 117

Enabling IEC 61850 functionality 117

Configuring digital outputs for IEC 61850 control 118

Deleting an IEC 61850 configuration file 119

Distributed Network Protocol (DNP) 119

DNP supported features and default implementation 119

Inputs/Outputs 121

Inputs/Outputs overview 121

Input/output ION modules 121

Input/output ION modules, ports, and labels 122

Factory configured settings 122

9410 series - User manual Table of Contents

7EN05-0336-09 8

Table of Contents 9410 series - User manual

9 7EN05-0336-09

I/O option modules 123

Viewing I/O option module data 124

I/O option module configuration 124

Analog inputs 125

Analog input applications 125

Analog input voltage and current mode 125

Analog input behavior 125

Analog input zero scale and full scale values 125

Configuring option module analog inputs using ION Setup 126

Analog outputs 127

Analog output applications 127

Analog output behavior 127

Analog output zero scale and full scale values 127

Configuring option module analog outputs using ION Setup 128

Digital inputs 128

Digital input applications 128

IRIG-B time synchronization 129

Configuring onboard digital inputs using ION Setup 130

Configuring option module digital inputs using ION Setup 130

WAGES monitoring 131

Input metering 132

Digital outputs 134

Digital output applications 134

Configuring onboard digital outputs using ION Setup 135

Configuring option module digital outputs using ION Setup 135

Energy pulsing 136

Default energy pulsing LED sources 136

Configuring LED energy pulsing using IONSetup 137

Configuring digital output energy pulsing using ION Setup 138

Calculate your maximum kWh/pulse (pulse weight) value 139

Webpages 140

Webpage interface 140

Default meter webpages 140

Accessing webpages for data viewing and meter configuration 142

Embedding images and files in meter webpages 143

Creating custom webpages 143

Deleting custom webpages 144

Loading webpages using ION Setup 144

Loading webpages using SFTP 144

Sample data viewing webpage 145

Sample webpage data viewing result 145

Sample HTML code for data viewing webpage content 147

Sample setup webpage 150

Sample HTML code for setup webpage content 152

Display 156

Display overview 156

Home button 156

Revenue lock icon 157

Alarm icon 157

Alarm and status LED indicators 157

Navigation symbols 158

Using the onscreen keyboard 159

More screens access 160

Overrange indication 160

Auto-scaling feature 160

Display screens 161

Data display screens 161

Setup menu 162

Meter setup using your display 163

Display setup 165

Language setup 166

Creating custom displays using ION Setup 166

Remote display troubleshooting icons 167

Alarms and alerts 168

Alarms 168

Alarm types 168

Standard and high-speed alarms 168

Relative setpoint 171

Sag/swell alarms 171

Digital alarms 171

Alarm event priorities 171

Alarm indicators 172

Default alarms 173

Alarm information 174

Viewing and acknowledging alarms using the display 174

Alarm configuration 174

Alerts 180

Setpoint learning 181

Learning installation mode and learning duration 181

Implementing standard alarm setpoint learning using ION Setup 182

Implementing sag and swell limit learning using ION Setup 183

Power quality 185

Power quality configuration 185

Power quality logging 186

Sags and swells 186

Configuring Advanced Power Quality 188

Harmonics 190

Viewing harmonics information using the display 191

9410 series - User manual Table of Contents

7EN05-0336-09 10

Otros manuales para 9810 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Instrumento de medición de Siemens

Siemens

Siemens SITRANS FM100 Manual de usuario

Siemens

Siemens MicroSAM Manual de usuario

Siemens

Siemens SICAM Manual de usuario

Siemens

Siemens Sitrans F Series Manual de usuario

Siemens

Siemens OXYMAT 64 Manual de usuario

Siemens

Siemens DESIGO PX -U Series Manual de usuario

Siemens

Siemens SENTRON PAC1020 Manual de usuario

Siemens

Siemens SICAM Q80 Manual de usuario

Siemens

Siemens Pointek CLS200 Manual de usuario

Siemens

Siemens 5TT3 196 Manual de usuario

Siemens

Siemens Sitrans F Series Manual de usuario

Siemens

Siemens LDS 6 Guía del administrador

Siemens

Siemens SITRANS F FS200 Utility Manual del propietario

Siemens

Siemens 5SV8001-6KK Manual de usuario

Siemens

Siemens SICAM P 7KG7755 Manual de usuario

Siemens

Siemens Clinitek Advantus Manual

Siemens

Siemens sitrans LU01 Manual de usuario

Siemens

Siemens SIMATIC ST-1500 Manual de lista de piezas

Siemens

Siemens SICAM Q200 7KG97 Manual de usuario

Siemens

Siemens SITRANS F US Manual de usuario

Siemens

Siemens SITRANS FC430 Guía del administrador

Siemens

Siemens SBT WD2005 Manual de usuario

Siemens

Siemens LDS 6 Manual de usuario

Siemens

Siemens SITRANS F Series Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario

Acterna

Acterna MS1400 Manual de usuario
