Siemens Simatic S7-1500 Documento técnico

EQUIPMENT MANUAL

6ES7517-3TP00-0AB0

Edition

CPU 1517T-3 PN/DP

SIMATIC

S7-1500

11/2022

support.industry.siemens.com

Introduction 1

Safety instructions 2

Product overview 3

Wiring 4

Interrupts, error messages,

diagnostics and system

alarms 5

Technical specifications 6

Dimension drawing A

SIMATIC

S7-1500

CPU 1517T-3 PN/DP

(6ES7517-3TP00-0AB0)

Equipment Manual

11/2022

A5E36285525-AD

Siemens AG

Digital Industries

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E36285525-AD

Ⓟ 10/2022 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended or

approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of SiemensAG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

1 Introduction........................................................................................................................................ 5

1.1 Guide documentation S7-1500/ET 200MP......................................................................... 6

1.1.1 Information classes S7-1500/ET 200MP............................................................................. 6

1.1.2 SIMATIC Technical Documentation.................................................................................... 7

2 Safety instructions.............................................................................................................................. 10

2.1 Security information......................................................................................................... 10

3 Product overview................................................................................................................................ 11

3.1 New functions.................................................................................................................. 11

3.2 Application....................................................................................................................... 13

3.3 Hardware properties......................................................................................................... 19

3.4 Firmware functions........................................................................................................... 21

3.5 Operator controls and display elements............................................................................. 26

3.5.1 Front view of the CPU with closed front flap...................................................................... 26

3.5.2 Front view of the CPU without front flaps.......................................................................... 28

3.5.3 Rear view of the CPU......................................................................................................... 29

3.6 Mode selector................................................................................................................... 29

4 Wiring................................................................................................................................................. 30

5 Interrupts, error messages, diagnostics and system alarms.............................................................. 34

5.1 Status and error displays of the CPU.................................................................................. 34

6 Technical specifications...................................................................................................................... 37

A Dimension drawing............................................................................................................................ 38

CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

Table of contents

Introduction 1

Purpose of the documentation

This manual supplements the system manual of the S7-1500 automation system/ET200MP

distributed I/O system as well as the function manuals. This manual contains a description of

the module-specific information. The system-related functions are described in the system

manual. All system-spanning functions are described in the function manuals.

The information provided in this equipment manual and the system manual enables you to

commission the CPU.

Conventions

STEP7: In this documentation, "STEP7" is used as a synonym for all versions of the

configuration and programming software "STEP7 (TIAPortal)".

Please also observe notes marked as follows:

NOTE

A note contains important information on the product described in the documentation, on

the handling of the product or on the section of the documentation to which particular

attention should be paid.

Recycling and disposal

For environmentally friendly recycling and disposal of your old equipment, contact a certified

electronic waste disposal company and dispose of the equipment according to the applicable

regulations in your country.

Industry Mall

The Industry Mall is the catalog and order system of Siemens AG for automation and drive

solutions on the basis of Totally Integrated Automation (TIA) and Totally Integrated Power

(TIP).

You can find catalogs for all automation and drive products on the Internet

(https://mall.industry.siemens.com).

CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

1.1 Guide documentation S7-1500/ET 200MP

1.1.1 Information classes S7-1500/ET 200MP

The documentation for the SIMATIC S7-1500 automation system and the ET200MP

distributed I/O system is arranged into three areas.

This arrangement enables you to access the specific content you require. Changes and

supplements to the manuals are documented in a Product Information.

You can download the documentation free of charge from the Internet

(https://support.industry.siemens.com/cs/ww/en/view/109742691).

Basic information

The System Manual and Getting Started describe in detail the configuration, installation,

wiring and commissioning of the SIMATIC S7-1500 and ET200MP systems.

The STEP7 online help supports you in the configuration and programming.

Examples:

•Getting Started S7-1500

•S7-1500/ET 200MP System Manual

•Online help TIA Portal

Device information

Equipment manuals contain a compact description of the module-specific information, such

as properties, wiring diagrams, characteristics and technical specifications.

Examples:

•Equipment Manuals CPUs

•Equipment Manuals Interface Modules

•Equipment Manuals Digital Modules

•Equipment Manuals Analog Modules

•Equipment Manuals Communications Modules

•Equipment Manuals Technology Modules

•Equipment Manuals Power Supply Modules

6CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

Introduction

1.1 Guide documentation S7-1500/ET 200MP

General information

The function manuals contain detailed descriptions on general topics relating to the SIMATIC

S7-1500 and ET200MPsystems.

Examples:

•Function Manual Diagnostics

•Function Manual Communication

•Function Manual Motion Control

•Function Manual Web Server

•Function Manual Cycle and Response Times

•PROFINET Function Manual

•PROFIBUS Function Manual

Product Information

Changes and supplements to the manuals are documented in a Product Information. The

Product Information takes precedence over the device and system manuals.

You can find the latest Product Information on the S7-1500 and ET200MP systems on the

Internet (https://support.industry.siemens.com/cs/de/en/view/68052815).

Manual Collection S7-1500/ET200MP

The Manual Collection contains the complete documentation on the SIMATIC S7‑1500

automation system and the ET200MP distributed I/O system gathered together in one file.

You can find the Manual Collection on the Internet.

(https://support.industry.siemens.com/cs/ww/en/view/86140384)

SIMATIC S7-1500 comparison list for programming languages

The comparison list contains an overview of which instructions and functions you can use for

which controller families.

You can find the comparison list on the Internet

(https://support.industry.siemens.com/cs/ww/en/view/86630375).

1.1.2 SIMATIC Technical Documentation

Additional SIMATIC documents will complete your information. You can find these

documents and their use at the following links and QR codes.

The Industry Online Support gives you the option to get information on all topics. Application

examples support you in solving your automation tasks.

Introduction

1.1 Guide documentation S7-1500/ET 200MP

CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

Overview of the SIMATIC Technical Documentation

Here you will find an overview of the SIMATIC documentation available in Siemens Industry

Online Support:

Industry Online Support International

(https://support.industry.siemens.com/cs/ww/en/view/109742705)

Watch this short video to find out where you can find the overview directly in Siemens

Industry Online Support and how to use Siemens Industry Online Support on your mobile

device:

Quick introduction to the technical documentation of automation products per

video (https://support.industry.siemens.com/cs/us/en/view/109780491)

YouTube video: Siemens Automation Products - Technical Documentation at a

Glance (https://youtu.be/TwLSxxRQQsA)

mySupport

With "mySupport" you can get the most out of your Industry Online Support.

Registration You must register once to use the full functionality of "mySupport". After registra

tion, you can create filters, favorites and tabs in your personal workspace.

Support requests Your data is already filled out in support requests, and you can get an overview of

your current requests at any time.

Documentation In the Documentation area you can build your personal library.

Favorites You can use the "Add to mySupport favorites" to flag especially interesting or fre

quently needed content. Under "Favorites", you will find a list of your flagged

entries.

Recently viewed

articles

The most recently viewed pages in mySupport are available under "Recently viewed

articles".

CAx data The CAx data area gives you access to the latest product data for your CAx or CAe

system. You configure your own download package with a few clicks:

• Product images, 2D dimension drawings, 3D models, internal circuit diagrams,

EPLAN macro files

• Manuals, characteristics, operating manuals, certificates

• Product master data

You can find "mySupport" on the Internet. (https://support.industry.siemens.com/My/ww/en)

Application examples

The application examples support you with various tools and examples for solving your

automation tasks. Solutions are shown in interplay with multiple components in the system -

separated from the focus on individual products.

8CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

Introduction

1.1 Guide documentation S7-1500/ET 200MP

You can find the application examples on the Internet.

(https://support.industry.siemens.com/cs/ww/en/ps/ae)

Introduction

1.1 Guide documentation S7-1500/ET 200MP

CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

CPU 1517T-3 PN/DP (6ES7517-3TP00-0AB0)

Equipment Manual, 11/2022, A5E36285525-AD

Safety instructions 2

2.1 Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, systems, machines and networks.

In order to protect plants, systems, machines and networks against cyber threats, it is

necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial

security concept. Siemens’ products and solutions constitute one element of such a concept.

Customers are responsible for preventing unauthorized access to their plants, systems,

machines and networks. Such systems, machines and components should only be connected

to an enterprise network or the internet if and to the extent such a connection is necessary

and only when appropriate security measures (e.g. firewalls and/or network segmentation)

are in place.

For additional information on industrial security measures that may be implemented, please

visit (https://www.siemens.com/industrialsecurity).

Siemens' products and solutions undergo continuous development to make them more

secure. Siemens strongly recommends that product updates are applied as soon as they are

available and that the latest product versions are used. Use of product versions that are no

longer supported, and failure to apply the latest updates may increase customers' exposure to

cyber threats.

To stay informed about product updates, subscribe to the Siemens Industrial Security RSS

Feed visit (https://www.siemens.com/cert).

Otros manuales para Simatic S7-1500

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Electricidad industrial de Siemens

Siemens

Siemens MICROMASTER 440 Instrucciones de funcionamiento y mantenimiento

Siemens

Siemens 3VA9137-0EK1 Manual de usuario

Siemens

Siemens 3WN1 Manual de usuario

Siemens

Siemens SIVACON 8PS Manual de usuario

Siemens

Siemens SIMATIC ET 200SP Manual de usuario

Siemens

Siemens E87010-A0104-T003-A6-CLM0 Instrucciones de montaje

Siemens

Siemens SIMOTION D45 Series Manual de usuario

Siemens

Siemens 3VA921-0JC22 Series Manual de usuario

Siemens

Siemens HM656A Manual de usuario

Siemens

Siemens CLM0C Instrucciones de montaje

Siemens

Siemens SINUMERIK 840D sl Manual de usuario

Siemens

Siemens RCD310 Series Manual de usuario

Siemens

Siemens TSSG3A Manual de usuario

Siemens

Siemens 3VT9200-3MJ00 Manual de usuario

Siemens

Siemens 3VT94 6AD00 Series Manual de usuario

Siemens

Siemens SIMATIC ET 200SP Manual de usuario

Siemens

Siemens MOBIC T8 for Windows CE 3.0 Manual de usuario

Siemens

Siemens 3NJ412 Manual de usuario

Siemens

Siemens 3RV1952-1E Series Manual de usuario

Siemens

Siemens 3VA9078-0VM10 Manual de usuario

Siemens

Siemens 3VA9602-0WA05 Manual de usuario

Siemens

Siemens 3VA9.70-0WC00 Manual de usuario

Siemens

Siemens MICROMASTER 440 Instrucciones de funcionamiento y mantenimiento

Siemens

Siemens 7XR6004 Series Manual

Manuales populares de Electricidad industrial de otras marcas

Rexroth Indramat

Rexroth Indramat DURADRIVE SYSTEM200 Manual técnico

Abtech

Abtech HVJB Series Guía

Murata

Murata GRM0335C1H8R1DA01 Series Manual de usuario

SAF-HOLLAND

SAF-HOLLAND CBX 5415.5 Manual de usuario

Eaton

Eaton Ulusoy HMH24-04 Manual de usuario

Newlong

Newlong NP-7H Manual de usuario

Murata

Murata GJM0335C1E4R4BB01 Series Manual de usuario

Stahl

Stahl 8575/12 Manual de usuario

SI Pegasus Manual de usuario

Murata

Murata GRM1555C1H2R7CA01 Seies Manual de usuario

Murata

Murata GRM0225C1E6R4BA03 Series Manual de usuario

Cooper Power Systems

Cooper Power Systems VXE15 Manual de usuario

S&C

S&C Vista SD Manual de usuario

Murata

Murata GRM0335C2A7R3CA01 Series Manual de usuario

Murata

Murata GRM32ER60G227ME05 Series Manual de usuario

Rockwell Automation

Rockwell Automation Allen-Bradley MP-Series Manual de usuario

Phasemation

Phasemation DG-100 Manual de usuario

Murata

Murata GRM219R61C225KA88 Series Manual de usuario
