Siemens SIMATIC ET 200SP Manual de usuario

Server module

(6ES7193-6PA00-0AA0)

___________________

SIMATIC

ET 200SP

Server module

(6ES7193-6PA00-0AA0)

Manual

03/2015

A5E03575337

-AB

Preface

Documentation guide

Product overview

Parameters/address space

Diagnostics alarms

Technical specifications

Parameter data record

Dimensional drawing

Siemens AG

Division Digital Factory

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E03575337-AB

Ⓟ

03/2015 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by

personnel qualified

for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance a

re required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

Server module (6ES7193-6PA00-0AA0)

4Manual, 03/2015, A5E03575337-AB

Preface

Purpose of the documentation

This manual supplements the ET 200SP distributed I/O system

(http://support.automation.siemens.com/WW/view/en/58649293) system manual.

Functions that generally relate to the system are described in this manual.

The information provided in this manual and in the system/function manuals supports you in

commissioning the ET 200SP distributed I/O system.

Conventions

Please also observe notes labeled as follows:

Note

A note contains important information on the product described in the documentation, on the

handling of the product, or on the section of the documentation to which particular attention

should be paid.

Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, solutions, machines, equipment and/or networks. They are

important components in a holistic industrial security concept. With this in mind, Siemens’

products and solutions undergo continuous development. Siemens recommends strongly

that you regularly check for product updates.

For the secure operation of Siemens products and solutions, it is necessary to take suitable

preventive action (e.g. cell protection concept) and integrate each component into a holistic,

state-of-the-art industrial security concept. Third-party products that may be in use should

also be considered. You can find more information about industrial security on the Internet

(http://www.siemens.com/industrialsecurity).

To stay informed about product updates as they occur, sign up for a product-specific

newsletter. You can find more information on the Internet

(http://support.automation.siemens.com).

Server module (6ES7193-6PA00-0AA0)

Manual, 03/2015, A5E03575337-AB 5

Table of contents

Preface ................................................................................................................................................... 4

1 Documentation guide .............................................................................................................................. 6

2 Product overview .................................................................................................................................... 8

2.1 Properties..................................................................................................................................8

3 Parameters/address space ..................................................................................................................... 9

3.1 Parameters ...............................................................................................................................9

3.2 Explanation of the parameters................................................................................................10

3.3 Address space ........................................................................................................................10

3.3.1 Input data for interface modules with maximum 12 I/O modules ...........................................12

3.3.2 Input data for interface modules with maximum 32 I/O modules ...........................................13

3.3.3 Input data for CPU/interface modules with maximum 64 I/O modules...................................14

3.3.4 Evaluating feedback voltage...................................................................................................15

4 Diagnostics alarms................................................................................................................................ 17

5 Technical specifications ........................................................................................................................ 18

5.1 Technical specifications ..........................................................................................................18

6 Parameter data record .......................................................................................................................... 19

6.1 Parameter assignment and structure of parameter data record.............................................19

A Dimensional drawing............................................................................................................................. 21

A.1 Server module.........................................................................................................................21

Server module (6ES7193-6PA00-0AA0)

6Manual, 03/2015, A5E03575337-AB

Documentation guide

The documentation for the SIMATIC ET 200SP distributed I/O system is arranged into three

areas.

This arrangement enables you to access the specific content you require.

Basic information

The system manual describes in detail the configuration, installation, wiring and

commissioning of the SIMATIC ET 200SP. distributed I/O system. The STEP 7 online help

supports you in the configuration and programming.

Device information

Product manuals contain a compact description of the module-specific information, such as

properties, terminal diagrams, characteristics and technical specifications.

General information

The function manuals contain detailed descriptions on general topics regarding the SIMATIC

ET 200SP distributed I/O system, e.g. diagnostics, communication, Web server, designing

interference-free controllers.

You can download the documentation free of charge from the Internet

(http://w3.siemens.com/mcms/industrial-automation-systems-simatic/en/manual-

overview/tech-doc-et200/Pages/Default.aspx).

Changes and supplements to the manuals are documented in a Product Information.

Documentation guide

Server module (6ES7193-6PA00-0AA0)

Manual, 03/2015, A5E03575337-AB 7

Manual Collection ET 200SP

The Manual Collection contains the complete documentation on the SIMATIC ET 200SP

distributed I/O system gathered together in one file.

You can find the Manual Collection on the Internet

(http://support.automation.siemens.com/WW/view/en/84133942).

My Documentation Manager

The My Documentation Manager is used to combine entire manuals or only parts of these to

your own manual.

You can export the manual as PDF file or in a format that can be edited later.

You can find the My Documentation Manager on the Internet

(http://support.industry.siemens.com/My/ww/en/documentation).

Application examples

Applications examples support you with various tools and examples for solving your

automation tasks. Solutions are shown in interplay with multiple components in the system -

separated from the focus in individual products.

You can find application examples on the Internet

(https://support.industry.siemens.com/sc/ww/en/sc/2054).

CAx Download Manager

The CAx Download Manager is used to access the current product data for your CAx or CAe

systems.

You configure your own download package with a few clicks.

In doing so you can select:

●Product images, 2D dimension drawings, 3D models, internal circuit diagrams, EPLAN

macro files

●Manuals, characteristics, operating manuals, certificates

●Product master data

You can find the CAx Download Manager on the Internet

(http://support.industry.siemens.com/my/ww/en/CAxOnline).

TIA Selection Tool

With the TIA Selection Tool, you can select, configure and order devices for Totally

Integrated Automation (TIA).

This tool is the successor of the SIMATIC Selection Tool and combines the known

configurators for automation technology into one tool.

With the TIA Selection Tool, you can generate a complete order list from your product

selection or product configuration.

You can find the TIA Selection Tool on the Internet

(http://w3.siemens.com/mcms/topics/en/simatic/tia-selection-tool).

Server module (6ES7193-6PA00-0AA0)

8Manual, 03/2015, A5E03575337-AB

Product overview

2.1

Properties

Article number

6ES7193-6PA00-0AA0

View of the module

Figure 2-1 View of the server module

Properties

The module has the following technical properties:

●Closes off the backplane bus of the ET 200SP

●Contains a support for 3 spare fuses (5 × 20 mm)

The module supports the following functions:

●Firmware update

●I&M identification data

●Reconfiguration in RUN

●Representation of the statuses of supply voltage L+ and the feedback voltage (Page 15)

per slot.

●Retentive storage of device name for device replacement without topological

configuration of the IM 155-6 PN BA.

You can configure the module with STEP 7 (TIA Portal) and with a GSD file.

Function and properties

Product version of the module

as of

Firmware version of the module

as of

Support of the IM 155-6 PN BA

V1.1.1

Server module (6ES7193-6PA00-0AA0)

Manual, 03/2015, A5E03575337-AB 9

Parameters/address space

3.1

Parameters

Parameters for the server module

The effective range of the configurable parameter depends on the type of configuration.

Possible configuration: Distributed operation on PROFINET IO in an ET 200SP system.

When assigning parameters in the user program, use the "WRREC" instruction to transfer

the parameter to the module by means of data records, see section Parameter assignment

and structure of parameter data record (Page 19).

The following parameter settings are possible:

Table 3- 1 Configurable parameter and its default (GSD file)

Parameters

Range of values

Default

Reconfiguration in

RUN

Effective range with configuration

software, e.g., STEP 7 (TIA Portal)

GSD file

PROFINET IO

GSD file

PROFIBUS DP

Group diagnostics: No

supply voltage L+

•Disable

•Enable

No Yes ET 200SP ---

Parameters/address space

3.2 Explanation of the parameters

Server module (6ES7193-6PA00-0AA0)

10 Manual, 03/2015, A5E03575337-AB

3.2

Explanation of the parameters

Group diagnostics: No supply voltage L+

When you enable this parameter, the ET 200SP generates one diagnostic per potential

group (as group information) when the supply voltage L+ fails.

This function does not depend on enabling the parameter "Diagnostics: No supply voltage

L+" of the I/O modules.

The diagnostics is formed from the states of the supply voltage of the installed I/O modules

within the potential group.

Requirements

●All I/O modules must be inserted, i.e. the current configuration must not have any empty

slots.

●If no I/O modules are inserted on light-colored BaseUnits BU..D, the beginning of this

potential group is not recognized. The I/O modules of this potential group are therefore

part of the previous potential group.

If the I/O module is installed on the light-colored BaseUnit, the potential group is

detected, the diagnostics is reevaluated according to the potential group arrangement

and new diagnostics may be reported. The position of the light-colored BaseUnit remains

stored in the structure until the supply voltage 1L+ of the CPU/interface module is turned

off.

3.3

Address space

Introduction

You can read out the status of the supply voltage L+ and the feedback voltage of I/O

modules via the address space of the server module:

●All I/O modules:

No supply voltage L+ or no I/O module available

●Additional digital output module HF:

feedback voltage present

Requirements

●The I/O module used must support monitoring of the supply voltage.

●The I/O module used must support monitoring of a feedback voltage.

Otros manuales para SIMATIC ET 200SP

101

Tabla de contenidos

Otros manuales de Controladores de Siemens

Siemens

Siemens SIDOOR ATE500E Manual de usuario

Siemens

Siemens Powermite 599 Series Manual del propietario

Siemens

Siemens LOGO! PROM Manual de usuario

Siemens

Siemens VWPG51 Q Series Manual de usuario

Siemens

Siemens Simatic S7-1500 Manual de usuario

Siemens

Siemens RWD68 Manual de usuario

Siemens

Siemens 125-5033 Manual de usuario

Siemens

Siemens ACVATIX SAX319.03 Manual de usuario

Siemens

Siemens SQM50.484R8A Manual del propietario

Siemens

Siemens SIMATIC TP700 Comfort Outdoor Guía del administrador

Siemens

Siemens LOGO! 24RC Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual del propietario

Siemens

Siemens Simatic S7-1500 Manual de usuario

Siemens

Siemens MT Series Manual del propietario

Siemens

Siemens Simatic S7-300 Manual de usuario

Siemens

Siemens Climatix POL822 Manual de usuario

Siemens

Siemens LOGO! 8 Manual de usuario

Siemens

Siemens Simatic S7-1500 Manual de usuario

Siemens

Siemens SIMATIC S7 Instrucciones de uso

Siemens

Siemens Simatic S7-300 Manual de usuario

Siemens

Siemens SIMATIC S5-100U Guía del usuario

Siemens

Siemens OpenAir GCA Series Manual del propietario

Siemens

Siemens Simatic S7-300 Manual de usuario

Siemens

Siemens SIMATIC S7-1200 CP 1243-8 IRC Guía del usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario

3M MicroTouch EX113 Manual de usuario
