Siemens XCI2001-U1 Guía

XCI2001-U1

Releasing module

Mounting

Installation

A6V10315050_e_en_--

Building Technologies

2016-10-27 Siemens Industry, Inc.

Legal notice

2 | 14

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

Legal notice

Technical specifications and availability subject to change without notice.

Transmittal, reproduction, dissemination and/or editing of this document as well as

utilization of its contents and communication thereof to others without express

authorization are prohibited. Offenders will be held liable for payment of damages. All

rights created by patent grant or registration of a utility model or design patent are

reserved.

Issued by:

Siemens Industry, Inc.

Building Technologies Division

8 Fernwood Road

Florham Park, NJ 07932

Tel. +1 973-593-2600

www.sbt.siemens.com/FIS

Edition: 2016-10-27

Document ID: A6V10315050_e_en_--

3 |

Building

Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

Table of contents

1Description............................................................................................... 5

2Mounting.................................................................................................. 6

3Views....................................................................................................... 7

4Pin assignments for releasing module.......................................................... 8

4.1 X5 plug connection for releasing relay output.................................................... 8

5Indicators ................................................................................................10

6Adjusting elements for releasing module .....................................................11

7Technical data..........................................................................................12

8FCC Statement........................................................................................13

Building Technologies

A6V10315050_e_e

Siemens Industry, Inc.

2016

4 | 14

Description

5 |

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

1Description

The releasing module XCI2001 supports activation of releasing valves in releasing and

sprinkler systems. Activation can be event-controlled or performed manually. The

releasing module is mounted on the periphery board.

Properties

●Automatic or manual activation

●Dual-channel control

●Supervision of releasing circuit (wiring as class A or class B circuit)

●Supports several valve systems

●Suited to indoor applications (not wet rooms)

Mounting

6 | 14

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

2Mounting

The releasing module XCI2001 is installed on the periphery board as shown and

screwed onto the back box. Slot X901 is also used for the NAC module (1A/2B).

Figure 1: Installing the releasing module on the periphery board

1Periphery board (250p) or periphery board (500p)

2 Threaded standoffs on back box

3 Releasing module XCI2001

4 2x fixing screw

X901 Slot in periphery board

X5 Connection terminal on releasing module

1. Plug the releasing module (3) into slot X901 on the periphery board.

2. Fasten the releasing module to the threaded standoffs (2) in the back box using the

two fixing screws (4).

3. Wire up the releasing module according to the pin assignment.

Views

7 |

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

3Views

Figure 2: Printed circuit board view for XCI2001

Element Des. Function

Connector X1 Plug for periphery board connection

X2 Service plug for programmed connection (not used)

X4 Diagnostic service plug (not used)

X5 Releasing relay outputs

Adjustment elements S1* Switch: Arm/Disarm releasing output 1

S2* Switch: Arm/Disarm releasing output 2

S3 Reset key

X3 Jumper for degraded mode enable

LEDs H1 Display: Releasing output 1 status ON/OFF

H2 Display: Releasing output 2 status ON/OFF

H3 Flashing: Releasing module is active

* For Class A wiring, both S1 and S2 must be in the same position at all times when

used to disarm or arm the circuit.

Pin assignments for releasing module

X5 plug connection for releasing relay output

8 | 14

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

4Pin assignments for releasing module

4.1 X5 plug connection for releasing relay output

Pin Designation Description

4REL_CIR1 (+) Relay output for releasing 1

3REL_CIR1 (-) Relay output for releasing 1

2REL_CIR2 (+) Relay output for releasing 2

1REL_CIR2 (-) Relay output for releasing 2

Admissible cable cross-section: 12…18 AWG, unshielded

XCI2001-U1 supports two Class B circuits or one Class A circuit as shown below:

Class B wiring

Figure 3: Class B wiring

REL_CIR1

REL_CIR2

SOLENOID

REL-EOL

Pin assignments for releasing module

X5 plug connection for releasing

relay output

9 |

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

Class A wiring

Figure 4: Class A wiring

Note 1 Loop wires must be terminated directly onto the SOLENOID

Note 2 Loop wires must be terminated directly onto the SOLENOID

*REL-EOL: Terminating resistor 24 kΩand diode (Siemens part number 500-696359)

The maximum length of line of the relay connections is limited to a resistance of 3.5 Ω.

REL_CIR1

REL_CIR2

REL-EOL

SOLENOID

Note 1

Note 2

Indicators

10 | 14

Building Technologies

A6V10315050_e_en_

Siemens Industry, Inc.

2016

5Indicators

LED indicators

LED Color Function Condition Meaning

H1 Green Status of releasing circuit 1 Off Releasing circuit 1 inactive

On Releasing circuit 1 activated

H2* Green Status of releasing circuit 2 Off Releasing circuit 2 inactive

On Releasing circuit 2 activated

H3 Green Status of processor Off (steady) Processor is not running

Flashing Processor is running

On (steady) Processor is not running

* Not applicable for Class A wiring.
