Siemens SIMATIC S5 CPU Direct Driver Manual de usuario

Siemens AG

SIMATIC S5 CPU

Direct Driver

1 System Configuration....................................................................................................... 3

2 Selection of External Device ............................................................................................ 7

3 Example of Communication Setting ................................................................................. 8

4 Setup Items ...................................................................................................................... 9

5 Cable Diagram ............................................................................................................... 14

6 Supported Device........................................................................................................... 16

7 Device Code and Address Code.................................................................................... 17

8 Error Messages.............................................................................................................. 18

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 2

PREFACE

This manual describes how to connect the Display and the External Device (target PLC).

In this manual, the connection procedure will be described by following the below sections:

1System Configuration

This section shows the types of External

Devices which can be connected and SIO

type.

)"1 System Configuration" (page 3)

2Selection of External Device

Select a model (series) of the External

Device to be connected and connection

method.

)"2 Selection of External Device" (page 7)

3Example of Communication Settings

This section shows setting examples for

communicating between the Display and

the External Device.

)"3 Example of Communication Setting" (page

4Setup Items

This section describes communication

setup items on the Display.

Set communication settings of the Display

with GP-Pro EX or in offline mode.

)"4 Setup Items" (page 9)

Operation

5Cable Diagram

This section shows cables and adapters

for connecting the Display and the

External Device.

)"5 Cable Diagram" (page 14)

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 3

1 System Configuration

The system configuration in the case when the External Device of Siemens AG and the Display are connected is

shown.

Connection Configuration

[1:1 Connection]

Series Name CPU Link I/F SIO Type Setting

Example

Cable

Diagram

Series

90U-115U

CPU 90U

CPU 95U

CPU 100

CPU 102

CPU 103

CPU 941

CPU 942

CPU 943

CPU 944

CPU 945

PG port on CPU RS232C

Setting

Example 1

(page 8)

Cable

Diagram 1

(page 14)

Series

135U/155U

CPU 922

CPU 928

CPU 928B

CPU 946

CPU 947

CPU 948

PG port on CPU RS232C

• Set the execution time of the logic functions in the Display to “100 ms” or less. If the longer time is

set, an error may occur in the communication with the external device.

Display External Device

CA6-CBLTTY/5M-01

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 4

IPC COM Port

When connecting IPC with an External Device, the COM port used depends on the series and SIO type. Please

refer to the IPC manual for details.

Usable port

Series

Usable Port

RS-232C RS-422/485(4 wire) RS-422/485(2 wire)

PS-2000B COM1*1 , COM2,

COM3*1, COM4

*1 The RI/5V can be switched. Use the IPC’s switch to change if necessary.

PS-3450A, PS-3451A,

PS3000-BA, PS3001-BD COM1, COM2*1*2 COM2*1*2 COM2*1*2

PS-3650A (T41 model),

PS-3651A (T41 model) COM1*1 --

PS-3650A (T42 model),

PS-3651A (T42 model) COM1*1*2, COM2 COM1*1*2 COM1*1*2

PS-3700A (Pentium®4-M)

PS-3710A

COM1*1, COM2*1,

COM3*2 , COM4

*2 Set up the SIO type with the DIP Switch. Please set up as follows according to SIO type to be used.

COM3*2 COM3*2

PS-3711A COM1*1, COM2*2 COM2*2 COM2*2

PS4000*3

*3 When making communication between an External Device and COM port on the Expansion slot,

only RS-232C is supported. However, ER (DTR/CTS) control cannot be executed because of the

specification of COM port.

For connection with External Device, use user-created cables and disable Pin Nos. 1, 4, 6 and 9.

Please refer to the IPC manual for details of pin layout.

COM1, COM2 - -

PL3000 COM1*1*2, COM2*1,

COM3, COM4 COM1*1*2 COM1*1*2

PE-4000B Atom N270 COM1, COM2 - -

PE-4000B Atom N2600 COM1, COM2 COM3*4 , COM4*4,

COM5*4, COM6*4

*4 Set up the SIO type with the BIOS. Please refer to the IPC manual for details of BIOS.

COM3*4, COM4*4,

COM5*4, COM6*4

PS5000 (Slim Panel Type

Core i3 Model) *5 *6 COM1, COM2*4 COM2*4 COM2*4

PS5000 (Slim Panel Type

Atom Model)

*5 *6

COM1, COM2*7 COM2*7 COM2*7

PS5000 (Enclosed Panel

Type)*8 COM1 - -

PS5000 (Modular Type

PFXPU/PFXPP)*5 *6

PS5000 (Modular Type

PFXPL2B5-6)

COM1*7 COM1*7 COM1*7

PS5000 (Modular Type

PFXPL2B1-4) COM1, COM2*7 COM2*7 COM2*7

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 5

DIP Switch settings (PL3000 / PS3000 Series)

RS-232C

*5 When setting up communication between an External Device and the RS-232C/422/485 interface

module, use the IPC (RS-232C) or PS5000 (RS-422/485) cable diagrams. However, when using

PFXZPBMPR42P2 in a RS-422/485 (4-wire) configuration with no flow control, connect 7.RTS+

and 8.CTS+, and connect 6.RTS- and 9.CTS-.

When using RS-422/485 communication with External Devices, you may need to reduce the

transmission speed and increase the TX Wait time.

*6 To use RS-422/485 communication on the RS-232C/422/485 interface module, the DIP Switch

setting is required. Please refer to "Knowledge Base" (FAQs) on the support site. (http://www.pro-

face.com/trans/en/manual/1001.html)

*7 Set up the SIO type with the DIP Switch. Please refer to the IPC manual for details of DIP Switch.

The BOX Atom has not a switch to set the RS-232C, RS-422/485 mode. Use the BIOS for the

setting.

*8 For the connection with the External Device, on the user-created cable read as if the connector on

the Display-side is a M12 A-coding 8 pin socket. The pin assignment is the same as described in

the cable diagram. For the M12 A-coding connector, use PFXZPSCNM122.

DIP Switch Setting Description

1OFF

*1 When using PS-3450A, PS-3451A, PS3000-BA and PS3001-BD, turn ON the set value.

Reserved (always OFF)

2OFF

SIO type: RS-232C

3OFF

4 OFF Output mode of SD (TXD) data: Always output

5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None

6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None

7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Not available

8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Not available

9OFF

RS (RTS) Auto control mode: Disabled

10 OFF

Settings FAQ ID

PFXZPBMPR42P2, RS422/485 change method FA263858

PFXZPBMPR42P2 termination resistor setting FA263974

PFXZPBMPR44P2, RS422/485 change method FA264087

PFXZPBMPR44P2 termination resistor setting FA264088

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 6

RS-422/485 (4 wire)

RS-422/485 (2 wire)

DIP Switch Setting Description

1 OFF Reserved (always OFF)

2ON

SIO type: RS-422/485

3ON

4 OFF Output mode of SD (TXD) data: Always output

5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None

6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None

7 OFF Short-circuit of SDA (TXA) and RDA (RXA): Not available

8 OFF Short-circuit of SDB (TXB) and RDB (RXB): Not available

9OFF

RS (RTS) Auto control mode: Disabled

10 OFF

DIP Switch Setting Description

1 OFF Reserved (always OFF)

2ON

SIO type: RS-422/485

3ON

4 OFF Output mode of SD (TXD) data: Always output

5 OFF Terminal resistance (220Ω) insertion to SD (TXD): None

6 OFF Terminal resistance (220Ω) insertion to RD (RXD): None

7 ON Short-circuit of SDA (TXA) and RDA (RXA): Available

8 ON Short-circuit of SDB (TXB) and RDB (RXB): Available

9ON

RS (RTS) Auto control mode: Enabled

10 ON

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 7

2 Selection of External Device

Select the External Device to be connected to the Display.

Setup Items Setup Description

Number of Devices/

PLCs Enter an integer from 1 to 4 to define the number of Devices/PLCs to connect to the display.

Manufacturer Select the manufacturer of the External Device to connect. Select "Siemens AG".

Series

Select the External Device model (series) and the connection method. Select "SIMATIC S5

CPU Direct".

In System configuration, make sure the External Device you are connecting is supported by

"SIMATIC S5 CPU Direct".

)"1 System Configuration" (page 3)

Port Select the Display port to connect to the External Device.

Use System Area

Check this option to synchronize the system data area of the Display and the device (memory)

of the External Device. When synchronized, you can use the External Device’s ladder

program to switch the display or display the window on the Display.

Cf. GP-Pro EX Reference Manual "LS Area (Direct Access Method Area)"

This feature can also be set in GP-Pro EX or in the Display's offline mode.

Cf. GP-Pro EX Reference Manual "System Settings [Display Unit] - [System Area]

Settings Guide"

Cf. Maintenance/Troubleshooting Guide "Main Unit - System Area Settings"

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 8

3 Example of Communication Setting

Examples of communication settings of the Display and the External Device, recommended by Digital

Electronics Corp., are shown.

3.1 Setting Example 1

Settings of GP-Pro EX

Communication Settings

To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].

Device Setting

To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]

window, select the external device and click [Settings] .

Settings of External Device

The communication setting of the External Device is fixed.

You need not set it.

• When you use CPU 945, CPU946, CPU947 or CPU948, check the [Use CPU945] checkbox or

[Use CPU946/947/948] checkbox. The checkbox is switched depending on the series you select.

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 9

4 Setup Items

Set communication settings of the Display with GP-Pro Ex or in offline mode of the Display.

The setting of each parameter must be identical to that of External Device.

)"3 Example of Communication Setting" (page 8)

4.1 Setup Items in GP-Pro EX

Communication Settings

To display the setup screen, from the [Project] menu, point to [System Settings] and select [Device/PLC].

Setup Items Setup Description

SIO Type Displays the SIO type to communicate with the External Device.

Speed Displays the communication speed between the External Device and the Display.

Data Length Displays data length.

Parity Displays how to check parity.

Stop Bit Displays stop bit length.

Flow Control Displays the communication control method to prevent overflow of transmission and

reception data.

Timeout Use an integer from "1 to 127" to enter the time (s) for which the Display waits for the

response from the External Device.

Retry In case of no response from the External Device, use an integer from "0 to 255" to enter

how many times the Display retransmits the command.

Wait To Send Use an integer from "0 to 255" to enter standby time (ms) for the Display from receiving

packets to transmitting next commands.

SIMATIC S5 CPU Direct Driver

GP-Pro EX Device/PLC Connection Manual 10

Device Setting

To display the [Individual Device Settings] dialog box, from [Device-Specific Settings] in the [Device/PLC]

window, select the external device and click [Settings] .

RI/VCC

You can switch RI/VCC of the 9th pin if you select RS232C for SIO type.

It is necessary to change RI/5V by changeover switch of IPC when connect with IPC.

Please refer to the manual of the IPC for more detail.

• Refer to the GP-Pro EX Reference Manual for Indirect Device.

Cf. GP-Pro EX Reference Manual "Changing the Device/PLC at Runtime (Indirect

Device)"

Setup Items Setup Description

Series Select a model of the External Device.

Use CPU945 Select the checkbox when you use CPU 945. This checkbox is available when [S5 90U-

115U] is selected in [Series].

Use CPU946/947/948 Select the checkbox when you use CPU 946, CPU 947 or CPU 948. This checkbox is

available when [S5 135U/155U] is selected in [Series].

Setup Items Setup Description

Otros manuales para SIMATIC S5 CPU Direct Driver

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de control de Siemens

Siemens

Siemens SIMATIC Manual de usuario

Siemens

Siemens SINUMERIK ONE MCP 2200 Documento técnico

Siemens

Siemens QAX850 Manual de usuario

Siemens

Siemens Sicharge CC AC22-ERK Manual de usuario

Siemens

Siemens SIMATIC NET MOBIC T8 Manual de usuario

Siemens

Siemens SIMATIC C7-635 Manual de usuario

Siemens

Siemens SIMATIC PCS 7 Manual de lista de piezas

Siemens

Siemens SICAM MIC Guía del usuario

Siemens

Siemens LOK16 Series Manual de usuario

Siemens

Siemens REV32 Manual de usuario

Siemens

Siemens QAX850 Manual de usuario

Siemens

Siemens SINUMERIK 828D Turning Guía de instalación

Siemens

Siemens BC80 Series Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual de lista de piezas

Siemens

Siemens SINUMERIK 808D Manual de usuario

Siemens

Siemens SIMOTION Manual de lista de piezas

Siemens

Siemens SIMATIC PCS 7 OSx Manual de usuario

Siemens

Siemens SIMATIC PCS 7 Manual de usuario

Siemens

Siemens SINUMERIK 828D Turning Manual de usuario

Siemens

Siemens SIMOCODE 3UF Manual de usuario

Siemens

Siemens SINUMERIK 802D Suplemento

Siemens

Siemens SIMATIC ET 200PA SMART Manual de usuario

Siemens

Siemens SIMATIC HMI ITC1500 V3 PRO Manual de usuario

Siemens

Siemens SIMATIC PCS 7 Manual de lista de piezas

Manuales populares de Sistema de control de otras marcas

Pentair Pool Products

Pentair Pool Products Compool Manual de usuario

ComfortNET

ComfortNET CTK04 Manual de usuario

Fireye

Fireye InSight II 95DSS3 Manual de usuario

CAME

CAME G3000 Manual de usuario

Idemia

Idemia MorphoAccess VP MD Manual de usuario

Axis

Axis P1445-LE-3 Manual de usuario

HEIDENHAIN

HEIDENHAIN TNC 150 B Manual de usuario

CNC-Step

CNC-Step High-Z T-Series Manual de usuario

Doosan

Doosan DVF Series Manual de usuario

Honeywell

Honeywell KAP 140 Manual de usuario

Honeywell

Honeywell vk41 series Manual de usuario

AirBench

AirBench FPW Guía de instalación

Cypress

Cypress HHR-3160 Manual de usuario

CAME

CAME GLT40AOS Manual de usuario

Zonex

Zonex GEN II -VVT Guía del usuario

Altronics

Altronics K 9650 Manual de usuario

micro-trak

micro-trak RoadMaster Manual de usuario

micro-trak

micro-trak Calc-An-Acre II Manual de usuario
