Introduction

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

About this document

Purpose of this document

This manual is a guide to the configuration procedures for the integration of Geute-

brück Video systems in MM8000 management stations.

This guide is part of the general DMS8000 documentation set which includes the

Composer Technical Manual, the other DMS8000 Connectivity Guides (Net-

work/Fire/Intrusion, Access Control, and OPC), and the Installation, Configuration,

and Commissioning manual (ICC) for each specific product.

Scope

This document applies to the MM8000 Management Station MP4.15 and higher.

Target audience

This documentation is intended for the following users:

- Project Managers

- Project Engineers

- Commissioning Personnel

Individuals performing the operations described in this manual are expected to

have prior expertise and training in the field of security, at least a moderate level of

familiarity with the Siemens Building Technologies product line, and experience

with the installation, configuration, and commissioning of security management

systems.

Documentation resource information

The DMS8000 Documentation Resource Information Guide document assem-

bles in one place important information regarding documentation resources. It con-

tains the following:

– Comprehensive definitions of the target audiences for FS DMS documents

– Training program information including the Siemens intranet link

– A complete list of all available DMS8000 documents

– Instructions for how to obtain a document via the Siemens intranet using the

STEP Documentation Repository System

– A map of relevant documents for each target audience group

– Customer Support links & resources

– A glossary containing definitions of all terms and acronyms used in

DMS8000 documentation

To access the DMS8000 Documentation Resource Information Guide (STEP

#A6V10089056), go to the link and follow the instructions below:

https://workspace.sbt.siemens.com/content/00001123/default.aspx

1. Click on the STEP WEB Client image:

2. Choose 04 Fire -3F from the Product Segment box and select Activate filter.

3. Select All in the Documents section of the Quick Search page and then

select Advanced Search.

4. Enter the document number in the Brochure No. field (e.g. A6V10089056) and

press Enter.

Introduction

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

Operational and safety regulations

iBefore beginning work on the DMS8000 systems, you must have read and under-

stood the related documents, in particular the Safety Regulations included in the In-

stallation, Configuration, and Commissioning manual (ICC) for each specific product.

Liability disclaimer for damage or injuries

Before products are delivered, they are tested to ensure they function correctly

when used properly. Siemens disclaims all liability for damage or injuries caused

by the incorrect application of the instructions, or the disregard of danger adviso-

ries. This disclaimer applies in particular to personal injuries or damage caused by:

– Improper and/or incorrect use.

– Disregard of safety instructions in the documentation or on the product.

– Poor maintenance or a lack of maintenance.

We have checked the contents of this manual for agreement with the hardware and

software described. Since deviations cannot be precluded entirely, we cannot

guarantee full agreement. However, the data in this manual are reviewed regularly

and any necessary corrections included in subsequent editions. Suggestions for

improvement are welcome.

Modification index

Version Date Notes

A6V10067792_a_en 06.2009 Corresponds with DMS8000 MP4.20

A6V10067792_a_en 06.2008 Corresponds with DMS8000 MP4.15

A6V10067792_a_en 06.2007 Corresponds with DMS8000 MP4.10

009424_b_en 06.2006 Corresponds with DMS8000 MP3.20

Introduction

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

1 Introduction

This is a guide to the software configuration procedures for the Geutebrück MultiS-

cope Digital Video Recorder (DVR) in the MM8000 Management Station and

MK8000 OPC server.

For a complete guide to the configuration process, this manual should be used with

the DMS8000 Network, Fire and Intrusion Guide, and with the Installation, Configu-

ration and Commissioning manual (ICC) of the specific product.

Video devices software version

The exact software version to use in the video device to integrate into the

DMS8000 systems is indicated in the latest MM8000 or MK8000 Release Notes.

2 Installation

The Geutebrück package is provided in the MM8000 product CD as add-on. It can

be installed using the standard Add-on Manager.

2.1 Software installation

2.1.1 Requirements

The Geutebrück Multiview application is required for running MM8000 with Geu-

tebrück MultiScope. This application should be installed before MM8000.

Geutebrück settings utilities

The DMS8000 directory:

<installation folder>\Utilities\Reg

(usually C:\Program Files\Utilities\Reg )

contains the following registry-setting scripts:

– Geutebrueck - Set Multiview User connection routing.reg

Enable Multiview application for all Windows users.

– Geutebrueck - Multiview without MM8000.reg

Set Multiview application for stand-alone use (upon starting up, MM8000 reduces

to minimum, i.e. to the sole screen image, the application window).

2.1.2 Software License

MM8000 license must include specific items for the Geutebrück Add-on, for the

driver, and for the required DVR units.

Therefore, the required license includes:

WW8000 Composer (project configuration and download): Composer License

or Service key.

MM8000 core, no. of subsystems.

This license should include the number of DVR units.

Geutebrück add-on license.

Geutebrück driver license.

Other licenses, covering more MM8000 options, may or may not be used and they

are not related to the Geutebrück support.

Configuring CCTV network

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

3 Configuring CCTV network

3.1 Video integration

The DMS8000 systems MM8000 and MK8000 can support the connection to

Geutebrück MultiScope Digital Video Recorder (DVR) in the following way:

Integration of video network, made up of the following devices:

Manufact. Model Device type

Geutebrück MultiScope II Plus Digital Video Recorder (DVR)

Geutebrück MultiScope III Digital Video Recorder (DVR)

This integration allows providing advanced control capabilities as well as the

access to video images in MM8000 event treatment and navigation.

A detailed configuration guide for this video device is provided in this section.

3.2 Video Network Manager

The advanced video functionalities require a basic communication infrastructure

between MM8000/MK8000 and the CCTV units; this is actually a LAN network.

In Composer, a Video Network Manager and the associated drivers should be

added to the MM8000/MK8000 main station in order to support the video network

communication. The drivers concern the SISTORE, the TELSCAN, and the MultiS-

cope units.

The Fig 1 illustrates how to add the VNM to the configuration:

1. In the MM8000 physical configuration, select the main station name:

‘Supervisor System Settings MM8000 System Physical configuration 

<Station name>’.

In the MK8000 project, the selection is quite similar:

‘MK8000 System MK8000 Physical configuration <Station name>’.

2. Click the button A to add the VNM (see Fig 1).

A new node is added. No further configuration is required for the VNM.

Fig 1 Adding the Video Network Manager (A)

Note: Adding the VNM results in the entire Composer project being expanded in

order to support the CCTV functions. Particularly, the new tab ‘Camera Extensor’ is

added to all nodes. Depending on the size of the configuration tree, the operation

may take a few minutes.

The Composer plug-in #251701 is required.

Configuring CCTV network

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

Fig 2 New tab added by the VNM in the MM8000 project

3.2.1 Video Drivers

The VNM can support the drivers required to handle the network communication

with:

Geutebrück MultiScope (OPC driver)

Depending on the specific configuration required, add one or both drivers to your

project. Proceed as follows:

1. Select .the VNM node.

2. In the toolbar, click the icon corresponding to the driver you need (Fig 3):

C – Geutebrück MultiScope (OPC driver)

Fig 3 Video drivers

A Select this icon to add the SISTORE driver

B Select this icon to add the TELSCAN driver

C Select this icon to add the OPC client driver (Geutebrück MultiScope)

3.3 CCTV components

If the VNM is present, the Video menu of the Composer button bar on the left hand

side includes an additional icon, corresponding to the following CCTV component:

Geutebrück MultiScope Digital Video Recorder (DVR)

The following Fig 4 illustrates the menu options and the corresponding CCTV com-

ponents.

Configuring CCTV network

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

Fig 4 CCTV components menu

A Select this icon to add a Camera folder

B Select this icon to add a Monitor folder

C Select this icon to add a TELSCAN Video Web Server

D Select this icon to add a SISTORE AX Digital Video Recorder (DVR)

E Select this icon to add a SISTORE MX and MX Pro Digital Video Recorder (DVR)

F Select this icon to add a SISTORE CX and SX Digital Video Recorder (DVR)

G Select this icon to add a SIMATRIX switching crossbar

H Select this icon to add a Geutebrück MultiScope (MSC) Digital Video Recorder

Configuring CCTV network

Building Technologies 048_DMS_MM8000_GEUTEBRUECK_Add-On_MP4.20_A6V10067796_a_en

Fire Safety & Security Products 06.2009

3.4 Geutebrück MultiScope (MSC) DVR configuration

The Geutebrück MultiScope (MSC) is a family of Digital Video Recorders capable

of acquiring the video signals from 4, 8, 16 or 32 cameras, showing the images on

a local monitor, and storing them in digital form on local hard disks.

– Options are also available for video outputs and input/output management

– The host connection is based on a TCP/IP connection on a LAN network

Two basic MultiScope models and a total of 12 variants can be configured in the

MM8000 Video Network. Namely:

– MultiScope II Plus, handling 4, 8, 2x4 dual-speed, 16, 4x4 quad-speed, and 32

video inputs.

– MultiScope III, supporting 4, 8, 2x4 dual-speed, 16, 4x4 quad-speed, and 32

video inputs.

MSC models and variants only differ on the number of cameras, and their configu-

ration in Composer is exactly the same (as illustrated in this section).

In the Geutebrück MultiScope DVRs, MM8000 only supports the video and monitoring

functions related to camera inputs.

In case of network-distributed solutions, be aware that DCOM security must be con-

figured in order to enable the correct communication over the network.

In general, the MM8000 internal user (see MM8000 Installation, Configuration, and

Commissioning manual) must be recognised by the server (i.e. defined locally on the

server computer or at domain level) and granted the DCOM permissions for the Video

server process (DCOMCNFG settings).

Also, the computer running MM8000 should be configured in order to grant access the

user of the video server.

3.4.1 Configuration checklist

Verify that you have satisfied the items needed in the first checklist before proceed-

ing to the configuration procedure that follows.

ITEMS NEEDED FOR CONFIGURATION

The MultiScope model and variant, i.e. the number of video inputs

The MultiScope parameter settings, including:

– Local address (0 to 99)

– IP address

The camera connections

Video application required for integrating Geutebrück MultiScope:

– Geutebrück Multiview

Plug-ins needed:

– Plug-ins #252101 (ST DV SIVMS / ST VD OPC) and 353801 (OPCDVRST / OPC

DVR ST), which must be installed before you can configure your system

Otros manuales para DMS8000 MP4 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de control de Siemens

Siemens

Siemens SIMATIC BATCH Manual de usuario

Siemens

Siemens SIMATIC PCS 7 FOUNDATION Fieldbus Guía de inicio rápido

Siemens

Siemens SINUMERIK 828D Turning Guía de inicio rápido

Siemens

Siemens SIMATIC PCS 7 Guía del usuario

Siemens

Siemens SIMATIC 6ES7673-2CC40-0YA0 Manual de usuario

Siemens

Siemens SINUMERIK 828D Turning Manual de lista de piezas

Siemens

Siemens Climatix HMI-LED POL831.25/STD Manual del operador

Siemens

Siemens SIMATIC ET 200PA SMART Manual de usuario

Siemens

Siemens SINUMERIK 828D Turning Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Guía de inicio rápido

Siemens

Siemens SIRIUS 3TK2820 Manual de usuario

Siemens

Siemens SIMATIC PCS 7 Manual de lista de piezas

Siemens

Siemens SINUMERIK 828D Turning Manual de usuario

Siemens

Siemens SIMATIC HMI ITC1500 V3 PRO Manual de usuario

Siemens

Siemens SIMATIC NET TeleControl SINAUT ST7 Guía del usuario

Siemens

Siemens SIMATIC PC BI45 Manual de lista de piezas

Siemens

Siemens SINUMERIK 802D Suplemento

Siemens

Siemens SICAM RTU Manual de usuario

Siemens

Siemens Sicharge CC AC22-ERK Manual de usuario

Siemens

Siemens RRV852 Manual de usuario

Siemens

Siemens SIMATIC PCS 7 Guía de instalación

Siemens

Siemens Desigo TRA Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual del propietario

Manuales populares de Sistema de control de otras marcas

Pentair Pool Products

Pentair Pool Products Compool Manual de usuario

ComfortNET

ComfortNET CTK04 Manual de usuario

Fireye

Fireye InSight II 95DSS3 Manual de usuario

CAME

CAME G3000 Manual de usuario

Idemia

Idemia MorphoAccess VP MD Manual de usuario

Axis

Axis P1445-LE-3 Manual de usuario

HEIDENHAIN

HEIDENHAIN TNC 150 B Manual de usuario

CNC-Step

CNC-Step High-Z T-Series Manual de usuario

Doosan

Doosan DVF Series Manual de usuario

Honeywell

Honeywell KAP 140 Manual de usuario

Honeywell

Honeywell vk41 series Manual de usuario

AirBench

AirBench FPW Guía de instalación

Cypress

Cypress HHR-3160 Manual de usuario

CAME

CAME GLT40AOS Manual de usuario

Zonex

Zonex GEN II -VVT Guía del usuario

Altronics

Altronics K 9650 Manual de usuario

micro-trak

micro-trak RoadMaster Manual de usuario

micro-trak

micro-trak Calc-An-Acre II Manual de usuario
