Shure BLX4R Manual de usuario

Quick Start Guide

1. a. Connect receiver to power source.

ANTENNA B POWER MIC OUT INSTRUMENT OUT VOLUME ANTENNA A

௟ ௠

b. Connect receiver to mixer or amplifier. Press the power button to turn on the receiver.

ANTENNA B POWER MIC OUT INSTRUMENTOUT VOLUME ANTENNA A

௟ ௠ BLX4R

group channel

(A-Y) (9-0)

2. Press group button on receiver to perform a group scan.

group

(A-Y)

3. Install batteries and turn on transmitter.

group

(A-Y)

channel

(9-0)

a.

b. On the transmitter, set the group and channel to match the receiver. The RF bars and battery LED on the receiver should illuminate.

1/2©2017 Shure Incorporated

BLX4R

BLX4R Quickstart

channel

group

group channel

channel

group

group

group channel

If setting up additional systems, leave the first transmitter and receiver on. For each additional receiver, manually set the group to match the first receiver.

Note: The receiver will automatically perform a channel scan to find an available frequency after the group has been selected. Set the transmitter fre-

quency to match the receiver.

4. If sound is too faint or distorted, adjust the gain accordingly.

5 s

channel group

-10 dB

-10 dB

channel group

group

(A-Y)

channel

(0-9)

Shure IncorporatedBLX4R BLX4R Quickstart

2/2

Shure Incorporated 5800 West Touhy Avenue Niles, IL 60714-4608 USA Phone: +1-847-600-2000 Email: [email protected]
