Shure MV88+ Manual de usuario

MV88plus Streaming Kit

MV88+ Video Kit

The Shure digital stereo streaming microphone, MV88 Plus Streaming Kit, user guide.

Version: 1.0 (2020-K)

Shure Incorporated
2/33
Table of Contents
MV88plus Streaming Kit   MV88+ Video Kit 4
General Description 4
Features 4
Quick Setup 4
Mounting the Microphone 5
Recording Audio with the ShurePlus MOTIV app. 6
The MV88+ Microphone 6
Microphone Orientation 6
MV88+ Outputs 7
Aiming the Microphone 7
Audio Recording 8
Audio Interview (Tabletop) 8
Landscape (Horizontal) Video Recording 8
Portrait/Selfie (Vertical) Video Recording 9
Video Interview 9
Handheld Recording 10
The MOTIV App 11
Mic Setup 11
Preset Modes 13
Custom Presets 13
Polar Pattern Selection (Stereo and Mono Settings) 14
Monitor Mix Blend 15
Advanced Mic Settings 15
Limiter 16
Compressor 16
High Pass Filter 16
Left-Right Channel Swap 16
Equalizer 16
Demo Mode 17
Record 17
Bit Depth and Sample Rate 19
Recording Tips 19
Turn On Airplane Mode and Do Not Disturb 19
Use Lock Mode to Lock In Your Sound 19
Record in Mono 19
Record in Stereo 19
Use the Dark Theme 19
Capture the Complete Performance 20
Monitor your Recordings 20
Keep Screen Awake During Recording 20
Keep equipment connected during updates 20
Using MV88+ with your Mac and PC 20
My Recordings 20
Converting Multiple Files 21
Playback 21
Editing Your Audio 22
Navigating The Timeline 23
Creating A Loop 23
Markers 23
Editor 24
Editing in Split Mode 25
Sharing MOTIV Recordings 25
Save to Camera Roll 26
Customize Track Artwork 26
Save to Dropbox 27
AirDrop® with MOTIV 27
Save to iTunes 27
Troubleshooting 28

Shure Incorporated

3/33

Firmware 29

System Requirements 29

System Requirements and Compatibility: iOS 29

System Requirements and Compatibility: Android 29

Specifications 29

Supported Audio Formats 31

Accessories 31

Furnished Accessories 32

Optional Accessories 32

Certifications 32

Information to the user 32

Shure Incorporated

4/33

•

MV88plus Streaming Kit 

MV88+ Video Kit

General Description

The Shure MV88+ is a professional quality condenser microphone that plugs directly into a mobile device using a Lightning or

USB-Cconnector.TwomicrophonecapsulesinaMid-Sideconfigurationprovideanadjustablestereoimage,suitableforcap-

turing a variety of sources, including music and speech. The ShurePlus MOTIV app allows you to customize your sound with

digital signal processing (DSP), preset mode selection, gain adjustment, compression, and stereo width control.

Features

Mid-Side Stereo

Supports the classic mid-side stereo recording technique. Uses coincident cardioid and bidirectional capsules to adjust the

stereo width while providing excellent mono capability.

Plug-and-Play Operation

Compatible with iOS, Android, PC and Mac devices.

Note: See https://wwww.shure.com/MOTIVcompatibility for information on supportive Android devices.

Compact and Durable

Lightweight, all-metal construction and small enough to carry anywhere. Like all Shure products, ensures reliability in the field.

Flexible Recording Control with the ShurePlus MOTIV App

The MOTIVrecordingappcontrolsmicrophonesettings,suchasgain,stereowidth,andpresetmodes,andincludesthefol-

lowing features:

Landscape or portrait record options

Basic audio editing

Markers for keeping track of audio

Dark theme for low-light recording situations

Support for all MOTIV microphones

Five band equalizer

Live streaming capability

Dropbox , AirPlay and Bluetooth support

Factory and custom user presets

Virtual mic options in demo mode

Multiple bit depth and sample rate options

™

™® ®

Shure Incorporated

5/33

Quick Setup

Mounting the Microphone

Note: Use the knob on the back of the phone clamp to keep the cable in place and out of the way of the camera.

Shure Incorporated

6/33

Recording Audio with the ShurePlus MOTIV app.

Use the MOTIV app to change microphone settings and to record and edit your audio.

Adjust your microphone settings.

Select a preset mode that matches your recording situation. Set mic gain and stereo width to optimize audio recordings.

See "Aiming the Microphone" for mic placement information and "The MOTIVApp"forinformationonadjustingcom-

pression, equalization, and more.

Set your device to Airplane Mode and Do Not Disturb.

This allows you to record with no audio interruptions from phone calls or app notifications.

Test your settings.

Make a test recording. Listen to playback and adjust your settings as needed. Once you start recording, only mic gain

can be adjusted.

Press the red Record button to begin recording.

The microphone retains settings from the last time you used the MOTIV app.

The MV88+ Microphone

The MV88+ features two capsules: one capsule has a cardioid pattern and picks up sound directly in front of the microphone.

The other is bidirectional and captures sound from the left and right sides.

Microphone Cartridge

Microphone Orientation

Rotatethemicrophonebarrelinthemiccliptoensurethatyourstereorecordingsareaccurate.Pointthefrontofthemicro-

phone toward the sound source. For landscape (horizontal) recording, position the L and R indicators to the right and left. For

portrait (vertical) recording, simply rotate the microphone barrel in the mic clip.

Note: The app has a Left-Right Channel Swap to flip the audio channels.

Shure Incorporated

7/33

•

MV88+ Outputs

3.5mm monitor output for connecting to headphones and earphones

Send audio to your recording device using the micro-B USB port

MV88+ LEDs

iOS Android/Mac/PC

Green: Mic active, audio flowing Green: Power is on

Amber: Error

Flash Amber: Firmware is updating

Red: Microphone is muted

Flash Red: Audio is clipping

Aiming the Microphone

Thefollowingsuggestionsarefortypicalusecases.Keepinmindthattherearemanyeffectivewaystorecordasource.Ex-

periment to find what works best for you. The MV88+ fits into a standard A25D mic clip. So, you can place it anywhere that you

can put a mic stand.

Tip: For correct stereo orientation, ensure that the Shure name is clearly visible on the top of the microphone. If the name is

not visible, adjust the microphone accordingly.

Shure Incorporated

8/33

Audio Recording

Position your recording device so you can monitor the recording. Aim the front of the microphone toward the source, with left

and right sides of the microphone barrel facing the appropriate directions.

Audio Interview (Tabletop)

Attach the mic clip directly onto the Manfrotto mic stand. Select the MONO BIDIRECTIONAL polar pattern in the MOTIV app.

Point one side of the microphone barrel toward the subject and the other toward the interviewer.

Landscape (Horizontal) Video Recording

Aim the front of the microphone toward the source. Ensure that the left and right sides of the microphone barrel are facing the

appropriate sides.

Shure Incorporated

9/33

•

Portrait/Selfie (Vertical) Video Recording

Aim the microphone toward yourself and select Left - Right Swap.

Tip: If you begin shooting in portrait mode, video will remain in portrait mode even if device orientation is turned to landscape.

Video Interview

To record audio from on-camera audio only, select the CARDIOID polar pattern and point the microphone toward your

subject.

Shure Incorporated

10/33

•To capture the voices of both the on-camera subject and the off-camera interviewer, select the MONO BIDIRECTIONAL

polar pattern in the app. Position the microphone with the left and right sides facing each person.

Handheld Recording

The legs collapse to create a portable hand-held stand.
