Introduction
Safety Rules
Welcome!
You made the right decision by choosing this sophisticated and intelligent
product. Every unit has been thoroughly tested and carefully packed before
shipment. Unpack the shipping carton carefully, saving the carton and all
packing materials for possible later use.
Check carefully for sure your product is not damaged and all accessories not
missing. If your product appears to be damaged or missing, please do not use
it and contact your local distributor immediately.
Please read this manual carefully and thoroughly, as it gives important
information regarding safety, use and maintenance. Keep this manual with the
unit for possible future reference.
To reduce the risk of electrical shock or fire, do not expose this unit to
rain or moisture.
Do not spill water or other liquids into or on to your unit.
Be sure that the local power outlet matches that of the required voltage
for your unit.
Do not attempt to operate this unit if the power cord has been damaged.
Turn off immediately in the event of malfunction.
Should you notice smoke or an unusual smell coming from the equipment,
please discontinue using it and disconnect from the power immediately.
Do not open the unit - there are no user serviceable parts inside.
Do not dismantle or modify the unit, as this voids all warranties.
Do not attempt repairs. Repairs by unqualified people could cause
damage or faulty operation. Contact your local authorized service center.
1
Introduction
Notice Information
Keep dry
This product is not waterproof, and may malfunction if exposed to high levels of
humidity. Rusting of the internal mechanism can cause irreparable damage.
Do not drop
This product may malfunction if subjected to strong shocks or vibration.
Keep away from strong magnetic fields
Do not use or place this device in vicinity of equipment that generates strong
electromagnetic radiation or magnetic fields. Strong static charges or the magnetic
fields produces by equipment such as radio transmitters could interfere with the
display or affect the product's internal circuitry.
Cleaning
Due to fog residue, smoke, and dust cleaning the exterior of the case may become
necessary. Use normal glass cleaner and soft cloth to wipe down the outside casing.
Copyright Notice
No part of the manual included with this product may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form,
by any means, without authorized written permission.
CF cards
Memory card may become hot during use. Observe due caution when removing
memory cards from this device.
Attention! Use recommended 32 M Compact Flash Card only.
2
Model:
LCD:
Inputs/Outputs
Power Requirement:
Housing:
DMX Channels
Specification
Stage Master Pro
240x128 -dot, TFT LCD with contrast adjustment
512 max., Configurable for fixtures
DMX OUT:
3-pin & 5-pin Neutrik chassis connector
MIDI IN/THRU/OUT:
Standard 5-pin DIN connector
RS-232 Port:
DB9 connector
Audio IN:
1/4" unbalanced stereo jack
AC 230V/ AC 120V
ABS plastic case with black matte painting
Audio trigger:
Overall Dimensions:
Weight:
Built-in microphone or line in
688x550x165mm
Approx. 11.8 Kg
3
****** All rights reserved. Improvement and changes to specifications,
design and this manual may be made at any time without prior notice.
Memory Card:
USB connector, 5V/1W gooseneck light
ScanDisk 32 MB Compact Flash Card
DJ Lamp:
Optional Accessory:
Getting acquainted
Principle Features
Professional 512-channel DMX controller, ideal for fixtures
64 fixtures, each with a maximum of 20 channels
16-bit/ 8-bit resolution of Pan/Tilt movement
Free access of 36 shows, 128 scenes, 9 groups and a sequencer
Each show is allocated with 32KB memory, cross-fade time and
stand time are programmable
Internal library is editable, up to 255 fixtures types can be created
Free access of CF card(32MB) for the exchange of data file
Data file can be downloaded or uploaded to a PC (RS 232 port)
Music sync. functions with audio gain adjustment
USB socket for DJ lamp(5V, 1W), lighting adjustable
Joystick for Pan/ Tilt adjustment of projector
Blackout enables to shut all fixtures off
240x128 dots LCD display with contrast adjustment
Neutrik XLR sockets for 512 DMX channels output
MIDI In/ Thru/ Out connectors
AC 120V / AC 230V selectable
Auto/ Music/Manual chase
Jack socket for cable control for stepping
4
The software can be updated with new versions
