Sharper Image 206927 Manual de usuario

Thank you for purchasing the Sharper Image Bionic Compression Knee Massager. Please take

a moment to read this guide and store it for future reference.

FEATURES

• 19 red physiotherapy lights

• Air bag massage

• Infrared heating

• Includes rechargeable lithium batteries and DC5V adapter for charging

IDENTIFICATION OF PARTS

LCD SCREEN PANEL

Power button

• Short press the power button to start the device

• Long press the power button to turn the unit oﬀ

Note: The default is medium temperature and medium pressure. All 19 red lights will be bright

red when powered on

- 1 -

Item No. 206927

User Guide

BIONIC COMPRESSION KNEE MASSAGER

Control Panel

Shell

Air Pressure Display

Charging Lamp

Power Button

Stop Button

Temperature Display

Temperature Button

Air Button

19 Red

Physiotherapy

Lights

Product Schematic

Screen Display

Massage and

Infrared Heating

Temperature button

• 1st level: 45±3ºC

• 2nd level: 50±3ºC

• 3rd level: 55±3ºC

Note: Medium level temperature will start while the unit is activated. Long press the

temperature button to turn oﬀ this feature

Air button

• The medium level of air compression starts by default when the unit is turned on.

There are 3 levels of intensity (Low, Medium, and High)

• Long press the air button to turn oﬀ the pressure function

Stop button

• All 19 red lights will be bright red when powered on. Press the stop button to turn oﬀ

heat and air compression

• Short press the stop button to stop all functions. Short press again to restore the

functions

CHARGING INSTRUCTIONS

• Use the DC5V adapter and plug the charging cable with the unit into the adapter

at the USB end and the 3.5 DC end at the other end into the power socket of the

unit. The battery icon on the display panel will turn bright red, which means that the

battery is charging

• When charging is completed, the battery icon will change from red to green

Note: This unit runs on built-in lithium ion rechargeable batteries

• When using the product, if the battery icon ﬂashes red light, the product should be

stopped and charged immediately

• Charge the product using only the DC5V adapter that comes with the unit

LITHIUM-ION BATTERY WARNING

• The device contains a built-in lithium-ion battery. Batteries must be recycled or

properly treated

• Contact your local waste authority for battery recycling and disposal

CLEANING AND MAINTENANCE

1. Let the unit cool before you start cleaning.

2. Use a wet cloth to remove dust and dirt.

3. Do not use corrosive cleaners, such as benzene or a thinner to clean this product.

- 2 -

4. Do not use a wet cloth to clean the control panel. Only use a dry cloth to wipe the control

panel.

5. After cleaning, place the unit in a well ventilated and dry place.

TROUBLESHOOTING

If you have problems with the unit try the following steps:

SPECIFICATIONS

Adapter voltage: 5V

Working current: 1A

Input voltage: AC 100~240V 50/60Hz

Noise: ≤ 65dB

Rated power: 5W

Automatic timing: 15 minutes

Operation time: 100 minutes

Red light wavelength: 615-650nm

Standby current after shutdown: <20 uA

Product net weight: 790g

Storage environment: 0~140°F Humidity ≤ 90%

Product size: 7.5” L x 6.3” W x 6.5” H

Heating temperature: Low: 45 ± 3ºC, Medium: 50 ± 3ºC, High: 55 ± 3ºC

IMPORTANT SAFETY WARNINGS

• Do not allow any foreign matter to enter the clearance between the massage head and the

casing

• Do not allow this product to come into contact with water as this may result in a short

circuit

• If the main cable or plug is damaged, do not disassemble or attempt to repair it by yourself

- 3 -

Problem Possible Causes Action

The unit isn’t

turning on

The unit just

ﬁnished a

15-minute massage

and shut oﬀ

automatically

If you want to start

another massage

session, turn the unit

back on by pressing the

power button

• Ensure that the main power is suitable for this produc.

• Disconnect the product from the main supply after use or before cleaning to avoid personal

injury or damage to the device

• Do not use any spare parts and attachments other than those recommended

• Do not use this product if its casing or main cable is damaged

• Do not use this product if you are under the inﬂuence of alcohol or sick

• Do not use excessive force when operating this device

• Do not keep this product on for more than 15 minutes to avoid overheating

• Do not use this product within one hour of eating

WORKING ENVIRONMENT

• Do not use this product in a highly humid environment such as a bathroom

• Do not use this product immediately after there has been a sudden change in

environmental temperature

• Do not use this product in an environment where lots of dust or corrosive gases are

present

• Do not use this product when it is covered by a blanket or pillow, etc.

THIS PRODUCT IS NOT FOR:

• People with contagious skin conditions

• Patients with osteoporosis

• Patients with heart disease, pacemakers, etc.

• People with a high fever

• Women that are pregnant or menstruating

• Those who are injured or suﬀering from skin diseases

• The unit has a heated surface. People who are sensitive to heat must be careful when

using

• Children under the age of 14 or people with mental disabilities should be supervised while

using this machine

• Do not use this product on a pet

SAFETY PRECAUTIONS

• Do not plug or unplug this product when your hands are wet

• Do not pull the cable when unplugging. Unplug gently from the outlet

• Do not damage the cable or change the circuit of the product

- 4 -

• Stop using this product and consult Sharper Image Customer Service if you notice

anything abnormal with the product during use

• If the supply cord is damaged, it must be replaced. Contact Sharper Image Customer

Service

• This product should not be used in the bathroom and kitchen because of high

temperatures, lights, damp areas, high voltage and the source of ﬁre and/or water

• Keep this item away from sharp objects

WARRANTY / CUSTOMER SERVICE

Sharper Image branded items purchased from SharperImage.com include a 1-year limited

replacement warranty. If you have any questions not covered in this guide, please call our

Customer Service department at 1 (877) 210-3449. Customer Service agents are available

Monday through Friday, 9:00 a.m. to 6:00 p.m. ET.

- 5 -

The SHARPER IMAGE® name and logo are registered trademarks.
