Sharp FO-10 Manual de usuario

MODEL

FO-10

FO-50

FO-70

1. Installation

2. Sending Documents

3. Receiving Documents

4. Making Copies

5. Making Telephone Calls

6. Answering Machine Hookup

7. Special Functions

8. Printing Lists

9. Maintenance

10. Troubleshooting

Introduction

Note: This fascismile machine is Year 2000 compliant.

*Based on ITU-T Test Chart #1 at standard resolution in Sharp special mode,

excluding time for protocol signals (i.e., ITU-T phase C time only).

Automatic dialing Rapid Key Dialing: 5 numbers

(Note for FO-10: Rapid Key Dialling is not

avaiable)

Speed Dialing: 35 numbers

(Note for FO-10: 10 numbers)

Fax paper Initial starter roll (included with machine):

10 m

Recommended replacement roll:

FO-20PRw, 30 m (12.7mm core)

Paper cutting method FO-10/FO-50: Tear off by hand

FO-70: Automatic cutter

Modem speed 9600 bps with automatic fallback to lower

speeds.

Transmission time* Approx. 15 seconds

Resolution Horizontal: 8 pels/mm

Vertical:

Standard: 3.85 lines/mm

Fine /Halftone: 7.7 lines/mm

Super fine: 15.4 lines/mm

Automatic document

feeder

5 pages max. (20 lb paper)

(Note for FO-10: This function is not

available)

Haftone (grayscale) 64 levels

Welcome, and thank you for

choosing a Sharp facsimile

machine! The features and

specifications of your new Sharp

fax machine are shown below.

all‑fo50hk.bookPage1Thursday,August26,19994:15PM

Display 16-digit LCD display

Compression scheme MR, MH, Sharp (H2)

Applicable telephone line Public switched telephone network

Compatibility ITU-T (CCITT) G3 mode

Input document size Automatic feeding:

Width: 148 to 216 mm

Length: 140 to 297 mm

Manual feeding:

Width: 148 to 216 mm

Length: 140 to 600 mm

Effective scanning width 210 mm max.

Effective printing width 210 mm max.

Contrast control Automatic/Dark selectable

Reception modes Fax, Tel, Tel/Fax, A.M.

Copy function Yes

Telephone function Yes (cannot be used if power fails)

Power requirements 220-240 V AC, 50/60 Hz

Operating temperature 5 - 35°C

Humidity Maximum: 85% RH

Power consumption Standby: 2.3 W

Maximum: 115 W

Dimensions Width: 304 mm

Depth: 236 mm

Height: 122 mm

Weight Approx. 2.6 kg

all‑fo50hk.bookPage2Thursday,August26,19994:15PM

As a part of our policy of continuous improvement, SHARP reserves the right to

make design and specification changes for product improvement without prior notice.

The performance specification figures indicated are nominal values of production

units. There may be some deviations from these values in individual units.

Important safety information

Be sure to save these instructions!

When using your fascimile equipment, basic safety precautions

should always be followed to reduce the risk of fire, electric shock

and injury to persons, including the following:

• Do not disassemble this machine or attempt any procedures not

described in this manual. Refer all servicing to qualified service

personnel.

• This machine must only be connected to a 220-240 V, 50/60 Hz,

grounded (3-prong) outlet. Connecting it to any other kind of outlet

will damage the machine and invalidate the warranty.

• Do not install or use the machine near water, or when you are wet.

For example, do not use the machine near a bath tub, wash bowl,

kitchen sink or laundry tub, in a wet basement, or near a swimming

pool. Take care not to spill any liquids on the machine.

• Unplug the machine from the power outlet and telephone jack and

consult a qualified service representative if any of the following sit-

uations occur:

- Liquid has been spilled into the machine or the machine has been

exposed to rain or water.

- The machine produces odors, smoke, or unusual noises.

- The power cord is frayed or damaged.

- The machine has been dropped or the housing damaged.

• Do not allow anything to rest on the power cord, and do not install

the machine where people may walk on the power cord.

all‑fo50hk.bookPage3Thursday,August26,19994:15PM

• Never insert objects of any kind into slots or openings on the

machine. This could create a risk of fire or electric shock. If an

object falls into the machine that you cannot remove, unplug the

machine and consult a qualified service representative.

• Do not place this machine on an unstable cart, stand or table. The

machine could be seriously damaged if it falls.

• Never install telephone wiring during a lightning storm.

• Never install telephone jacks in wet locations unless the jack is spe-

cifically designed for wet locations.

• Never touch bare telephone wires or terminals unless the telephone

line has been disconnected at the network interface.

• Use caution when installing or modifying telephone lines.

• Avoid using a telephone (other than a cordless type) during an elec-

trical storm. There may be a remote risk of electric shock from

lightning.

• Do not use a telephone to report a gas leak in the vicinity of the

leak.

• The power outlet must be installed near the equipment and must be

easily accessible.

Important:

• This facsimile machine is not designed for use on a line which has

call waiting, call forwarding, or certain other special services

offered by your telephone company. If you attempt to use the fax

machine in conjunction with any of these services, you may experi-

ence errors during transmission and reception of facsimile mes-

sages.

• This facsimile machine is not compatible with digital telephone sys-

tems.

all‑fo50hk.bookPage4Thursday,August26,19994:15PM

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Important safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Unpacking Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

A Look at the Operation Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Loading the Thermal Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Entering Your Name and Fax Number . . . . . . . . . . . . . . . . . . . . 20

Setting the Date and Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Setting the Reception Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Volume Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

2. Sending Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Transmittable Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Loading the Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Adjusting the Resolution and Contrast . . . . . . . . . . . . . . . . . . . . 36

Sending a Fax by Normal Dialing . . . . . . . . . . . . . . . . . . . . . . . . 38

Sending a Fax by Automatic Dialing . . . . . . . . . . . . . . . . . . . . . . 40

3. Receiving Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Using TEL/FAX Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Using FAX Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Using TEL Reception Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

4. Making Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

5. Making Telephone Calls. . . . . . . . . . . . . . . . . . . . . . . . . . 60

all‑fo50hk.bookPage5Thursday,August26,19994:15PM

Table of Contents

6. Answering Machine Connection . . . . . . . . . . . . . . . . . . .62

Connecting an Answering Machine . . . . . . . . . . . . . . . . . . . . . . . 62

Optional A.M. Mode Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

7. Special Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Caller ID (Requires Subscription to Service) . . . . . . . . . . . . . . . . 69

Duplex Ringing (Requires Subscription to Service). . . . . . . . . . . 75

Blocking Reception of Unwanted Faxes . . . . . . . . . . . . . . . . . . . 77

Polling (Requesting a Fax Transmission) . . . . . . . . . . . . . . . . . . 79

8. Printing Lists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

9. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83

10. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Problems and Solutions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Messages and Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Clearing Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Quick Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

all‑fo50hk.bookPage6Thursday,August26,19994:15PM

1. Installation

Unpacking Checklist

If any are missing,

contact your dealer or

retailer.

Before setting up,

make sure you have

all of the following

items.

Original document

support

Handset

Handset lead

Fax paper

(Sample roll)

Operation

manual

Telephone

line cord

Paper roll

shims

Paper shaft

all‑fo50hk.bookPage7Thursday,August26,19994:15PM

A Look at the Operation Panel

TEL FAX

RECEPTION

MODE

RESOLUTIONFUNCTION

DOWN VOLUME UP

A.M.

SPEED DIAL

REDIAL

SPEAKER

01 02

03 04

05 06

07 08

09 10/POLL

ABC DEF

JKL MNO

GHI

TUV WXYZ

PQRS

START

STOP

COPY/HELP

HOLD/SEARCH

TEL FAX

GHI

PQRS

JKL

ABC DEF

MNO

WXYZ

TUV

ABCDE/

STOP

COPY/

HELP

START

FUNCTION

VOLUME

SPEED

DIAL

REDIAL

HOLD/

SPEAKER

RESOLUTION/

RECEPTION MODE

123

789

456

10 11 12

8 9 13

TEL/FAX A.M.

POLL

Rapid Dial Keys

P r e s s o n e o f t h e s e k e y s t o d i a l a f a x n u m b e r a u t o m a t i c a l l y.

Note for FO-10: Rapid Key Dialling is not avaiable

Display

This displays messages and prompts during operation and

programming.

FUNCTION key

Press this key to select various special functions.

VOLUME key

Press this key to adjust the volume of the speaker when the

SPEAKER key has been pressed, the volume of the ringer at all

other times.

Number keys

Use these keys to dial numbers, and enter numbers and letters when

storing auto-dial numbers.

A Look at the Operation Panel

all‑fo50hk.bookPage8Thursday,August26,19994:15PM

A Look at the Operation Panel

1. Installation

SPEED DIAL key

Press this key to dial a fax or voice number using an abbreviated 2-

digit Speed Dial number.

REDIAL key

Press this key to automatically redial the last number dialed.

START key

Press this key to begin transmission when using Speed Dialing, Direct

Keypad Dialing, or Normal Dialing.

STOP key

Press this key to cancel an operation before it is completed.

COPY/HELP key

When a document is in the feeder, press this key to make a copy of a

document. At any other time, press this key to print out the Help List,

a quick reference guide to the operation of your fax machine.

RESOLUTION/RECEPTION MODE key

When a document is in the feeder, press this key to adjust the

resolution for faxing or copying. At any other time, press this key to

select the reception mode (an arrow in the display will point to the

currently selected reception mode).

SPEAKER key

Press this key to listen to the line and fax tones through the speaker

when faxing a document.

Note: This is not a speakerphone. You must pick up the handset to

talk with the other party.

HOLD/SEARCH key

Press this key to search for an auto-dial number, or, during a phone

conversation, press this key to put the other party on hold.

Panel release

Grasp this finger hold and pull toward you to open the operation

panel.

all‑fo50hk.bookPage9Thursday,August26,19994:15PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Máquina de fax de Sharp

Sharp

Sharp FO-785 Manual de usuario

Sharp

Sharp FO-P610 Manual de usuario

Sharp

Sharp FO-3150 Manual de usuario

Sharp

Sharp UX-A1000 Manual de usuario

Sharp

Sharp FO-A650 Manual de usuario

Sharp

Sharp UX-4000M - UX 4000 B/W Laser Printer Manual de usuario

Sharp

Sharp FO-A760 Manual de usuario

Sharp

Sharp UX-D50 Manual de usuario

Sharp

Sharp FO-885 Manual de usuario

Sharp

Sharp FO-4500 Manual de usuario

Sharp

Sharp FO-DC500 Manual de funcionamiento

Sharp

Sharp UXB700E Manual de usuario

Sharp

Sharp FO-3500 Manual de usuario

Sharp

Sharp UX-P100 Manual de usuario

Sharp

Sharp UX-A255 Manual de usuario

Sharp

Sharp FO-1850 Manual de usuario

Sharp

Sharp FO-775L Manual de usuario

Sharp

Sharp UX-A1000 Manual de usuario

Sharp

Sharp F-2700M Manual de usuario

Sharp

Sharp MX-FX11 Manual de usuario

Sharp

Sharp MX-FXX1 Manual de usuario

Sharp

Sharp FO-150 Manual de usuario

Sharp

Sharp FO-145 Manual de usuario

Sharp

Sharp FO-1530 Manual de usuario

Manuales populares de Máquina de fax de otras marcas

Samsung

Samsung SF-515 Manual de usuario

Radio Shack

Radio Shack TFX-1031 Manual de usuario

imagistics

imagistics 2030 Manual

Panasonic

Panasonic KX-FL501C Manual de usuario

Panasonic

Panasonic KX-FP200L Manual de usuario

Furuno

Furuno FAX-30 Manual de usuario

Savin

Savin 3740 Manual

Muratec

Muratec MFX-C3035 Manual de usuario

Panasonic

Panasonic KX-PD505DL Manual de usuario

Panasonic

Panasonic KX-FC265CX-S Manual de usuario

Canon

Canon FAX-L400 Manual de usuario

Ricoh

Ricoh 1000L Guía de inicio rápido

Kyocera

Kyocera KM-F1060 Manual de usuario

Panasonic

Panasonic KX-F850 Manual de usuario

Panasonic

Panasonic KX-FLM652CX Manual de usuario

Panasonic

Panasonic KX-F1000BX Manual de usuario

Canon

Canon JX510P Manual de usuario

Mita

Mita LDC-870 Manual
