UA-PN1U
Air Purifier
Operation manual
EN
CONTENTS
IMPORTANT SAFETY
INSTRUCTIONS......................... 1
PART NAMES ............................ 4
BEFORE FIRST USE................. 6
CARE AND MAINTENANCE ..... 7
FILTER REPLACEMENT........... 8
TROUBLESHOOTING............... 9
SPECIFICATIONS.................... 10
Plasmacluster
Plasmacluster treats the air
similar to the way nature cleans
the environment by emitting a
balance of positive and negative
ions.
“Plasmacluster” and “Device of a cluster of grapes” are
trademarks of Sharp Corporation.
* The number in this technology mark indicates an
approximate number of ions supplied into air of
1 cm3, which is measured around the centre of a
room applicable floor area (at 1.2 m height above the
floor) when the product is placed on the floor and is
operating with MAX mode.
Please read before operating your new Air Purifier
The air purifier draws in room air through the Air Inlet, circulates it through
a Pre-Filter, a Dust Collection and Deodorizing Integrated Filter inside the product,
and then discharges it through the Air Outlet. The Dust Collection and Deodorizing
Integrated Filter can remove dust particles and absorb odours as they pass through
the filter.
Some odours absorbed by the filters will break down over time, causing additional
odours. Depending on usage conditions, and especially if the product is used in
environments significantly more severe than a normal household, these odours
may become noticeable sooner than expected. If these odours persist, replace the
filters.
NOTE
• The air purifier is designed to remove air-suspended dust and the odours.
The air purifier is not designed to remove harmful gases such as carbon
monoxide contained in cigarette smoke.
The air purifier may not completely remove an odour if the source of the odour
is still present.
Dear Customer, Thank you for having
purchased this SHARP product. We would
like to inform you that your warranty rights
are in the European warranty card.
You can download them from
www.sharpconsumer.eu
or contact your retailer where you
purchased your device. You can also
obtain the copy of the warranty rights via
the electronic or conventional mail after
submitting your request to
service.gb@sharpconsumer.eu (UK)
service.ie@sharpconsumer.eu (IE)
or calling the number
+44 (0) 330 024 0803 (UK)
+353 1443 3323 (IE).
Calls are charged at your normal
telephone call rate.
Keep proof of purchase because it is
necessary to apply warranty rights.
WARRANTY
Thank you for purchasing this SHARP Air
Purifier. Please read this manual carefully
before using the product. This manual should
be kept in a safe place for handy reference.
1
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using electrical
appliances, including the following:
WARNING – Always observe the following to reduce the risk of
electrical shock, fire, or injury:
• Read all instructions before using the product.
• Use only a 220 - 240 volt outlet.
• Use only the AC adapter of the product.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, a Sharp authorized
Service Centre or similarly qualified persons in order to
avoid a hazard. Contact the nearest Service Centre for any
problems, adjustments, or repairs.
• Do not repair or disassemble the product yourself.
• Be sure to remove the AC adapter before performing
maintenance, when removing and attaching and replacing
the filter and when not using for a long time. Failure to do
so can cause a short circuit resulting in electrical shock or
fire.
• Do not use the product if the power cord or AC adapter is
damaged or if the connection to the wall outlet is loose.
• Periodically remove dust from the AC adapter.
• Do not insert fingers or foreign objects into the Air Inlet or Air
Outlet.
• When removing the AC adapter, always hold the AC adapter
and never pull on the cord. Failure to do so can cause a short
circuit resulting in electrical shock or fire.
2
• Be careful not to damage the power cord. Failure to do so can
cause electric shock, heat generation, or fire.
• Do not remove the AC adapter when your hands are wet.
• Do not use this product near gas appliances or fireplaces.
When the product is operated with gas appliances in same
room, Ventilate a room periodically, otherwise it may cause
Carbon monoxide poisoning.
• Do not operate the product in rooms where aerosol insecticides
are present. Do not operate the product in rooms where there
is oily residue, incense, sparks from lit cigarettes, or chemical
fumes in the air.
• Keep the product away from water. Do not operate the product
in places where it may get wet, such as a bathroom.
• Do not expose the product to water. Doing so can cause a short
circuit or electrical shock.
• Be cautious when cleaning the product. Strong corrosive
cleansers can damage the exterior.
NOTE – What to do if the product interferes with radio or TV
reception
If the air purifier interferes with radio or television reception, try
one or more of the following measures:
• Adjust or reposition the receiving antenna.
• Increase the distance between the product and the radio or TV.
• Connect the equipment into an outlet on a circuit different from
that of the radio or TV receiver.
• Consult the dealer or a qualified radio or TV technician.
CAUTIONS CONCERNING OPERATION
• Do not block the Air Inlet or Air Outlet.
• Do not place the product near or on hot objects, such as stoves
or heaters, or where it may come into contact with steam.
• Always operate the product in an upright position.
• Do not move the product when it is in operation.
• If the product is on easily damaged flooring, an uneven surface,
or thick-piled carpet, lift it up when moving.
• Do not operate the product without the filters properly installed.
3
• Do not wash and reuse the Dust Collection and Deodorizing
Integrated Filter. Doing so will not improve filter performance
and can also cause electric shock or operating malfunctions.
• Clean the exterior with a soft cloth only. Do not use volatile
fluids or detergents. The product surface may be damaged or
cracked with Benzine paint thinner, alcohol or polishing powder.
• Do not scrub the Pre-Filter hard during its maintenance.
• Do not use the AC adapter for other products.
• Do not get or lean on the product.
INSTALLATION GUIDELINES
• Avoid locations where furniture, fabrics, or other objects can
come in contact with the product and interfere with the Air Inlet
and Air Outlet.
• Avoid locations where the product is exposed to condensation
or drastic changes in temperature. Appropriate room
temperature is between 0 – 35 ºC.
• Place the product on a level and stable surface with sufficient
air circulation. Place the product in the centre of the room for
better air circulation. When placed on heavy carpet, the product
may vibrate slightly.
• Avoid locations with grease, oil smoke, alcohol, hypochlorous
acid, or chemicals in the air. Doing so can cause the product
exterior to crack.
• The surrounding walls and floor of the product may become
dirty over time. When using the product for an extended period
of time at the same location, periodically clean the walls and
floor adjacent to it.
• Do not use fluororesin or silicone-containing products
(cosmetics, hair care products, etc.,) near the product. The
fluororesin or silicone could get stuck inside the product,
preventing it from producing Plasmacluster ions.
FILTER GUIDELINES
• Follow the instructions in this manual for proper filter care and
maintenance.
4
PART NAMES
1 2
3
4
8
9
10
NOTE
• When using for the first time, please
remove the plastic bag from the Dust
Collection and Deodorizing Integrated
Filter. (Page 6)
5
6
7
BACK SIDE
11
1Operation Panel 8Power code
2Night Light
9
Power Lamp (Blue)
• The lamp lights up while the AC
adapter is connected to the outlet.
3Air Outlet
4Air Inlet
5Dust Collection and Deodorizing
Integrated Filter 10
AC Adapter
• Shape of adapter depends on
country.
6Pre-Filter
7Bottom Cover 11 AC Adapter Terminal
5
NOTE
• In LOW mode, the lamps on the Operation Panel lights up dimly.
POWER ON/OFF AND SETTING MODE
LOW MED MAX POWER
OFF
NOTE
• Plasmacluster ion will become
always ON when after
disconnecting and connecting
the AC adapter again.
PLASMACLUSTER ION ON/OFF
ON OFF
Press for 3 sec.
NIGHT LIGHT ON/OFF
ON
The rear lights up.
OPERATION PANEL
1Power ON/OFF and Mode Button
2Night Light Button
3Plasmacluster Ion Lamp (Blue)
4Mode Lamps (White)
1
3
2
4
6
BEFORE FIRST USE
1Turn the product upside
down.
2Remove the Bottom Cover.
1
2
3Remove the Pre-Filter
( 1 ) and the Dust
Collection and Deodorizing
Integrated Filter ( 2 ).
1
2
Always be sure to remove
the AC Adapter from the
wall outlet.
4Remove the Plastic Bag.
5Attach the Dust Collection
and Deodorizing Integrated
Filter.
Tag
6Attach the Pre-Filter.
1
2
Click
7Attach the Bottom Cover.
1
2
Click
7
NOTE About Pre-Filter
• Do not apply excessive pressure when scrubbing the Pre-Filter.
• How to clean hard to remove dirt.
1. Add a small amount of kitchen detergent to water and soak
for about 10 minutes.
2. Rinse off the kitchen detergent with clean water.
3. Completely dry the filter in a well ventilated area.
CARE AND MAINTENANCE
Always be sure to remove
the AC Adapter from the
wall outlet.
MAIN BODY
AIR INLET / PRE-FILTER
Wipe with a dry, soft cloth.
Remove the dust gently with a cleaning tool such as a vacuum
cleaner.
1 2
Once a month
When it gets dirty
Pre-Filter
Bottom Cover
8
Always be sure to remove
the AC Adapter from the
wall outlet.
Dust Collection and Deodorizing Integrated Filter
Clean only the tagged surface.
Do not clean up the opposite
surface. The filter is fragile, so
be careful not to give too much
pressure.
Remove the dust on the
filter.
FILTER REPLACEMENT
LIFE OF FILTER
Filter life varies depending on the room
environment, usage conditions, and
location of the product.
Lifespan of the Dust Collection and
Deodorizing Integrated Filter and
replacement suggestions are based on
purifying a room in which 5 cigarettes are
smoked per day and the product’s dust
collection and deodorizing performance
has declined to half the level of a new
filter.
We recommend replacing the filter
more frequently if the product is used
in conditions significantly more severe
(PM2.5 etc.,) than a normal household.
• The life of the Dust Collection and
Deodorizing Integrated Filter is about
1 year after opening.
Tag
Dust Collection
and Deodorizing
Integrated Filter
NOTE
• Do not wash the filter. Do not expose to sunlight. (Otherwise these filter may
lose efficacy.)
• Some odours absorbed by the filter will break down over time, causing additional
odours. Depending on usage conditions, and especially if the product is used in
environments significantly more severe than a normal household, these odours may
become noticeable sooner than expected. Replace the filter in those cases or if dust
is unable to be removed after maintenance.
Whenever dust accumulates, or when odour emanates from the air outlet.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Purificador de aire de Sharp
Sharp
Sharp IG-A10EK-W Manual
Sharp
Sharp FP-J80E Manual de usuario
Sharp
Sharp FP-F30A Manual de usuario
Sharp
Sharp Plasmacluster FP-N25CX Manual de usuario
Sharp
Sharp FP-G50E Manual de usuario
Sharp
Sharp KC-G50E Manual de usuario
Sharp
Sharp KC-F30Y Manual de usuario
Sharp
Sharp KC-F31R Manual de usuario
Sharp
Sharp KC-G60EU Manual de usuario
Sharp
Sharp UJ-GC20E Manual de usuario
Sharp
Sharp IG-BC2E Plasmacluster Ion Manual de usuario
Sharp
Sharp Plasmacluster KC-860U Manual de usuario
Sharp
Sharp Plasmacluster FP-P40CX Manual de usuario
Sharp
Sharp KC-A60Y Manual de usuario
Sharp
Sharp FP-JM40B Manual de usuario
Sharp
Sharp FXJ80UW Manual de usuario
Sharp
Sharp FP-J40E Manual de usuario
Sharp
Sharp FP-JM30E Manual de usuario
Sharp
Sharp FU-425E Manual de usuario
Sharp
Sharp KC-D60EU-W Manual de usuario
Manuales populares de Purificador de aire de otras marcas
Winix
Winix NK300 Manual de usuario
Friedrich
Friedrich C-90A Instrucciones de funcionamiento e instalación
Surgically Clean Air
Surgically Clean Air JADE2.0 Manual de usuario
Base aire
Base aire 555 Pro Manual de usuario
Champion
Champion CP25 Manual de usuario
vollara
vollara Air & Surface Pro+ Manual de usuario
