PROGRAMMING MANUAL

KIOSK Printer

BT-T080R

Shandong New Beiyang Information Technology Co.,Ltd.

CONFIDENTIAL

BT-T080R Programming Manual

Declaration

If you need this manual, please comply with the Clause as below.

If you disagree with it, please return this manual immediately.

This manual contains the private confidential information belonging to Shandong New Beiyang

Info-Tech Co., Ltd. (hereinafter referred to as SNBC) or its distributors. You must keep its relative

content as the confidential information. If the users are commercial customers or entities, you

should be aware to disclose it to those people with the confidential responsibility including your

employees, agencies and partners. When you terminate the cooperation with SNBC or bring

about your request, you have to stop using this manual and return it to SNBC or its distributor, or

destroy the confidential information.

If any relative organ such as court, arbitrator or government authority requests you to disclose any

confidential information of this manual, you must inform SNBC quickly and also agree that you

shall cooperate or assist with SNBC reasonably during the negotiation.

SNBC has the right to disclose its confidential information and does not be responsible for the

loss or damages caused from the wrong usage or reference of this manual by users.

Information in this document is subject to change without notice, which is only used for product

maintenance or service relative to this manual. SNBC reserves the right to improve products as

new technology, components, software, and firmware become available. If users need further

data about the products, please feel free to contact SNBC or your local distributor.

No part of this document may be reproduced or transmitted in any form or by any means,

electronic or mechanical, for any purpose without the express written permission of SNBC.

Printed in China.

Version 1.0.

Technical Contact Information

In CHINA:

Address:169 HuoJu Road, Hi-Tech Zone Weihai, Shandong, CHINA

Tel: 0086-631-5673777, 5675888

Fax: 0086-631-5673778

P. C.: 264209

Http: www.newbeiyang.com

E-mail: [email protected]

BT-T080R Programming Manual

Contents

1. General Information...................................................................................................................1

1.1 Commands classification .....................................................................................................1

1.2 Key Terms ............................................................................................................................1

1.3 Command Explanation.........................................................................................................2

2. Kiosk Command Set..................................................................................................................3

2.1 Print Command ....................................................................................................................3

LF ........................................................................................................................................... 3

FF........................................................................................................................................... 3

CR .......................................................................................................................................... 3

ESC FF................................................................................................................................... 4

ESC J n .................................................................................................................................. 4

ESC d n .................................................................................................................................. 5

2.2 Location command...............................................................................................................5

HT........................................................................................................................................... 5

ESC $ nL nH........................................................................................................................... 6

ESC D n1...nk NUL................................................................................................................. 7

ESC T n.................................................................................................................................. 8

ESC W xL xH yL yH dxL dxH dyL dyH ................................................................................... 9

ESC \ nL nH.......................................................................................................................... 11

ESC a n ................................................................................................................................ 12

GS $ nL nH........................................................................................................................... 13

GS L nL nH........................................................................................................................... 14

GS P xL xH yL yH................................................................................................................. 15

GS W nL nH ......................................................................................................................... 16

GS \ nL nH............................................................................................................................ 16

2.3 Character command...........................................................................................................17

CAN...................................................................................................................................... 17

BT-T080R Programming Manual

ESC SP n ............................................................................................................................. 18

ESC ! n ................................................................................................................................. 19

ESC % n............................................................................................................................... 21

ESC & y c1 c2 [x1 d1...d(y × x1)]...[xk d1...d(y × xk)] ........................................................... 21

ESC – n ................................................................................................................................ 23

ESC ? n ................................................................................................................................ 24

ESC E n................................................................................................................................ 25

ESC G n ............................................................................................................................... 25

ESC M n ............................................................................................................................... 26

ESC R n ............................................................................................................................... 26

ESC V n................................................................................................................................ 27

ESC t n ................................................................................................................................. 28

ESC { n................................................................................................................................. 28

GS ! n ................................................................................................................................... 29

GS B n.................................................................................................................................. 30

FS ! n.................................................................................................................................... 31

FS & ..................................................................................................................................... 32

FS - n.................................................................................................................................... 32

FS ........................................................................................................................................ 33

FS 2 c1 c2 d1...dk................................................................................................................. 33

FS S n1 n2............................................................................................................................ 34

FS W n ................................................................................................................................. 35

2.4 Bitmap Command ..............................................................................................................35

ESC * m nL nH d1... dk ........................................................................................................ 35

GS # n .................................................................................................................................. 37

GS * x y d1...d(x × y × 8) ...................................................................................................... 38

GS / m .................................................................................................................................. 38

GS v 0 m xL xH yL yH d1....dk.............................................................................................. 39

FS p n m............................................................................................................................... 40

FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n......................................................... 41

BT-T080R Programming Manual

2.5 Status command ................................................................................................................43

DLE EOT n ........................................................................................................................... 43

GS a n .................................................................................................................................. 46

GS r n ................................................................................................................................... 48

2.6 Barcode command .............................................................................................................48

GS H n.................................................................................................................................. 48

GS f n ................................................................................................................................... 49

GS h n .................................................................................................................................. 49

GS k m d1...dk NUL GS k m n d1...dn①②............................................................................ 50

GS p n .................................................................................................................................. 53

GS q n .................................................................................................................................. 53

GS w n.................................................................................................................................. 54

2.7 Other commands................................................................................................................54

ESC 2 ................................................................................................................................... 54

ESC 3 n ................................................................................................................................ 54

ESC = n................................................................................................................................ 55

ESC @ ................................................................................................................................. 55

ESC L ................................................................................................................................... 56

ESC S................................................................................................................................... 56

ESC c 0 n ............................................................................................................................. 57

ESC c 3 n ............................................................................................................................. 57

ESC c 1 nL nH...................................................................................................................... 58

ESC c 4 n ............................................................................................................................. 59

ESC c 5 n ............................................................................................................................. 59

ESC c @ n............................................................................................................................ 59

ESC c A n............................................................................................................................. 60

ESC i .................................................................................................................................... 60

ESC I n X0l X0h Y0l Y0h X1l X1h Y1l Y1h ........................................................................... 60

ESC v ................................................................................................................................... 61

GS FF................................................................................................................................... 61

BT-T080R Programming Manual

GS ( A pL pH n m ................................................................................................................. 62

GS : ...................................................................................................................................... 63

GS C 0 n m........................................................................................................................... 63

GS C 1 aL aH bL bH n r ....................................................................................................... 64

GS C 2 nL nH ....................................................................................................................... 65

GS C : sa ; sb ; sn ; sr ; sc ;.................................................................................................. 66

GS I n ................................................................................................................................... 67

GS V m GS V m n①② ......................................................................................................... 68

GS c ..................................................................................................................................... 68

GS ^ r t m ............................................................................................................................. 69

GS . B E . . > n ..................................................................................................................... 70

GS . B E . . ？n .................................................................................................................... 70

3.Programming Instructions.........................................................................................................72

3.1 General Information ...........................................................................................................72

3.2 Programming ABC .............................................................................................................72

3.2.1 Print modes ................................................................................................................. 72

3.2.2 Paper supported .......................................................................................................... 73

3.3 Programming examples .....................................................................................................73

3.3.1Initialization................................................................................................................... 73

3.3.2 Set printing and print data(character /barcode/bit image)............................................ 73

3.3.3 Print and cut paper ...................................................................................................... 78

3.3.4 Status check................................................................................................................ 78

3.3.5 Download bit images into RAM or FLASH................................................................... 79

3.3.6 Recommendations on applicable flow for programm................................................... 83

3.4 Data return format of USB interface ...................................................................................83

3.4.1 Summary of inquiry commands ................................................................................... 83

3.4.2 Data returen format of USB interface .......................................................................... 83

Appendix A: ASCII TABLE ...........................................................................................................85

Appendix B: Code Page Table.....................................................................................................86

BT-T080R Programming Manual

Appendix C: Code 128 Bar Code ................................................................................................96

BT-T080R Programming Manual

1. General Information

1.1 Commands classification

This receipt printer commands are classified as below:

Print commands: used for printing and feeding paper;

Position commands: to control the print position;

Character commands: to set characters property;

Bitmap commands: to download bitmap and print, including NV and RAM bitmap;

Status commands: used for printer status query;

Barcode commands: barcode print and property settings;

Other commands: used for periphery control, Micro-definition and initialization;

Command instruction refers to the detailed function of relative commands.

1.2 Key Terms

Real-time commands – These commands are acted on immediately upon being received by the

printer (regardless the printer’s busy or error status).

Page mode -- Under this mode, the printer possesses all data in specified memory and thinks of

this as a virtual page. The page is printed when the printer receives print command either FF or

ESC FF.

Standard mode – Standard mode is the default mode of printer uses to operate. Under this mode,

the printer prints data and feeds paper upon print line buffer full (data is enough for one print line)

or receiving print command like LF.

Marked paper mode– Configuration of printer is marked paper.

HRI Characters – Human readable interpretation of the barcode.

NV – Non-volatile memory in which data stored does not loss when power off.

RAM – Random Access Memory

Motion unit – The motion unit has vertical motion unit and horizontal motion unit, which specify

the least space for vertical motion and horizontal motion.

ASB – Auto status back

DPI – Print dots per inch (one inch equals to 25.4mm). It is used to identify the resolution of a

printer. FI, 203DPI means 203 print dots per inch. DPI: Dot Per Inch.

Font 0 – A standard character, Font A size for 203 DPI model is 12 x 24; the size for 300 DPI is 18

x 34;

Font 1 – Compressed character, Font B size for 203 DPI model is 9 X 17; the size for 300 DPI is

13 X 24;

Asia Character Set – Double-byte code character used in Asia, the size for 203DPI is 24 x 24;

the size for 300DPI is 36 x 36.

BT-T080R Programming Manual

1.3 Command Explanation

[Function] The name and function summary of commands;

[Format] The command expressed in ASCII, Hex and Decimal separately. If not specified,

the value in “range” part is decimal. For instance, in range” 1 ≤n≤4”, ‘1’ is not an

ASCII code but a decimal number;

[Range] The value range of parameter in the command;

[Note] Explain the main features and application notices of commands;

[Default] The initial value used after the printer initialized;

[Relative] Other commands related to current commend;

[Example] Example used for current or relative commands.

All command data in programming Example use HEX. All normal font/characters

are data. There is no explanation for the data of command such as 42 43 which is

data. The font/character underlined and emphasized is a command such as 1B 40.

All the data inside parentheses after all commands in Example is used to explain

the meanings of this command. The parentheses and data inside it is not the

command to be transmitted to the printer.

BT-T080R Programming Manual

2. Kiosk Command Set

2.1 Print Command

[Function] Print and feeds one line.

[Format] ASCII LF

Hex 0A

Decimal 10

[Note] Under standard mode, prints the data in the print buffer and feeds one line. It only

feeds one line when current buffer area is blank.

Under page mode, executes carriage return and moves the print position to the

beginning of next line.

This command sets the print position to the beginning of th

[Relative] ESC 2, ESC 3

[Function] Print and feed paper.

[Format] ASCII FF

Hex 0C

Decimal 12

[Note] Under page mode prints the data in the print buffer collectively and returns to

standard mode.

Under standard mode, this command functions the same as LF command.

The buffer data is deleted after being printed.

This command sets the print position to the beginning of the line.

[Relative] ESC FF, ESC L, ESC S

[Function] Print and carriage return

[Format] ASCII CR

Hex 0D

Decimal 13

[Notes]

When automatic line feed is enabled, this command functions the same as LF;

This command is disabled according to the printer configuration

When automatic line feed is disabled, this command is ignored.

[Relative] LF
