Installation

SENTROL ZX400/ZX410

Security System Control

New Features............................................................................................................. 5

ZX400/ZX410 Wiring Diagrams................................................................................ 6

ZX400/ZX410 Terminal Descriptions........................................................................ 8

“2 in 1” Zoning™ ...................................................................................................... 9

Conventional Methods of Wiring ........................................................................... 11

Class ‘B’ End-Of-Line Resistor Supervised Zones ..................................................... 11

Non-Supervised Closed Circuit Loop (No EOL Resistor Supervision) ...................... 11

Control Station Addressing and Supervision ......................................................... 12

SSD, LCD, and VFD Control Stations ...................................................................... 12

LED Control Stations .............................................................................................. 12

Control Station Troubleshooting............................................................................ 13

Clearing Trouble Messages ..................................................................................... 13

12 VDC Outputs ...................................................................................................... 14

Additional Outputs.................................................................................................. 14

Expansion Zones ..................................................................................................... 16

ZXEXP Zone Expander Module............................................................................... 17

Installation ............................................................................................................. 17

Wireless Devices ...................................................................................................... 18

Fire Zone Modules .................................................................................................. 19

ZEM Zone Expansion Module ................................................................................ 19

ZRM Zone Relay Module ........................................................................................ 21

ZXCFK Fire Module Kit ........................................................................................... 21

Power Issues ............................................................................................................ 22

Optional Battery Configurations ............................................................................. 22

ZX400/ZX410 Power Worksheet ............................................................................ 22

Auxiliary Power Supply Installation ......................................................................... 23

ZXPTR Printer Interface Module............................................................................. 24

Table of Contents

TABLE OF CONTENTS

Specifications And Features .................................................................................... 25

Control Board ........................................................................................................ 25

Power Supply ......................................................................................................... 25

Recommended Battery ........................................................................................... 25

Recommended Transformer ................................................................................... 25

Enclosure................................................................................................................ 25

Digital Communicator............................................................................................ 25

Control Stations ..................................................................................................... 26

ZXLCD Control Station........................................................................................... 26

ZXVFD Control Station ........................................................................................... 26

ZXLED12 Control Station ....................................................................................... 26

ZXSSD Control Station ........................................................................................... 26

Optional Accessories .............................................................................................. 26

Output Provisions ................................................................................................... 27

List Of Compatible Accessories ............................................................................... 28

ESL Two-Wire Smoke Detectors .............................................................................. 28

ESL Four-Wire Smoke Detectors .............................................................................. 28

System Sensors Two-Wire Smoke Detectors............................................................ 28

System Sensors Four-Wire Smoke Detectors ........................................................... 28

Wheelock ............................................................................................................... 28

Compatible Central Station Receivers ..................................................................... 28

Agency Requirements ............................................................................................. 29

UL and ULC Listings ............................................................................................... 30

National Fire Protection Association (NFPA) Rules ................................................ 31

Smoke Detector Locations ...................................................................................... 31

Testing ................................................................................................................... 31

System Troubleshooting ......................................................................................... 32

FCC Compliance ...................................................................................................... 34

TABLE OF CONTENTS

The Sentrol ZX400/ZX410 Security Control features

ease of installation and programming. The ZX400/

ZX410 is easily programmed with any one of four

Control Stations (LCD, LED, SSD, or VFD). The con-

trol may also be programmed remotely with the aid

of a personal computer (PC) and a modem using

Sentrol’s remote programming software (RPM2PRO)

and a panel support module (PRO400). The Control

Stations are easy-to-operate and contain features

such as cross-zoning, delay-before-dialing and an

audibles “mute” function to help reduce false alarms.

The ZX400/ZX410 Security Control is pre-pro-

grammed from the factory with twelve burglar zones

(one delay, two interior, and nine instant) and one

2-wire smoke detector zone to allow for out-of-box

power-up and operation. The twelve burglar zones

have been configured in a ‘paralleled’ condition us-

ing Sentrol’s unique “2 in 1” Zoning™. A zone ex-

pander may be added to provide an additional 2-

wire smoke detector zone and, with the use of “2 in

1” Zoning™, up to 16 additional zones.

Sentrol Series 4000 RF Gateway receivers and sen-

sors allow you to overcome installation obstacles and

increase profit potential. The wireless sensors have

been engineered for long term stability and reliabil-

•12 Zones with Sentrol’s unique “2 in 1” Zoning™

•Plus one 2-wire fire zone

•Expandable to 28 zones, plus two 2-wire fire zones

•Integrated Sentrol Series 4000 Wireless

•Two truly independent partitions

•Up to 50 user codes with 15 levels of authority

•75 event log

•Four interchangeable Control Stations to choose from

•Customized scheduling with special supervisory report

•Ideal for residential, commercial, and industrial applications

•Control Station programming in less than 2 minutes with factory defaults

New Features

NEW FEATURES

ity. Using the Series 4000 Wireless System, you can

expand the ZX400/ZX410 to include up to 16 wire-

less zones.

The Control’s on-board RAM maintains its data even

with the power disconnected. A “Watchdog” timer

monitors the microprocessor to ensure the opera-

tional integrity of the system. The ZX400/ZX410

Control Board is equipped with one low current pro-

grammable output (PGO1) and one high current bell

output (BELL) which may be used for Fire, Burglar,

Auxiliary and/or Holdup alarms. In addition, two

ZXODMs (Output Driver Modules) can be added to

provide 20 more programmable low current out-

puts which may be used to trigger other devices.

The ZX400 Security Control may be purchased in

the ZX410 pre-configured package assembly. This

assembly incorporates the ZX400 Control Board

mounted inside a larger 14" x 14" x 3.5" enclosure,

EX1414. The ZX410 must be purchased for Com-

mercial and Industrial UL Listed applications. For UL

Listed Commercial Fire applications, the ZX440F is

available. It consists of the ZX400 Control Board in

a red EX1414 enclosure, with a ZXCFM (Commer-

cial Fire Module), a CR860 dual battery harness and

other cabling.

See Specification and Features section for a complete list of compatible accessories.

FIGURE 1 Suggested UL Household Burglar Alarm and/or Fire (ƒƒ) Alarm Hookup

ZX400/ZX410 Wiring Diagrams

ZX400/ZX410 WIRING DIAGRAMS

SW NEG

GREEN

Red and Black Leads RED = POS. (+) BLACK = NEG. (-)

GROUND

SCREW

Enclosure

Door

Ground

Wire

UNIFIED

EARTH

GROUND

QUIESCENT CHARGE

CURRENT: 20mA.

Replacement: Every 3 - 5 years.

FLOAT BATTERY VOLTAGE:

13.6 - 13.8V

Max. current: 500mA.

WARNING

Internally Fused.

Do Not Short.

Do Not Connect

To A Switched

Receptacle.

TRANSFORMER

Basler BE 116235

16.5VAC/35VA

U.L. Class II 50/60Hz

OFF

I.C. Load Number 1

1500Ω(CR854)

(CONV ZONING)

AC XFMR

AUX12

BELL

2WS

NEG

DAT A

DAT B

KP+12

NEG

Z1/7

Z2/8

NEG

Z3/9

Z4/10

NEG

Z5/11

Z6/12

NEG

1 2

++--

POWER ALARM

CONTACTS

LISTED RATE OF RISE OR

FIXED TEMPERATURE THERMOSTAT

TO ANY ZONE DEFINED

AS 24-HOUR FIRE

POWER SUPERVISION UNIT

ESL MODEL 204-12/24V OR EQUIV.

1500ΩEOL

SUPERVISION

UL LISTED

SIGNALING DEVICE

Ademco AB12M

CONTROL STATIONS

ZONE EXPANDER

PRINTER INTERFACE

ODMs

RED

BLACK

BROWN BROWN

1500Ω

1/2 WATT

N.O.

N.C. ZONE 1

825Ω

1/4 WATT

1500Ω

1/2 WATT

N.C.

ZONE 9

ZONE 3

825Ω

1/4 WATT

1500Ω

1/2 WATT

N.C.

N.C. ZONE 11

ZONE 5

1500Ω(CR854)

(EOL DEVICE)

MOTION

DETECTOR

POWER

SMOKE DETECTOR

SENTROL 2-WIRE MODELS

(See ZX400/ZX410 Interconnect Label

P/N 64600310-NOTE 2)

METHOD 1 METHOD 2

SMOKE DETECTOR

SENTROL 4-WIRE MODELS

(See ZX400/ZX410 Interconnect Label

P/N 64600310-NOTE 2)

MODEL CR853 - 825ΩE.O.L.

MODEL CR854 - 1500ΩE.O.L.

UL LISTED RESISTORS

12V SEALED

LEAD ACID BATTERY

RED

BLACK

WHITE

PG01

TEL

SUPV

J-3

Class II

Power-

Limited

Class II

Power-

Limited

Yuasa B-1270

ADEMCO AB12M

GRADE A BELL

COMMERCIAL

POLARIZATION AND

NOISE SUPPRESSION

DIODE

CONNECTION OF UL COMMERCIAL

BURGLAR AUDIBLE

JUMPER

ALL WIRING

BETWEEN CONTROL

& BELL MUST BE IN

CONDUIT.

1500Ω(CR854)

(EOL DEVICE)

BELL

NEG

Z2/8

CONNECT

RJ31/33/45

CORD

J-10

J-4

FIGURE 2 Programmable Output And Telco Supervision Wiring Diagram

ZX400/ZX410 WIRING DIAGRAMS

+12V NEG TG+ TG - COM NC NO

MPI-206

TO TERMINAL 10

TO TERMINAL 20

OPTIONAL - When relay is required

PG01

PROGRAMMABLE

OUTPUT 1

CONNECTION

+12V NEG TG+ TG - COM NC NO

MPI-206

INSTALL

JUMPER

CUT

JUMPER

TEL

SUPV

TELEPHONE

SUPERVISION

CONNECTION

TO TERMINAL 7

TO TERMINAL 4

OPTIONAL - When Telco Supervision is required

ORANGE

BLUE

SENTROL RJ38 CORD

(shown)

1, 2 AC Input Connect the appropriate UL Class II transformer using 18 gauge minimum 2

conductor wire. Do not exceed 50 feet. Use a 16.5 VAC 35 VA transformer or an

optional 16.5 VAC 20 VA transformer.

CAUTION: Do not short the terminals of the transformer together. This

causes the internal fuse to blow. The transformer must be connected to a

120 VAC, 24-hour outlet not controlled by a switch other than an approved

over-current protection device.

3 Switched Negative (-) Current limited 100 mA terminal. Negative connection for 4-wire smoke

detectors, glass break detectors, and devices requiring resettable power.

4 Auxiliary Power (+)12 VDC 500 mA continuous power. Overcurrent protected at 1.35 amps

(PTC4). Used for powering motion detectors, 4-wire smoke detectors, glass

break detectors, and other accessories.

CAUTION: Use terminals 4 and 10 when calculating total current drain.

5 Supervised Bell Output (+)12 VDC. Combined alarm current should not exceed 1.5 amps. Overcurrent

protected at 1.85 amps (PTC2). A 1500 Ohm EOL resistor (CR854) must be con-

nected between terminals 5 and 7; otherwise a bell output fault will occur.

6 Two Wire Smoke (Zone 30) (+)12VDC of two-wire smoke detectors connected to this terminal. A 1500

(power-limited) Ohm EOL resistor (CR854) must be connected between terminals 6 and 7

regardless of whether a two-wire smoke detector is used or not. The maximum

series resistance is 60 Ohms.

7, 11 Common Negative BLACK WIRE - (-)12 VDC. Negative connection for Control Stations, zone

expander, printer interface, RF Gateway, ODMs, 2-wire smoke detectors,

motion detectors, and other devices.

8 Local Data Bus In (A) GREEN WIRE - Connection for Control Stations, zone expander, printer

interface, RF Gateway and ODMs. Use 22 guage wire up to 1000 ft. Use 18

guage wire up to 2000 ft.

9 Local Data Bus Out (B) WHITE WIRE - Connection for Control Stations, zone expander, printer

interface, RF Gateway and ODMs. Use 22 guage wire up to 1000 ft. Use 18

guage wire up to 2000 ft.

10 Control Station Power RED WIRE - (+)12 VDC 500 mA continuous power connection for control

stations, zone expander, printer interface, RF Gateway and ODMs. Overcurrent

protected at 1.35 amps (PTC4).

CAUTION: Use terminals 4 and 10 when calculating total current drain.

12 Zone 1/7 Loop (+)

13 Zone 2/8 Loop (+)

14 Common Negative

15 Zone 3/9 Loop (+)

16 Zone 4/10 Loop (+)

17 Common Negative

18 Zone 5/11 Loop (+)

19 Zone 6/12 Loop (+)

20 Common Negative

PGO1 Programmable Output 1 Use PGO1 as a +12V, 40 mA programmable output (see Figure 2).

TEL SUPV Telephone Supervision Use TEL SUPV as a telephone line trouble input (see Figure 2).

J4 Telco Jack RJ-31X connection.

TERMINAL FUNCTION DESCRIPTION

ZX400/ZX410 Terminal Descriptions

Each loop requires a 1500 Ohm end-of-line resistor (P/N CR854) for the primary

zone, and an 825 Ohm end-of-line resistor (P/N CR853) for the secondary zone.

A common negative is shared among all zones. The need for end-of-line resistors

may be eliminated on all Burglar defined zones through programming. See

Figure 1 for “2 in 1” Zoning™ wiring examples.

(power-limited)

ZX400/ZX410 TERMINAL DESCRIPTIONS

Method 2 wires two separate zone loops back into

one set of terminals. The panel recognizes each

loop independently because two different EOL re-

sistor values are used to differentiate between the

Primary Zone (1500 Ohm 1/2 Watt) and the Sec-

ondary Zone (825 Ohm 1/4 Watt). This method

provides two zones with one set of terminals and is

ideal for pre-wire or already installed wiring.

Figure 4 “2 in 1” Zoning™ Wiring - Method 2

The resistors in Figure 3 & 4 are 1%

values to maintain proper loop resis-

tance values. If replacements are re-

quired, please refer to the manufac-

turer for correct replacements. The

1500 ohm resistor is color coded

Brown•Green•Black•Brown•Brown.

The 825 ohm resistor is color coded

Gray•Red•Green•Black•Brown.

All zones sense five different voltage levels enabling

one zone to act as two. Troubleshooting is simple

using just a voltmeter at the control. The control

monitors the voltage level across the zone and uses

the voltage levels in Table 1 to determine whether

the zone is normal, open, or shorted.

If a Normally Open Device (i.e., 4-wire

smoke detector) is used with “2 in 1”

Zoning™, a short will occur across

both zone loops when that device

goes into alarm. It is recommended

that these types of devices be used

with Conventional Zone wiring only.

The Sentrol ZX400/ZX410 Security Control intro-

duces an all new method of wiring zones that saves

both time and wire costs. “2 in 1” Zoning™ allows

the installer to wire two separate zones in parallel

into one set of terminals.

Each zone is uniquely identified by its end-of-line re-

sistor. The Primary Zone (zones 1-6) in each termi-

nal is identified by a 1500 Ohm EOL resistor. The

Secondary Zone (zones 7 - 12) is identified by an

825 Ohm EOL resistor. The Primary and Secondary

zones operate as two independent zones to provide

separate reporting, programming, and displays. Each

zone is fully programmable as described in the

ZX400/ZX410 Programming Manual. The zones are

for Form A, Form B, or Form C sensors. Maximum

total loop wire and contact resistance (not includ-

ing EOL) must not exceed 100 Ohms for the loop

to function properly.

There are two methods of wiring for “2 in 1” Zon-

ing™. Method 1 wires one zone loop back to the

control while a second zone loop is added in parallel

off the first. This method may be employed in sys-

tem retrofits, system expansions, or just simply to

save wire cost and labor.

Figure 3 “2 in 1” Zoning™ Wiring - Method 1

NOTE

Secondary Zone

825Ω1/4W

1500Ω1/2W

Primary Zone

Secondary Zone

825Ω1/4W

1500Ω1/2W

Primary Zone

“2 in 1” Zoning™

NOTE

“2 in 1” Zoning™

Primary Zone and Secondary Zone Infinite Ohms 5.24 - 8.25 V

Open Contacts; Loop Cut or Open

Secondary Zone Open Contact, 1500 Ohms 4.24 - 5.23 V

Primary Zone Normal

Primary Zone Open Contact, 825 Ohms 3.24 - 4.23 V

Secondary Zone Normal

Primary Zone and Secondary Zone 825 Ohms in parallel with 2.00 - 3.23 V

Normal 1500 Ohms = 532 Ohms

Primary Zone and Secondary Zone 0 Ohms 0 - 1.99 V

Shorted

CONDITION NOMINAL LOOP RESISTANCE VOLTAGE READING

TABLE 1 “2 in 1” Zoning™ Troubleshooting Chart

“2 in 1” Zoning™

Otros manuales para ZX400

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de seguridad de Sentrol

Sentrol

Sentrol ZX400 Instrucciones de funcionamiento

Sentrol

Sentrol ZX300 Instrucciones de montaje

Sentrol

Sentrol ZX200 Guía de instalación

Sentrol

Sentrol ZXLCDL Manual de usuario

Sentrol

Sentrol X440F Manual de usuario

Sentrol

Sentrol ZXLCD Manual de usuario

Sentrol

Sentrol ZXCD Instrucciones de funcionamiento

Sentrol

Sentrol Arrowhead SC800 Instrucciones de montaje

Sentrol

Sentrol ZXLED8 Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
