Sentiotec Pro C3 Manual de usuario

Version 12/21 ID no. 1-026-969

INSTRUCTIONS FOR INSTALLATION AND USE

English

Sauna control unit

PRO C3

PRO-C3 / 1-015-451

Table of Contents

1. About this instruction manual 5

2. Important information for your safety 6

2.1. Intended use 6

2.2. Safety information for the installer 7

2.3. Safety information for the user 8

3. Product description 9

3.1. Scope of delivery 9

3.2. Optional accessories 9

3.3. Product functions 9

3.4. Sauna operating modes 11

3.5. Sensor operating modes 11

4. Installation 13

4.1. Installing the sauna control unit 13

4.2. Installing the heater sensor F1 with excess temperature fuse 15

4.3. Installing bench sensor F2 (optional) 16

4.4. Installing the humidity temperature sensor FTS2 (optional) 16

4.5. Installing the foil sensor (optional) 17

5. Electrical connection 18

5.1. Connecting the power supply cable, heater and evaporator 19

5.2. Connecting the light 19

5.3. Connecting the fan (optional) 20

5.4. Connecting the additional output (optional) 20

5.5. Connecting the power booster (optional) 20

5.6. Connecting heater sensor F1 21

5.7. Installing bench sensor F2 (optional) 21

5.8. Installing humidity temperature sensor FTS2 (optional) 21

5.9. Connectingthelmsensor(optional) 21

5.10. Connectingthesafetyshut-o󰀨 22

5.11. Remote start 22

5.12. Status output 23

5.13. Finishing installation 23

6. Performing tests 24

7. Connection diagram 26

8. Starting up 27

8.1. Function selection switch settings 27

8.2. Settings in the technician menu 29

9. Operating elements 34

9.1. Description of the operating elements 34

9.2. The function selector 34

9.3. The intensity selector 35

10. Operation 35

10.1. Switching on the light 35

10.2. Switching on the sauna control unit 36

10.3. Starting sauna mode 36

10.4. Starting combi mode 37

10.5. Starting additional output 38

10.6. Switching on the light 40

10.7. Starting the fan 41

10.8. Setting the preset time 42

10.9. Cancelling the preset time function 43

10.10.Setting the duration 43

10.11.Activating standby for remote operation 44

10.12.Changing the preset values 44

10.13.Cancelling the post-drying programme 45

10.14.Switchingo󰀨functions 45

10.15.Switchingo󰀨thesaunacontrolunit 45

11. User program 46

11.1. Preset user programs 46

11.2. Accessing user programs 47

11.3. Creating your own user programs 47

12. The Eco-function 49

13. Cleaning and maintenance 50

13.1. Cleaning 50

13.2. Maintenance 50

14. Disposal 50

15. Troubleshooting 51

15.1. Error messages 51

15.2. Low-water display 52

15.3. Fuses 52

16. Technical data 53

Instructions for installation and use p. 5/54

1. About this instruction manual

Read these instructions for installation and use carefully and keep them within

reach of the sauna control unit. This ensures that you can refer to information

regarding your safety and regarding operation at any time.

Symbols used for warning notices

In these instructions for installation and use, a warning notice located next to

an activity indicates that this activity poses a risk. Always observe the warning

notices. This prevents damage to property and injuries, which in the worst case

may be fatal.

The warning notices contain keywords, which have the following meanings:

DANGER!

Serious or fatal injury will occur if this warning notice is not observed.

WARNING!

Serious or fatal injury can occur if this warning notice is not observed.

CAUTION!

Minor injuries can occur if this warning notice is not observed.

ATTENTION!

This keyword is a warning that damage to property can occur.

Other symbols

This symbol indicates tips and useful information.

These installation and operating instructions can also be found in the

downloads section of our website: www.sentiotec.com/downloads.

Instructions for installation and use p. 6/54

2. Important information for your safety

The sauna control unit Pro C3 has been produced in accordance

with the applicable safety regulations for technical units. However,

hazards may occur during use. Therefore adhere to the following

safetyinformationandthespecicwarningnoticesintheindividual

chapters. Also observe the safety information for the devices con-

nected.

2.1. Intended use

The sauna control unit Pro C3 is used exclusively for operating and

controlling the sauna functions in accordance with the technical data.

The sauna control unit Pro C3 may only be used for operating and

controllingasaunaheaterwhichhasbeencertiedassatisfying

the combustion test described in paragraph 19.101 of EN 60335-

2-53. If the heater does not meet this requirement, an appropriate

safetyprecautionmustbetaken(forexample:safetyshut-o󰀨,see

5.10 on page 22).

The sauna control unit Pro C3 may only be used for operating and

controlling 3 heating circuits with a maximum heating capacity of

3.5 kW per heating circuit. The maximum evaporator capacity totals

3.5 kW. The maximum additional output capacity totals 3.5 kW.

Any use exceeding this scope is considered improper use. Improper

use can result in damage to the product, in severe injuries or death.

Instructions for installation and use p. 7/54

2.2. Safety information for the installer

●Installationmayonlybeperformedbyaqualiedelectricianor

similarlyqualiedperson.

●Work on the sauna control unit may only be performed when the

power has been disconnected.

● Anall-poledisconnectingdevicewithfullcut-o󰀨compliantwith

overvoltagecategoryIIImustbettedon-site.

●The sauna control unit must be installed outside the sauna room

at a height of approx. 1.70 m or in accordance with the rec-

ommendation issued by the sauna manufacturer. The ambient

temperature must be within a range spanning -10 °C to +40 °C.

●The heater sensor must be attached in a way that it is not af-

fectedbyaowofair.

●The heater supply cable must have a minimum cross-section of

2.5 mm2and be temperature resistant up to 150 °C.

●Also comply with the regulations applicable at the installation

location.

●For your own safety, consult your supplier in the event of prob-

lemsthatarenotexplainedinsu󰀩cientdetailintheinstallation

instructions.

Instructions for installation and use p. 8/54

2.3. Safety information for the user

●The sauna control unit must not be used by children under

8 years old.

●The sauna control unit may only be used by children above 8 years

old, by persons with limited psychological, sensory or mental

capabilities or by persons with lack of experience/knowledge:

– When they are supervised.

– When they have been shown how to use the device safely

and are aware of the hazards that could occur.

●Children must not play with the sauna control unit.

●Children under 14 years of age may only clean the sauna control

unit if they are supervised.

● Forhealthreasons,donotusethesaunawhenundertheinu-

ence of alcohol, medication or drugs.

● Makesurethatnoammableobjectshavebeenplacedonthe

sauna heater before the sauna control unit is switched on.

● Makesurethatnoammableobjectshavebeenplacedonthe

heater before activating the preset time function or the stand-by

mode for the remote start.

●Make sure that no flammable objects have been placed on

or in front of the infrared lamp before the sauna control unit is

switched on.

● Makesurethatnoammableobjectshavebeenplacedonthe

heater before activating the infrared lamp or the stand-by mode

for the remote start.

●For your own safety, consult your supplier in the event of prob-

lemsthatarenotdescribedinsu󰀩cientdetailintheoperating

instructions.

Instructions for installation and use p. 9/54

3. Product description

3.1. Scope of delivery

●Sauna control unit

●Heater sensor with integrated excess temperature fuse

●Installation material

●Wire jumper for bridging terminals V1 and Wm for combi heaters without

low-watershut-o󰀨

3.2. Optional accessories

●Bench sensor (item number: O-F2), sensor wires 1.5 m

●Humidity temperature sensor (item number: O-FTS2), sensor wires 3 m

●Foil sensor (item number: P-ISX-FF), sensor wires 3 m

●Power booster (item number: O-S2-18 / O-S2-30)

● Safetyshut-o󰀨(itemnumber:HT-SWL)

●pronet web server (item number: PRO-NET)

3.3. Product functions

The sauna control unit Pro C3 features the following functions:

●Regulation of combi heaters with a heating output of up to 10.5 kW and

evaporator output of up to 3.5 kW in the temperature range spanning 30 °C

to 110 °C and a humidity range spanning 5 % to 100 %.

●A power booster allows the maximum contact rating to be increased from

10.5 kW to 18 kW or 30 kW.

●Optional dimming or activation of a room light (up to 100 W)

●Optional dimmer function or activation of a fan (up to 100 W)

●Remote start function

Instructions for installation and use p. 10/54

●Status output

●Preset time function (up to 24 hours)

●Additional output

Either for dimming (up to 500 W), switching (up to 3.5 kW) or regulating the

sauna room temperature via the additional output.

The additional output has no excess temperature fuse. For this reason, only

intrinsically safe devices should be operated using the additional output.

– If infrared heaters are connected to the additional output, these must

have an excess temperature fuse. We recommend using the following

infrared lamps:

●DIR-350-R, WIR-350-R, DIR-500-R, WIR-500-R, DIR-750-R,

WIR-750-R, DIR-1300-R, WIR-1300-R

●ECO-350-R, ECO-350-G, ECO-500-R, ECO-500-G, ECO-750-R

– If one of the following infrared heat plates is connected to an additional

output, the foil sensor P-ISX-FF must be used, and must be activated

in the technician menu (see 8.2. Settings in the technician menu on

page 29):

●IR-WP-100, IR-WP-175, IR-WP-390, IR-WP-510

●IR-WPHL-100, IR-WPHL-175, IR-WPHL-390, IR-WPHL-510

●User program

The user program enables favourite sauna settings to be saved and accessed

again.Thereare5presetuserprogramsavailablewhichcanbemodied

according to user requirements.

●Automatic heating period limiter

The sauna control unit shuts down automatically after the maximum heating

period for safety reasons. The maximum heating period can be set to 6 h,

12 h, 18 h or 24 h.

●Post-drying programme

Oncecombi-modehasnished,thepost-dryingprogrammestartsautomati-

cally to prevent mould or rot from forming in the sauna room. This involves

heating the sauna room to 80 °C with the fan running for 30 minutes.

Otros manuales para Pro C3

Tabla de contenidos

Idiomas:

Otros manuales de Unidad de control de Sentiotec

Sentiotec

Sentiotec Just Sauna Fin Series Manual de usuario

Sentiotec

Sentiotec A2 Manual de usuario

Sentiotec

Sentiotec IHS 1 Manual de lista de piezas

Sentiotec

Sentiotec just sauna fin Manual de usuario

Sentiotec

Sentiotec wave.com4 touch Manual de usuario

Sentiotec

Sentiotec Pro B Manual de usuario

Sentiotec

Sentiotec just sauna combi Manual de usuario

Sentiotec

Sentiotec Karibu Modern FinnischPlug'n'Play Manual de usuario

Sentiotec

Sentiotec Wave.com4 infra Manual de usuario

Sentiotec

Sentiotec IS1 P-IS1-T Manual de usuario

Sentiotec

Sentiotec Pro D2 Manual de usuario

Sentiotec

Sentiotec Pro C3 Manual de usuario

Sentiotec

Sentiotec just sauna fin Manual de usuario

Sentiotec

Sentiotec A2 Manual de usuario

Sentiotec

Sentiotec just sauna combi series Manual de usuario

Sentiotec

Sentiotec CV 41 Manual del operador

Sentiotec

Sentiotec Pro B2 Manual de usuario

Sentiotec

Sentiotec K1 Next Manual de usuario

Sentiotec

Sentiotec PRO-B3 Manual de usuario

Sentiotec

Sentiotec IS1 Manual de usuario

Sentiotec

Sentiotec time4wellness K2 NEXT Manual de usuario

Sentiotec

Sentiotec A1 Manual de usuario

Sentiotec

Sentiotec CK 41 Manual de usuario

Sentiotec

Sentiotec Pro-C2 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
