Mounting and operating instructions

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 2 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

Table of contents

SAFETY AND PRECAUTIONS 3

PRODUCT DESCRIPTION 4

ARTICLE CODES 4

INTENDED AREA OF USE 4

TECHNICAL DATA 4

STANDARDS 4

OPERATIONAL DIAGRAMS 5

WIRING AND CONNECTIONS 5

MOUNTING INSTRUCTIONS IN STEPS 5

VERIFICATION OF INSTALLATION 8

OPERATING INSTRUCTIONS 8

TRANSPORT AND STORAGE 9

WARRANTY AND RESTRICTIONS 9

MAINTENANCE 9

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 3 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

SAFETY AND PRECAUTIONS

Read all the information, the datasheet, Modbus map, mounting and operating

instructions and study the wiring and connection diagram before working with the

product. For personal and equipment safety, and for optimum product performance,

make sure you entirely understand the contents before installing, using or maintaining

this product.

For safety and licensing (CE) reasons, unauthorised conversion and/ or modiﬁcations

of the product are inadmissible.

e product should not be exposed to abnormal conditions, such as extreme

temperatures, direct sunlight or vibrations. Long-term exposure to chemical

vapours in high concentration can aﬀect the product performance. Make sure the

work environment is as dry as possible; avoid condensation.

All installations shall comply with local health and safety regulations and local

electrical standards and approved codes. is product can only be installed by

an engineer or a technician who has expert knowledge of the product and safety

precautions.

Avoid contacts with energised electrical parts. Always disconnect the power

supply before connecting, servicing or repairing the product.

Always verify that you apply appropriate power supply to the product and use

appropriate wire size and characteristics. Make sure that all the screws and nuts

are well tightened and fuses (if any) are ﬁtted well.

Recycling of equipment and packaging should be taken into consideration and these

should be disposed of in accordance with local and national legislation/regulations.

In case there are any questions that are not answered, please contact your

technical support or consult a professional.

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 4 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

PRODUCT DESCRIPTION

e SPVL8-010-EP is a speed controller and monitoring device for Modbus RTU

fans with DCI interface (EBM-Papst protocol). e Modbus RTU/DCI interface (DCI

Gen. 1) is used to conﬁgure, control and monitor up to 20 fans. Fans featuring the

EBM-Papst Modbus/DCI interface will be addressed automatically by the SPVL8-EP

controller. is results in much faster commissioning.

ARTICLE CODES

Code Supply voltage

SPVL8-010-EP 85—305 VAC / 50—60 Hz

INTENDED AREA OF USE

■Speed control, monitoring and commissioning of EBM-Papst ﬁlter fan units (FFUs)

with EC motor

TECHNICAL DATA

■Modbus RTU/DCI interface (daisy chain interface)

■Linear digital output signal according to the position of the potentiometer

■Automatic initial conﬁguration of each fan

■Automatic assignment of network ID of each fan

■Control from low to high or from high to low speed, selectable via Modbus RTU

holding registers

■Fan status monitoring via RGB LED and Modbus input registers

■OFF position

■Bootloader for updating the ﬁrmware via Modbus RTU

■Adjustable minimum (Vmin) and maximum (Vmax) output value via Modbus RTU

holding registers

■Flush or surface mounting

■Push in terminal block

■Compatible with EBM-Papst K3G-series FFU with Modbus RTU/DCI interface

■Enclosure:

►External: ASA, white colour (28049P ), IP54 (according to EN 60529)

►Internal: polyamide, natural colour, IP44 (according to EN 60529)

■Operating ambient conditions:

►temperature: 0—40 °C

►rel. humidity: 5—95 % rH (non-condensing)

STANDARDS

■Low Voltage Directive 2014/35/EU

►60529:1991 Degrees of protection provided by enclosures (IP Code)

Amendments AC:1993, A1:2000, A2:2013, AC:2016-12 and AC:2019-12 to EN

60529

►EN 60730-1:2011 Automatic electrical controls for household and similar use.

Part 1: General requirements

►EN 60730-2-8:2002 Automatic electrical controls for household and similar

use. Part 2-8: Particular requirements for electrically operated water valves,

including mechanical requirements Amendment A1:2003 to EN 60730-2-8

►EN 60730-2-9:2010 Automatic electrical controls for household and similar use.

Part 2-9: Particular requirements for temperature sensing controls

■EMC directive 2014/30/EU:

►EN 60730-1:2011 Automatic electrical controls for household and similar use -

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 5 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

Part 1: General requirements

►EN 60730-2-8:2002 Automatic electrical controls for household and similar

use - Part 2-8: Particular requirements for electrically operated water valves,

including mechanical requirements Amendment A1:2003 to EN 60730-2-8

►EN 60730-2-9:2010 Automatic electrical controls for household and similar use

- Part 2-9: Particular requirements for temperature sensing controls

■RoHs Directive 2011/65/EU – Restriction of use of certain hazardous substances

in electrical and electronic equipment

►EN IEC 63000:2018 Technical documentation for the assessment of electrical

and electronic products with respect to the restriction of hazardous substances

OPERATIONAL DIAGRAMS

From low to high speed From high to low speed

Output [%]

Min range

Max range

100 %

10 %

Max

Off

Switch

0 %

Potentiometer position

Min

Output [%]

Min range

Max range

10 %

100 %

Max

Off

Switch

0 % Potentiometer position

Min

WIRING AND CONNECTIONS

LPower supply, line (85—305 VAC / 50—60 Hz)

NPower supply, neutral (85—305 VAC / 50—60 Hz)

8 - DCI Modbus DCI output

7 - GND Ground

6 and 2 - /B Modbus RTU (RS485), signal /B

5 and 4 Do not connect

3 and 1 - A Modbus RTU (RS485), signal A

Connections

Supply cables Cable cross section: 0,5—1,5 mm2

Modbus DCI communication /

RS485 + DCI Cat5 cable / UTP

DCI

GND

RJ45

MOUNTING INSTRUCTIONS IN STEPS

Before you start mounting the unit, read carefully “Safety and Precautions” and

follow the steps:

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 6 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

Flush mounting

1. Disconnect the mains supply.

2. Remove the knob by pulling it out.

3. Unscrew the washer to remove the cover of the external enclosure.

4. Do the wiring according to the wiring diagram (see Fig. 1 Wiring and connections).

5. Mount the internal enclosure into the wall according to the mounting dimensions

shown in Fig. 2 Mounting dimensions - ﬂush mounting.

Fig. 1 Wiring and connections

Modbus RTU (RS485)

Power supply:

230 VAC / 50—60 Hz

DCI

GND

Modbus DCI

DCI

GND

RJ45

Fig. 2 Mounting dimensions - ﬂush mounting

20 38

Correct Incorrect

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 7 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

6. Mount back the cover and secure it with the washer.

7. Put back the knob and turn it to oﬀ position.

8. Install all Modbus/DCI controlled motors and carry out electrical wiring according

to their datasheet.

9. Connect the controller to the motors using appropriate cables. See Fig. 4

Connection.

Fig. 4 Connection

SPVL8-010-EP

controller

EBM-papst FFU 1 EBM-papst FFU 2 EBM-papst FFU X

10. Turn on the power supply.

11. Turn on the controller.

12. All motors connected to the controller will be conﬁgured automatically.

13. Check the connection status via the LED indication. Turn the knob of the controller

to control the speed of the FFUs.

14. Customise the factory settings to the desired ones via the 3SModbus software

or SenteraWeb. For the default factory settings, see the Modbus register map.

Surface mounting

1. Disconnect the mains supply.

2. Remove the knob by pulling it out and open the cover.

3. Unscrew the washer to remove the cover of the external enclosure.

4. Mount the external enclosure onto the surface by means of the screws and dowels

adhering to the mounting dimensions shown in Fig. 3 Mounting dimensions -

surface mounting.

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 8 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

Fig. 3 Mounting dimensions - surface mounting

20 38

Correct Incorrect

5. Insert the cables through the grommets.

6. Do the wiring according to the wiring diagram (see Fig. 1 Wiring and connections).

7. Insert the internal enclosure into the external one and ﬁx it using the screws.

Mount back the cover and secure it with the washer.

8. Put back the knob and turn it to oﬀ position.

9. Install all Modbus DCI controlled motors and carry out electrical wiring according

to their datasheet.

10. Connect the controller to the motors using appropriate cables. See Fig. 4

Connection.

11. Turn on the power supply.

12. Turn on the controller.

13. All motors connected to the controller will be conﬁgured automatically.

14. Check the connection status via the LED indication. Turn the knob of the controller

to control the speed of the FFUs.

15. Customise the factory settings to the desired ones via the 3SModbus software

or SenteraWeb. For the default factory settings, see the Modbus register map.

For the complete Modbus register data, refer to the product Modbus Register

Map, which is a separate document attached to the article code on the website

and contains the registers list. Products with earlier ﬁrmware versions may not be

compatible with this list.

NOTE

Optional settings

To assure correct communication, the NBT needs to be activated. See the Modbus

NOTE Mount the unit so that the terminal block and connections are at the lower side.

www.sentera.eu

MIW-SPVL8-010-EP-EN-000-23/06/2023 9 - 9

back to the table of contents

SPVL8-010-EP EC FAN CONTROLLER WITH

MODBUS/DCI OUTPUT

VERIFICATION OF INSTALLATION

ATTENTION Use only tools and equipment with non-conducting handles when working on

electrical devices.

As soon as the unit has detected at least one FFU, addressing and conﬁguration will

be completed automatically.

For installation status, please check the LED indications in the product datasheet.

OPERATING INSTRUCTIONS

ATTENTION Use only tools and equipment with non-conducting handles when working on

electrical devices.

e unit is intended for use with EC fans / motors. It restarts after power failure.

In case of faulty operation, please check if:

■the right voltage is applied

■all connections are correct

■Modbus communication is working and all settings are accessible via Modbus RTU

TRANSPORT AND STORAGE

Avoid shocks and extreme conditions; stock in original packing.

WARRANTY AND RESTRICTIONS

Two years from the delivery date against defects in manufacturing. Any modiﬁcations

or alterations to the product after the date of publication relieve the manufacturer

of any responsibilities. e manufacturer bears no responsibility for any misprints or

mistakes in this data.

MAINTENANCE

In normal conditions this product is maintenance-free. If soiled, clean with a dry or

damp cloth. In case of heavy pollution, clean with a non-aggressive product. In these

circumstances the unit should be disconnected from the supply. Pay attention that

no ﬂuids enter the unit. Only reconnect it to the supply when it is completelydry.

Tabla de contenidos

Otros manuales de Controladores de Sentera Controls

Sentera Controls

Sentera Controls RMFPM-2R Manual de servicio

Sentera Controls

Sentera Controls ECA-1-10-AC Manual de servicio

Sentera Controls

Sentera Controls ECMF8-EW Manual de servicio

Sentera Controls

Sentera Controls MTY-0-05-AT Manual de servicio

Sentera Controls

Sentera Controls MTY-7-15-AT Manual de servicio

Sentera Controls

Sentera Controls RTR-1 Manual de servicio

Sentera Controls

Sentera Controls RDCZ Series Manual de servicio

Sentera Controls

Sentera Controls RDCV Manual de servicio

Sentera Controls

Sentera Controls STRS1 Series Manual de servicio

Sentera Controls

Sentera Controls SD Manual de servicio

Sentera Controls

Sentera Controls SER-1 Series Manual de servicio

Sentera Controls

Sentera Controls GTEX1-60-DM Manual de servicio

Sentera Controls

Sentera Controls HPSPX-2 Manual de servicio

Sentera Controls

Sentera Controls RMFPX-2R Manual de servicio

Sentera Controls

Sentera Controls MTP-D010 Series Manual de servicio

Sentera Controls

Sentera Controls RTVS8 Series Manual de servicio

Sentera Controls

Sentera Controls EVSS1 Series Manual de servicio

Sentera Controls

Sentera Controls STVS1 Series Manual de servicio

Sentera Controls

Sentera Controls HPSPX-LP Manual de servicio

Sentera Controls

Sentera Controls AH2A1-6 Manual de servicio

Sentera Controls

Sentera Controls GTTE1 Manual de servicio

Sentera Controls

Sentera Controls TCMF8-DM Manual de servicio

Sentera Controls

Sentera Controls SDX-DM Series Manual de servicio

Sentera Controls

Sentera Controls STR-1 Manual de servicio

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
