SENSTAR Symphony 7.2 Series Manual de usuario

Senstar Symphony

7.2.x

User Guide

Contents

Introduction........................................................................................................................................ 6

Network configuration............................................................................................................6

Getting started......................................................................................................................... 7

Symphony Server............................................................................................................................... 9

Symphony Server services......................................................................................................9

Devices.....................................................................................................................................11

Cameras........................................................................................................................ 11

Templates..................................................................................................................... 17

Hardware...................................................................................................................... 19

Access control devices................................................................................................ 19

Device tree....................................................................................................................20

Carousels.......................................................................................................................21

Security....................................................................................................................................22

Users..............................................................................................................................22

Groups...........................................................................................................................24

Security profiles........................................................................................................... 25

Logins............................................................................................................................ 34

Active Directory authentication................................................................................. 34

Security authentication...............................................................................................35

Watermarking.............................................................................................................. 35

Rules........................................................................................................................................ 35

Create a rule................................................................................................................ 36

Edit a rule..................................................................................................................... 36

Delete a rule.................................................................................................................36

Events............................................................................................................................ 37

Action sets.................................................................................................................... 39

Schedules...................................................................................................................... 45

Licenses................................................................................................................................... 46

Refresh licenses........................................................................................................... 46

Show license XML........................................................................................................46

Settings....................................................................................................................................46

Servers...........................................................................................................................46

General..........................................................................................................................49

Notifications..................................................................................................................56

Cloud services.............................................................................................................. 57

Maintenance.................................................................................................................57

Backup and restore.....................................................................................................58

Analytics.................................................................................................................................. 59

Add a video analytic license to a camera................................................................ 60

TCP Listener..................................................................................................................60

Analog Video Signal Loss........................................................................................... 60

Automatic License Plate Recognition....................................................................... 60

Camera Tampering......................................................................................................64

Crowd Detection.......................................................................................................... 65

Image Stabilization......................................................................................................68

Senstar Symphony User Guide 2

Contents

Indoor People Tracking.............................................................................................. 68

Left and Removed Item Detection............................................................................71

Motion Detection.........................................................................................................72

Outdoor People and Vehicle Tracking......................................................................73

PTZ Auto-Tracking....................................................................................................... 76

Face Recognition..........................................................................................................77

Calibrate a camera...................................................................................................... 79

Symphony Client.............................................................................................................................. 81

Open command..................................................................................................................... 81

View log files.......................................................................................................................... 81

View events.............................................................................................................................82

Lock times...............................................................................................................................82

Adjust the number of locked camera view panels................................................. 82

Customize the toolbar.......................................................................................................... 82

Disable single sign-on...........................................................................................................83

Device tree..............................................................................................................................83

Search the device tree................................................................................................83

Display a list of users viewing a camera..................................................................83

Suspending access to video.......................................................................................83

Create a camera tour..................................................................................................84

Change IO state...........................................................................................................85

Link a camera view..................................................................................................... 85

Server list................................................................................................................................ 85

Enable the server list.................................................................................................. 85

Camera view panels.............................................................................................................. 85

View a camera..............................................................................................................86

View a Thin Client........................................................................................................86

View picture in picture................................................................................................86

View instant replay......................................................................................................87

Save a camera view.................................................................................................... 87

Load a camera view....................................................................................................87

Open a docked camera view..................................................................................... 87

Open a floating camera view.................................................................................... 87

Add a camera view panel...........................................................................................87

Add an alarm............................................................................................................... 88

Add an alarm indicator...............................................................................................88

Configure a camera view panel................................................................................ 88

Search............................................................................................................................91

Export video to file......................................................................................................91

Export video to the cloud...........................................................................................92

View video by date......................................................................................................92

Record video manually............................................................................................... 92

Open by address......................................................................................................... 93

View summary video...................................................................................................93

Video controls.............................................................................................................. 93

PTZ controls..................................................................................................................95

Camera controls.......................................................................................................... 96

Timeline...................................................................................................................................96

Timeline colors.............................................................................................................96

Display the timeline.................................................................................................... 97

Senstar Symphony User Guide 3

Contents

Maps........................................................................................................................................ 97

Add a map....................................................................................................................97

Add a GIS map.............................................................................................................98

View a map...................................................................................................................98

Add a device to a map............................................................................................... 98

Map icons..................................................................................................................... 98

Display field of view....................................................................................................99

Messenger.............................................................................................................................. 99

Send a message.......................................................................................................... 99

Carousels...............................................................................................................................100

Add a carousel........................................................................................................... 100

Edit a carousel........................................................................................................... 100

Delete a carousel.......................................................................................................100

Settings..................................................................................................................................101

View camera activity................................................................................................. 101

Customize the toolbar.............................................................................................. 101

Change timeline colors.............................................................................................101

Startup settings......................................................................................................... 102

Display settings..........................................................................................................102

Alarms settings.......................................................................................................... 103

Video settings.............................................................................................................104

Customize settings.................................................................................................... 106

Sound settings........................................................................................................... 107

Regional settings....................................................................................................... 108

Global settings........................................................................................................... 108

Bookmarks............................................................................................................................108

Create a bookmark................................................................................................... 108

Delete a bookmark....................................................................................................108

Video wall..............................................................................................................................109

Register a client.........................................................................................................109

Create a video wall....................................................................................................109

Server configuration............................................................................................................109

Connect to a server...................................................................................................109

Disconnect from a server.........................................................................................110

Delete recorded video.............................................................................................. 110

Get information about the server...........................................................................110

Configure the server manually................................................................................110

Windows authentication...........................................................................................111

Reports.................................................................................................................................. 111

Create an alarm report.............................................................................................111

Create an alarm statistics report............................................................................ 112

Create a Face Recognition report........................................................................... 113

Create a heat map image report............................................................................ 115

Create an LPR report................................................................................................ 116

Create an object counts report............................................................................... 117

Create an object counts across a line report........................................................ 118

Create an object statistics report............................................................................119

Edit a report...............................................................................................................120

Run a report...............................................................................................................120

Alarms....................................................................................................................................120

Disable alarms for a camera................................................................................... 120

Senstar Symphony User Guide 4

Contents

Disable alarms for a server..................................................................................... 121

Alarm console............................................................................................................ 121

Visual tracking......................................................................................................................123

Add a visual tracking link.........................................................................................123

Symphony Web Client...................................................................................................................124

Log in to the Web Client.................................................................................................... 124

Configure the Web Client...................................................................................................124

Symphony Player........................................................................................................................... 125

Install the Player..................................................................................................................125

Enable watermark verification...........................................................................................125

Play a video file....................................................................................................................125

Legal information.......................................................................................................................... 127

Third-party attributions...................................................................................................... 127

Senstar Symphony User Guide 5

Introduction

Senstar Symphony is an award-winning, intelligent video surveillance software that offers a single,

innovative, and open IP video platform for video management, video analytics, system integration,

and alarm management.

Symphony installs on standard IT hardware, supports both analog and IP cameras from hundreds of

manufacturers, provides a feature-rich, easy-to-use interface, and incorporates IT friendly features

to make administration simple. The Symphony Server can reside on a single computer or multiple

computers in a server farm.

Symphony comprises two main components: the Symphony Server and the Symphony Client. You

can use the server configuration interface to configure the Symphony Server and the client interface

to interact with the cameras connected to Symphony.

Symphony also includes the Symphony Web Client and the Symphony Player. The Web Client

provides functionality similar to the Client, but in a Web browser and without requiring installed

software. The Player allows you to play video files that you export from Symphony.

Related concepts

Symphony Server on page 9

Symphony Client on page 81

Symphony Web Client on page 124

Symphony Player on page 125

Network configuration

The Symphony Server uses the network ports below by default.

Single-server network configuration

Port Protocol Description

80 TCP HTTP web server that forwards to HTTPS on port 443 for

server configuration

443 TCP HTTPS secure web server for server configuration

8433 TCP Mobile Bridge (mobile listening port)

8488 TCP Mobile Bridge (video proxy listening port)

50000 TCP HTTP web server for the web client

50001 TCP Web service (control and notification port)

50010 TCP RTSP live and historical video

50014 TCP HTTPS secure web server for the web client (if configured)

Senstar Symphony User Guide 6

Introduction

Server farm network configuration

Port Protocol Description

80 TCP HTTP web server that forwards to HTTPS on port 443 for

server configuration

443 TCP HTTPS secure web server for server configuration

1433 TCP Outbound rule for SQL server on the SQL server firewall

1434 UDP Port for SQL communication

5045 UDP Port for health checks

8433 TCP Mobile Bridge (mobile listening port)

8488 TCP Mobile Bridge (video proxy listening port)

50000 TCP HTTP web server for the web client

50001 TCP Web service (control and notification port)

50004 TCP Port for server sub-services

50010 TCP RTSP live and historical video

50014 TCP HTTPS secure web server for the Web Client (if configured)

Additional network configuration

Port Protocol Description

5041 TCP Access control

50002 TCP SSO authentication requests

50005 TCP Video wall

50015 TCP SSO authentication requests and cryptography

Getting started

Task Topic

I want to add a digital camera to Symphony. Add a camera manually

Add a camera automatically

I want to save video to a file. Export video

I want to view video from a camera. View a camera

Senstar Symphony User Guide 7

Introduction

Task Topic

I want to add an alert to Symphony. Create a rule

I want to view an event across different cameras. View Camera Activity

Related tasks

Add a camera manually on page 12

Add a camera automatically on page 12

View a camera on page 86

Export video to file on page 91

Create a rule on page 36

View camera activity on page 101

Senstar Symphony User Guide 8

Symphony Server

The Symphony Server includes functionality to manage devices, security, rules, sites, and settings.

You configure the Symphony Server using the server configuration interface. You can access the

server configuration interface directly in a browser or from the client interface.

Related concepts

Introduction on page 6

Symphony Client on page 81

Symphony Web Client on page 124

Symphony Player on page 125

You can open the server configuration interface in a browser.

You can also access the Web Client from the server configuration interface.

1. In a browser, navigate to the IP address of your Symphony Server.

2. In the language list, select your language.

3. Type your username and password.

4. Click Server Configuration.

Symphony Server services

The Symphony Server runs the following services.

Service Function

AI Authentication Service • Performs single sign-on authentication

• Log file prefix:

•sso

AI AxisPACSListener • Communicates with Axis access control devices

• Optional service/Manual installation

• Log file prefix:

•aacl

AI DataAccessService • Communicates with the Symphony database

• Log file prefix:

•da

AI Enterprise Management

Service

• Communicates with the Enterprise Manager

• Updates Symphony Server software automatically when using

Enterprise Manager to make configuration changes

• Log file prefix:

•fs

Senstar Symphony User Guide 9

Symphony Server

Service Function

AI InfoService • Hosts the Symphony Web service that receives all requests from the

Symphony Client

• Hosts the Web server for the server configuration interface

• Retrieves timeline data from footage storage

• Log file prefixes:

•is (information service)

•isac (access control)

•isbk (automatic backup)

AI Mobile Bridge • Facilitates communication between mobile devices and the Symphony

Server

• Facilitates communication between Thin Client devices and the

Symphony Server

• Log file prefix:

•mo

AI NetSendHist • Retrieves historical video from the footage storage

• Streams video

• Creates historical images

• Log file prefix:

•hs

AI OPCServer • Communicates with the OPC Server

• Optional service/Manual installation

• Log file prefix:

•op

AI Scheduler • Polls hardware alarm inputs

• Generates alarms

• Generates reports

• Removes expired video files

• Retrieves search results (video and XML) from the NAS

• Log file prefixes:

•sc (scheduler)

•scac (actions)

•scax (access)

•sccl (cleaner)

•sccp (CPU/memory)

•scis (multicaster)

•scpm (PTZ)

•scse (searches)

AI SNMP Registry • Registers sub-agents

Senstar Symphony User Guide 10
