Sennheiser Ew 500-935 g3 Manual de usuario

• Sturdy metal housing

• PC-supported frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Wireless microphone with a quick-change microphone head from the e 900 Series

• Large range of replaceable microphone heads from the successful evolution Series

• NEW: Ethernet port for connecting to the Wireless Systems Manager (WSM) software for control via computer –

this delivers a good overview of monitoring and professional data management for multi-channel systems

• NEW: Wireless synchronization of transmitters via infrared interface

• NEW: Enhanced frequency bank with up to 32 compatible frequencies

• NEW: 42 MHz bandwidth  1680 switchable frequencies

• NEW: Increased range for audio sensitivity

• NEW: Large, illuminated dot matrix display with warning indicator

• NEW: More control options (menu)

• NEW: Enhanced AF frequency range

• NEW: Switchable RF output power

• NEW: Contacts for recharging the BA 2015 accupack directly in the transmitter

• Soundcheck mode

• Integrated equalizer

• 2 AA batteries for more than 8 hours of use

• 4-level charge indicator for transmitter battery

• HDX compander for crystal-clear sound

• True diversity receiver for optimum reception

• Incl. installation kit for 19" rack mounting (1 U)

Lends strong voices a strong sound –

the 500 series vocal set ensures brilliant sound,

even during quiet tones.

This means that professional soul and rock

voices sound as perfectly nuanced as classical

singing voices. Experienced sound engineers

rely on this set, especially for large stages and

unusual live events.

Pros can select from three different

microphone heads with cardioid and

supercardioid directional patterns.

You Know

You CanVocal Set

500 Series

Vocal

Set

• Sturdy metal housing (transmitter & receiver)

• Automatic frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Various optional quick-change microphone heads available from

the e 800 and e 900 series

Designed and engineered in Germany

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com Formore accessories, please visit www.sennheiser.com

Technical Data

ew 500 g

Modulation wideband FM

Frequency ranges 516-558, 566-608, 626-668, 734-776, 780-822, 823-865

Transmission/Receiving frequencies 20 channel banks, 6 xed banks, 32 factory preset channels each

Switching bandwidth 42 MHz

Noise reduction system Sennheiser HDX

AF frequency response 25 – 18.000 Hz

S/N ratio (at 1mV and peak deviation) ≥ 115 dBA

THD (at nominal deviation and 1 kHz) ≤ 0,9 %

EM 500 g

SKM 500 g

Delivery includes

Receiver principle True Diversity

Sensitivity (with HDX, peak deviation) <2 µV at 52 dBAeff S/N

Adjacent channel rejection ≥ 75 dB

Intermodulation attenuation ≥ 70 dB

Blocking ≥ 75 dB

Pilot-tone squelch detachable

Antenna inputs 5 BNC sockets

AF output voltage (at peak deviation, 1kHz AF) ¼“ (6.3 mm) jack socket, unbalanced: +12 dBu XLR socket,

balanced: +18 dBu

Power supply 12 V DC

Dimensions 202 x 212 x 43 mm (7.95" x 8.35" x 1.69")

Weight approx. 980 g (2.16 lbs)

RF output power at 50 O typ. 30/10mW, switchable

AF frequency response 80 – 18.000 Hz

Power supply 2 AA batteries, 1.5 V

Nominal voltage 2.4 V

Operating time typ. 8h

Dimensions Ø 50 x 265 mm (Ø 1.97" x 10.43")

Weight approx. 450 g (15.87 oz)

• EM 500 g rack-mount receiver

• SKM 500 g handheld transmitter

• MZQ 1 microphonce clip

• GA 3 rackmount adapter

For recommended accessories please visit www.sennheiser.com

ew 500-935 / 945 / 965 g
