Sennheiser Evolution E 901 Manual de usuario

e 901

Bedienungsanleitung

Instruction manual

Notice d‘emploi

Istruzioni per l‘uso

Instrucciones de uso

Manual de utilização

Gebruiksaanwijzing

Инструкция по эксплуатации

使用说明

Stage Microphones









1 2

3 4

125 Hz

250 Hz

500 Hz

1,000 Hz

2,000 Hz

4,000 Hz

8,000 Hz

16,000 Hz

30°

0°

180°

150°

120°

60°

90°

30°

0°

180°

150°

120°

60°

90°

- 50

- 60

- 70

- 80

- 90

- 40

dBV

0°, 1 m

0°, 5 cm

Important safety information

• Please read this instruction manual carefully and completely before

using the product.

• Make this instruction manual easily accessible to all users at all

times.

• Always include this instruction manual when passing the product on

to third parties.

Before operation

• Never open the housing of the product. If products are opened by

customers in breach of this instruction, the warranty becomes null

and void.

• Only use attachments, accessories or spare parts specified by

Sennheiser.

During operation

• Liquids entering the product can short-circuit the electronics or

damage the mechanics. Keep all liquids away from the product.

• Solvents or cleansing agents can damage the surface of the product.

Only use a soft, slightly damp cloth to clean the product.

• Do not expose the product to extreme temperatures.

After operation

• Handle the product with care and store it in a clean, dust-free

environment.

Intended use

Intended use includes:

• having read this instruction manual, especially the chapter “Impor-

tant safety information”,

• using the product within the operating conditions and limitations

described in this instruction manual.

“Improper use” means using the product other than as described in

this instruction manual, or under operating conditions which differ

from those described herein.

The e 901

A balanced kick sound to set and forget

The e 901 is a rugged boundary microphone with an extraordinary

ability to handle high sound pressure levels. Tailored to give the kick

drum a highly precise, very dry sound character, the e 901 realistically

captures every lightning fast attack.

The positioning of the e 901 in a bass drum couldn‘t be simpler: just

put it in – done. The integrated preamp and gold-plated XLR connector

have proven themselves to be exceptionally practical on stage.

Features

• Condenser microphone

• Highly precise and dry kick drum sound

• Natural sound, fast transient response

• Designed especially for high sound pressure levels

• Integrated preamp and gold-plated XLR connector

• Non-slip rubber damping plate on base

• Extremely rugged metal housing

Package contents

1 e 901 microphone

1 pouch

1 instruction manual

Product overview A*

1 Sound inlet basket

2 XLR-3 connector

3 Rubber damping plate

4 Mounting slots

Diagrams can be found on the cover pages.

Using the microphone

Positioning the microphone in a drum B

XPlace the e 901 in the drum. Position the microphone so that its

sound inlet basket 1is directed upwards.

Pos. Resulting sound Commentary

B.1 • Much resonance

• Much attack

• Less attack: Turn

the microphone

away from where

the beater strikes.

Position the microphone at the bottom

of the kick drum, approx. 10–20 cm

from the batter head.

B.2 • The e 901 is used

for picking up the

attack, the e 902

for picking up the

fundamental.

Combined with an e 902 positioned at

the resonant head. The lower micro-

phone must be phase-reversed to

avoid phase-cancellation effects due

to the second microphone being on the

other side of the drumskin.

Positioning the microphone on sound-reflecting sur-

faces B

XPlace the e 901 on the desired sound-reflecting surface. Position the

microphone so that its sound inlet basket 1is directed towards the

sound source.

Pos. Resulting sound Commentary

B.3 • Less room resonance

portions or comb filter

elements

• Improved speech

intelligibility

• Greater gain reserves in

contrast to free-standing

microphones

Lying on the altar or lectern.

Unobtrusive due to flat

design. No microphones in

the field of vision.

B.4 • Less room resonance in

contrast to free-standing

microphones

Lying on the conference

table, directed towards the

conference participants.

Microphone must not be

covered by papers, folders or

similar objects.

Pos. Resulting sound Commentary

B.5 • Less room resonance in

contrast to free-standing

microphones

• Improved speech intelligi-

bility

Lying at the edge of the

stage and directed towards

the stage. As spot micro-

phone of the PA system or

for monitoring purposes

in the theater cloakrooms.

Excellent rejection of rumble

noise; if necessary, place the

microphone on a soft pad

(e.g. mousepad).

If necessary, combine with

overhead microphones (e.g.

Sennheiser ME 36 with

MZH 30 B & MZC 30).

Positioning the monitor loudspeakers

XTo prevent feedback and crosstalk, position your monitor loudspeak-

ers in the angle area of the highest cancellation of the microphone

(approx. 180°).

Cleaning and maintaining the e 901

Caution Liquids can damage the electronics of the product!

Liquids entering the housing of the product can cause a

short-circuit and damage the electronics.

XKeep all liquids away from the product.

XDo not use any solvents or cleansing agents.

XOnly use a soft, slightly damp cloth to clean the product.

Specifications

Transducer principle pre-polarized condenser microphone

Frequency response 20 ... 20,000 Hz

Pick-up pattern half-cardioid

Sensitivity

(free field, no load at 1 kHz) 0.5 mV/Pa

Nominal impedance (at 1 kHz) < 100 Ω

Min. terminating impedance 1 kΩ

Connector XLR-3

Dimensions 126.5 x 105 x 26.5 mm

Weight 550 g

The polar diagram and the frequency response curve Ccan be found on

the cover pages.

Connector assignment

+ +

XLR 6.3 mm

XLR

6.3 mm

balanced

XLR

Manufacturer Declarations

Warranty

Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months

on this product.

For the current warranty conditions, please visit our website at

www.sennheiser.com or contact your Sennheiser partner.

FOR AUSTRALIA ONLY

Sennheiser goods come with guarantees that cannot be excluded

under the Australian Consumer Law. You are entitled to a replacement

or refund for a major failure and compensation for any other reason-

ably foreseeable loss or damage. You are also entitled to have the

goods repaired or replaced if the goods fail to be of acceptable quality

and the failure does not amount to a major failure.

This warranty is in addition to other rights or remedies under law.

Nothing in this warranty excludes, limits or modifies any liability of

Sennheiser which is imposed by law, or limits or modifies any remedy

available to the consumer which is granted by law.

To make a claim under this warranty, contact

Sennheiser Australia Pty Ltd, Unit 3, 31 Gibbes Street Chatswood NSW

2067, AUSTRALIA.

Phone: (02) 9910 6700, email: [email protected].

All expenses of claiming the warranty will be borne by the person

making the claim.

The Sennheiser International Warranty is provided by Sennheiser

Australia Pty Ltd (ABN 68 165 388 312), Unit 3, 31 Gibbes Street

Chatswood NSW 2067 Australia.

In compliance with the following requirements

• WEEE Directive (2012/19/EU)

Please dispose of this product at the end of its operational

lifetime by taking it to your local collection point or recycling

center for such equipment.

CE Declaration of Conformity

• RoHS Directive (2011/65/EU)

• EMC Directive (2004/108/EC)

The declaration is available at www.sennheiser.com.

e 608

e 614

e 609 silver

e 604

e 602-II

e 835

e 845

e 865

e 901

e 902

e 904

e 906

e 908

e 914

e 935

e 945

e 965
