Sennheiser Ew 152 G3 Manual de usuario

• Sturdy metal housing

• Automatic frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Programmable MUTE switch

• Headset microphone with optimized acoustics

• NEW: Wireless synchronization of transmitters via infrared interface

• NEW: Enhanced frequency bank management with up to 12 compatible frequencies per bank

• NEW: 42 MHz bandwidth  1680 switchable frequencies

• NEW: Increased range for audio sensitivity

• NEW: Easy-to-read illuminated dot matrix display

• NEW: 4-level charge indicator for transmitter battery

• NEW: More control options (menu)

• NEW: Enhanced AF frequency range

• NEW: Soundcheck mode

• NEW: Integrated equalizer

• NEW: Contacts for recharging the BA 2015 accupack directly in the transmitter

• 2 AA batteries for more than 8 hours of use

• HDX compander for crystal-clear sound

• True diversity receiver for optimum reception

• High RF output power for large range

• Suitable for 19" rack mounting (1 U)

Regardless of whether singer, dancer or ﬁtness

trainer – those who want to move across the

entire stage while keeping their hands free

during a performance will love the gHeadSet.

On the one hand, the condenser headset micro-

phone is ultra-light – so light, in fact, that you

will forget you’re wearing it during the show.

And on the other, it supplies a powerful sound,

making it able to reach the very last row in

crystal-clear quality.

You Know

You CanHeadset

100 Series

Head Head

Head

Set

• Sturdy metal housing (transmitter & receiver)

• Automatic frequency management for transmitter and receiver

• Tunable UHF frequencies within a large switching bandwidth

• Programmable MUTE switch

• Headset microphone with optimized acoustics

Designed and engineered in Germany

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

For more accessories, please visit www.sennheiser.com

Technical Data

ew 100 g

Modulation wideband FM

Frequency ranges 516-558, 566-608, 626-668, 734-776, 780-822, 823-865

Transmission/Receiving frequencies 20 channel banks, 1 xed bank, 12 factory preset channels each

Switching bandwidth 42 MHz

Noise reduction system Sennheiser HDX

AF frequency response 25 – 18.000 Hz

S/N ratio (at 1mV and peak deviation) ≥ 110 dBA

THD (at nominal deviation and 1 kHz) ≤ 0,9 %

EM 100 g

SK 100 g

ME 3-ew

Receiver principle True Diversity

Sensitivity (with HDX, peak deviation) <2,5 µV at 52 dBAeff S/N

Adjacent channel rejection 65 dB

Intermodulation attenuation 65 dB

Blocking 70 dB

Pilot-tone squelch detachable

Antenna inputs 2 BNC sockets

AF output voltage (at peak deviation, 1kHz AF) ¼" (6.3 mm) jack socket, unbalanced: +12 dBu XLR socket,

balanced: +18 dBu

Power supply 12 V DC

Dimensions 190 x 212 x 43 mm (7.48" x 8.35" x 1.69")

Weight approx. 900 g (1.99 lbs)

RF output power at 50 typ. 30 mW

AF frequency response 25 – 18.000 Hz (Line)

80 – 18.000 Hz (Mic)

Max input voltage transmitter / line 3 Veff

Input impedance transmitter / line 40 kO, unbalanced / 1 MO

Power supply 2 AA batteries, 1.5 V

Nominal voltage 2.4 V

Operating time typ. 8h

Dimensions 82 x 64 x 24 mm (3.23" x 2.52" x 0.94")

Weight approx. 160 g (5.64 oz)

Transducer principle condenser

Sensitivity 1.6 mV/Pa

Pick-up pattern cardioid

Max. SPL 150 dB SPL

Delivery includes

• EM 100 g rack-mount receiver

• SK 100 g handheld transmitter

• ME 3-ew headset microphone

For recommended accessories please visit www.sennheiser.com

ew 152 g
