Sennheiser ADN D1 Manual de usuario

FEATURES

Gooseneck microphone with Sennheiser



super-cardioid capsule

High-performance twin loudspeakers



Convenient cabling via RJ45 sockets



Modern industrial design, hidden cable



connections

Strain relief available for ﬁxed



installations

DSP limiter



ARCHITECT’S

SPECIFICATIONS

A digital desktop discussion microphone

unit is provided for use as a delegate ver-

sion for use with a central control unit. The

digital desktop discussion microphone unit

connects to the central control unit via

network using industry standard Category

5 (24 AWG) cabling. The unit shall include

a 15.47“ long gooseneck microphone with

a super-cardioid capsule. A 3.5mm head-

phone output jack shall be included. Twin

loudspeakers are provided in a top-moun-

ted orientation. RJ45 jacks for connec-

tion are provided by hidden connections

beneath the unit; optional strain reliefs

are provided for ﬁxed installations. The

audio signal path shall include a digital

signal processor limiter. Operating voltage

shall be 35vDC to 52.8vDC. Maximum

power consumption shall be 3.8W. Total

harmonic distortion shall be a maximum

of 0.03% at 50mW/16 Ohms. Operating

temperature shall be +10°C to +40°C. The

unit dimensions shall be, without goo-

seneck microphone, 7.28“ x 2.48“ x 5.51“

(WxHxD). Weight shall be approximately

1.5 lbs. The digital desktop delegate

discussion unit shall be manufactured by

Sennheiser and shall be type ADN D1.

The digital delegate unit ADN D1

offers high speech-intelligibility in a modern

design. The gooseneck microphone is equipped

with a super-cardioid capsule that attenuates

unwanted ambient noise efﬁciently. A twin-loudspeaker

system guarantees a homogenous sound level in the

meeting room. The cabling of the units, which is done by

CAT5 cables and hidden connections can be optionally

secured with strain reliefs for ﬁxed installations.

TECHNICAL DATA

Operating voltage................................................ 35 V to 52,8 VDC

Power consumption ............................................max. 3,5 W

Pick-up pattern ....................................................Super-cardioid

THD, total harmonic distortion .........................0,03 % at 50 mW / 16 O

Operating temperature ......................................+10° C to + 40°C

Dimensions (WxHxD)..........................................185 x 63 x 140 mm

(without gooseneck)

7,28“ x 2,48“ x 5,51“

Weight ...................................................................approx. 700 g / 1,5 lbs

DELIVERY INCLUDES

ADN D1 Delegate unit

Quick-Guide

ADN D1Digital delegate discussion unit

DIMENSIONS

PRODUCT VARIANTS

502758 ADN D1 Delegate unit

502759 ADN C1 Chairperson unit

RECOMMENDED ACCESSORIES

ADN TR1, ADN strain relief Cat.No. 504001

SDC CBL RJ45-2, Cat 5 cable 2m Cat.No. 009842

SDC CBL RJ45-3, Cat 5 cable 3m Cat.No. 009843

SDC CBL RJ45-5, Cat 5 cable 5m Cat.No. 009844

SDC CBL RJ45-10, Cat 5 cable 10m Cat.No. 009845

SDC CBL RJ45-20, Cat 5 cable 20m Cat.No. 009846

SDC CBL RJ45-50, Cat 5 cable 50m Cat.No. 009847

ADN CU1-EU central unit Cat.No. 505553

ADN CU1-UK central unit Cat.No. 505554

ADN CU1-US central unit Cat.No. 505555

ADN PS-EU Cat.No. 505546

ADN PS-UK Cat.No. 505547

ADN PS-US Cat.No. 505548

ADN D1 Digital delegate discussion unit

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com
