Sennheiser UI 760 Manual de usuario

UI760 The Multi-Purpose Amplifier

The UI 760 is a Universal Amplifier Box offering

superior features:

Dynamic Volume ControlTM keeps all incoming calls

at the same sound level and prevents sudden noises

from coming through to the headset

Sound Clarity SystemTM reduces background noise

and enhances the caller’s voice

Automatic Power Save function for outstanding

battery lifetime of up to 2 years

Switching between telephone and PC use

Secures compliance with the EU Noise at Work

Directive with a single switch

Integrated Dictaphone interface for economical and

easy call recording

Technical data

Connectors..…………………. modular RJ 9 4/4 and 2.5 mm jack

Battery……………………….. 1.5 volt (IEC LR 14 C)

Dimensions………………….. 32 x 91 x 101 mm

Weight without battery…. 137 grams / 4.9 ounces

Accessories

Included:

1.5 volt C-size battery (IEC LR 14 C)

The UI 760 is the ideal headset interface box and even allows for

economical call recording or integration of a PC into the system.

Main features include:

Easy switching option between handset and headset as well as

between phone and PC use

Microphone mute allows the user to privately converse with

others close by

Large volume control dial for adjusting the signal during the

call for optimal comfort

Three position switch and microphone sensitivity adjustment

ensures simple installation

Secures compliance with the Noise at work directive from EU

by simply setting a switch

Compatible with practically any digital or analogue telephone

Telephone connecting cable (RJ 9 4/4)

Modular to Easy Disconnect cable (Headset bottom cable)

Instruction Manual

Hook hanger (hook with self adhesive tape)

Optional:

Headset stand – for easy storage of headset. The 3-in-1

kit consists of headset stand, desk mount, fixation kit

Dictaphone cable 3.5 mm jack to 3.5 mm jack (for voice

recording)

PC interface cable - RJ 9 4/4 to 2 x 3.5 mm jack

PC USB interface cable - modular to USB

.
