USER’S GUIDE
2
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
Table of Contents
Table of Contents:
Introduction ..................................................................................................................................................................3
Overview .......................................................................................................................................................................4
Precautions ...................................................................................................................................................................5
Setup Instructions
Connecting to a Computer ........................................................................................................................... 6-7
Connecting to an Audio Interface or Sound Card .............................................................................. 8-9
The Mono Button ......................................................................................................................................................9
The Mute Button .........................................................................................................................................................9
Troubleshooting ........................................................................................................................................................10
Specifications .............................................................................................................................................................11
Warranty ...................................................................................................................................................................... 12
3
Thank you for choosing Senal.
The Senal PMC-II is a passive monitor controller that is designed for anyone who
uses powered monitors and needs a precise and easy way to control monitor
volume. Equipped with XLR/TRS combo inputs as well as a TRS stereo mini
input, this controller is compatible with a variety of pro and consumer equipment,
and it can be used anywhere a separate volume controller is needed.
The PMC-II adds the convenience of accurately adjusting the volume of your monitors
without having to access the computer’s or sound card’s volume controls. Designed
to be inserted between powered monitors and a computer, sound card, or audio
interface, it is a suitable and dependable control surface for pro, project, or home
studios. This controller is equipped with a 1/8″ TRS stereo mini input jack so that it
also can be used with an iPod or any mobile device with a stereo mini output.
The PMC-II’s passive design will not alter or color the sound originating on
your computer or other device. With its steel housing and wood panels, the
PMC-II is a stylish and effective addition to any workstation or studio.
Introduction
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
4
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
Overview
Overview
1/8″ (3.5 mm) TRS
Stereo Mini Input
Stereo Stereo
R L
OutputInput
Passive Monitor Controller
Mono Mute
PMC-II
0
-1
-2
-5
-10
-18
-22
-26
-36
-60
-85
dB Attenuation
R L
Volume Control
Knob
Mono Button
Mute Button
XLR/TRS
Combo Inputs
XLR Outputs
1/8″ (3.5 mm) TRS
Stereo Mini Output
5
Precautions
▪ Please read and follow these instructions, and keep this manual in a safe place.
▪ Keep this unit away from water and any flammable gases or liquids.
▪ Clean the unit with a soft, dry cloth.
▪ Do not attempt to disassemble or repair the equipment—doing so will void
the warranty, and Senal will not be responsible for any damage.
▪ All images are for illustrative purposes only.
Precautions
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
6
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
Connecting to a Computer
Setup Instructions
Important! Make sure your powered monitors are turned off so that loud noises or pops
won’t occur when making the connections to the PMC-II.
Connecting to a Computer
To connect the PMC-II to a computer or other device with a 1/8ʺ TRS stereo output, follow
these steps:
1. With a 1/8″ TRS Stereo Mini to 1/8″ TRS Stereo Mini cable, connect the audio output jack
of your computer or device to the stereo mini input of the PMC-II.
Stereo Stereo
R L
OutputInput
Passive Monitor Controller
R L
XLR/F
1/8″TRS Stereo Mini XLR/M
7
Connecting to a Computer
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
2. Connect the outputs of the PMC-II to your monitors.
Monitors with XLR inputs can be connected with XLR cables Monitors with 1/8″ TRS
stereo inputs can be connected via the mini output jack with a 1/8″ TRS stereo mini cable.
3. Set the sound output of your computer to its maximum level.
4. Turn the volume control knob of the PMC-II to full attenuation (all the way to the left).
5. Turn on the monitors.
6. Start playing audio on your computer and gradually turn up the volume control of the
PMC-II to the desired level.
Note: If no sound is heard, see the troubleshooting section on page 10.
8
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
Connecting to an Audio Interface or Sound Card
Connecting to an Audio Interface or Sound Card
To connect the PMC-II to an audio interface, sound card, or other devices with XLR or 1/4ʺ
TRS outputs, follow these steps:
1. Connect the outputs of your interface or sound card to the inputs of the PMC-II.
The PMC-II will accept XLR or 1/4ʺ TRS plugs.
2. Connect the XLR outputs of the PMC-II to your monitors.
3. Set the sound output of your computer to its maximum level.
Stereo Stereo
R LR L
OutputInput
Passive Monitor Controller
XLR/F XLR/MXLR/MXLR/FUSB/Firewire
9
Connecting to an Audio Interface or Sound Card / Mute Button / Mono Button
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
4. Turn the volume control knob of the PMC-II to full attenuation (all the way to the left).
5. Turn on the monitors.
6. Start playing audio on your computer and gradually turn up the volume control of the
PMC-II to the desired level.
Note: If no sound is heard, see the troubleshooting section on page 10.
Mute Button
The mute button quickly silences the sound output. To mute the sound, press the mute
button. To unmute, depress the mute button.
Mono Button
The mono button is a convenient feature for listening to your mixes in mono and check for
balance or phasing issues. To monitor your mix in mono, press the mono button. Depress the
mono button to return to monitoring in stereo.
10
▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪ ▪
Troubleshooting
Troubleshooting
Problem Solution
No sound is
coming out of
the speakers.
If the sound
is coming
directly out of
the computer’s
audio output:
Check the sound preferences on your computer to ensure that
the master volume is at its highest level.
Make sure your speakers are correctly connected to the PMC-II.
Make sure the volume knob of the PMC-II is turned up.
Make sure the mute button is not active.
If the sound is
coming from your
audio interface:
Check your settings in the Sounds and Audio Devices control
panel (Windows) or the Sound Preferences (Mac OS). Make sure
you have selected the appropriate default output device and
that the output volume is turned up to the highest volume.
Make sure your speakers are correctly connected to the PMC-II.
Make sure the volume knob of the PMC-II is turned up.
Make sure the mute button is not active.
