Sena Pi Manual de usuario

BLUETOOTH COMMUNICATION HEADSET

FOR HELMETS

USER’S GUIDE

ENGLISHVersion 1.0.0

1. ABOUT pi 4

1.1 Product Features 4

1.2 Product Details 4

1.3 Package Contents 5

2. INSTALLING THE HEADSET ON YOUR HELMET 6

3. GETTING STARTED 7

3.1 Downloadable Sena Software 7

3.1.1 Sena Utility App 7

3.1.2 Sena Device Manager 7

3.1.3 Firmware Upgrades 7

3.2 Charging 8

3.3 Powering On and Off 8

3.4 Checking the Battery Level 8

3.5 Volume Adjustment 9

4. PAIRING THE HEADSET WITH OTHER

BLUETOOTH DEVICES 10

4.1 Phone Pairing 10

4.1.1 Initially Pairing the pi 10

4.1.2 Pairing When the pi Is Turned Off 11

4.1.3 Pairing When the pi Is Turned On 11

4.2 Second Mobile Phone Pairing - Second Mobile

Phone and GPS 12

TABLE OF CONTENTS

TABLE OF CONTENTS CONTINUED

5. MOBILE PHONE USAGE 13

5.1 Making and Answering Calls 13

5.2 Bluetooth Stereo Music 13

6. BLUETOOTH INTERCOM 14

6.1 Intercom Pairing 14

6.1.1 Using the Smart Intercom Pairing (SIP) 14

6.1.2 Using the Button 15

6.2 Two-Way Intercom 15

6.2.1 HD Intercom 15

7. UNIVERSAL INTERCOM 16

7.1 Universal Intercom Pairing 16

7.2 Two-Way Universal Intercom 16

8. FUNCTION PRIORITY 17

9. CONFIGURATION SETTING 18

9.1 Headset Conﬁguration Menu 18

9.2 Software Conﬁguration Setting 18

9.2.1 Unit Language 19

9.2.2 Voice Prompt (Default: Enable) 19

9.2.3 Advanced Noise Control™ (Always on) 19

10. TROUBLESHOOTING 20

10.1 Fault Reset 20

10.2 Factory Reset 20

pi Bluetooth Communication Headset for Helmets | 4

1. ABOUT pi

1.1 Product Features

Bluetooth®4.1

Two-Way Intercom

Intercom up to 400 m (0.2 mi)*

Advanced Noise Control™

* in open terrain

1.2 Product Details

Microphone DC Power Charging &

Firmware Upgrade Port

(+) Button

LED Status

(–) Button

CHAPTER

pi Bluetooth Communication Headset for Helmets | 5

1 ABOUT pi

Left Speaker Right Speaker

1.3 Package Contents

Headset USB Power & Data Cable

(USB-C)

pi Bluetooth Communication Headset for Helmets | 6

2. INSTALLING THE HEADSET ON YOUR

HELMET

①Secure the headset to the chinstrap using the strap hooks on both

sides.

②Slide the headset as close to the helmet as possible.

Note:

• The (R) and (L) markings are located on the back of the headset.

• Make sure that the cable is facing toward the helmet.

③Hide the cable under the inner pad in the front of the helmet.

④Adjust the headset upward or downward so that the speakers are

facing your ears.

Note: The SENA logo will appear as above after proper installation.

CHAPTER

pi Bluetooth Communication Headset for Helmets | 7

3. GETTING STARTED

3.1 Downloadable Sena Software

3.1.1 Sena Utility App

By simply pairing your phone with your headset, you can use the Sena

Utility App for quicker, easier set up and management.

Sena Utility

• Download Sena Utility App on Google Play Store or App Store.

3.1.2 Sena Device Manager

The Sena Device Manager allows you to upgrade firmware and

configure settings directly from your PC.

Sena Device Manager

• Download the Sena Device Manager at sena.com.

3.1.3 Firmware Upgrades

The headset supports firmware upgrades.

Please visit sena.com to check for the latest software downloads.

• Download the ﬁrmware at sena.com.

CHAPTER

pi Bluetooth Communication Headset for Helmets | 8

3 GETTING STARTED

3.2 Charging

Charging the Headset

Depending upon the charging

method, the headset will be fully

charged in about 2.5 hours.

Note:

• Please make sure to take off your headset while charging. The

headset automatically turns off during charging.

• Any 3rd party USB charger can be used with Sena products if the

charger is approved by either the FCC, CE, IC or other locally

approved agencies that Sena accepts.

• The pi is compatible with 5 V input USB-charged devices only.

3.3 Powering On and Off

Powering On

• Press and hold the (+) Button and the (-) Button for 1 second.

Powering Off

• Tap the (+) Button and the (-) Button.

3.4 Checking the Battery Level

There are two ways to check battery level:

1) Visual Method

Powering On

2) Audible Method

• While the headset is on,

press and hold the (-) Button

for 3 seconds.

“Battery level is high/

medium/low”

pi Bluetooth Communication Headset for Helmets | 9

3 GETTING STARTED

Note:

• The battery performance may be reduced over time with usage.

• Battery life may vary depending on conditions, environmental

factors, functions of the product in use, and devices used with it.

3.5 Volume Adjustment

Volume is set and maintained independently at different levels for each

audio source, even when the headset is rebooted.

Volume Up/Down

• Tap the (+) Button or the (-) Button.

pi Bluetooth Communication Headset for Helmets | 10

4. PAIRING THE HEADSET WITH OTHER

BLUETOOTH DEVICES

When using the headset with other Bluetooth devices for the ﬁrst time,

they will need to be “paired.” This enables them to recognize and

communicate with one another whenever they are within range.

The pairing operation is required only once for each Bluetooth device.

The headset can pair with multiple Bluetooth devices such as a mobile

phone, GPS, or MP3 player via Mobile Phone Pairing and Second

Mobile Phone Pairing.

4.1 Phone Pairing

There are three ways to pair the phone.

4.1.1 Initially Pairing the pi

The headset will automatically enter the phone pairing mode when you

initially turn on the headset or in the following situation:

• Rebooting after executing Factory Reset.

①Press and hold the

(+) Button and the (-) Button

for 1 second.

Blinking

“Phone Pairing”

②Select pi in the list of Bluetooth

devices detected.

Device B

Bluetooth

Note:

• The phone pairing mode lasts for 3 minutes.

• To cancel pairing, tap the (+) Button or (-) Button.

CHAPTER
