SENA
QUICK START GUIDE
ENGLISH
For Arai Quantic Helmet
SENA Technologies, Inc.
Customer Support: sena.com
Downloadable Sena Software
Download the Sena Utility App at Google Play Store or
App Store.
Sena Utility
Download the following items at sena.com.
Firmware
Sena Device Manager
• Firmware upgrade
• Device configuration setting
Quick Start Guide,
User’s Guide
Follow us on Facebook, YouTube, Twitter and Instagram to check
the latest information and helpful tips.
Product Details
Main Unit
Antenna
Microphone Connector
Speakers Connectors
Status LED
DC Power Charging &
Firmware Upgrade Port
Pinhole Fault Reset Button
(–) Button
(+) Button
Center Button
Installation
• The ACS10 is compatible with Arai Quantic Helmets.
• For more information about installation, refer to the User’s Guide.
1 2
3 4
5 6
1
2
7 8
Icon Legend
1x
TAP Tap button the specified
number of times 10s
HOLD Press and Hold button for the
specified amount of time
“Hello” Audible prompt
Basic Operations
Powering On
1s
HOLD
Volume Up
1x
TAP
Powering Off
1x
TAP
Volume Down
1x
TAP
Checking the Battery Level
Powering On
=
=
=
Phone Pairing
When you initially turn on the headset:
① 1s
HOLD Blinking
“Phone Pairing”
② Select ACS10 in the list of
Bluetooth devices detected.
Device B
Pi
Bluetooth
ACS10
• For more information on phone pairing, refer to the User’s Guide.
Using the Phone
Answer a Call
1x
TAP
Reject a Call
2s
HOLD
End a Call
2s
HOLD
Voice Dial
3s
HOLD in
stand-by
mode
Music Control
Play/Pause
1s
HOLD
Track Forward
1s
HOLD
Track Backward
1s
HOLD
Bluetooth Intercom
Up to three other people can be paired with the headset for
Bluetooth intercom conversations.
A
B
C
D
YOU
Intercom Pairing
There are two ways to pair the headset.
Using the Smart Intercom Pairing (SIP)
SIP allows you to quickly pair with your friends for intercom
communication by scanning the QR code on the Sena Utility App
without remembering the button operation.
① Pair the mobile phone with the headset.
② Open the Sena Utility App.
③ Click the Smart Intercom Pairing Menu.
④ Click the Add Button to open the QR scanning screen.
⑤ Scan the QR code displayed on your friend (B)’s mobile phone.
• Your friend (B) can display the QR code on the mobile
phone by opening the Sena Utility App and clicking the
Smart Intercom Pairing Menu.
⑥ Click the Confirm Button and check that your friend (B) is paired
with you (A) correctly.
⑦ Repeat steps 4-6 to pair with Intercom Friends (C) and (D).
Note: The Smart Intercom Pairing (SIP) is not compatible with
Sena products that use Bluetooth 3.0 or below.
Using the Button
AB
YOU
① Users (You, B) enter into Intercom Pairing.
5s
HOLD Blinking
“Intercom Pairing”
② Tap the Center Button on either headset.
1x
TAP
Turns blue
Confirms intercoms are paired
AB
YOU
③ Repeat the steps above to pair with other headsets (C and D).
Last-Come, First-Served
If a headset has multiple paired headsets for intercom conversations,
the last paired headset is set as the first intercom friend.
Intercom Pairing Order Last-Come, First-Served
A
B
C
D
YOU
1
2
3
ADCB
YOU Intercom
Friend 1
Intercom
Friend 2
Intercom
Friend 3
Two-way Intercom
Start/End Conversation with the First Intercom Friend D
1x
TAP
Start/End Conversation with the Second Intercom Friend C
2x
TAP
Start/End Conversation with the Third Intercom Friend B
3x
TAP
