Seiko 5R86 Manual de usuario
Cal. 5R86
INSTRUCTIONS (P. 3)
BEDIENUNGSANLEITUNG (S. 31)
INSTRUCTIONS (P. 59)
ISTRUZIONI (P. 87)
INSTRUCCIONES (P. 115)
INSTRUÇÕES (P. 143)
(171 )
2
You are now the proud owner of a Spring Drive Watch. For the best results, please read the
instructions in this booklet carefully before using your Spring Drive Watch. Please keep this
manual handy for ready reference.
Sie sind jetzt stolzer Besitzer einer „Spring Drive-Uhr”. Lesen Sie diese Bedienungsanleitung
vor der Verwendung Ihrer „Spring Drive-Uhr” aufmerksam durch, um ihre optimale Nutzung zu
gewährleisten. Heben Sie diese Bedienungsanleitung gut auf, um jederzeit wieder nachlesen zu
können.
Vous êtes maintenant l’heureux propriétaire d’une Montre Spring Drive. Pour en obtenir les meilleurs
résultats, veuillez lire attentivement les instructions de cette brochure avant d’utiliser votre Montre
Spring Drive. Veuillez conserver ce manuel à portée de la main pour pouvoir vous y référer facilement.
Congratulazioni per l’acquisto di questo nuovo orologio con trascinamento a molla (“Spring
Drive”). Per ottenere i massimi risultati dall’orologio leggere attentamente questo manuale di
istruzioni prima di passare all’uso dell’orologio stesso, e conservarlo poi per qualsiasi eventuale
futura consultazione.
Usted es ahora un orgulloso propietario de un Reloj Spring Drive. Para los mejores resultados,
por favor, lea cuidadosamente las instrucciones de este panfleto antes de utilizar este Reloj Spring
Drive. Le rogamos guardar este manual a mano para futura referencia.
Você pode agora sentir-se orgulhoso de possuir um Relógio Spring Drive. Para obter os melhores
resultados, leia atentamente as instruções contidas neste opúsculo antes de usar o relógio. Conserve
este manual para consultas futuras.
ENGLISH
3
CONTENTS
Page
FEATURES.................................................................................................................. 4
NAMES OF THE PARTS ............................................................................................ 5
HOW TO USE............................................................................................................. 6
How to manually wind the mainspring.................................................................. 6
How to set the time .............................................................................................. 7
How to set the date............................................................................................... 13
How to adjust the time difference......................................................................... 14
Time difference table............................................................................................. 16
How to use the stopwatch.................................................................................... 18
HOW TO READ THE POWER RESERVE INDICATOR................................................ 20
TO PRESERVE THE QUALITY OF YOUR WATCH...................................................... 22
PLACES TO KEEP YOUR WATCH .............................................................................. 26
PERIODIC CHECKS .................................................................................................... 27
TROUBLESHOOTING................................................................................................. 28
SPECIFICATIONS ....................................................................................................... 30
English
4
FEATURES
Spring Drive, the unique mechanism made available only by SEIKO technology,
ensures high accuracy while using the mainspring as its sole power source.
The watch will work continuously for approximately 72 hours (three days) when the
mainspring is fully wound. The watch features a power reserve indicator to show
the winding state of the mainspring. The glide-motion second hand works in a per-
fectly smooth movement.
This is an automatic watch equipped with a manual winding mechanism. When first
using the watch, manual winding is convenient.
CAUTION
• This watch is powered by the mainspring. To ensure constant operation
of the watch, be sure to wind up the mainspring sufficiently before the
power reserve indicator points to“ 0.”
•
The watch may stop if the power reserve indicator is showing less than
one-sixth of the power reserve, especially if it is left at a temperature
below 0ºC.
English
5
NAMES OF THE PARTS
6
* The position or design of the displays may differ depending on the model.
a)
Normal position : winding up the mainspring (manual operation)
b)
First click position : hour-hand independent adjustment, date setting
c) Second click position : time setting
Power reserve indicator
Hour hand
Small second hand
Date
CROWN
a b c
CROWN 24-hour hand
Minute hand
STOPWATCH second hand STOPWATCH minute hand
STOPWATCH hour hand
A
B
English
6
HOW TO USE
This watch is an automatic watch equipped with a manual winding mechanism.
• When the watch is worn on the wrist, the motion of the wearer's arm winds the
mainspring of the watch.
• If your watch is completely stopped, it is recommended that you manually wind the
mainspring by turning the crown.
●How to manually wind the mainspring
* With manual winding, if you give the crown five full
rotations, it provides the power to run the watch for
approximately ten hours.
* Turning the crown counterclockwise (the 6 o’clock
direction) does not wind the mainspring.
1. Slowly turn the crown clockwise (the 12 o’clock
direction) to wind the mainspring.
2. Wind the mainspring until the power reserve
indicator shows a fully-wound state. The sec-
ond hand will start moving.
* To check the winding state of the mainspring,
refer to
"HOW TO READ THE POWER RESERVE
INDICATOR"
on page 20.
* There is no need to turn the crown further when
the mainspring is fully wound. But the crown can
be turned without damaging the watch mechanism.
6
English
7
●How to set the time
• When setting the time, ensure that the watch is working: the main
spring is sufficiently wound.
• The 24-hour hand can be used in two ways. Since the time setting
method differs according to the usage, please choose the mode before
setting the time.
<Mode 1> Simply using the 24-hour hand to show
the 24-hour time as an AM/PM indicator.
• This is the standard usage type for the
24-hour hand.
<Mode 2> Using the 24-hour hand to indicate the
time in a different time zone.
• For instance, by setting the 24-hour hand
to GMT while setting the hour and minute
hands to indicate the time in your area,
you can easily check GMT with the 24-hour
hand at any time.
6
6
English
8
6
How to set the 24-hour hand as a regular 24-hour indicator
<When the mode 1 usage is selected>
Second click position
1. Pull out the crown to the second click.
* Pull the crown out when the small second hand is at the 12
o’clock position and the small second hand will stop on the
spot.
* When setting the time, ensure that the watch is working:
the mainspring is sufficiently wound.
English
9
4. Pull out the crown to the first click.
3. Push the crown back in simultaneously with the
time signal.
* The setting of the 24-hour, minute and small second
hands to the current time is now completed.
<Example>
To set to 6:00 P.M., adjust the
24-hour hand to indicate “18”
on the 24-hour scale (9 o’clock
position), and the minute hand to
the “0” minute position.
6
* Only the 24-hour and minute hands are to be set at this
stage. The hour hand is to be set later so it is not neces-
sary to adjust the hour hand yet, even if it is indicating the
wrong time.
* The date may be altered depending on the position of the
hour hand, however it should not cause any concern since
it can also be adjusted later.
* Set the minute hand slightly behind the time you wish to
set, and then slowly advance it to the desired time.
2. Turn the crown counterclockwise to set the 24-hour
and minute hands to the current time.
English
10
1. Pull out the crown to the second click.
* Pull the crown out when the small second hand is at the 12
o’clock position and the small second hand will stop on the
spot.
* When setting the time, ensure that the watch is working: the
mainspring is sufficiently wound.
6
How to set the 24-hour hand as a dual time indicator for a “dif-
ferent time zone area” <when the mode 2 usage is selected>
Second click position
5. Turn the crown to set the hour hand to the current hour.
* Also, adjust the date at this point if necessary.
*
The moment the date changes is midnight. When setting the hour hand, be sure that AM/PM is
set correctly.
* Turn the crown slowly, checking that the hour hand moves in one-hour increments.
* When adjusting the hour hand, the other hands may move slightly. However, this is not a mal-
function.
6. Push the crown back in upon completion of time setting.
