Sealey SWT1120 Manual de usuario

WELDING TABLE 1120 X 610MM

MODEL NO: SWT1120

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

9Select a work area suitable for the table and keep the area clean, tidy and free from unrelated materials. Ensure there is adequate

9lighting.

9Stand the table on a stable floor strong enough to take the weight of the table.

9Maintain the table in good condition.

9Replace or repair damaged parts. Use recommended parts only, unauthorised parts may be dangerous and will invalidate the warranty.

9Remove ill fitting clothing, remove ties, watches, rings and other loose jewellery and contain long hair.

9Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.

9Keep children and unauthorised persons away from the work area.

2. INTRODUCTION

Heavy-duty galvanised welding table with 30mm MIG torch mounting point. Portable and foldable for ease of transportation and storage when

not in use. Sturdy locking pin system and adjustable foot for eliminating wobble when in use.

3. SPECIFICATION

Model no .................................................................SWT1120

Size folded ............................................ 1120 x 610 x 915mm

Weight capacity............................................................ 100kg

4. OPERATION

4.1. Laytableupsidedownonoor.Removelegsecuringpin,(seeg.1).

4.2. Pullinnerleg(theonewiththeheightadjustingbolt),upandovertoerectlegs.

4.3. Oncethelegsreachtheirstop,reinsertthepinand‘R’clipinitsend,tosecurethelegsinposition,(seeg.2).

4.4. Get the help of an assistant to turn the table the right way up.

4.5. Use the height adjusting bolt to stabilise the table before using.

Original Language Version

Refer to

instruction

manual

fig.1

fig.2

fig.3

SWT1120Issue:3(3)|15/04/20

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids

according to local regulations.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

Original Language Version
