Sealey PC40.V2 Manual de usuario

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

WARNING! The blade used by this cutter is razor sharp and should be treated with due

caution.

9Store the cutter in a safe childproof place when not in use.

9Use in a suitable, clean and tidy work area, free from unrelated materials. Ensure there is

adequate lighting.

9Use the cutter for rubber and soft vinyl pipes only.

8DO NOT use cutter on hard reinforced pipe. If the blade does not penetrate the pipe, then the material used to make the pipe is too hard.

Applying excessive pressure may cause the pipe to shatter.

8DO NOT continue to attempt cutting any pipe that withstands penetration.

8DO NOT insert a finger into the cutting area at any time.

8DO NOT turn the pipe whilst cutting.

8DO NOT allow untrained people to use the cutter.

8DO NOT allow children to use or play with the cutter.

8DO NOT use the cutter for tasks it is not designed to perform.

8DO NOT operate cutter if any parts are damaged or missing as this may cause failure and/or personal injury.

8DO NOT

operate the cutter when you are tired or under the influence of alcohol, drugs or intoxicating medication.

2. INTRODUCTION

Pistol-type, ratchet action, die-cast aluminium alloy body with heat treatedAUS-8 stainless steel blade honed and shaped for smooth cutting action.

Ratchet cutting action avoids crushing pipe. Long-life blade suitable for cutting extrusions and pipes. Textured grip with rubber inlay gives added

comfort and control.

3. SPECIFICATION

Model:.....................................................................PC40.V2

Capacity:................................................................Ø6-42mm

Length:.......................................................................210mm

4. OPERATION

Original Language Version

Refer to

instructions

PLASTIC PIPE AND EXTRUSION CUTTER

MODEL No: PC40.V2

PART NUMBER FOR SPARE BLADE

PC40/B

PLACE PLASTIC PIPE INTO

‘U’ JAW WITH THE BLADE

POINT ALIGNED WITH THE

TUBE CENTRE

SQUEEZE TRIGGER HANDLE

REPEATEDLY TO PIERCE AND

CUT THROUGH THE PIPE

TO RETRACT THE BLADE

PUSH THE BUTTON AT THE

REAR OF THE TOOL

PC40.V2 Issue 3 12/10/21

Original Language Version

3.1. ADJUSTING PC40.V2 TO CUT SMALLER PIPE SIZES

UNDER 26MM

3.1.1 The PC40 has a switch on its top surface which adjusts the

starting position of the blade to more conveniently cut pipe sizes

of 26mm or less.

3.1.2 To select the 26mm position first retract the blade by pressing the

retraction button (See fig.1-R).

3.1.3 Now squeeze the handle/trigger fully six times, then move the

switch to the 26mm position. The blade will only now retract

sufficiently to allow a 26mm tube to be inserted.

3.1.4 To return to the 42mm position first press the retraction button

which will partially retract the blade.

3.1.5 Now squeeze the handle/trigger fully three times, then move the

switch to the 42mm position. The blade will now fully retract

when the retraction button is pressed.

DO NOT SQUEEZE THE

TRIGGER HANDLE WHILST

PUSHING THE BUTTON

UNDO THE FIXING SCREWS

WITH 2.5MM ALLEN KEY AND

CAREFULLY LIFT OUT BLADE

REPLACEMENT IS A REVERSAL

OF THIS PROCEDURE

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENVIRONMENT PROTECTION

Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call

our technical team on technical@sealey.co.uk or 01284 757505.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

TO CHANGE THE BLADE

SQUEEZE THE TRIGGER

HANDLE THREE TIMES
