Seagate SKYHAWKLITE ST2000VX007 Manual de usuario

100825411, Rev. E

Gen 17 - May 2019

Standard models

ST2000VX007

ST1000VX008

SATA Product Manual

Publication number: 100825411, Rev. E May 2019

Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. SkyHawk Lite and SeaTools are either

trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trade-

marks are the property of their respective owners.

No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.

Call 877-PUB-TEK1(877-782-8351) to request permission.

When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different

standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage.

Actual quantities will vary based on various factors, including file size, file format, features and application software. Actual data rates may vary depending on operating environment and

other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of Commerce, Bureau of Industry and Security (for more

information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.

Document Revision History

Revision Date Pages affected

Rev. A 08/24/2017 Initial release.

Rev. B 11/21/2017

fc, 6, 13, 21 & 23: Revised name to SkyHawk Lite

fc, 6, 8 & 28-29: Added 1TB model = ST1000VX008

6: Revised Drive Bays - up to 2 bays

6: Removed statement: Rotational Vibration - mitigation....

6: Updated bullet to - Supports up to 32 HD cameras for recording and playback

6: Revised Transient power = 1.1A spin-up current

6 & 9: Revised Workload to 120TB/year

9: Revised Non-recoverable read errors to 1014 & L/UL cycles to 300,000

13: Added Figure 1: Location of the HDA temperature check point

16-20: Updated Safety, EMC, FCC & RoHS Sections 2.12 through 2.13.3, per Compliance Council

22: Updated fastener penetration depth to 0.140 inches in Section 3.4 & Figure 3

Rev. C 02/28/2018 8 & 10: Removed references to cache size

Rev. D 04/13/2018 16: Added Regulatory Model Number

Rev. E 05/28/2019

6: Removed TGMR bullet

20: Updated Table 6 Taiwan - Restricted Substances

bc: Removed APAC & EMEA addresses

Seagate SkyHawk Lite Product Manual, Rev. E 2

Contents

Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1 About the SATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.0 Drive Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.1 Specification summary tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.2.1 LBA mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3 Default logical geometry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.4 Recording and interface technology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.5 Physical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.6 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.7 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.7.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.7.2 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.7.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.7.4 Power-management modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.8 Environmental specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.8.1 Ambient Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.8.2 Temperature gradient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.8.3 Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.8.4 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.8.5 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.8.6 Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.9 Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.9.1 Test for Prominent Discrete Tones (PDTs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.10 Electromagnetic immunity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.11.1 Data loss under power interruption with write cache enabled . . . . . . . . . . . . . . . . . . . . . . 16

2.11.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Seagate SkyHawk Lite Product Manual, Rev. E 3

Contents

2.12 Agency and Safety Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.12.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.12.2 European Union (EU) CE Marking Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.12.3 Australian RCM Compliance Mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.12.4 Canada ICES-003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.12.5 South Korean KC Certification Mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.12.6 Morocco Commodity Mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.12.7 Taiwanese BSMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.12.8 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.13 Environmental protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.13.1 European Union Restriction of Hazardous Substance Law. . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.13.2 China Requirements —China RoHS 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

2.13.3 Taiwan Requirements — Taiwan RoHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.14 Corrosive environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.0 Configuring and Mounting the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.1 Handling and static-discharge precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.2 Configuring the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.3 SATA cables and connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

3.4 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.0 SATA Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.1 Hot-Plug compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.2 SATA device plug connector pin definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.3 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.3.1 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.3.2 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.3.3 S.M.A.R.T. commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Seagate SkyHawk Lite Product Manual, Rev. E 4

Figures

Figure 1 Location of the HDA temperature check point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 2 Attaching SATA cabling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 3 Mounting dimensions (1-disk models). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Seagate SkyHawk Lite Product Manual, Rev. E 5

For information regarding online support and services, visit: http://www.seagate.com/contacts/

For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/

For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/

For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/

Seagate® Technology Support Services

Seagate SkyHawk Lite Product Manual, Rev. E 6

1.0 Introduction

This manual describes the functional, mechanical and interface specifications for the following

Seagate® Skyhawk™ Lite and model drives:

These drives provide the following key features:

• 1M hour MTBF - designed for high write duty cycle across SkyHawk Lite

• ATA AV Command support - streaming video command support across SkyHawk Lite

• Best-in-class acoustic performance means virtually silent operation

• Built-in error recovery for non-stop video streaming

• Compliant with RoHS requirements in China and Europe

• Full-track multiple-sector transfer capability without local processor intervention

• Idle3 power mode support

• Low activity power

• Low-RPM spindle speed

• Native Command Queuing with command ordering to increase performance in demanding applications

• Performance-tuned for seamless video applications

• Reliability for 24×7 video surveillance applications

• SeaTools diagnostic software performs a drive self-test that eliminates unnecessary drive returns.

• State-of-the-art cache and on-the-fly error-correction algorithms

• Streaming video optimization - consistent command completion times & ERC support across SkyHawk Lite

• Support for S.M.A.R.T. drive monitoring and reporting

• Supports up to 2 drive bays

• Supports ATA8 streaming commands

• Supports latching SATA cables and connectors

• Supports up to 32 HD cameras for recording and playback

• Thermal monitoring and reporting for 24×7 operations

• Transient power on management - <=1.1A spin-up current

• Uncompromising reliability supports flexible surveillance design with case temperatures up to 70ºC

• Workload ratings of 120TB/year

• Worldwide Name (WWN) capability uniquely identifies the drive

SkyHawk Lite models

ST2000VX007 ST1000VX008

Seagate SkyHawk Lite Product Manual, Rev. E 7

www.seagate.com Introduction

1.1 About the SATA interface

The Serial ATA (SATA) interface provides several advantages over the traditional (parallel) ATA interface. The primary

advantages include:

• Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other

configuration options.

• Thinner and more flexible cabling for improved enclosure airflow and ease of installation.

• Scalability to higher performance levels.

In addition, SATA makes the transition from parallel ATA easy by providing legacy software support. SATA was designed to

allow users to install a SATA host adapter and SATA disk drive in the current system and expect all of the existing

applications to work as normal.

The SATA interface connects each disk drive in a point-to-point configuration with the SATA host adapter. There is no

master/slave relationship with SATA devices like there is with parallel ATA. If two drives are attached on one SATA host

adapter, the host operating system views the two devices as if they were both “masters” on two separate ports. This

essentially means both drives behave as if they are Device 0 (master) devices.

The SATA host adapter and drive share the function of emulating parallel ATA device behavior to provide backward

compatibility with existing host systems and software. The Command and Control Block registers, PIO and DMA data

transfers, resets, and interrupts are all emulated.

The SATA host adapter contains a set of registers that shadow the contents of the traditional device registers, referred to as

the Shadow Register Block. All SATA devices behave like Device 0 devices. For additional information about how SATA

emulates parallel ATA, refer to the “Serial ATA International Organization: Serial ATA Revision 3.0”. The specification can be

downloaded from www.sata-io.org.

Note

The host adapter may, optionally, emulate a master/slave environment to host software where two

devices on separate SATA ports are represented to host software as a Device 0 (master) and Device 1

(slave) accessed at the same set of host bus addresses. A host adapter that emulates a master/slave

environment manages two sets of shadow registers. This is not a typical SATA environment.

Seagate SkyHawk Lite Product Manual, Rev. E 8

2.0 Drive Specifications

Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For

convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models:

2.1 Specification summary tables

The specifications listed in Table 1 are for quick reference.

For details on specification measurement or definition, refer to the appropriate section of this manual. .

SkyHawk Lite models

ST2000VX007 ST1000VX008

Table 1 Drive specifications summary for 2TB & 1TB model

Drive Specification* ST2000VX007 ST1000VX008

Formatted capacity (512 bytes/sector)** 2000GB (2TB) 1000GB (1TB)

Guaranteed sectors 3,907,029,168 1,953,525,168

Heads 2 1

Disks 1

Bytes per sector (emulated at 512-byte sectors) 4096 (physical)

Default sectors per track 63

Default read/write heads 16

Default cylinders 16,383

Recording density (max) 2294 kB/in

Track density (avg) 540 ktracks/in

Areal density (avg) 1203 Gb/in2

SATA interface transfer rate 600 MB/s

Maximum data transfer rate 180 MB/s 175 MB/s

ATA data-transfer modes supported

PIO modes: 0 to 4

Multiword DMA modes: 0 to 2

Ultra DMA modes 0 to 6

Height (max) 20.20mm / 0.795 in

Width (max) 101.6mm (± 0.25) / 4.0 in (± 0.010)

Length (max) 146.99mm / 5.787 in

Weight (typical) 415g / 0.915 lb

Average latency 6.0 ms

Power-on to ready (typ) 9.0s

Standby to ready (typ) 9.0s

Startup current (typical) 12V 1.1A

Voltage tolerance (including noise) 5V ±5% / 12V ±10%

Non-Operating (Ambient °C) –40° to 70°

Operating ambient temperature (min °C) #0°

Operating temperature (drive case max °C) 70°†

Temperature gradient 20°C per hour max (operating)

30°C per hour max (non-operating)

Relative humidity 5% to 90% (operating)

5% to 95% (non-operating)

Relative humidity gradient (max) 30% per hour

Wet bulb temperature (max) 30°C max (operating)

40°C max (non-operating)

Seagate SkyHawk Lite Product Manual, Rev. E 9

www.seagate.com Drive Specifications

* All specifications above are based on native configurations.

** One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity.

Accessible capacity may vary depending on operating environment and formatting.

*** During periods of drive idle, some offline activity may occur according to the S.M.A.R.T.

specification, which may increase acoustic and power to operational levels.

† Seagate does not recommend operating at sustained case temperatures above 60°C.

Operating at higher temperatures will reduce useful life of the product.

# The operating case temperature is 0 to 70C (32 to 158F).

The recommended measure location can be found in Figure 3.

Altitude, operating –304m to 3048m

(–1000 ft to 10,000 ft)

Altitude, non-operating

(below mean sea level, max)

–304m to12,192m

(–1000 ft to 40,000+ ft)

Operational shock (max) 80 Gs (read) / 70 Gs (write) at 2ms

Non-operational shock (max) 350 Gs at 2ms

Vibration, operating

10Hz to 22Hz: 0.25 Gs, Limited displacement

22Hz to 350Hz: 0.50 Gs

350Hz to 500Hz: 0.25 Gs

Vibration, non-operating

5Hz to 22Hz: 3.0 Gs

22Hz to 350Hz: 3.0 Gs

350Hz to 500Hz: 3.0 Gs

Drive acoustics, sound power

Idle*** 1.8 bels (typical)

1.9 bels (max)

Seek 2.0 bels (typical)

2.1 bels (max)

Non-recoverable read errors 1 per 1014 bits read

Rated workload

Average annualized workload rating: <120TB/year.

The specifications for the product assumes the I/O workload does not exceed the

average annualized workload rate limit of 120TB/year. Workloads exceeding the

annualized rate may degrade and impact reliability as experienced by the

particular application. The average annualized workload rate limit is in units of TB

per calendar year.

Warranty

To determine the warranty for a specific drive, use a web browser to access the

following web page:

http://www.seagate.com/support/warranty-and-replacements/

From this page, click on “Is my Drive under Warranty”. Users will be asked to

provide the drive serial number, model number (or part number) and country of

purchase. The system will display the warranty information for the drive.

Load/unload cycles 300,000 at 25°C, 50% rel. humidity

Supports hotplug operation per the

Serial ATA Revision 3.2 specification Yes

Note If the drive is powered-off before issuing flush cache command, in some instances,

the end user data in the DRAM cache might not be committed to the disk.

Table 1 Drive specifications summary for 2TB & 1TB model (continued)

Drive Specification* ST2000VX007 ST1000VX008

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Almacenamiento de Seagate

Seagate

Seagate ST8000VE000 Manual de usuario

Seagate

Seagate ST3146807FC - Cheetah 146.8 GB Manual de usuario

Seagate

Seagate 7200.9 - Barracuda 7200.9 Hard Drive Manual de usuario

Seagate

Seagate MEDALIST 275XE Manual de usuario

Seagate

Seagate ST1200MM0007 Manual de usuario

Seagate

Seagate 1200 Manual de usuario

Seagate

Seagate MEDALIST 1270 Manual de usuario

Seagate

Seagate Momentus ST9808211A Manual de usuario

Seagate

Seagate ST3000VX000 Manual de usuario

Seagate

Seagate BARRACUDA ST11950N/ND/W/WD Manual de usuario

Seagate

Seagate U Series 9 CE Manual de usuario

Seagate

Seagate ST12000NM0027 Manual de usuario

Seagate

Seagate IronWolf Pro ST8000NE001 Manual de usuario

Seagate

Seagate 3.5-inch Pushbutton Backup External Hard... Manual de usuario

Seagate

Seagate ST6000NM0115 Manual de usuario

Seagate

Seagate ST9120822A - Momentus 5400.3 120 GB Hard... Manual de usuario

Seagate

Seagate ST18000NM000J Manual de usuario

Seagate

Seagate EXOS ST10000NM018G Manual de usuario

Seagate

Seagate ST31000340NS - Barracuda 1 TB Hard Drive Manual de usuario

Seagate

Seagate EE25.2 - Series 80 GB Hard Drive Manual de usuario

Seagate

Seagate Duet Manual de usuario

Seagate

Seagate Momentus 5400.3 ST9100828AB Manual de usuario

Seagate

Seagate Barracuda 7200.7 ST3160022A Manual de usuario

Seagate

Seagate IronWolf ST1000VNZ02 Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
