SC05.6100

HDMI (HDBaseT) Extender, 100m

18Gbps, 4K/60Hz. 4:4:4

User Manual

Version 1.0

SCION

User Manual

Scion Tech SC05.6100

Thank you for purchasing this product

For optimum performance and safety, please read these instructions carefully before connecting, operating or

adjusting this product. Please keep this manual for future reference.

Surge protection device recommended

This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric

shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and

extend the life of your equipment.

Table of Contents

1. Introduction…………………………………………………….…………………………….…….…………….……………………….

2. Features……………………………………………………………………………………………………….……….…………….……..

3. Package Contents…………………………………….……………………………………………………………….……….………..

4. Specifications…………………………………………………………………….………………………………………………….……

5. Panel Description………………………………………………….….………….…………………………………………….……….

6. Connecting…………………………………………………………….…….…………….…………….…………………………………

7. LED Indicators………………………………………………………………….…………………….………………………….………

8. Application Drawing………………………………………………….….…….…….…………………….………………………….

9. Maintenance…………………………………………………………….….……….……………………………….……………………

9.1. Servicing………………………………………………….…….…………………………………………….……….…….……….

9.2. Warranty………………………………………………………………….……………………….…….………….……………….

9.3. Returning a Product………………………………………..….…………………………….…….…………………………….

9.4. Warranty Limits and Exclusions………………………………………….………………….….….……………………..

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 1

User Manual

Scion Tech SC05.6100

1. Introduction

The SC05.6100 extends the distance between the HDMI source and display using a single CAT5e/6 cable by up to

100m. Uncompressed Ultra HD 4K signals are transmitted without signal loss and automatically adjusts for

CAT5e/6 cable lengths. Bi-Directional Infra-Red provides control for both the source and screens. The extenders

use HDBaseT Class A technology to achieve Ultra HD 4K@60Hz, YUV 4:4:4. The transmitter has a looped HDMI

output for a local display.

These units are only 20mm thick making them ideal for mounting behind wall mounted displays and a second

HDMI output is provided for back to back displays mounted on pillars.

The SC05.6100 is supplied as a pair and contains Tx/Rx infra-red cables and PSU . These units are ideal for home,

office and general retail display screens.

2. Features

●Extends HDMI up to 100m@1080p/60Hz and 70m@4K/60Hz

●Resolution: 4K/60Hz, RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0

●Standards: HDMI 2.0, HDCP 2.2, HDR, CEC, 3D

●Uncompressed zero delay video

●Audio: LPCM, Dolby Digital™, DTS Surround Sound

●Full Duplex RS232 pass-through

●Bi-Directional IR

●Transmitter has a looped HDMI output for local screen

●Receiver has 2 x HDMI outputs

●PoC (power over cable) only one device needs power, either the transmitter or receiver

3. Package contents

1. 1 x Transmitter SC05.6100-TX

2. 1 x Receiver SC05.6100-RX

3. 2 x Infra-Red Sender Cable

4. 2 x Infra-Red Receiver Cable

5. 2 x 3-Pin Phoenix Terminal

6. 1 x 24V Power Supply

7. 1 x User Manual

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 2

User Manual

Scion Tech SC05.6100

Connectivity

Signal input: 1 x HDMI Type A, 19-Pin Female

Looped output: 1 x HDMI Type A, 19-Pin Female

Signal output: 1 x RJ45 Data Socket

Infra-Red: 2 x 3.5mm Jack Socket

RS232: 1 x 3-Pin Phoenix Terminal

Power: 1 x DC Jack Socket 2.1mm

Signal

Input: HDMI

Output: HDBaseT

Standards: HDMI 2.0, HDCP 2.2

Bandwidth: 18Gbps

Video resolution: Up to 4K/60Hz

Colour space: RGB/YCbCr 4:4:4, YCbCr 4:2:2,

YUV 4:2:0, HDR

Colour depth: 8/10/12-bit

Audio: DTS-HD™, Dolby-HD™

Infra-Red: 30KHz to 56KHz (940nm)

RS232: Full Duplex

Power

Type: AC to DC Mains Adaptor

Input: 100 ~ 240V AC 50/60Hz

Output: DC 24V / 1A

Consumption: 6 Watts

Environment

Storage temperature: -20° to 60°C

Operating temperature: -0° to 40°C

Operating humidity: 20% to 90% RH (no

condensation)

Dimensions: (W) 140 x (D) 67 x (H) 20mm

Weight: 700g

ESD: Human body +/-8Kv, (air gap discharge) and

+/-4Kv (contact discharge)

Safety and Emissions: CE, FCC, RoHS

4. Specifications

Connectivity

Signal input: 1 x RJ45 Data Socket

Signal output: 2 x HDMI Type A, 19-Pin Female

Infra-Red: 2 x 3.5mm Jack Socket

RS232: 1 x 3-Pin Phoenix Terminal

Power: 1 x DC Jack Socket 2.1mm

Signal

Input: HDBaseT

Output: HDMI

Standards: HDMI 2.0, HDCP 2.2, HDR

Bandwidth: 18Gbps

Video resolution: Up to 4K/60Hz

Colour space: RGB/YCbCr 4:4:4, YCbCr 4:2:2,

YUV 4:2:0, HDR

Colour depth: 8/10/12-bit

Audio: DTS-HD™, Dolby-HD™

Infra-Red: 30KHz to 56KHz (940nm)

RS232: Full Duplex

Power

Type: Receives power from the transmitter

Input: 100 ~ 240V AC 50/60Hz

Output: DC 24V / 1A

Consumption: 6 Watts

Environment

Storage temperature: -20° to 60°C

Operating temperature: -0° to 40°C

Operating humidity: 20% to 90% RH (no

condensation)

Dimensions: (W) 140 x (D) 67 x (H) 20mm

Weight: 700g

ESD: Human body +/-8Kv, (air gap discharge) and

+/-4Kv (contact discharge)

Safety and Emissions: CE, FCC, RoHS

TRANSMITTER RECEIVER

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 3

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 4

User Manual

Scion Tech SC05.6100

8. Panel Description

1 2 3 4 5 6 7 8 9

1. HDMI Input

2. HDMI Looped Output

3. Connect IR RX cable to IR-In port

4. Connect IR TX cable to IR-Out port

5. Power DC 24V

6. USB for Firmware Upgrade

7. RJ45 Data Socket Output (HDBaseT)

8. EDID Selection Switch

9. RS232 Pass Through

Transmitter Front Panel Transmitter Rear Panel

CAT5e/6

TX GND RX

IR-Out

HDMI In DC 24V

IR-In

HDMI Out Local Remote

Auto

Update

2 3 4 5 6 7 8

1. HDMI Output

2. HDMI Output

3. Connect IR RX cable to IR-In port

4. Connect IR TX cable to IR-Out port

5. Power DC 24V

6. USB for Firmware Upgrade

7. RJ45 Data Socket Input (HDBaseT)

9. RS232 Pass Through

Receiver Front Panel Receiver Rear Panel

CAT5e/6

TX GND RX

IR-Out DC 24V

IR-In

HDMI Out Update

HDMI Out

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 5

User Manual

Scion Tech SC05.6100

6. Connecting

Important:

These extenders are designed to work over a point to point connection using Category 5e or greater twisted pair

cable, under no circumstances should they be used with third party equipment including network switches,

modems or another manufacturers similar product.

1. Connect a HDMI cable to your source device and the transmitters input using a premium quality HDMI cable.

2. Connect a HDMI cable to your local display and the transmitters looped output.

3. Connect the HDMI cables to the displays or sink devices and the receivers outputs using a premium quality

HDMI cables.

4. Transmitter IR connections: The “IR TX” cable connects to the “IR-Out” port for transferring IR to your source

device IR sensor window. The “IR TX” emitter LED should be attached to IR sensor window using the 3M™

sticker provided. The “IR RX” cable connects to the “IR-In” port for sending IR to the receiver for controlling

devices at the remote end.

5. Receiver IR connections: The “IR RX” cable connects to the “IR-In” port for sending IR to the transmitter for

controlling the source devices. The “IR TX” cable connects to the “IR-Out” port for transferring IR to the

remote end device. The “IR TX” emitter LED should be attached to IR sensor window using the 3M™ sticker

provided.

6. Using the 3-pin Phoenix terminals provided, connect the “Tx, Rx & Ground” cables to the transmitter and

receiver taking care to follow the correct polarisation.

7. Connect one end of the CAT5e patch cable to the transmitter and the other end to your wall outlet or patch

panel.

8. Connect one end of the CAT5e patch cable to the receiver an the other end to your wall outlet.

9. The default setting for the EDID selection switch is “Auto”, check to make sure this hasn’t moved in transit.

The “local” setting is used for copying the EDID from the screen connected to the transmitters looped HDMI

output and the “remote” setting copies the EDID from the remote screen connected to “output 1” of the

receiver.

10. Connect the power supply to the transmitter or receiver and lock the DC connector for added security.

7. LED Indicators

Transmitter

●RJ45 Data Socket “Green” LED: Power indicator

●RJ45 Data Socket “Green” LED: HDBaseT connection indicator

Receiver

●RJ45 Data Socket “Green” LED: Power indicator

●RJ45 Data Socket “Green” LED: HDBaseT connection indicator

User Manual

Scion Tech SC05.6100

8. Application Drawing

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 6

IR-Out

HDMI In DC 24V

IR-In

HDMI Out

CAT5e/6

TX GND RX

Local Remote

Auto

Update

CAT5e/6

TX GND RX

Update

IR-Out DC 24V

IR-In

HDMI OutHDMI Out

CAT5e/6 (max 100m)

RS232

Matrix

Controller

Matrix

RS232

Remote Display

4K/60Hz, 4:4:4

Remote Display

4K/60Hz, 4:4:4

Local Display

4K/60Hz, 4:4:4

HDMI Source

IR Tx/Rx IR Tx/Rx

SC05.6100 Transmitter SC05.6100 Receiver

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 7

User Manual

Scion Tech SC05.6100

9. Maintenance

Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices.

9.1 Servicing

Damage requiring service: This product should be serviced by a qualified service engineer if:

●The DC power cord or AC adaptor has been damaged.

●Objects or liquids have entered the housings.

●The product has been exposed to rain.

●The product has stopped working or shows signs of significant change in operating performance or function.

●The unit has been dropped or severely damaged externally.

Servicing personnel: Do not attempt to service the product beyond that described in these instructions. Refer all

other servicing to authorised serving personnel.

Replacement parts: When parts need replacing ensure the service engineer uses parts specified by the

manufacture or parts that have the same characteristics as the original parts. Unauthorised substitutes may

result in fire, electric shock or other hazards.

Safety check: After a repair or service, ask the engineer to perform safety checks to confirm the product is in

proper working condition.

9.2 Warranty

If your product does not work properly because of a defect in materials or workmanship, our Company (referred

to as "the warrantor" ) will , for the length of the period indicated as below, (Parts and labour 2 years) which

starts with the date of original purchase ("Limited Warranty period"), at its option either (a) repair your product

with new or refurbished parts, or (b) replace it with a new of a refurbished product. The decision to repair or

replace will be made by the warrantor.

During the "Labour" Limited Warranty period there will be no charge for labour. During the "Parts" warranty

period, there will be no charge for parts. You must mail-in your product during the warranty period. This Limited

Warranty is extended only to the original purchaser and only covers product purchased as new. A purchase

receipt or other proof of original purchase date is required for Limited Warranty service.

9.3 Returning a Product

When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the original

carton. Include a letter detailing the complaint and provide a day time phone number and/or email address

where you can be reached.

User Manual

Scion Tech SC05.6100

Tel: +44 (0) 1635 862484 www.scion-tech.co.uk [email protected]

Page 8

9.4 Limited warranty limits and exclusions

This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT

COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages

which occurred in shipment, or failures which are caused by products not supplied by warrantor, or failures

which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation,

set-up adjustments, maladjustment of consumer controls, improper maintenance, power line surge, lightning

damage, modification, or service by anyone other than a Factory Service centre or other authorized service

engineer, or damage that is attributable to acts of God.

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY COVERAGE".THE

WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF

THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As examples, this excludes damages

for lost time, cost of having someone remove or re-install an installed unit if applicable, travel to and from the

service, loss of or damage to media or images, data or other recorded content. The items listed are not exclusive,

but are for illustration only).

PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY.

This returns policy does not affect your legal rights. Details of your legal rights are available from Trading

Standards or Citizens Advice Consumer Service.

Scion Tech Limited

Thatcham, Berkshire, United Kingdom

Tabla de contenidos

Otros manuales de Extensor de Scion

Scion

Scion PRO-9010 Guía de inicio rápido

Scion

Scion SC05.3100 Manual de usuario

Scion

Scion SC05.9000F Manual de usuario

Scion

Scion SC05.8100VS Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
