Schwank STS-JZ Instrucciones de funcionamiento

STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

INSTALLATION / OWNER’S MANUAL

Improper installation, adjustment, alteration, service or

maintenance can cause property damage, injury or death.

Read the installation and operating and maintenance instruc-

tions thoroughly before installing or servicing this equipment.

SAFETY ALERT:

This heater must be installed and serviced only by a trained gas service techni-

cian. Failure to comply could result in personal injury, death, fire and/or property

damage.

Do not store or use gasoline or other flammable vapours and liquids in the

vicinity of this or any other gas fired appliance.

IF YOU SMELL GAS:

 Extinguish any open flame

 Do not attempt to light this or any other appliance

 Don’t touch any electrical switch, or telephone

 Immediately call your gas supplier from a neighbor’s phone

 Follow any and all instruction from your gas supplier

 If your gas supplier is not available, call the fire department

WARNING

FIELD CONVERTIBILITY:

This appliance is field con-

vertible to LP gas - except

inputs 100,000, 175,000,

and 200,000 Btuh.

Keep this manual in a secure place .

Record for future reference:

Model #:

Serial #:

(located on heater rating label)

Model

STS-JZ

LOWINTENSITYTUBETYPE

INFRAREDHEATERS

&Model

LOWINTENSITYTUBETYPE

INFRAREDHEATERS

STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

NOTICE:

This manual is current for this product. Occasional revision of the product Certification Stan-

dard may require changes to the product and/or this manual.

This publication, or parts thereof, may not be reproduced in any form, without prior written

consent from The Manufacturer. Unauthorized use or distribution of this publication is strictly

prohibited.

Schwank Group - Schwank and InfraSave

5285 Bradco Boulevard

Mississauga, Ontario,L4W 2A6

PO Box 988, 2 Schwank Way

Waynesboro, Georgia 30830

Customer & Technical Services

Phone: 877-446-3727

Fax: 866-361-0523

e-mail: [email protected]

www.schwankgroup.com

www.infrasave.com

3 STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

TABLE OF CONTENTS

TOPIC .........PAGE

IMPORTANT INFORMATION - READ FIRST

APPLICATION..............................................4

HEATER EXPANSION ...........................5, 35

GAS CONNECTION ...............................5, 35

VENTING.................................................5, 29

START UP ‘SMOKE’....................................5

THERMOSTAT SETTING / COMFORT .......5

TUBE ‘GLOW’ ..............................................6

CLEARANCE TO COMBUSTIBLES............6

Clearances Figure & Table ........................7

STACKING HEIGHT SIGN .........................8

1. LABOR REQUIREMENTS ...............................9

2. INSTALLATION: AIRCRAFT HANGARS.........9

3. INSTALLATION: COMMERCIAL GARAGE ....9

4. INSTALLATION: NOT SPACE HEATING........9

5. PRE-INSTALLATION SURVEY......................10

6. MOUNTING CLEARANCES...........................11

SERVICE CLEARANCE.................................11

HEATER PLACEMENT GUIDELINES...........12

7. SUSPENDING THE SYSTEM - General........13

8. SYSTEMS WITH 90° & 180° ELBOWS ... 16-19

ELBOW KIT DIMENSIONS ...………..16, 54

9. BURNER & TUBE INSTALLATION................20

TURBULATOR LENGTH & LOCATION.........23

SPECIAL COUPLING -100,175 & 200 Mbh..24, 25

10. REFLECTOR INSTALLATION......................26

11-A SEISMIC RESTRAINT ................................28

11-B HIGH WIND RESTRAINT ...........................28

12. FLUE VENTING..............................................29

12A. MIN./MAX. SYSTEM LENGTHS ..................32

13. COMBUSTION AIR DUCT.............................33

TOPIC ……...PAGE

14. GAS SUPPLY / HEATER EXPANSION..........34

FLEXIBLE GAS CONNECTION............... 35 - 36

15. ELECTRICAL AND THERMOSTAT.................37

16. HIGH ALTITUDE INSTALLATION...................37

17. LIGHTING INSTRUCTIONS ...........................37

18. RECOMMENDED MAINTENANCE.................37

19. WIRING DIAGRAM: FENWAL DSI..................38

HONEYWELL S87J DSI...............63

CHANNEL MICRO 50N DSI.........65

19-A. WIRING DIAGRAM MULTIPLE HEATERS

PER THERMOSTAT.....................................39

20. SEQUENCE OF OPERATION: FENWAL DSI .....40

SPARK IGNITER SET UP...............................42

21. TROUBLESHOOTING GUIDE: FENWAL DSI......43

22. TROUBLESHOOTING GUIDE: HEATER.............44

23. START– UP / COMMISSIONING SHEET.......46

WARRANTY STATEMENT ...................BACK PAGE

PRODUCT DIMENSIONS & METRICS

24. HEATER DIMENSIONS / WEIGHTS ………48

INSTALLATION DIMENSIONS ………. ..49

25. BURNER / TUBE KIT ASSEMBLY CHART.....50

26. GAS CONVERSION OF BURNER ………….. 51

27. HIGH ALTITUDE & ORIFICE CHART...... 52 - 53

28. OPTIONAL ACCESSORIES..................... 54 - 56

31. BURNER PARTS LIST ............................ 57 - 59

32. TUBE SYSTEM PARTS LIST...........................60

DSI CONTROL ADDENDUM: PREVIOUS MODELS

HONEYWELL S87J DSI............................ 61 - 62

CHANNEL MICRO 50N DSI...................... 63 - 65

STS-JZ and IQ SERIES

GAS FIRED INFRARED

LOW INTENSITY TUBE TYPE

STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

APPLICATION

A gas-fired radiant tube heater may be installed for heating of commercial / industrial non-

residential spaces. It is beyond the scope of these instructions to consider all conditions that

may be encountered. Installation must conform with local building codes or, in the absence of

local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 in the U.S.A. or the Natu-

ral Gas and Propane Installation Code, CSA B149.1 in Canada. The latest edition Electrical

Code ANSI/NFPA N0 70 in the U.S.A. and PART 1 CSA C22.1 in Canada must also be ob-

served.

Installation of a gas fired tube heater must conform to all heating installation design procedures

including clearance to combustibles, connection to the gas and electrical supplies, and ventila-

tion.

This heater is not for installation in a Class 1 or Class 2 explosive environment, nor a resi-

dence. If installation of this equipment is in question, consult with local authorities having juris-

diction (Fire Marshall, labor department, insurance underwriter, or others).

Revisions to codes and/or standards, may require revision to equipment and installation proce-

dures. In case of discrepancy, the latest codes, standards, and installation manual will take pri-

ority over prior releases.

Models STS-JZ and IQ may be installed for heating of commercial / industrial non-residential

indoor spaces.

MODELS AVAILABLE FOR OTHER APPLICATIONS:

Models SPW-JZ and IWP have a powder coated water resistant burner enclosure

and may be installed for heating of commercial / industrial non-residential outdoor

spaces and wet indoor environments.

Models STW-JZ and IW have a stainless steel water resistant burner enclosure and

may be installed for heating of commercial / industrial non-residential outdoor

spaces and harsh wet indoor environments.

Improper installation, adjustment, alteration, service or maintenance can cause

property damage, injury or death. Read and understand this installation and op-

eration manual thoroughly prior to assembly, installation, operation or service to

this appliance.

This heater must be installed and serviced only by a trained gas service techni-

cian.

Do not store or use gasoline or other flammable vapours and liquids in the vicinity

of this or any other gas fired appliance.

Failure to comply could result in personal injury, death, fire and/or property dam-

age.

Do not store or use gasoline or other flammable vapours and liquids in the vicinity

of this or any other gas fired appliance.

This appliance may have sharp edges and corners. Wear protective clothing such

as gloves and protective eye wear when servicing this or any other appliance.

WARNING

5 STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

Heater Expansion

It is a normal condition that during heat-up and cool-down a tube

heater will expand and contract. Allowances for heater expansion

must be made in the gas connection, venting and combustion air

ducting. Improper installation, alteration, or adjustment can result in

property damage, injury or death. Refer to Section 13

WARNING

Venting

Inadequate venting of a heater may result in asphyxiation, carbon

monoxide poisoning, injury or death. This heater may be directly or

indirectly vented from the space. Venting must be in accordance with

all local, state, provincial, and national codes (ANSI Z223.1/NFPA 54

in USA; B149.1 in Canada) and as indicated in this manual. Refer to Sections 11 & 12

Gas Connection

Improper installation, connection, or adjustment can result in property

damage, toxic gases, asphyxiation, injury or death. Using an ap-

proved flexible gas connector in the USA or Type 1 hose connector in

Canada, the gas supply to the heater must be connected and tested

in accordance with all local, state, provincial, and national codes (ANSI Z223.1/NFPA 54 in

USA; B149.1 in Canada) and as indicated in this manual. Refer to Section 13

WARNING

WARNING Start-Up ‘SMOKE’ Condition

During start up, the heating of material coatings used in the production process of tubes and

reflectors will create smoke during the initial period of operation. This condition is normal and

temporary .

Ensure that there is sufficient ventilation to adequately clear any smoke from the space.

Notify site and safety personnel to ensure that alarm systems are not unduly activated.

IMPORTANT THERMOSTAT SETTING FOR COMFORT

Infrared radiant (IR) heating system provide comfort with the effect of radiant heat and ambient

air heat.

If your IR system is controlled with a thermostat (TruTemp or ThermoControl Plus) that senses

radiant heat, then set the thermostat to the desired comfort temperature (ie: 65°; 68°; 20°C).

If your IR system is controlled with a standard 24V or 120V thermostat that senses only air tem-

perature, then start with a thermostat setting that is 5° to 7°F (3° to 5°C) lower than the desired

comfort temperature. Some trial and error setting may be required to ‘fine tune’ the comfort tem-

perature that best suits your site and provides most economical operation.

WARNING

STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

Clearance to combustibles

Location of flammable or explosive objects, liquids or vapors close to the heater may cause fire

or explosion and result in property damage, injury or death. Do not use, store or locate flamma-

ble or explosive objects, liquids or vapors in proximity of the heater.

The clearance to combustible material represents the minimum dis-

tance that must be maintained between the outer heater surface and

a nearby surface. The stated clearance to combustibles represents a

surface temperature of 90F° (50C°) above room temperature. It is the

installer’s responsibility to ensure that building materials with a low

heat tolerance which may degrade at lower temperatures are pro-

tected to prevent degradation. Examples of low heat tolerance mate-

rials include vinyl siding, fabrics, some plastics, filmy materials, etc.

In locations used for the storage of combustible materials, signs must be posted to specify the

maximum permissible stacking height to maintain the required clearances from the heater to

the combustibles. Such signs must either be posted adjacent to the heater thermostats or in

the absence of such thermostats in a conspicuous location. In addition to stored or stationary

material, consideration must also be given to moveable objects such as cranes, vehicles, and

overhead doors, and structural objects such as sprinkler heads, electrical and gas lines, and

electrical fixtures.

It is beyond the scope of these instructions to consider all conditions that may be encountered.

Consult local authorities such as the Fire Marshall, insurance carrier, or safety authorities if you

are uncertain as to the safety or applicability of the proposed installation.

Refer to Figure 1 and Table 1 for the certified clearances to combustibles for the appro-

priate model input/size.

WARNING

WARNING Tube “GLOW”

It is a normal condition that the combustion tube (1st tube) can appear to “glow red”. For inputs

up to 150,000 Btuh, the top surface of the tube can appear red where heat is trapped between

the reflector and the tube. The stainless steel tube used for inputs 175,000 and greater can ap-

pear to entirely glow red. The tube material is designed into the heater because it can with-

stand the high temperature of combustion, and the “red glow” is a normal occurrence.

7 STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

TABLE 1 MINIMUM CLEARANCES TO COMBUSTIBLES*

FIGURE 1 MINIMUM CLEARANCES TO COMBUSTIBLES* - refer to Table 1 for values

*The clearance to combustible materials represents the minimum distance that must be main-

tained between the heater and a nearby surface. The stated clearance to combustibles

represents a surface temperature of 90F° (50C°) above room temperature. .

NOTE: A ‘PEEL & STICK’ SIGN IS SUPPLIED: USE AN INDELIBLE MARKER TO

ENTER VALUES ‘H’, ‘S’, ‘F’, & ‘B’ ON .

POST THE SIGN ADJACENT TO THE HEATER THERMOSTAT OR IN A

PROMINENT LOCATION. See next page for details.

S S

Suspended at an

angle up to 45° Suspended

horizontally

FLOOR

Maximum

Stack Height

H= T- C

‘T’ is meas-

ured on site,

FLOOR

Maximum

Stack Height

H= T- C

‘T’ is meas-

ured on site,

MODEL SUSPENDED AT AN ANGLE

UP TO 45 DEGREES SUSPENDED

HORIZONTALLY

inches (cm) B

inches (cm) F

inches (cm) C

inches (cm) A

inches (cm) S

inches (cm) C

inches (cm)

STS-JZ / IQ 200 13 (33) 6(15.2) 74 (188) 70 (178) 14 (36) 44 (112) 76 (193)

STS-JZ / IQ 175 12 (31) 6(15.2) 72 (183) 68 (172) 13 (33) 42 (107) 74 (188)

STS-JZ / IQ 155 5.5 (14) 1(2.5) 44 (112) 64 (163) 3.5 (9) 19 (48) 64 (163)

STS-JZ / IQ 130 4.5 (11) 1(2.5) 35 (89) 60 (152) 3.3 (9) 11 (28) 60 (152)

STS-JZ / IQ 110 3.5 (9) 1(2.5) 26 (66) 54 (137) 2 (5) 10 (25) 54 (137)

STS-JZ / IQ 100 6.5 (16.5) 1(2.5) 57 (145) 68 (172) 6 (15) 22 (56) 68 (172)

STS-JZ / IQ 80 3(8) 1(2.5) 23 (59) 38 (97) 1.75 (5) 6 (15) 38 (97)

STS-JZ / IQ 60 2.5 (6) 1(2.5) 17 (43) 34 (86) 1.5 (4) 5.5 (14) 34 (86)

STS-JZ / IQ 45 2.75 (7) 1(2.5) 24 (61) 32 (81) 2.25 (6) 7 (18) 32 (81)

STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

VENT END CLEARANCE: Clearances from the vent pipe are determined by local or national

installation codes, but must not be less than 6 inches (15 cm). For ‘unvented’ installation, a

minimum distance of 48 inches (122 cm) is required from the end of heater to a combustible

surface.

In locations used for the storage of combustible materials: Signs

must be posted specifying the maximum permissible stacking height to

maintain the required clearances from the heater to the combustibles.

The signs must be posted either adjacent to the IR heating system thermostats or in the ab-

sence of such thermostats, in a conspicuous place.

For your convenience a “peel and stick” sign

is provided with this heater. Use a permanent

marker to record the required dimensions on

the sign.

To calculate the value ‘H’: (H= T- C)

 Measure the on site distance between bottom of

the heater and the floor = ‘T’ inches (cm).

 Refer to Table 1 to get the value ‘C’ that corre-

sponds to the model you are installing

 Subtract the clearance below the heater ‘C’ from

‘T’ to get value ‘H’.

 Enter this value ‘H’ on the sign.

Refer to the information for the heater model

being installed in Figure 1 and Table 1 to get

the values for dimensions ‘S’, ‘F’ and ‘B’.

WARNING

Post this sign as instructed above.

NOTE that in the above table the clearances are measured from the reflector.

It is the installer’s responsibility to ensure that building materials with a low heat tol-

erance which may degrade at lower temperatures are protected to prevent degrada-

tion. Examples of low heat tolerance materials include vinyl siding, fabrics, some

plastics, filmy materials, etc.

9 STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

2. INSTALLATION IN COMMERCIAL AIRCRAFT HANGARS

Low intensity radiant tube heaters are suitable for use in aircraft hangars when installed in ac-

cordance with the latest edition of the Standard for Aircraft Hangars, ANSI/NFPA No 409 in the

USA, or the Canadian Natural Gas and Propane Installation Code, B149.1.

A. A minimum clearance of 10 ft (3 m) above either the highest fuel storage compartment or

the highest engine enclosure of the highest aircraft which may occupy the hangar. The

clearance to the bottom of the heater shall be measured from the upper surface of either

the fuel storage compartment or the engine enclosure, whichever is higher from the floor.

B. A minimum clearance of 8 ft (2.4 m) must be maintained from the bottom of the heater to

the floor in other sections of the aircraft hangar, such as offices and shops, which communi-

cate with areas for servicing or storage. Refer to Table 1 for proper mounting clearances to

combustibles.

C. Heaters must be located so as to be protected from damage by aircraft and other objects,

such as cranes and movable scaffolding.

D. Heaters must be located so as to be accessible for servicing and adjustment.

1. LABOR REQUIRMENTS

Two persons are required to safely install this equipment. Wear gloves and other required

safety protection.

3. INSTALLATION IN COMMERCIAL GARAGES AND PARKING STRUCTURES

Low Intensity Heaters are suitable for use in commercial garages when installed in accordance

with the latest edition of the Standard for Parking Structures, ANSI/NFPA 88A, or the Standard

for Repair Garages, ANSI/NFPA No. 88B, or the Canadian Natural Gas and Propane Installa-

tion Code, B149.1.

An overhead heater shall be located high enough to maintain the mini-

mum distance to combustibles, as shown on the heater rating plate, from

the heater to any vehicles parked below the heater.

Overhead heaters shall be installed at least 8 ft (2.4 m) above the floor.

4. INSTALLATIONS OTHER THAN SPACE HEATING

Use for process or other applications that are not space heating will void the C.S.A. certification

and product warranty. Process application requires field inspection and/or certification by local

authorities having jurisdiction.

WARNING

STS-JZ-F / IQ-F I&O Manual

IM101220

RD: MAY 2014

RL: 17A

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause

property damage, injury or death. Read and understand this installation and

operation manual thoroughly prior to assembly, installation, operation or service to

this appliance.

This heater must be installed and serviced only by a trained gas service technician.

Do not store or use gasoline or other flammable vapours and liquids in the vicinity

of this or any other gas fired appliance.

Failure to comply could result in personal injury, death, fire and/or property damage.

Do not store or use gasoline or other flammable vapours and liquids in the vicinity

of this or any other gas fired appliance.

5. PRE INSTALLATION SURVEY

It is recommended that a full heating design including heat loss calculation be conducted on

the structure or area to be heated. Heater sizing and placement must consider available

mounting height, sources of greatest heat loss, and the certified clearances to combustibles

with respect to stored material, moveable objects (cranes, vehicles, lifts, overhead doors, etc),

sprinkler system heads, and other obstructions on the site. Consideration must also be given to

vent / duct placement and the allowable combined lengths of vent and duct. Carefully survey

the area to be heated, and for best results place burner and combustion chamber in the coldest

area(s) .

Installation must conform with all local, state, provincial and national code requirements includ-

ing the current latest edition ANSI Z223.1 (NFPA 54) in the U.S.A. and B149.1 installation

code in Canada, for gas burning appliances and equipment. The latest edition Electrical Code

ANSI/NFPA N0 70 in the U.S.A. and PART 1 CSA C22.1 in Canada must also be observed.

The heating system must have gas piping of the correct diameter, length, and arrangement to

function properly. For this reason, a layout drawing is necessary.

Otros manuales para STS-JZ

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Calentador de Schwank

Schwank

Schwank SST-MX Series Manual de instrucciones

Schwank

Schwank SchwankAir 3200-Recessed Series Manual de usuario

Schwank

Schwank STS-JZ Instrucciones de funcionamiento

Schwank

Schwank P40U Manual de usuario

Schwank

Schwank Select14 Series Manual de usuario

Schwank

Schwank ECOSCHWANK-MILLIVOLT Instrucciones de funcionamiento

Schwank

Schwank InfraSave Manual de usuario

Schwank

Schwank Select12 Series Manual de usuario

Schwank

Schwank STR Series Instrucciones de funcionamiento

Schwank

Schwank Swift5 Series Manual de usuario

Schwank

Schwank SchwankAir 4000-Recessed Series Manual de usuario

Schwank

Schwank sportSchwank Series Instrucciones de instalación

Schwank

Schwank STR-JZ Instrucciones de funcionamiento

Schwank

Schwank IL-X 200 Instrucciones de funcionamiento

Schwank

Schwank X-Series Instrucciones de funcionamiento

Schwank

Schwank 4003 series Manual de usuario

Schwank

Schwank SPW2-JZ Series Instrucciones de funcionamiento

Schwank

Schwank STW-JZ Manual de usuario

Schwank

Schwank STV-JZ Manual de usuario

Schwank

Schwank UHE Instrucciones de instalación

Schwank

Schwank infrasave SET Series Instrucciones de funcionamiento

Schwank

Schwank 20S L Manual de usuario

Schwank

Schwank STS-JZ Instrucciones de funcionamiento

Schwank

Schwank SCH-200-N Instrucciones de instalación

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
