ThermoControl Plus 4M

Controller with four heating zones

Modulation or 2-stage control

(alternative: eight heating zones with 1-stage control)

Operating and

Installation Manual

Schwank Group

5285 Bradco Blvd., Mississauga, ON L4W 2A6

2 Schwank Way, Waynesboro, GA 30830

Tel.: 1-8 -446-3 2 Fax: 1-866-361-0523

[email protected]

www.schwankgroup.com

Version: v.2_ March 2021

- 2 -

Content:

1 INTRODUCTION ................................................................................................. 3

2 SAFETY .............................................................................................................. 4

3 Structure and Function ........................................................................................ 5

4 OPERATION ....................................................................................................... 6

4.1 Basic operational parameters........................................................................... 6

4.1.1 Further information ........................................................................................ 6

4.1.2 Selection of a heating zone ...........................................................................

4.1.3 Turning the selected zone on/off...................................................................

4.1.4 Special information on the default screen .....................................................

4.2 Display and change of day- and night time temperature .................................. 8

4.3. How to read and modify time and date............................................................ 9

4.4 Scheduling ..................................................................................................... 11

4.4.1 How to read program schedule ................................................................. 11

4.4.2 How to clear a on/off program ................................................................... 12

4.4.3 How to clear a schedule ............................................................................... 12

4.4.4 How to protect the schedule program .......................................................... 12

4.4.5 How to program the on/off commands ......................................................... 13

4.5 Vacation program ........................................................................................... 14

4.6 Manual operation

FIX

.................................................................................. 15

4. Button for system check mode ...................................................................... 15

5 SET UP THE OPERATING PARAMETERS ..................................................... 16

5.1 Enter the number of heating zones ................................................................ 16

5.2 Set up the parameters.................................................................................... 1

5.3 The Heat-up optimization ............................................................................... 19

5.4 COPY ............................................................................................................. 19

5.5 How to do a security save and how to reload all parameters: ........................ 20

6 INSTALLATION................................................................................................. 20

6.1 Important general instructions ........................................................................ 21

6.2 Sensor connections ........................................................................................ 21

6.3 Connection of the heaters .............................................................................. 21

6.3.1 Modulation outputs (2-10V) ......................................................................... 21

6.4 Wiring connections ......................................................................................... 22

6.5 Exhaust fan connection .................................................................................. 24

6.5.1 Air-proving contact inputs ............................................................................ 24

6.6 Alarm contact input......................................................................................... 24

6. Remote-Control ........................................................................................ 24

6.8 Signal input fault............................................................................................. 24

6.9. Temperature display ºF / ºC selection ........................................................... 25

6.10 Communication connection .......................................................................... 25

6.11 Common ERROR signal............................................................................... 26

TECHNICAL PARAMETERS ............................................................................ 2

8 APPENDIX ........................................................................................................ 28

- 3 -

1 ntroduction

The Schwank ThermoControl Plus 4M is suitable for the control of single or two-stage /

modulation gas-infrared heating systems.

Depending on the selected operation mode, the controller has 4 to 8 heating zones.

Please read this manual carefully before installing or using the control unit. Failure to follow the

manual and warnings will affect your warranty. They are also a prerequisite for a professional

installation and correct handling.

Please pay special attention to chapter 2 „Safety“.

The ThermoControl Plus 4M is designed to be used for industrial/commercial building heating

systems.

Schwank will not be held responsible for any damages whatsoever resulting from incorrect use.

The controller measures the room temperature and switches the heater on/off by relays.

The controller features different operating programs.

P1…P5: Single-stage, Two-stage and Modulating heaters.

Daytime heating period extension +h

Available as a special feature is the extension of the programmed heating period by a manually

operated button. This button can be installed parallel to the sensor. By pushing the button

(~1 sec.), the value of the programmed daytime temperature in the selected heating zone is

maintained for an additional time period. (Default is 1h, adjustable in the parameter menu)

Programmed temperature values and operating programs

The temperatures and operating programs of every single heating zone are independently

selectable.

- Daytime- , night time- or frost protection temperature , selected by a weekly

schedule

- Continuous daytime ( F X) night time, ( F X) or frost protection temperature ( F X).

- Vacation program: the controller is able to save eight vacation periods, which are programmed

according to the calendar.

Other Features:

– Four air-proving contact inputs

– Four 2-10V modulation outputs

– Illuminated display

– Selectable ºF / ºC temperature display

–

Button for system check mode

–

Real-time clock with calendar, including automatic summmer- / winter time correction

– Outdoor temperature sensor (OAS)

– Heat-up optimization: the heater starts/switches on earlier to ensure that the desired

temperature is achieved exactly at the programmed time.

–

Remote acess control

– Working-hour/time-counter at every relay output

– Error-relay: relay switches on in any case of error

- 4 -

2 Safety

nstallation details

This is a 24VAC Class 2 extra low

voltage temperature controller. Use

only Class 2 rated power supply. Do

not install on voltages higher than

30VAC.

Read all information in this manual

before installing or programming the

appliance. The electrical installation

and wiring must conform to local and

national building and electrical

standards. Check the electrical

equipment regularly. Defective wires

etc. must be replaced immediately.

Be sure that power routed to the

controller has been powered off

before beginning installation or

making any setting. Make sure that

nobody can connect appliance to the

power supply while you are working.

The Schwank ThermoControl Plus 4M

has to be mounted on/at a place,

where it’s not affected by vibrations

or shocks.

Please install the ThermoControl

Plus 4M ensuring conformity to the

wiring diagram.

Ensure that the controller and the

heater relays are connected by 16

AWG cable and controller and

sensor connected by a 18 AWG

cable.

nstall the room-temperature-

sensor between the radiation

area of two heaters at a height of

2.5 m. Therefore the controller

receives an optimal value of the

nominal temperature.

+If the controller is installed in a large

building or in a building with

extreme temperature differences

(temperature gradiants), you can

also measure average temperature,

connecting additional room-

temperature sensors for every

single heating zone control circuit.

- 5 -

3 Structure and Function

Front panel layout:

1. /O Main switch on / off

2. LCD Display: All functional- and operating-information is shown on the default screen

(picture above).The control unit switches back to the default screen, if no button is

pushed for more than one minute.

3. If you push the button or the button, the daytime or night time temperature

setpoint will be displayed immediately. By using the +/- buttons the values can be

modified.

4. + / - With these buttons the currently displayed value can be increased or decreased.

5. D SP „Display-button“: To change the displayed screen. This button also offers the ability

to switch back to the default screen immediately.

6. SEL „SELECT”: This button allows you to select a certain parameter out of every

parameter shown on the display. The chosen/selected parameter can be modified by

the +/- buttons.

FIX

9. PR

Clock-button: It can be used to display and modify time and date.

Push to switch between programmed and FIXed operation modes.

To check and modify the weekly schedule program in the displayed heating zone.

10. CLR „Clear-button“: To delete a switch-point or a complete schedule program.

11. Copy Push to copy time- and temperature programs.

12. ERROR The system-error light turns on for any kind of error. A blinking sign on the display

will provide information about the cause.

13. ZONE Push to switch between different heating zones.

14. Push to turn on/off the selected heating zone.

15. SERV CE „Maintenance”: If this sign appears, the system requires maintenance: please call

16.

service.

Push to program vacation operation mode.

17. Button for system check operation mode: all heating zones will operate with full

load.

- 6 -

4 Operation

4.1 Basic operational parameters

By starting the ThermoControl with the I/O switch an automatic display-test is activated. The

controller starts up with default settings. Afterwards the display jumps to the default screen,

which shows all the important operational information.

4.1.1 Further information

Actual control mode, in

this case: day

mode Present status of the heater:

full load

partial load (2-stage or Modulatingl)

heater is turned off

Measured temperature

in the room/zone

(18.2°C)

The exhaust fan is

working (optional)

1: Air-proving closed

1: Air-proving open

ID number of the

selected heating zone

ID number of relay outputs and sensor

inputs assigned to the currently selected

heating zone.

Outdoor temperature – value measured by OAS

outdoor temperature sensor only

Operation time counter: All stage relays have a

counters in two-stage control mode

Push the SEL button to

switch between the stage

counters. The shown data

cannot be modified, after

199999 hours the display

resets to zero.

The default screen gives all important operating data,

further information can be retrieved by pushing the

D SP button.

Value of the entered frost protection temperature .

The displayed value can be changed by pushing the

+/- buttons. Value range: +3 ... +20 °C / 3 ...68 ºF

Current level of heater output.

In one-stage operation it only shows 0% or 100%.

- -

4.1.2 Selection of a heating zone

4.1.3 Turning the selected zone on/off

If you want to stop heating a certain zone, push the button. The symbol will sign the

off-state of the zone. Measurement and display of zone temperature still works in a zone that is

turned off. You can turn the zone on again by pushing the button.

4.1.4 Special information on the default screen

The screen content, and adjustable

parameters belong to the selected

heating zone. The zone can be

selected by pushing the ZONE

button. After pushing the button, all

settings of the heating zone can be

adjusted and set.

During the optimized heat-up period, you will notice the

OPT symbol. The starting time of a specific zone is

determined by an algorithm. This way the controller

automaticaly adapts to environmental specifics like outdoor

temperature, heat-up performance, and possible structural

changes in the heating zone. The feature can only be

deactivated in the setup-menu. An OAS outdoor

temperature sensor is required for this feature.

While using the vacation-mode the sign will be marked.

To stop or modify the vacation program, please push the

button (chapter 4.5).

Option: After pushing the override button the day time

mode starts for a preset, adjustable time (0:00-24:00h;

default is 1h). At the same time the +h symbol will be

marked. This operation can be stopped by using the

FIX

button.

Night time mode has been selected remotely ( ? ). All

three operation modes ( 4 21 ) are possible, just like

in case of FIXed modes.

- 8 -

4.2 Display and change of day- and night time temperature

The desired temperature for every heating zone can be programmed separately.

Pushing the D SP button, (or automatically after

one minute, without pushing a button) the display

jumps back to the default screen.

The current day- or night

time temperatures can be

displayed, if you push the

or button.

The displayed values can be

modified by pushing the +/-

buttons.

All modifications are saved

immediately.

The temperature setpoint

values can be adjusted in

the following range:

+3…+35

°C / 3 ...95

- 9 -

4.3. How to read and modify time and date

To read and modify time and date, the button has to be pushed.

All heating zones have a separate program schedule. This function takes place in the digital

clock. At first the time is shown (in the picture: 14:03). Afterwards you have to use the button

again, to be able to change the year (2021), after pushing the button for the third time month and

day (in this case: 3 = March, 24) are displayed. „3 Day” stands for the third day of the

ongoing week, in other words: Wednesday. ( 1= Monday, etc.)

After using the button once more the display jumps back to the normal clock.

The display jumps to default screen, if you press the D SP button.

Setting the time

To change the time, the

SEL button has to be

pressed. At first the

minutes start to blink

(03), which can be

modified by using the

buttons +/-.

After pushing the SEL

button again, the hours

will start to blink. (14)

The hours can also be

changed with the +/-

buttons.

The setting of the time

can be finished by using

the button.

Afterwards the display

goes back to the year.

Remark: symbols or figures, which are framed are

blinking ones!

- 10 -

Setting the year

After the time has been modified, you have to set the right year, month and day as well.

Otherwise the automatic summer- / wintertime correction won’t work correctly.

Setting the month and day

To change the year, you have

to press the SEL button. The

last two figures will start to blink

(20), they can be modified with

the +/- buttons.

Afterwards the button has to

be pushed, and month and day

respectively will be shown on

the display. When the year has

been modified, the day of the

week might be changing,

according to the calendar (in

this case 3).

To change the setting you have

to press SEL. At first the month

(3) will start to blink, the setting

can be modified with +/-.

To change the day please push

the SEL button again. Now, the

day starts to blink (24). The day

can also be modified with the

buttons +/-.

Once more the day of the week

changes according to the

calendar (first from 3 to 6, then

from to ).

If the setting is completed push

D SP. After pushing the button,

the display switches back to the

default screen.

Tabla de contenidos

Otros manuales de Controladores de Schwank

Schwank

Schwank ThermoControl Plus 4 Manual de usuario

Schwank

Schwank SchwankAir 4000 Series Manual de usuario

Schwank

Schwank ThermoControl Plus M2 Hoja de especificaciones

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
