Mini Compact Terminal SCTMc
Operating Instructions
WWW.SCHMALZ.COM EN-US · 30.30.01.02107 · 00 · 07/19
Note
The Operating instructions were originally written in German. Store in a safe place for future reference.
Subject to technical changes without notice. No responsibility is taken for printing or other types of er-
rors.
Published by
© J.SchmalzGmbH, 07/19
This document is protected by copyright. J.SchmalzGmbH retains the rights established thereby. Repro-
duction of the contents, in full or in part, is only permitted within the limits of the legal provisions of
copyright law. Any modifications to or abridgments of the document are prohibited without explicit writ-
ten agreement from J.SchmalzGmbH.
Contact
J. Schmalz GmbH
Johannes-Schmalz-Str. 1
72293 Glatten, Germany
T: +49 7443 2403-0
www.schmalz.com
Contact information for Schmalz companies and trade partners worldwide can be found at:
www.schmalz.com/salesnetwork
2 / 26 EN-US · 30.30.01.02107 · 00 · 07/19
Contents
EN-US · 30.30.01.02107 · 00 · 07/19 3 / 26
Contents
1 Important information ...................................................................................................................................5
1.1 Note on Using this Document ............................................................................................................... 5
1.2 The technical documentation is part of the product ........................................................................... 5
1.3 Warnings in This Document................................................................................................................... 5
1.4 Other Applicable Documents ................................................................................................................ 5
1.5 Symbol..................................................................................................................................................... 5
1.6 Type Plate ............................................................................................................................................... 6
2 Fundamental Safety Instructions...................................................................................................................7
2.1 Emissions ................................................................................................................................................. 7
2.2 Intended Use........................................................................................................................................... 7
2.3 Non-Intended Use .................................................................................................................................. 7
2.4 Personnel Qualification.......................................................................................................................... 8
2.5 Modifications to the Product................................................................................................................. 8
3 Product Description ........................................................................................................................................9
3.1 Mini compact terminal description ....................................................................................................... 9
3.2 Description of the Ejector ...................................................................................................................... 9
3.2.1 Suction of the Workpiece (Vacuum Generation) ......................................................................9
3.2.2 Depositing the Workpiece/Part (Blowing Off)......................................................................... 10
3.3 Variants and product keys ................................................................................................................... 10
3.4 Components of the Mini Compact Terminal ...................................................................................... 11
4 Technical Data ...............................................................................................................................................12
4.1 General parameters.............................................................................................................................. 12
4.2 Mechanical Data................................................................................................................................... 12
4.2.1 Performance Data...................................................................................................................... 12
4.2.2 SCTMc dimensions .....................................................................................................................13
4.2.3 SCTMc-MP dimensions...............................................................................................................13
5 Transport and Storage..................................................................................................................................15
5.1 Checking the Delivery .......................................................................................................................... 15
5.2 Reusing the Packaging......................................................................................................................... 15
6 Installation.....................................................................................................................................................16
6.1 Installation Instructions........................................................................................................................ 16
6.2 Installation ............................................................................................................................................ 16
6.3 Pneumatic connection.......................................................................................................................... 17
6.4 Connecting the Compressed Air and Vacuum.................................................................................... 17
6.5 Optional: External blow-off connection (EB) ..................................................................................... 18
6.6 Electrical Connection............................................................................................................................ 18
6.6.1 Variant with plug connector M8 .............................................................................................. 19
6.6.2 Variant with multipole (MP) connection .................................................................................19
7 Operation ......................................................................................................................................................21
7.1 General Preparations ........................................................................................................................... 21
7.2 Changing the Blow-Off Flow Rate on the Ejector.............................................................................. 21
8 Warranty........................................................................................................................................................22
Contents
4 / 26 EN-US · 30.30.01.02107 · 00 · 07/19
9 Spare and wearing parts, accessories .........................................................................................................23
9.1 Spare and Wearing Parts ..................................................................................................................... 23
9.2 Accessories ............................................................................................................................................ 23
10 Decommissioning and Recycling..................................................................................................................24
10.1 Disposing of the mini compact terminal............................................................................................. 24
11 EC Declaration of Conformity ......................................................................................................................25
Important information
EN-US · 30.30.01.02107 · 00 · 07/19 5 / 26
1Important information
1.1Note on Using this Document
J.SchmalzGmbH is generally referred to as Schmalz in these Operating instructions.
These Operating instructions contain important notes and information about the different operating
phases of the product:
• Transport, storage, start of operations and decommissioning
• Safe operation, required maintenance, rectification of any faults
The Operating instructions describe the product at the time of delivery by Schmalz.
1.2The technical documentation is part of the product
1. For problem-free and safe operation, follow the instructions in the documents.
2. Keep the technical documentation in close proximity to the product. The documentation must be ac-
cessible to personnel at all times.
3. Pass on the technical documentation to subsequent users.
ðFailure to follow the instructions in these Operating instructions may result in life-threatening in-
juries!
ðSchmalz is not liable for damage or malfunctions that result from failure to heed these instructions.
If you still have questions after reading the technical documentation, contact Schmalz-service at:
www.schmalz.com/services
1.3Warnings in This Document
Warnings warn against hazards that may occur when handling the product. This document contains three
levels of danger that you can recognize by the signal word.
Signal word Meaning
WARNING Indicates a medium-risk hazard which, if not avoided, could result in death or
serious injury.
CAUTION Indicates a low-risk hazard which, if not avoided, could result in minor or
moderate injury.
NOTE Indicates a danger that leads to property damage.
1.4Other Applicable Documents
Important:
These instructions explain how to mount the mini compact terminal as well as the important points that
must be taken into account when using such a terminal.
For safe operation, the operating instructions 30.30.01.01963 for the mini compact ejector SCPMc must be
observed. They describe operation and explain all of the functions.
1.5Symbol
This sign indicates useful and important information.
üThis symbol represents a prerequisite that must be met prior to an operational step.
4This sign represents an action to be performed.
ðThis sign represents the result of an action.
Important information
6 / 26 EN-US · 30.30.01.02107 · 00 · 07/19
Actions that consist of more than one step are numbered:
1. First action to be performed.
2. Second action to be performed.
1.6Type Plate
1 2
The type plates (1) and (2) are permanently attached to the Terminal and must always be clearly legible.
The type plate (1) contains the following data:
• Designation, incl. individual configuration codes (terminal “XY”, ejector “AAA”)
The type plate (2) contains the following data:
• Part number
• Permitted pressure range
• Manufacturing date
• Serial number
• QR code
Identical individual discs are installed in groups in the terminal as blocks. The following counting method
is defined for identification of the ejector blocks:
The ejector block to the right of the type plate (1) is the first ejector block. The second ejector block is as-
sembled next to that one, and so on, up to a maximum of four blocks.
Please specify all the information above when ordering replacement parts, making warranty claims or for
any other inquiries.
Fundamental Safety Instructions
EN-US · 30.30.01.02107 · 00 · 07/19 7 / 26
2Fundamental Safety Instructions
2.1Emissions
The device emits noise due to operation with compressed air and a vacuum.
CAUTION
Noise pollution caused by exhaust air or leakage during operation
Hearing damage
4In the event of leakage, check connections and lines and remedy leakages
4Wear ear protectors.
2.2Intended Use
The terminal is built in accordance with the latest standards of technology and is delivered in a safe oper-
ating condition; however, hazards may arise during use.
The terminal is designed to generate a vacuum for gripping and transporting objects when used in con-
junction with suction cups. Depending on the design, the control signals are transmitted directly or via ap-
propriate communication lines.
Neutral gases are approved as evacuation media. Neutral gases include air, nitrogen and inert gases (e.g.
argon, xenon and neon). For further information, see (> See ch. Technical Data).
The product is intended for industrial use.
Any other use is considered improper by the manufacturer and is deemed as contrary to the designated
use.
2.3Non-Intended Use
WARNING
Extraction of hazardous media, liquids or bulk material
Personal injury or damage to property!
4Do not extract harmful media such as dust, oil mists, vapors, aerosols etc.
4Do not extract aggressive gases or media such as acids, acid fumes, bases, biocides, dis-
infectants or detergents.
4Do not extract liquids or bulk materials, e.g. granulates.
Schmalz accepts no liability for damages caused by non-intended usage of the SCTM.
In particular, the following are considered non-intended use:
• Use in potentially explosive atmospheres
• Use in medical applications
• Lifting people or animals
• Evacuation of objects that are in danger of imploding
Fundamental Safety Instructions
8 / 26 EN-US · 30.30.01.02107 · 00 · 07/19
2.4Personnel Qualification
Unqualified personnel cannot recognize dangers and are therefore exposed to higher risks!
1. Only instruct qualified personnel to perform the tasks described in this manual.
2. The product may only be operated by persons who have undergone appropriate training.
3. Electrical work and installations may only be carried out by qualified electrical specialists.
4. Assembly and maintenance work may only be carried out by qualified personnel.
The following target groups are addressed in this manual:
• Installers who are trained in handling the product and can operate and install it
• Technically trained service personnel performing the maintenance work
• Technically trained persons who work on electrical equipment
2.5Modifications to the Product
Schmalz assumes no liability for consequences of modifications over which it has no control:
1. The product must be operated only in its original condition as delivered.
2. Use only original spare parts from Schmalz.
3. The product must be operated only in perfect condition.
Product Description
EN-US · 30.30.01.02107 · 00 · 07/19 9 / 26
3Product Description
3.1Mini compact terminal description
The Schmalz mini compact terminal SCTMc, or SCTMc for short, is a compact unit of multiple vacuum gen-
erators known as ejectors. Thanks to its modular design, up to 16 individual ejectors can be controlled and
configured independently. It can be used to handle different parts simultaneously and independently us-
ing just one vacuum system.
3.2Description of the Ejector
Every SCTMc mini compact ejector has an electrical connection to the voltage supply and to communica-
tion with the control for the superordinate machine.
The compressed air supply can be connected centrally for all ejectors. As an alternative, there can also be
a compressed air supply for each ejector.
3.2.1Suction of the Workpiece (Vacuum Generation)
The ejector is designed for vacuum handling of airtight parts in combination with suction systems. The
vacuum is generated in a nozzle according to the Venturi principle, i.e. by using suction generated by the
flow of accelerated compressed air. Compressed air is channeled into the ejector and flows through the
nozzle. A vacuum is generated immediately downstream of the motive nozzle; this causes the air to be
sucked through the vacuum connection. The air and compressed air that have been removed by the suc-
tion exit together via the silencer or exhaust air channel.
The venturi nozzle on the ejector is activated and deactivated using the suction command:
• In the NO (normally open) variant, the venturi nozzle is deactivated when the suction signal is re-
ceived.
Product Description
10 / 26 EN-US · 30.30.01.02107 · 00 · 07/19
• In the NC (normally closed) variant, the venturi nozzle is activated when the suction signal is re-
ceived.
An integrated sensor records the vacuum generated by the venturi nozzle. The exact vacuum value is
shown on the display.
The diagram below shows the vacuum curve for when the air saving function is activated:
Vacuum
[mbar]
Vacuum on Time [s]
SP1
SP2
rP1
rP2
The ejector has an integrated air saving function and automatically regulates the vacuum in suction
mode:
• The electronics switch the venturi nozzle off as soon as the vacuum limit value set for switching
point SP1 is reached.
• When objects with airtight surfaces are picked up, the integrated non-return valve prevents the vac-
uum from dropping.
• If leaks cause the system vacuum to drop below the limit value configured for the switching point
rP1, the venturi nozzle is switched back on.
3.2.2Depositing the Workpiece/Part (Blowing Off)
In blow off mode, the vacuum circuit of the ejector is supplied with compressed air. This ensures that the
vacuum drops quickly, allowing the workpiece to be quickly deposited.
During blow off, [-FF] is shown on the display.
The ejector provides two blow off modes for selection:
• Externally controlled blow off
• Internally time-controlled blow off
3.3Variants and product keys
The item designation of the SCTM is composed of a product key, which indicates the number of ejectors
installed and their exact properties.
The SCTM product key (so-called system configuration), e.g. SCTMc-MP-6-XY-2AAF-2AB0-2AAH, is com-
posed as follows:
Feature Variants Comment
Product class SCTM terminal with c-ejectors
Basic: b
Controlled: c
—
Otros manuales para SCTMc
1
Tabla de contenidos
Otros manuales de Terminal táctil de Schmalz
Schmalz
Schmalz SCTMi Series Manual de usuario
Schmalz
Schmalz SCTMc Manual de usuario
Schmalz
Schmalz SCTMi IO-Link Manual de usuario
Schmalz
Schmalz SCTMi 2 Manual de usuario
Schmalz
Schmalz SCTMi Manual de usuario
Schmalz
Schmalz SCTSi Especificaciones técnicas
Schmalz
Schmalz SCTSi IOL Manual de usuario
Schmalz
Schmalz SCTMb Manual de usuario
