Scale Calibration
In the event that the scale loses accuracy, recalibration may be required.
Recalibration is required if the load cell of the scale is overloaded due to
dropping something heavy on the scale, or dropping it.
If the scale did come from a colder or warmer environment, wait for some time
for the scale to be at the same temperature as your current environment.
Plug in the DC power supply at the back of the scale.
Press the key and hold it for about 5~7 seconds. The scale will enter
the calibration mode. “E0” will be displayed on the LCD. Press again
(within 4 seconds of the display of “E0”) and the display will change to “E1”.
Once the “E1” is displayed on the LCD, wait until the scale displays the base
frequency. The base frequency (without anything on the platform) should be
between 500~2500.
If the displayed number is below 500 or over 2500, it must be adjusted at the
internal potentiometer around 1500. (To access this adjustment the scale must
be opened and this should only be done by a qualified technician)
If the base frequency (0kg frequency) is not in the range of 500~2500 the
scale will not proceed with the calibration.
Note: In most cases all that has to be done is to turn off the scale and
use it.
CAUTION: The following can only be done if you have calibration
weights:
Wait for sometime and “1” is displayed. Put 5oz on the platform and wait. “E”
appears on the display indicating the end of the calibration.
Turn the scale off. Calibration is completed.
Scale Specifications
Operates from either a 9V alkaline battery or 9V included AC adapter
Load cell Technology
Liquid Crystal Display (LCD)
Capacity 1lb 1.75oz
Graduation 0.01oz
Tare function up to the scale’s overload range.
Auto shutoff after 4 minutes while on battery
Switch able to gram mode (500g/0.1g)
PW500
Electronic Digital Scale
Max. 1lbs, d=0.01oz
Operating Instructions
Unpack and assemble your scale
Unpack your scale and remove protective insertion (if any) in between the
platform and the upper case of the scales.
Using the Supplied AC Adapter
Connect the AC adapter into the power jack on the rear of the scale and plug it
into an outlet. It is advisable to remove the battery when using AC power
Using Scale with Batteries
You will require 1 new 9V alkaline leak proof battery. Remove the battery
compartment cover underneath the scale and connect the battery. Insert the
battery into the compartment making certain that the wiring is not placed in
tension. Replace the battery compartment cover. Remember to remove the
battery if the scale is to be stored for a long period of time, or if AC power is to
be used.
Operate on a Firm, Flat, Level surface
In order to operate correctly, the scale must be installed on a firm, level, flat
surface. Weighing an Item
Press the key. The number will appear on the display for a
short time while the scale performs a self-checking / zero routine and then
displays on the display. Your scale is now ready to weigh an
item. Place an item on the scale and the weight will register on the display
after a short delay.
Use of the TARE/ZERO Function
1. To reset the scale to read 0.00oz press the key.
2. When you wish to weigh only the contents of a container, you can
remove the weight of the container from the display by pressing the
key as follows.
Place the container on the scale and press the key.
(Note: Pressing this key for long time will toggle the display mode
between oz and gram)
The scale should now display .
Then place the item or material to be weighed into the container. The
scale will now show the weight of the item or material in the container
and exclude the weight of the container.
Error Messages
If an symbol appears in the display, this means that the weight
capacity of the scale has been exceeded.
If a sign appear on the upper left side of the LCD, this means that the low
input voltage (less than 7V).
Operating Temperature
The scale is designed to operate in a normal room temperatures. If subjected
cold or warm temperatures, it should be allowed to reach room temperature
before operating.
Toggling between gram and lb-oz mode
When the scale is in oz mode, press key for about 3~4 seconds, the
display will change to percent mode and vice versa.
(Note: If the ON/TARE key is pressed for short time the scale will tare the
weight placed on the platform)
