Savin 3350DNP Manual de usuario
3350DNP/5450
OPERATING INSTRUCTIONS
TPEH162N
Read this manual carefully before you use this product and keep it handy for future
reference.
For safety, please follow the instructions in this manual.
Note to users in the United States of America
Notice:
This equipment has been tested and found to comply with the limits for a Class A digital devices, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, might cause harmful interference to radio communications. Operation of
this equipmentin a residential area is likelyto causeharmful interference in which case the user will be
required to correct the interference at his own expense.
Warning
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Note to users in Canada
Warning:
This Class A digital apparatus compiles with Canadian ICES-003.
Remarque concernant les utilisateurs au Canada
Avertissement:
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
In accordance with ISO Standard 7001, this machine uses the following symbols for the main switch:
a
aa
ameans POWER ON.
b
bb
bmeans POWER OFF.
Copyright © 1998 Ricoh Co., Ltd.
i
Safety Information
When using your machine, the following safety precautions should always be
followed.
Safety During Operation
In this manual, the following important symbols are used:
Examples Of Indications
R
WARNING:
Ignoring this warning could cause serious injury or even death.
R
CAUTION:
Ignoring this caution could cause injury or damage to property.
Symbols Rmean a situation that requires you take care.
Do NOT carry out the operation represented by this symbol m.
This example means “Do not take apart”.
Symbols $mean you MUST perform this operation.
This example means “You must remove the wall plug”.
ii
R
RR
R
Warning:
•
Only connect the machine to the power source described on
the inside front cover of this manual.
•
Avoid multi-wiring.
•
Do not damage,break or make any modifications to the pow-
er cord. Do not place heavy objects on it, pull it hard or bend
it more than necessary. These actions could cause an elec-
tric shock or fire.
•
Do not plug or unplug the power cord with your hands wet.
Otherwise, an electric shock might occur.
•
Make sure the wall outlet is near the machine and freely ac-
cessible so that in event of an emergency it can be un-
plugged easily.
•
Do not remove any covers or screws other than those spec-
ified in this manual. Some parts of the machine are at a high
voltage and could give you an electric shock. When the ma-
chine needs to be checked, adjusted, or repaired, contact
your service representative.
•
Do not take apart or attempt any modifications to this ma-
chine. There is a risk of fire, electric shock, explosion or loss
of sight.
•
If the machine looks damaged or breaks down, smoke is
coming out, there is a strange smell or anything looks un-
usual, immediately turn off the main switch then unplug the
power cord from the wall. Do not continue using the ma-
chine in this condition. Contact your service representative.
•
If metal, liquid or foreign matter falls into the machine, turn
off the main switch and unplug the main power cord. Con-
tact your service representative. Do not keep using the ma-
chine with a fault or defect.
•
Do not put any metal objects or containers holding water
(e.g. vases, flowerpots, glasses) on the machine. If the con-
tents fall inside the machine, a fire or electric shock could
occur.
iii
R
RR
R
Caution:
•
Keep the machine away from humidity and dust. A fire or an elec-
tric shock might occur.
•
Do not place the machine on an unstable or tilted surface. If it top-
ples over, it could cause injury.
•
After you move the machine, fix it with the caster fixture. Other-
wise, the machine might move or come down to cause a personal
injury.
•
When you move the machine, unplug the power cord from the
wall outlet to avoid fire or electric shock.
•
When the machine will not be used for a long time, unplug the
power cord.
•
When you pull out the plug from the socket, grip the plug to avoid
damaging the cord and causing fire or electric shock.
•
If you use the machine in a confined space, make sure there is a
continuous air turnover.
•
Do not reuse stapled paper. Do not use aluminum foil, carbon-
containing paper or other conductive paper. Otherwise, a fire
might occur.
•
This machine has been tested for safety using this supplier's
parts and consumables. We recommend you only use these
specified supplies.
•
This equipment is only to be installed by a qualified service per-
sonnel.
•
Deliver to collection point for waste products. Do not be disposed
of via domestic refuse collection.
•
If ink comes into contact with your eyes, rinse immediately in run-
ning water. In the case of any abnormal symptoms, consult a
doctor.
iv
•
Keep the ink or ink container out of reach of children.
•
If ink is ingested, force vomiting by drinking a strong saline solu-
tion and consult a doctor immediately.
•
Be careful not to cut yourself on any sharp edges when you reach
inside the machine to remove misfed sheets of paper or masters.
•
While printing, do not touch the belt at the end of the paper deliv-
ery tray or the job separator. You might be injured.
•
When your machine is equipped with the PC controller option:
•
Do not place this equipment on an unstable or tilted surface. If
you do, it could fall.
•
Do not place heavy objects on top of this equipment. They
might cause the equipment to become unstable and topple
over.
•
When your machine is equipped with the PC controller option:
•
If by any chance this equipment falls over or a breakage oc-
curs (e.g., the cover), turn off the main switch of this equip-
ment, unplug the power cable and contact your service
representative. If you continue to use the equipment in this
state it could result in fire or electric shock.
v
How To Read This Manual
Symbols
In this manual, the following symbols are used:
R
WARNING:
This symbol indicates a potentially hazardous situation that might result in
death or serious injury when you misuse the machine without following the in-
structions under this symbol. Be sure to read the instructions, all of which are de-
scribed in the Safety Information section.
R
CAUTION:
This symbol indicates a potentially hazardous situation that might result in mi-
nor or moderate injury or property damage that does not involve personal injury
when you misuse the machine without following the instructions under this
symbol. Be sure to read the instructions, all of which are described in the Safety
Information section.
* The statements above are notes for your safety.
Important
If this instruction is not followed, paper might be misfed, originals might be
damaged, or data might be lost. Be sure to read this.
Preparation
This symbol indicates the prior knowledge or preparations required before op-
erating.
Note
This symbol indicates precautions for operation, or actions to take after misop-
eration.
Limitation
This symbol indicates numerical limits, functions that cannot be used together,
or conditions in which a particular function cannot be used.
Reference
This symbol indicates a reference.
[ ]
Keys that appear on the machine's panel display.
{ }
Keys built into the machine's operation panel.
vi
Making Prints
Before making prints using this ma-
chine, you have to make a master by
pressing the {
Start
}key. When you
press the {
Start
}key, the machine
scans the original image and makes a
master. This procedure describes
how to make basic prints.
ASet your originals.
When you set original on the
exposure glass (contact glass)
ASet one original face down.
When you set originals in the
optional document feeder
ASet the originals face up.
BPress the {
{{
{
Start
}
}}
}key.
CPress the {
{{
{
Proof
}
}}
}key.
Check the print image.
Reference
When you want to change the
image position, see ⇒P.25 “Ad-
justing Print Image Position”.
When you want to increase the
image density, press the {W}
key. See ⇒P.26 “Adjusting Print
Image Density”.
When you want to decrease the
image density, press the {V}
TPEH270E
TPEH281E
Program Clear Modes
Auto Cycle
Proof
Print
Enter Start
Clear/Stop
TPES050N
Program Clear Modes
Auto Cycle
Proof
Print
Enter Start
Clear/Stop
TPES060N
TPES560E
vii
key. See ⇒P.26 “Adjusting Print
Image Density”.
DEnter the desired number of
prints with the Number keys.
EPress the {
{{
{
Print
}
}}
}key.
When the print job has finished,
press the {
Clear Modes
}key. Previ-
ously entered job settings will be
cleared.
Combine Class Slow Fast
Speed
1
TPES100N
Program Clear Modes
Auto Cycle
Proof
Print
Enter Start
Clear/Stop
TPES040N
Program Clear Modes
Auto Cycle
Proof
Print
Enter Start
Clear/Stop
TPES070N
viii
What You Can Do With This Machine
❖
❖❖
❖
Standard Printing
See ⇒P.20 “Standard Printing”.
❖
❖❖
❖
Adjusting Print Image Position
See ⇒P.25 “Adjusting Print Image
Position”.
*: Paper feed direction
❖
❖❖
❖
Adjusting Print Image Density
See ⇒P.26 “Adjusting Print Image
Density”.
❖
❖❖
❖
Halftone Printing
See ⇒P.27 “Tint Mode—Halftone
Printing”.
❖
❖❖
❖
Changing The Printing Speed
See ⇒P.28 “Changing The Printing
Speed”.
❖
❖❖
❖
Reducing And Enlarging Using Preset
Ratios
See ⇒P.30 “Preset Reduce/En-
large—Reducing And Enlarging Us-
ing Preset Ratios”.
❖
❖❖
❖
Having The Machine Choose The Re-
production Ratios
See ⇒P.32 “Auto Magnification Se-
lection—Having The Machine Choose
The Reproduction Ratios”.
❖
❖❖
❖
Reducing And Enlarging In 1 % Steps
See ⇒P.35 “Zoom—Reducing And
Enlarging In 1 % Steps”.
GRPOSI0E
GRTINT0E
GRRATI0E
GRAUTO0E
GRZOOM0E
