SATO LP 100R L Manual de usuario

LP 100R Laser Printer

Installation Guide

Part No. 9855148

Revision number

Date

Reason for update

Rev 0

March, 2009

Initial release

Rev 1

April, 2014

USB Support, Company Info

No part of this work may be reproduced or copied in any form without the express

written consent of:

SATO America, Inc.

1140 Windham Pkwy.

Romeoville, IL 60446

Notice

All rights are reserved for devices, circuits, techniques, software, and names

appearing in this publication.

SATO America, Inc. ("SATO"), also reserves the right to make changes to this

publication and to the equipment described herein without notice.

Considerable effort has been made to ensure that this publication is free of

inaccuracies and omissions. SATO, however, makes no warranty of any kind

including, but not limited to, any implied warranties of merchantability and fitness for a

particular purpose with regard to this publication.

This publication is in conformance with international standards and guidelines valid at

the date of printing.

Trademarks

METO® is a registered trademark of SATO.

Kodescript™ and KodescriptPlus™ are trademarks of SATO.

HP®, Hewlett-Packard®, and PCL® are registered trademarks of Hewlett-Packard

Company.

Intel® is a registered trademark of Intel Corporation.

PostScript® is a registered trademark of Adobe Systems Incorporated.

TrueType™ is a trademark of Apple Computer, Inc.

All rights are reserved. This publication may not be copied in whole or in part, nor

transferred to any other media or language without the express written permission of

SATO America, Inc.

Liability Disclaimer

SATO America, Inc., products are warranted in accordance with the terms of the

applicable SATO product specification. Product performance is affected by system

configuration, software, the application, customer data, and operator control of the

system, among other factors. While SATO products are compatible with the

standards for which they are advertised, implementation by customers of the product

may vary. The suitability of a product for a specific application, therefore, must be

determined by the customer and is not warranted by SATO.

This manual is as complete and factual as possible at the time of printing; however,

the information in this manual may have been updated since that time. SATO

reserves the right to change the functions, features, or specifications of its products at

any time, without notice.

SATO America, Inc., has prepared this manual for use by SATO employees and

customers. The information contained herein is the property of SATO and must not be

reproduced without prior written approval from SATO.

MSDS sheets are available by request.

INSTALLATION GUIDE

III

Regulatory Notices

Laser Safety

This product employs a Class 3B laser diode having maximum power of 35 mW and wavelength of 770-800 nm.

This product is certified as a Class 1 laser product. Since the laser beam is concealed by protective housings, the

product does not emit hazardous laser radiation as long as the product is operated according to the instructions in

this manual.

Internal Laser Radiation

Maximum average radiation power: 22 μW at the PC Drum

Wavelength: 770-800 nm

!DANGER

Use of controls or adjustments or performance of procedures

other than those specified in this manual may result in

hazardous radiation exposure.

Complies with 21 CFR 1040.10 and 1040.11

except for deviations pursuant to laser notice

No.50, dated June 24, 2007

Or/and

INSTALLATION GUIDE

FCC Regulations

This equipment generates and uses radio frequency and, if not installed in accordance with the instruction manual,

may cause interference to radio and television reception. The equipment has been tested and found to comply

within the limits for a Class A computing device in accordance with specifications in subpart J of Part 15 of the

Federal Communication Commission (FCC) Rules, which are designed to provide reasonable protection against

such interference in a commercial installation.

Note: Use a shielded and properly grounded I/O cable to ensure that this unit complies to the limits specified in the

FCC Rules.

There is no guarantee, however, that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off

and on, the user, at his or her own expense, will be required to take whatever measures may be necessary to

correct the interference.

For more information on preventing radio frequency interference, see the Manufacturer’s Instructions and User’s

Responsibility sections that follow.

INSTALLATION GUIDE

Manufacturer’s Instructions

The user must observe the following precautions in installing and operating this device:

1. Operate the equipment in strict accordance with the manufacturer’s instructions for the model.

2. Plug the printer into a properly grounded wall outlet and use, unmodified, the power cord supplied with the unit.

3. Always operate the printer with all factory-installed covers on the unit.

4. Make no modification to the equipment that would affect its meeting the specified limits of the FCC Rules.

5. Maintain the equipment in a satisfactory state of repair.

6. Use a shielded and properly grounded I/O cable to ensure compliance of this unit to the specified limits of the

FCC Rules.

User’s Responsibility

The user is ultimately responsible for correcting problems arising from harmful radio frequency emissions from

equipment under his or her control. If this equipment does cause interference to radio or television reception

(which as specified can be determined by turning the printer off and on), SATO encourages the user to try to

correct the interference by changing one of the following:

•Equipment orientation

•Equipment location

•Power source

All of these responsibilities and any others not mentioned are exclusively at the user's expense.

If necessary, the user should consult SATO for additional suggestions.

Note: If it is determined that equipment operation is causing harmful interference, the equipment operator may be

required to stop operating the equipment until the interference problem is corrected.

INSTALLATION GUIDE

DHHS

This printer is certified as a Class 1 Laser Product under the United States Department of Health and Human

Services (DHHS) Radiation Standard according to the Radiation Control for Health and Safety Act of 1968. This

means that the printer does not produce hazardous laser radiation.

Since radiation emitted inside the printer is wholly confined within protected housings and external covers, the

laser beam cannot escape from the equipment during any phase of user operation.

CDRH Regulations

The Center of Devices and Radiological Health (CDRH) of the United States Food and Drug Administration

implemented regulations for laser products on August 2, 1976. These regulations apply to laser products

manufactured from August 1, 1976. Compliance is mandatory for laser products marketed in the United States.

The following statement, which indicates compliance with the CDRH regulations, must be affixed to the laser

products marketed in the United States:

THIS PRODUCT CONFORMS WITH CDRH

RADIATION PERFORMANCE STANDARD

TITLE 21 CFR CHAPTER 1, SUBCHAPTER J

INSTALLATION GUIDE

VII

General Notes, Warnings, and Cautions

Note: The LP 100R printer uses an electrophotographic printing system, which requires more precautions in

observing paper specifications than those required for conventional impact line printers. In an electrophotographic

printing system, improper toner transfer and missing characters are evident if the paper absorbs moisture and

ripples in the vicinity of the perforation.

Note: When paper is stored in unfavorable conditions or does not meet the specifications cited in the

LP 100R Operator's Guide, print quality, as well as feeding and fusing functions, will suffer.

!WARNING

Paper not within specifications may cause physical damage to the LP 100R

printer and jeopardize printer performance (leading to the creation of waste

and a consequent loss of production).

SATO advises that the printer be connected to a power source that has an

isolated, dedicated ground to prevent interference from other equipment

(which may cause printer memory loss during operation).

!CAUTION

Before gaining access to any internal parts of the printer, always remove

power from the unit by unplugging the AC power cord.

This manual must be reviewed and understood

before performing any service on the LP 100R printer.

INSTALLATION GUIDE

VIII

Preface

Purpose of This Guide

To present installation instructions for the LP 100R printer. This guide provides all installation instructions, from

initial unpacking through electromechanical setup, that are required to prepare the printer for paper loading and

operation using the instructions provided in the LP 100R Operator's Guide (Document Number 9855063).

How to Use This Guide

Start with paragraph 1.1 and follow the instructions provided. Note that the order in which groups of instructions

are performed can change due to such variables as the printer location when unboxed and the width of the door

openings through which it must be moved.
