Quick Start Guide

Midi Plus Electronic Pipetting Controller

Getting Started

1. Midi Plus is delivered with the battery inserted. The battery poles are covered by a

plastic protective film. Before first use, remove the plastic film by pulling it gently from

below the battery cover.

2. Charge Midi Plus for at least 4 hours before first use.

- To charge with AC-adaptor: connect Midi Plus to the charger cable and plug the

charger into the mains power outlet.

3. The battery status is indicated by a LED. When the battery is fully charged the LED

emits a green light, and the Midi Plus is ready for use.

Midi Plus is equipped with an adapter set (nose-cone and silicone adapter) that fits all

commonly used serological or volumetric pipettes.

Features

1. Nose-cone, silicone adapter and hydrophobic filter

2. Locking button

3. Operating buttons

a. Aspiration

b. Dispensing

4. Handle cover release buttons

5. Fold-out stand

6. Speed adjustment wheel

7. LED battery indicator

Operation

1. Make sure the hydrophobic filter is inserted

2. Inserting a pipette:

- Gently push a pipette into the silicone adapter holding the pipette at the top. Make sure

the pipette is attached firmly and is air-tight.

3. Adjust the speed by turning the speed adjustment wheel

4. Aspiration:

- Immerse the pipette into the liquid

- Press the aspirating button until the pipette is filled just above the desired volume

- Lift the pipette from the liquid

- Press the dispensing button to slowly dispense the liquid until the level is exactly at the

desired volume

5. Dispensing:

- Place the pipette against the receiving vessel wall

- Press the dispensing button until the pipette is empty

- To activate the blow-out, press the dispensing button completely

NOTE! Press the dispensing button gently to let the liquid flow out by the force of gravity. Fine-tune the

speed by adjusting finger pressure while dispensing.

NOTE! To ease the aspiration of certain liquids, such as volatile or viscous ones, increase the speed, especially

when using a large volumetric pipette.

Fold-out stand

Other Recommendations

1. When not in use, Midi Plus should always be placed

on a table to rest on the fold-out stand.

2. The LED indicator starts to blink when the battery

charge level is low: connect the Midi Plus to the

power supply.

- Pipetting is possible while connected to the

AC-adaptor.

3. Midi Plus can be used with Sartorius Optifit 5 ml and

10 ml tips. Adapters for the 5 ml and 10 ml Optifit

Tips are available as accessories.

LED indicator starts to blink when

the battery charge level is low

Pipetting is possible while

connected to the AC-adaptor

Midi Plus, with a variety of optional nose-cones and silicone

adapters. Optional extras include the Optifit 5 ml and 10 ml tips,

corresponding nose-cones and silicone adapters, and are available

separately.

Standard nose-cone and silicone

adapter set

The status of the information, specifications and illustrations in this quick guide are subject

to change. Sartorius reserves the right to make changes to the technology, features,

specifications and design of the equipment without notice.

All trademarks are Sartorius property unless otherwise stated.

Sartorius Biohit Liquid Handling Oy

Laippatie 1

00880 Helsinki, Finland

Phone +358.9.755.951

[email protected]

Publication No. SUL6008-e161105 ∙ Order No. 85037-542-24 ∙ Ver. 11 | 2016 © Sartorius Biohit Liquid Handling Oy

Midi Plus and Accessories

Order Code Item Qty / Unit

710931 Midi Plus 1

LH-7129120 Replacement filter, 0,45 µm, non-sterile, autoclavable 5

LH-7129130 Replacement filter, 0,2 µm, sterile 5

LH-711019 Adapter set (standard) including nose-cone and the

silicone adapter

LH-711017 Adapter set for 5 ml pipette tip, autoclavable, including

nose-cone and the silicone adapter

LH-711018 Adapter set for 10 ml pipette tip, autoclavable, including

nose-cone and the silicone adapter

LH-712146 Nose-cone (standard) 1

LH-712144 Nose-cone for 5 ml Optifit Tip 1

LH-712145 Nose-cone for 10 ml Optifit Tip 1

LH-712153 Silicone adapter (standard) 1

LH-712151 Silicone adapter for 5 ml Optifit Tip 1

LH-712152 Silicone adapter for 10 ml Optifit Tip 1

780300 Optifit Tip 5 ml 100

780308 Optifit Tip 5 ml 1000

780310 Optifit Tip 10 ml (Extra long tip for Midi Plus) 100

NOTE! Only use the power supply provided with the Midi Plus.

This Quick Start Guide is for the basic operation of the Midi Plus pipette controller. For further

information and more detailed instructions, please see the user manual at www.sartorius.com.

A paper print-out is available on request from [email protected].

Sartorius Lab Instruments GmbH & Co. KG

Weender Landstrasse 94-108

37075 Goettingen, Germany

Phone +49.551.308.0

Fax +49.551.308.3289

www.sartorius.com

Nose-cone, silicone

adapter and filter

Give us feedback

www.sartorius.com/lh-satisfaction
