INSTALLATION MANUAL

Color CCD Camera

THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED

SERVICE PERSON AND SHOULD CONFORM TO ALL LOCAL

CODES.

Please read this installation manual carefully in order to ensure correct installation. In addition,

be sure to read carefully the electronic manual contained in the CD-ROM to ensure correct

operation of the camera.

Contents

Information To User. . . . . . . . . . . . . . . . . . . . 1

Parts Names and Functions . . . . . . . . . . . . . 3

Connections. . . . . . . . . . . . . . . . . . . . . . . . . . 5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

How to Perform the Settings in the Menu

Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Learning the Menu Setting Operations . . . 12

Using the Electronic Manual (CD-ROM) . . 14

Main specifications . . . . . . . . . . . . . . . . . . . 15

Dimensions . . . . . . . . . . . . . . . . . . Back page

VCC-ZMN600P

EnglishFrançaisDeutsch中文简体

Changing the Bracket for Mounting the

Camera

• Make sure to use the longer screws (A) to

secure the bracket.

Install the camera in a correct location so

that the intended object can be monitored

properly.

You should also adjust on the monitor

side.

• If you want to use a commercially available

platform for the camera, select an

appropriate type, taking into consideration

the gross weight of the camera and

platform, and secure it on a firm place.

• Images may blur under extremely bright

lighting; adjust the lighting angle to get

clear images.

(B) (A)

(A)

(B)

✱

Lens cap

Installing Camera

✱Hole for mounting the camera

(Remove the screw before mounting the camera.)

L5CC2_XE(INSTALLATION).book 0 ページ２００８年１月２３日　水曜日　午後４時８分

Information To User

Precautions

■In case of a problem

Do not use the unit if smoke or a strange odor

comes from the unit, or if it seems not to function

correctly. Turn off the power immediately and

disconnect the power cord, and then consult your

dealer or an Authorized Sanyo Service Center.

■Do not open or modify

Do not open the cabinet, as it may be dangerous

and cause damage to the unit. For repairs,

consult your dealer or an Authorized Sanyo

Service Center.

■Do not put objects inside the unit

Make sure that no metal objects or flammable

substance get inside the unit. If used with a

foreign object inside, it could cause a fire, a

short-circuit or damage. Be careful to protect the

unit from rain, sea water, etc. If water or liquid

gets inside the unit, turn off the power

immediately and disconnect the power cord, and

then consult your dealer or an Authorized Sanyo

Service Center.

■Be careful when handling the unit

To prevent damage, do not drop the unit or

subject it to strong shock or vibration.

■Do not install this unit close to magnetic

fields

The magnetic fields may result in unstable

operation.

■Protect from humidity and dust

To prevent damage, do not install the unit where

there is greasy smoke or steam, where the

humidity may get too high, or where there is a lot

of dust.

■Protect from high temperatures

Do not install close to stoves, or other heat

sources, such as spotlights,etc., or where it could

be subject to direct sunlight, as this could cause

deformation, discoloration or other damage.

Be careful when installing close to the ceiling, in

a kitchen or boiler room, as the temperature may

rise to high levels.

■Cleaning

• Dirt can be removed from the cabinetby wiping

it with a soft cloth. To remove stains, wipe with

a soft cloth moistened with a soft detergent

solution and wrung dry, then dry by wiping with

a soft cloth.

• Do not use benzine, thinner or other chemical

products on the cabinet, as this may cause

deformation and paint peeling. Before using a

chemical cloth, make sure to read all

accompanying instructions. Make sure that no

plastic or rubber material comes into contact

with the cabinet for a long period of time, as

this may cause damage or paint peeling.

L5CC2_XE(INSTALLATION).book 1 ページ２００８年１月２３日　水曜日　午後４時８分

For EU Users For Russian Users

This product certified by official

certification company which is

authorized by Russian Federation.

ДЛЯ ПОЛЬЗОВАТЕЛЕЙ

РОССИЯ

Данная продукция

сертифицирована официальным

органом по сертификации

Российской Федерации.

Please note:

Your SANYO product is designed and

manufactured with high quality

materials and components which can

be recycled and reused.

This symbol means that electrical and

electronic equipment, at their

end-of-life, should be disposed of

separately from your household waste.

Please dispose of this equipment at

your local community waste collection/

recycling centre.

In the European Union there are

separate collection systems for used

electrical and electronic products.

Please help us to conserve the

environment we live in!

This symbol mark and recycle

system are applied only to EU

countries and not applied to the

countries in the other area of the

world.

SANYO FISHER Sales (Europe) GmbH

Stahlgruberring 4, D-81829 München, Germany

SANYO Electric Co., Ltd.

1-1, Sanyo-cho, Daito City, Osaka 574-8534, Japan

This installation manual and the electronic manual are copyrighted by SANYO Electric Co., Ltd.

No materials contained in these manuals may be reproduced in any format without the prior

permission of the copyright holder.

L5CC2_XE(INSTALLATION).book 2 ページ２００８年１月２３日　水曜日　午後４時８分

Parts Names and Functions

1VIDEO OUT connector (BNC type)

Outputs video signal.

Connect this terminal to the video input terminal

of the external device.

2Control terminals (Push-lock)

Used to perform the control functions such as

controlling the camera remotely or inputting/

outputting alarm.

1ALARM IN 1/2 terminal

These terminals can be used as an input

terminal for either of the following functions.

Used to connect the alarm device that

detects intruders.

Connect this terminal to an external alarm

switch or an infrared sensor, etc.

Used to switch the viewing mode manually

between the color mode and the black/white

mode.

To do so, select [DAY/NIGHT], choose

“COLOR”, and set the [EXT ALARM] to the

desired alarm input channel.

2ALARM OUT terminal

Used to connect to an external buzzer or

lamp.

When an alarm is detected, the device

connected to the terminal notifies that an

alarm is detected.

3COM terminal (earth terminal)

4FOCUS terminal

Used to perform the focus adjustment

remotely by connecting an external switch.

• DC ± (6 - 12 V), +: FAR, –: NEAR

5ZOOM terminal

Used to zoom in/out by connecting an

external switch.

• DC ± (6 - 12 V), +: WIDE, –: TELE

Rear panel

POWER

VIDEO OUT

LAN

LINK

ALARM IN 2

ALARM IN 1 ALARM OUT

COM FOCUS

ZOOM

AC24V

DC12V

GND

ALARM IN 2

ALARM IN 1 ALARM OUT

COM FOCUS

ZOOM

POWER lamp

bHow to use the push-lock switch

When connecting the cable, press and hold

down the protrusion of the terminal, insert the

cable into the terminal, and then release the

protrusion.

L5CC2_XE(INSTALLATION).book 3 ページ２００８年１月２３日　水曜日　午後４時８分

3LINK lamp

When connected to the network, the camera

LINK lamp flashes. After you turn on the power,

it takes approximately one minute for the

“NETWORK” setting menu to appear on the

“OPTION” screen.

4LAN terminal (RJ45 terminal)

Used to connect the camera to your network.

5AC24V/DC12V terminal

Inputs the power.

Connect this terminal to the power supply.

• When the camera is turned on, the POWER

lamp lights and the version information of the

camera is displayed on the startup screen for

about 10 seconds.

bFor zoom/focus

While viewing the live image, you can perform

focusing or zooming operation.

1c: Tele d: Wide j: Near l: Far

2Pressing the button once starts auto-focus

function.

bFor menu operations

1j: Moves the cursor upward.

l: Moves the cursor downward.

c: Changes the setting value or moves the

cursor to the right.

d: Changes the setting value or moves the

cursor to the left.

2Pressing and holding the button for about

3 seconds displays the main menu.

While performing menu operations, the

button may be used to switch the menu

screen to the next one.

CAMERA VER X.XX-XX

SET

Side panel

L5CC2_XE(INSTALLATION).book 4 ページ２００８年１月２３日　水曜日　午後４時８分

Connections

■Connection when Using PoE (Power over Ethernet) Power Supply

This camera provides simultaneous delivery of video in the JPEG and H.264 formats and also

bi-directional video between the camera and PC.

●System Requirements

The system requirements for camera operation via network are as follows:

•PC:IBM PC/AT and compatibles

•OS:Windows XP Home Edition/Windows XP Professional

•CPU:Pentium IV (2.0 GHz or higher) (3.0 GHz or higher for using the VA-SW3050Lite)

• Memory: 512MB or more (1 GB or more for using the VA-SW3050)

• Network interface: 10Base-T/100Base-TX (RJ-45 connector)

• Graphics processor: nVIDIA: GeForce 6000 series or higher

ATI: RADEON X1000 series or higher

• Display card: 1024 x 768 pixels or higher, 16 million colors or higher

• Web browser: Internet Explorer Ver.6.0 or higher

Connect the camera to the LAN through a switching hub using shielded LAN cables.

●Do not use the power supply of the camera.

●Do not supply power to the PoE hub or PoE power adapter until the camera installation

is finished.

MEMO: You may extend the transmission distance by using multiple switching hubs with PoE support.

For details on the extendable distance, please refer to the hub performance in the

specifications, etc.

Switching hub

Video output

(BNC connector)

TV monitor

When directly connecting

the camera to a PC, use

the LAN cable (cross

type).

When using the IE/VA-SW3050Lite/

VA-SW3050 client version:

You need a PC for the

VA-SW3050 server version.

When using the IE/VA-SW3050Lite/

VA-SW3050 server version:

You need the VA-SW3050

client version to view live/

replayed video, because the

VA-SW3050 server version is

used for recording purpose

only.

PC PC

LAN cable

(CAT5 or higher, straight type)

Max. 100 m/109 yds

LAN cable

(CAT5 or higher, straight type)

Max. 100 m/109 yds

L5CC2_XE(INSTALLATION).book 5 ページ２００８年１月２３日　水曜日　午後４時８分

■Connection when Not Using PoE Power Supply

●Internet connection

Connect the camera to a router or ADSL modem with LAN interface using shielded LAN cables.

●About the internet connection

Port forwarding must be set on two of the router ports (camera side).

For details on how to set port forwarding, please refer to your router's instruction manual.

• Video port number

Conduct the following port forwarding settings with respect to the router:

IP address on the LAN side: Camera IP address (default: 192.168.0.2)

Port number on the LAN side: Camera video port number (default: 80)

Port number on the WAN side: Optional

For communication, use TCP/IP.

When connecting to a router, use the straight type LAN cable (CAT5 or higher).

When connecting to an ADSL modem or other devices, refer to the instruction manual for the device.

MEMO: When viewing video in H.264 format over the Internet, set the communication protocol of H.264

to "HTTP". (Refer to the instruction manual contained in the supplied CD-ROM.)

Router or

ADSL modem

Internet

L5CC2_XE(INSTALLATION).book 6 ページ２００８年１月２３日　水曜日　午後４時８分

Connections

✱1

POWER

VIDEO OUT

ALARM IN 2

ALARM IN 1 ALARM OUT

COM

FOCUS

ZOOM

AC24V

DC12V

GND

LAN

LINK

ALARM

SET

OFF

ALARM IN

ALARM OUT

ALARM DISPLAY

SYNC

CAMERA

LENS

ALARM

PRIVACY MASK

PASSWORD

LANGUAGE

OPTION

INT

SET

ALARM

SET

OFF

ALARM IN

ALARM OUT

ALARM DISPLAY

SYNC

CAMERA

LENS

ALARM

PRIVACY MASK

PASSWORD

LANGUAGE

OPTION

INT

SET

(COM)

(ZOOM)

(FOCUS)

(IN2)

(COM)

(IN1)

(COM)

(AL OUT)

Do not connect the power cord until all other

connections have been completed.

For details, see “Setting the Alarm Input

(ALARM IN)” in the electronic manual contained

in the CD-ROM.

bALARM IN 1 (“1” is selected)

bALARM IN 2 (“2” is selected)

Alarm

input signal

Alarm

input signal

Alarm Signal Input

If a lamp is connected to this cable, it will light

up when an alarm signal is received or when

the built-in motion sensor detects movement.

Alarm Signal Output

FOCUS ZOOM

DC+6V/+12V FAR WIDE

DC-6V/-12V NEAR TELE

Connection for Zoom/Focus

✱1 All connection cables should be 24 AWG or

higher with a maximum length of no more

than 600 m (656 yds).

BNC type

(Non-PoE power supply)

L5CC2_XE(INSTALLATION).book 7 ページ２００８年１月２３日　水曜日　午後４時８分

GND

–

GND

LAN

GND

–

bWith AC 24 V

Power Supply Connection

bWith DC 12 V

Check that +/- polarity is correct.

For the connections, use cables thicker

than 18 AWG.

For the connections, use cables thicker

than 18 AWG.

Monitor Connection

Digital Video

Recorder etc.

• Using different cables from those

specified here may attenuate the

video and/or sync signals and

interfere with correct transmission.

• RG-59U coaxial cables can be

used when distance between

devices is short, but not in duct or

aerial routing.

Cable type Length

RG-59U (3C-2V)

250 m (273 yds) max.

RG-6U (5C-2V)

500 m (547 yds) max.

RG-11U (7C-2V)

600 m (656 yds) max.

SYNC

CAMERA

LENS

ALARM

PRIVACY MASK

PASSWORD

LANGUAGE

OPTION

INT

SET

GAMMA

MOTION

POSITION

DAY/NIGHT

PRESET

0.45

OFF

COLOR

OFF

BACK

D/N SETTING-COLOR

EXT ALARM

(ALARM IN 1 or 2)

(COM)

The alarm input terminals can

also be used as terminals for

switching between color and

black/white video modes using

an external switch.

Open: Color

Close: Black/White

Make sure that

COLOR is selected. 1: ALARM IN 1 terminal

2: ALARM IN 2 terminal

Shielded LAN cable

See “Connection when Using PoE Power Supply” or “Connection

when Not Using PoE Power Supply”.

Color or Black-and-White Setting

L5CC2_XE(INSTALLATION).book 8 ページ２００８年１月２３日　水曜日　午後４時８分

Features

Zooming Function

bYou can store the zoom and focus

settings of surveillance locations by

camera setting number.

&[CAMERA] ⇒[POSITION]

bThe electronic zooming function can be

used to zoom in the object at the

magnification power higher than that in

the optical zoom.

&[LENS] ⇒[ZOOM] ⇒[EL ZOOM]

bYou can change the zooming speed.

&[LENS] ⇒[ZOOM] ⇒[SPEED]

POSITION

SET

x 3.0

POSITION

SET

x 1.0

CAMERA 1 CAMERA 2

Alarm Settings

bThe camera has a built-in motion sensor.

&[CAMERA] ⇒[MOTION] ⇒[ON]

bThe alarm condition can be detected by

connecting door switches or infrared

sensors.

&[ALARM] ⇒[ALARM IN]

Not detected Detected

Remote Operations

bThe camera can be controlled remotely

by establishing the network

communication.

&[OPTION] ⇒[NETWORK]

bYou can switch the viewing mode

manually between the color mode and

the black/white mode.

&[CAMERA] ⇒[COLOR] ⇒

[EXT ALARM]

Camera Title

You can set and display the camera title.

This helps you confirm from which camera

the image is sent when multiple cameras

are connected. (Maximum 16 characters)

&[OPTION] ⇒[DISPLAY] ⇒[TITLE]

ROOM1 ROOM2

Alarm Notice

bThe camera title you specified in the

[OPTION] menu blinks to notify that the

alarm condition is detected.

&[ALARM] ⇒[ALARM DISPLAY]

bWhen the alarm condition is detected,

the object on the screen is zoomed in.

&[ALARM] ⇒[ALARM IN] ⇒

[ACTION] ⇒[ZOOM]

bA buzzer or lamp can be used to notify

you of detection of alarm when you are in

a distant place from the monitor.

&[ALARM] ⇒[ALARM OUT]

DOOR1

&You can perform the settings on the camera by

navigating through the menu screens.

L5CC2_XE(INSTALLATION).book 9 ページ２００８年１月２３日　水曜日　午後４時８分

Tabla de contenidos

Idiomas:

Otros manuales de Cámara de seguridad de Sanyo

Sanyo

Sanyo VCC-P7574N - 1/4" Color CCD Indoor Mini Dome... Manual de usuario

Sanyo

Sanyo VDC-DP7584 - 1/4" Color CCD Vandal-Resistant Dome... Manual de usuario

Sanyo

Sanyo VCC-MC600P Manual de usuario

Sanyo

Sanyo VCB-7312P Manual de usuario

Sanyo

Sanyo VCC-5884EA - 1/3" Color CCD DSP High-Resolution... Manual de usuario

Sanyo

Sanyo VCC-PN9575P Manual de usuario

Sanyo

Sanyo VCC-4795P Manual de usuario

Sanyo

Sanyo VDC-HD3100 - Full HD 1080p Vandal Dome... Manual de usuario

Sanyo

Sanyo VCC-9000EBCP/EBSP Manual de usuario

Sanyo

Sanyo VCC-7912P Manual de usuario

Sanyo

Sanyo VCC-9600 Manual de usuario

Sanyo

Sanyo VCC-ZM300PA Manual de usuario

Sanyo

Sanyo THINK GAIA VCC-HD4600 Manual de usuario

Sanyo

Sanyo VDC-DP7584 - 1/4" Color CCD Vandal-Resistant Dome... Manual de usuario

Sanyo

Sanyo VCC-HD3300 Manual de usuario

Sanyo

Sanyo VDC-D2185VP Manual de usuario

Sanyo

Sanyo VCC-5974P Manual de usuario

Sanyo

Sanyo VCC-HD2100 - Full HD 1080p Network Camera Manual de usuario

Sanyo

Sanyo VCC-XZN600P Manual de usuario

Sanyo

Sanyo VCC-5984 Manual de usuario

Sanyo

Sanyo VCC-3972P Manual de usuario

Sanyo

Sanyo VCC-HD4000P Manual de usuario

Sanyo

Sanyo VCC-3924 Manual de usuario

Sanyo

Sanyo VCC-HD5600 - Full HD 1080p Day/Night Pan-Tilt-Zoom... Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
